Alienware 13 R3 Operation and maintenance manual

Alienware 13 R3
Setup and Specifications
Computer Model: Alienware 13 R3
Regulatory Model: P81G
Regulatory Type: P81G001

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make
better use of your product.
CAUTION: A CAUTION indicates either potential damage to
hardware or loss of data and tells you how to avoid the problem.
WARNING: A WARNING indicates a potential for property damage,
personal injury, or death.
© 2016 Dell Inc. or its subsidiaries. All rights reserved. This product is protected by
U.S. and international copyright and intellectual property laws. Dell and the Dell logo are
trademarks of Dell Inc. in the United States and/or other jurisdictions. All other marks
and names mentioned herein may be trademarks of their respective companies.
2016 - 09
Rev. A00

Contents
Set up your computer.................................................... 5
Views..............................................................................6
Base.................................................................................................6
Display............................................................................................. 7
Back.................................................................................................8
Left..................................................................................................9
Right................................................................................................9
Specifications................................................................11
Dimensions and weight.................................................................... 11
System information.......................................................................... 11
Memory...........................................................................................11
Ports and connectors.......................................................................12
Communications..............................................................................12
Audio............................................................................................. 12
Storage...........................................................................................13
Keyboard........................................................................................13
Camera...........................................................................................14
Touch pad.......................................................................................14
Battery........................................................................................... 14
Video............................................................................................. 15
Power adapter................................................................................15
Display........................................................................................... 16
Computer environment................................................................... 16
Keyboard shortcuts......................................................18
3

Getting help and contacting Alienware..................... 19
Self-help resources......................................................................... 19
Contacting Alienware.....................................................................20
4

Set up your computer
Connect the power adapter and press the power button.
5

Views
Base
1Power button (Alienhead)
Press to turn on the computer if it is turned off, in sleep state, or in hibernate
state.
Press to put the computer in sleep state if it is turned on.
Press and hold for 4 seconds to force shut-down the computer.
NOTE: You can customize the power-button behavior in Power
Options.
6

Display
1Left microphone
Provides digital sound input for audio recording and voice calls.
2Infrared emitter
Emits infrared light, which enables the infrared camera to sense depth and
track motion.
3Infrared camera
Depth-sensing feature of the camera enhances security when paired with
Windows Hello face authentication.
4Camera
Enables you to video chat, capture photos, and record videos.
5Camera-status light
Turns on when the camera is in use.
7

6Right microphone
Provides digital sound input for audio recording and voice calls.
7Service Tag label
The Service Tag is a unique alphanumeric identifier that enables Dell service
technicians to identify the hardware components in your computer and
access warranty information.
Back
1Network port (with lights)
Connect an Ethernet (RJ45) cable from a router or a broadband modem for
network or internet access.
The two lights next to the connector indicate the connectivity status and
network activity.
2Mini DisplayPort
Connect a TV or another DisplayPort-in enabled device. Provides video and
audio output.
3HDMI port
Connect a TV or another HDMI-in enabled device. Provides video and audio
output.
4Thunderbolt 3 (USB Type-C) port
Supports USB 3.1 Gen 2, DisplayPort 1.2, Thunderbolt 3 and also enables
you to connect to an external display using a display adapter.
Provides data transfer rates up to 10 Gbps for USB 3.1 Gen 2 and up to 40
Gbps for Thunderbolt 3.
5External graphics port
Connect an Alienware Graphics Amplifier to enhance the graphics
performance.
8

6Power-adapter port
Connect a power adapter to provide power to your computer and charge
the battery.
Left
1Security-cable slot
Connect a security cable to prevent unauthorized movement of your
computer.
2USB 3.0 port with PowerShare
Connect peripherals such as storage devices and printers.
Provides data transfer speeds up to 5 Gbps. PowerShare enables you to
charge your USB devices even when your computer is turned off.
NOTE: If the charge on your computer’s battery is less than 10
percent, you must connect the power adapter to charge your
computer, and USB devices connected to the PowerShare port.
NOTE: If a USB device is connected to the PowerShare port before
the computer is turned off or in Hibernate state, you must
disconnect and connect it again to enable charging.
3Microphone/headphone port (configurable)
Connect an external microphone for sound input or a headphone for sound
output.
4Headset port
Connect a headphone or a headset (headphone and microphone combo).
Right
9

1USB 3.0 (Type-C) port
Connect peripherals such as external storage devices, printers, and external
displays.
Provides data transfer speeds up to 5Gbps. Supports Power Delivery that
enables power supply to devices. Provides up to 15 W power output that
enables faster charging.
NOTE: Adapters (sold separately)are required to connect standard
USB and DisplayPort devices.
2USB 3.0 port
Connect peripherals such as storage devices and printers. Provides data
transfer speeds up to 5 Gbps.
10

Specifications
Dimensions and weight
Table 1. Dimensions and weight
Height • Touch: 22 mm (0.87 in)
• Non-touch: 24 mm (0.95 in)
Width 330 mm (13 in)
Depth 269 mm (10.60 in)
Weight 2.63 kg (5.80 lb)
NOTE: The weight of your
computer varies depending on
the configuration ordered and
the manufacturing variability.
System information
Table 2. System