ALGE-Timing Timy3 W Configuration guide

Manual
General
Version: E200128

Manual
Timy3 - General
-2-
Important Information
General
Before using your ALGE-TIMING device read the complete manual carefully. It is part of the device and
contains important information about installation, safety and its intended use. This manual cannot cover
all conceivable applications. For further information or in case of problems that are mentioned not at all
or not sufficiently detailed, please contact your ALGE-TIMING representative. You can find contact details
on our homepage www.alge-timing.com
Safety
Apart from the information of this manual all general safety and accident prevention regulations of the
legislator must be taken into account.
The device must only be used by trained persons. The setting-up and installation must only be executed
according to the manufacturer’s data.
Intended Use
The device must only be used for its intended applications. Technical modifications and any misuse are
prohibited because of the risks involved! ALGE-TIMING is not liable for damages that are caused by im-
proper use or incorrect operation.
Power supply
The stated voltage on the type plate must correspond to voltage of the power source. Check all connec-
tions and plugs before usage. Damaged connection wires must be replaced immediately by an author-
ized electrician. The device must only be connected to an electric supply that has been installed by an
electrician according to IEC 60364-1. Never touch the mains plug with wet hands! Never touch live
parts!
Cleaning
Please clean the outside of the device only with a smooth cloth. Detergents can cause damage. Never
submerge in water, never open or clean with wet cloth. The cleaning must not be carried out by hose or
high-pressure (risk of short circuits or other damage).
Liability Limitations
All technical information, data and information for installation and operation correspond to the latest
status at time of printing and are made in all conscience considering our past experience and
knowledge. Information, pictures and description do not entitle to base any claims. The manufacturer is
not liable for damage due to failure to observe the manual, improper use, incorrect repairs, technical
modifications, use of unauthorized spare parts. Translations are made in all conscience. We assume no
liability for translation mistakes, even if the translation is carried out by us or on our behalf.
Disposal
If a label is placed on the device showing a crossed out dustbin on wheels (see drawing),
the European directive 2002/96/EG applies for this device.
Please get informed about the applicable regulations for separate collection of electrical
and electronical waste in your country and do not dispose of the old devices as household
waste. Correct disposal of old equipment protects the environment and humans against
negative consequences!
Copyright by ALGE-TIMING GmbH
All rights reserved. Any duplication, either in full or in part, requires the prior written consent of the copy-
right holder.

Manual
Timy3 - General
-3-
Declaration of Conformity
We declare that the following products comply with the requirements of the listed standards.
We, ALGE-TIMING GmbH
Rotkreuzstrasse 39
A-6890 Lustenau
declare under our sole responsibility, that the timing device
Timy3 W-F and Timy3 WP-F
complies with the following standards/normative documents and in case of intended use com-
plies with the basic requirements of R&TTE 1999/5/EC:
Telecommunication (TC)terminal device
Short Range Device
When used as intended complies with the basic requirements of §3 and the other relevant Provisions of
the FTEG (article 3 R&TTE 1999/5/EC).
Health and safety according to §3(1)1. (article 3(1)a))
Applied harmonized standards…
EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013
Protection requirements with regard to electromagnetic compatibility §3 (1) 2, (article 3 (1) b).
Applied harmonized standards
EMC: EN301 489-17 v2.1.1. (2009-05) v2.2.1 (2012-09)
EN 300 328 v1.7.1 (2006-10) v1.9.1 (2015-02)
EN 55022 : 2010 / AC : 2011
EN 55024 : 2010 / A1: 2015
EN 61000 3-2:2014
EN 61000 3-3:2013
Additional Information:
The product herewith complies with the requirements of the Low Voltage Directive 73/23/EEC, also the
EMC Directive 2004/108EG and accordingly carries the CE-marking.
Lustenau, 2017-03-22 ALGE-TIMING GmbH
Albert Vetter
(General Manager)

Manual
Timy3 - General
-4-
Control elements
A..........paper roll
B..........thermal printer
C..........printer hood
D..........printer hood opener
E..........LCD graphic display
F ..........silicon keyboard
G..........carrying band eyelet
1...........USB interface
2...........charging socket
3...........ALGE-TIMING multiport
4...........connection for display board
5...........connection for start impulse
6...........connection for finish impulse
7...........standard ALGE-TIMING photocell
socket

Manual
Timy3 - General
-5-
Table of contents
1Device Description......................................................................................................7
1.1 Timy3 Models......................................................................................................7
1.2 Timy3 Software...................................................................................................8
1.3 Driver Installation ................................................................................................8
1.4 Keypad................................................................................................................9
1.5 Display of Timy3 ...............................................................................................10
1.6 Choose Language.............................................................................................11
2Start Up......................................................................................................................12
2.1 Switch On .........................................................................................................12
2.2 Switch Off .........................................................................................................12
2.3 Power Supply....................................................................................................12
3Printer ........................................................................................................................14
3.1 Change of Paper for Timy3 WP (Design 2) .......................................................14
3.2 Change of Paper for Timy3 WP (old Design).....................................................14
4Synchronizing ...........................................................................................................15
4.1 GPS Synchronization........................................................................................15
4.2 Synchronization of Timy3 from another Timing Device......................................15
4.3 Synchronization of other Devices with Timy3 by Cable .....................................16
4.4 Synchronization of Timy3 to Timy3 by WTN......................................................17
4.4.1 WTN Synchronization Switched Off <SYNC OFF>........................................................................17
4.4.2 Passive Synchronization by WTN <PASSIVE> .............................................................................17
4.4.3 Single Synchronization Output <ACTIVE>.....................................................................................17
4.4.4 Synchronization Output every Minute <ACTIVE PER MIN.>.........................................................17
5Connection of Auxiliary Devices..............................................................................18
5.1 Channels...........................................................................................................18
5.2 Delay and Block Times......................................................................................18
5.2.1 Delay Time.....................................................................................................................................18
5.2.2 Block Time.....................................................................................................................................18
5.3 Diagram of Delay and Block Time.....................................................................18
6Timy3 Update.............................................................................................................19
6.1 Update Firmware with USB cable......................................................................19
7Memory......................................................................................................................19
8Info Menu...................................................................................................................20
9Menu...........................................................................................................................20
9.1 CLASSEMENT..................................................................................................21
9.1.1 ALL................................................................................................................................................21
9.1.2 CLASS...........................................................................................................................................21
9.1.3 START LIST ..................................................................................................................................21
9.2 GENERAL.........................................................................................................21
9.2.1 PREC-ROUNDING........................................................................................................................21
9.2.2 CHANGE HEAT.............................................................................................................................21
9.2.3 STN-AUTOMATIC .........................................................................................................................21
9.2.4 SEC-MODE ...................................................................................................................................22
9.2.5 LANGUAGE...................................................................................................................................22
9.2.6 STANDARD...................................................................................................................................22
9.2.7 HARDWARE..................................................................................................................................22
9.2.8 HARDWARE 2...............................................................................................................................22
9.2.9 PROGS ON OFF ...........................................................................................................................22
9.2.10 GPS LEP SEC...............................................................................................................................22
9.2.11 CLR MEMORY ..............................................................................................................................22
9.2.12 AUTOMATIC PROG......................................................................................................................23
9.2.13 SYNC.............................................................................................................................................23

Manual
Timy3 - General
-6-
9.3 CHANNELS ......................................................................................................23
9.3.1 INTERNAL.....................................................................................................................................23
9.3.2 BEEP.............................................................................................................................................24
9.3.3 TED-RX .........................................................................................................................................24
9.3.4 CHANNEL-PATTERN....................................................................................................................24
9.3.5 WTN Delay ....................................................................................................................................25
9.3.6 ENABLE DISABLE ........................................................................................................................25
9.3.7 CHANNEL-USAGE........................................................................................................................25
9.3.8 PULSE HOLD................................................................................................................................25
9.4 DISPLAY...........................................................................................................26
9.4.1 RUNNING TENTH.........................................................................................................................26
9.4.2 DELAYTIME 1 ...............................................................................................................................26
9.4.3 DELAYTIME 2 ...............................................................................................................................26
9.4.4 BACK LIGHT .................................................................................................................................26
9.5 INTERFACE......................................................................................................26
9.5.1 DISPLAYBOARD...........................................................................................................................26
9.5.2 RS232............................................................................................................................................27
9.5.3 GSM-MODEM................................................................................................................................27
9.5.4 GSM-SETTINGS ...........................................................................................................................27
9.6 PRINTER..........................................................................................................27
9.6.1 PRINTER-MODE...........................................................................................................................27
9.6.2 PRINT STARTTIME.......................................................................................................................27
9.6.3 AUTO LINE FEED.........................................................................................................................27
9.6.4 START-LOGO ...............................................................................................................................27
9.6.5 PRINT DAYTIME...........................................................................................................................27
9.7 PROGRAM .......................................................................................................28
9.8 Program Specific Settings.................................................................................28
9.9 WTN..................................................................................................................28
9.9.1 WTN POWER................................................................................................................................28
9.9.2 STATE...........................................................................................................................................28
9.9.3 SETTINGS.....................................................................................................................................29
9.9.4 TEAM.............................................................................................................................................29
9.9.5 SOCKET........................................................................................................................................29
9.9.6 STATISTICS..................................................................................................................................30
It shows the number of data strings that have not reached the Timy3. The data is displayed per team.................30
9.9.7 BROADCAST PARM.....................................................................................................................30
9.10 KEYBOARD-LOCK...........................................................................................30
10 Timy Messages..........................................................................................................30
10.1 Long Time Timing Impulse................................................................................30
10.2 WTN: Old Version.............................................................................................30
10.3 Delay Time for Radio Impulses .........................................................................30
11 Technical data...........................................................................................................31
11.1 Pin Assignment.................................................................................................32
12 Interfaces...................................................................................................................34
12.1 RS232 Interface................................................................................................34
12.2 RS485 Interface................................................................................................37
12.3 Interface for Display Board................................................................................37
13 USB Interface.............................................................................................................37

Manual
Timy3 - General
-7-
1 Device Description
The ALGE-TIMING Timy3 is a handy device, equipped with high-quality technology.
In spite of the handy dimensions, the Timy3 provides a large and easy-to-use silicone keypad.
The model Timy3 WP has an integrated printer that records the entire competition.
The Timy3 is also equipped with the necessary interfaces for communication with external
devices: interface for display boards, RS232 interface for communication with a computer,
RS485 interface to establish a network of timing devices and future-proof USB interface.
The memory of the Timy3 can store up to 30,000 times which can be shown on the display or
transmitted to a computer by RS232 or USB interface at any time.
The integrated radio modem WTN allows linking the Timy3 via radio with all devices of the
WTN series.
For operating the Timy3 with the internal radio module please also refer to the manual WTN.
1.1 Timy3 Models
Both Timy3 models are equipped with a temperature compensated quartz-oscillator and there-
fore suited for highest accuracy. The extended temperature range allows operating the Timy3
from +50°C until -20°C (for summer and winter sports).
Timy3 W:
Timy3 W is a timing device without printer.
Timy3 WP (Design2):
Timy3 WP is a timing device with integrated printer.

Manual
Timy3 - General
-8-
1.2 Timy3 Software
Available programs for the Timy3:
Stopwatch: universal timing program which is suitable for several heats (run/total time)
Backup: to measure time of day times (e. g. as backup-system or as time reference
for the computer)
PC-Timer: to measure time of day times with simultaneous output of the running time
in 1/10 seconds via the RS232 interface; ideal as an accurate timing device
for the computer
LapTimer: timing program with run times and lap times (e. g. for motor sport)
TrackTimer: timing program for events with several lanes, e. g. athletics and swimming
Training Lite: universal training software (several intermediate times are possible)
Training REF: training software with reference run (several competitors on course)
Speed: speed measurement
Commander: terminal for diverse subprograms (see manual)
CycleStart: program for track cycling with countdown and lap counter
Terminal: terminal for judges (e. g. gymnastics)
Track + Field: for measuring the wind speed with anemometer WS2, to control a concen-
tration clock and infield display board
Parallel-Diff: timing for parallel slalom (difference time of both slopes)
Dual Timer: timing of two separate courses
Timeout: timing with timeout, also applicable for show jumping (with start countdown)
Swim Trainer: training program for swimming
Jumping: training program for jump trials, measures jumping height on the basis of
time between jump and landing on a contact mat (several subprograms)
Speed-Climbing: timing for parallel competitions at speed climbing with false start
Start-Liner: to control Startclocks ASC3 or display boards D-LINE when using individual
start time (e.g. Gunderson start)
Parallel-Start: to control and input start doors for opening with a different time delay
TV-Timer:simple timing program for controlling a display board or TV time flashes
Voting: radio judging console (WTN) for judges, voting, etc. (e.g. ski jumping)
Safe Driving 2: to control a display board and speed measurement for driver training
CC False Start: false start detection for cross country skiing sprint events
1.3 Driver Installation
For installation of drivers, separate manuals are available. You can download them from our
website www.alge-timing.com or contact your ALGE-TIMING representative.

Manual
Timy3 - General
-9-
1.4 Keypad
The Timy3 has a weather-proof (water-proof) silicone keypad. The keypad is ideal for outdoor
use. The keys are raised and have ideal pressure points. Although the Timy3 is small in di-
mensions, the keys are easy to operate.
Control keys: all-purpose keys; the function of
each one is always visible on the display.
START/ON: manual start impulse and switch on the Timy3
STOP/OFF: manual stop impulse and switch off the Timy3
Printer: paper output; combination and , opens printer menu
2nd: always used in combination with a second key (additional function)
Menu: enter the device menu
CLR: clear the marked times or memory
Cursor: move the cursor in the display
+beginning of a list
+ end of a list
OK green: switch on, confirm commands or start inputs
OK red: switch off, confirm commands or finish inputs

Manual
Timy3 - General
-10-
1.5 Display of Timy3
The Timy3 has a display with backlight. The backlight makes reading of the display at bad light
conditions easier. As the backlight consumes energy it is only switched on automatically when
the Timy3 is connected with an external power supply (e. g. PS12A). If you use the Timy3 in
battery mode you can switch on the backlight in the menu.
•Press menu key.
•Select <DISPLAY> with arrow down key.
•Press OK key (red or green).
•Select <Back Light> with arrow down key.
•Press OK key (red or green).
•The display shows:
ENERGY-SAVE: external supply: display back light on (100 % brightness)
battery operation: display back light off
ON: external supply: display back light on (100 % brightness)
battery operation: display back light on (50 % brightness)
AUTOMATIC: After each key stroke or timing impulse the back light is on for 5
seconds.
•Choose desired light function with arrow down key.
•Press OK key (green or red).
•Exit menu by pressing menu key.

Manual
Timy3 - General
-11-
1.6 Choose Language
Currently, you can choose between the following languages: German, English, French, Italian,
Spanish, Finnish and Dutch.
•Press menu key.
•Select <GENERAL> or <ALLGEMEIN> with arrow down key.
•Press OK-key (red or green).
•Select <LANGUAGE> or <SPRACHE> with arrow down key.
•Press OK-key (red or green).
•The display shows:
display in German display in English
•Select desired language with arrow down key.
•Press OK key (green or red).
•Exit the menu by pressing menu key.

Manual
Timy3 - General
-12-
2 Start Up
2.1 Switch On
•Press „START/ON“ key.
•Display shows:
“Really switch-on? Press the green OK
button!“
•If you press the green OK key within 10
seconds, the Timy3 switches on, other-
wise it automatically switches off again.
2.2 Switch Off
You have got two possibilities to switch off the Timy3:
Method 1:
•Press „STOP/OFF“ key for 3 seconds.
•Display shows:
“Really switch-off? Press the red OK button!“
•If you press the red OK key within 10 seconds, the
Timy3 switches off, otherwise it returns to the pro-
gram.
Method 2:
•Press „2nd“ and „STOP/OFF“ keys
•Display shows:
“Really switch-off? Press the red OK button!“
•If you press the red OK key within 10 seconds, the
Timy3 switches off, otherwise it returns to the pro-
gram.
2.3 Power Supply
The Timy3 has several possibilities for power supply:
External supply +8 to 24 VDC:
•power supply unit PS12
•power supply unit PS12A, ideal as the Deltron socket remains free
•external battery e. g. 12V plumb rechargeable battery
•ALGE-TIMING display board (e. g. GAZ4 or D-LINE)
NLG4 and NLG8 must NOT be used as the off-load voltage is too high. The Timy3 might be
destroyed!
With external supply of at least 11.0 VDC, the internal rechargeable batteries are charged.

Manual
Timy3 - General
-13-
Internal supply:
The battery compartment has space for six batteries type AA or rechargeable batteries. For
Timy3 WP you have to use the heat-sealed rechargeable battery-packs ONLY!
-20°C / -4F 20°C / 68F -20°C / -4F 20°C / 68F
Alkaline Batteries about 50 h about 100 h not possible not possible
NiMH Rechargeables NM-Timy2 about 50 h about 60 h about 25 h about 60 h
Timy3 W
Timy3 WP
Timy3 (Design 2)
This measurement took place without the Timy3 supplying external devices (e. g. no supply of
photocells) and for the WP with 3 printed lines per minute.
Battery types:
Alkaline batteries: These batteries must never be used in a Timy3 with integrated printer.
Alkaline batteries can only supply about 10 % of their original capacity at temperatures
of -20 °C. Thus they are only recommendable for warm weather. For environmental reasons it
is also recommendable that rechargeable batteries are used.
NiMH battery pack NM-TIMY2: The NiMH rechargeable battery pack is recommended for
every Timy3. These newly developed batteries dispose of an enormous persistence even at
very low temperatures and can supply a high current for the printer.
Charging:
The rechargeable batteries are charged inside the Timy3 with charger PS12 or PS12A, no
matter if the Timy3 is switched on or off. The charging period with NiMH batteries (NM-TIMY2)
takes with 1.5 Ah approx. 14 hours.
Charging Switch:
The Timy3 has got a switch (hidden behind the
battery label) for switching on or off the rechargea-
ble battery charging.
Using alkaline batteries, the charging must be
switched off - position ALKALI -, as otherwise the
batteries may leak.
During the operation with rechargeable batteries,
the switch should be on position NiCd/NiMH so that
the rechargeable batteries are charged.
Attention: Never use alkaline batteries in a
Timy3 when the charging switch is set
to NiCd/NiMH and a charger is connected.
Operating period:
The operating period depends on the Timy3 model, the batteries utilized and the ambient tem-
perature.

Manual
Timy3 - General
-14-
3 Printer
The Timy3 WP has an integrated thermal printer. We recommend using our ALGE-TIMING pa-
per as it is best suited. You can recognize it by the ALGE-TIMING logo print on the reverse side,
available with your ALGE-TIMING representative.
3.1 Change of Paper for Timy3 WP (Design 2)
•press printer hood opener (see picture on the right)
•lift printer hood
•take out paper axis
•place the axis inside a new paper roll
•insert paper roll with axis into Timy3
•thread paper through tear-off edge
•close printer hood
3.2 Change of Paper for Timy3 WP (old
Design)
•open printer hood
•take out paper axis
•place the axis inside the new paper roll
•insert paper roll with axis into Timy3
•thread paper through tear-off edge
•close printer hood

Manual
Timy3 - General
-15-
4 Synchronizing
The Timy3 can be synchronized with an ALGE-TIMING GPS-receiver GPS-A with the exact time
of day. It is also possible to synchronize the Timy3 with other Timy3 or other timing devices
(e.g TdC8001).
4.1 GPS Synchronization
It is possible to synchronize the Timy3 with a GPS mouse (GPS-TY). The synchronization can
be carried out in all Timy programs and is accurate to a 1/10,000 second.
•The GPS mouse (picture: GPS 18LVC) needs no exter-
nal power supply.
•The RS232 baud rate of the Timy3 has to be set to 9600
baud.
•In the menu <channels> the item <TED-RX> has to be
deactivated.
•The GPS synchronizes the Timy3. After this the Timy3
runs with its own precision quartz and the GPS can be
disconnected. The GPS mouse can now be used to
synchronize further devices.
Instead of the time of day setting, the display shows as
indicated on the right. As long as it says “NO SIGNAL”, the
GPS receiver is searching for satellites.
When “OK -UTC +UTC NO” is displayed in the bottom
line, the time for your region can be adjusted with keys
and . As soon as the correct time is shown, press
.
Attention!
After receipt of a valid GPS signal, the Timy3 verifies the checksum and measures the dura-
tion of the sync signal. If the sync signal is erroneous, the Timy3 carries out a reset. Thus, it is
impossible to generate an invalid sync time. If the Timy3 is supplied by external power, it au-
tomatically restarts. In case of operation with internal power, the Timy3 turns off and has to be
restarted.
Remove the GPS receiver from the Timy3. Press to
start the selected program.
4.2 Synchronization of Timy3 from another Timing Device
The Timy3 can be synchronized via your start channel C0 from any ALGE-TIMING timing de-
vice. You can also synchronize multiple timing devices at the same time.
•connect Timy3 with cable 000-xx or 004-xx to other timing device(s)
•switch on Timy3
•clear or save memory
•set the time of day at which the synchronization takes place and confirm with <OK>
•set the date and confirm with <OK>
•trigger start (can be with the <START> key of the Timy3 or by short-outing the start
line, e.g. with push button or start gate)

Manual
Timy3 - General
-16-
•check if all timing devices started
•trigger the start again and check if the start time is the same for all devices
•disconnect the sync cable if the start times were the same
4.3 Synchronization of other Devices with Timy3 by Cable
The Timy3 can send a synchronization signal via channel 0
every full minute when using the programs BACKUP or PC-
TIMER.
•Connect the Timy3 with the device to be synchronized.
•Enter the time of day (next full minute) to be synchro-
nized at the device.
•Press and hold both keys, the green and red OK key of
the Timy3. On the full minute the Timy3 sends a syn-
chronization impulse. The time of day of the other tim-
ing device must now run.

Manual
Timy3 - General
-17-
4.4 Synchronization of Timy3 to Timy3 by WTN
It is possible to synchronize the Timy3 from another Timy3 via WTN. For this, the devices
must be set to WTN mode and within radio range. There are two ways for synchronization.
Adjustment:
•press button
•move cursor with to <GENERAL>
•enter menu <GENERAL> by pressing
•move cursor with to <SYNC>
•enter menu <SYNC> by pressing
•move cursor with to <OVER WTN>
•enter menu <OVER WTN> by pressing
•select with key :
<SYNC OFF>
<PASSIVE> (factory setting)
<ACTIVE>
<ACTIVE PER MIN.>
4.4.1 WTN Synchronization Switched Off <SYNC OFF>
Timy3 does not output or read a synchronization time.
4.4.2 Passive Synchronization by WTN <PASSIVE>
The Timy3 can read and resume synchronization times from other Timy3. If the time
deviation is more than 0.0005 seconds, the new time of day must be confirmed or re-
jected at the passive Timy3.
4.4.3 Single Synchronization Output <ACTIVE>
The active Timy3 that executes the synchronization outputs the time of day to all pas-
sive Timy3 once.
4.4.4 Synchronization Output every Minute <ACTIVE PER MIN.>
The active Timy3 that executes the synchronization outputs the time of day to all pas-
sive Timy3 every minute.

Manual
Timy3 - General
-18-
5 Connection of Auxiliary Devices
A wide range of devices can be operated with the Timy3. Please ask your ALGE-TIMING repre-
sentative for the possibilities.
5.1 Channels
The Timy3 has nine independent timing channels.
Attention: Channels 0 to 5 have a maximum precision of 1/10,000 seconds but channel 6 to 8
only 1/100 seconds.
5.2 Delay and Block Times
The variable delay and block times prevent generating double impulses and loosing impulses.
The delay and block times can be changed in the menu.
5.2.1 Delay Time
After triggering an impulse, further impulses of the same impulse channel are disabled for the
duration of the delay time.
Default settings: start channel C0 1.0 s
stop channel C1 to C9 0.3 s
5.2.2 Block Time
The block time is the theoretic minimum interval between two valid impulses of the same
channel. Impulses within the block time are saved as invalid. The block time is only supported
by certain programs.
That is to say, for an interval start of 30 seconds the minimum clearance is approx. 20 sec-
onds. Thus the block time is 20 seconds, too.
5.3 Diagram of Delay and Block Time
∆t timing channel triggered
1 timing channel is triggered – valid time is saved – block time starts
2 end of impulse – delay time starts
3 timing channel is triggered within the delay time – no impulse triggering
4 end of impulse – delay time restarts
5 timing channel is triggered within the block time – invalid time is saved but not printed
6 end of impulse – delay time starts
7 timing channel is triggered – valid time is saved – block time starts

Manual
Timy3 - General
-19-
6 Timy3 Update
Please visit our website www.alge-timing.com for a free update for your Timy3 software.
6.1 Update Firmware with USB cable
•If not done yet, the Timy3 USB driver has to be installed. An instruction for this can be
found on our website
https://alge-timing.com/download/Software/Driver/TimyUSBDriver.exe
•log into the internet
•start your web browser
•input the following link: https://alge-timing.com/alge/download/software/IM.exe
•download the file and start the install manager “IM.exe”
•click on the folder “Timy USB”
•connect Timy3 with the USB cable to the PC
•start Timy3 – the program automatically searches for the Timy3
•As soon as the firmware recognizes the Timy3, the following is displayed
•Choose a method of updating the Timy3. Recommendable is an internet update as the
latest version is always available
•
7 Memory
The memory of the Timy3 can store approx. 30,000 times.
When switching on, the memory can either be saved or de-
leted. The free and saved space is indicated.

Manual
Timy3 - General
-20-
without external supply
8 Info Menu
Pressing the buttons opens the info mode. Important data is displayed.
•INFO = TIMY
•INFO2 = Timy2
•INFO3 = Timy3 / INFO3W – WTN module activated
•EXP = operation with external supply
•cts = RS232 cable on channel 1
•VERS = downloaded software version
•BOOT = boot version
•LEVEL = shows from which level the battery voltage is
too low to operate the printer; below this level, the
printer is automatically switched off in order to save
battery
•USB = PC is connected via USB-cable with Timy
•Ubatt = current battery voltage
•Ua = current output voltage
•Ser-Nr = device serial number – alternating every sec-
ond with HW_SN
•HW_SN = hardware serial number
•C0 – C3 = channel number is here if the channel is not triggered. When the channel is
triggered, the channel number and a black bar appear alternately.
•PRI INT = Timy with printer
•PRI EXT = Timy without printer
By pressing the left or right arrow buttons, the calibration date is shown. You return to the info
menu with the same buttons.
9 Menu
The Timy3 menu allows you to adjust individual settings. Push to access the main
menu. With the cursor buttons you can navigate through the menu.
enter or exit the menu
navigate up or down
next submenu
previous menu
confirm input or choice
On the following pages the different menu items are described. The program specific menu
settings are described in the separately available manuals for each program. Settings printed
bold are the ALGE-TIMING factory settings.
with external supply
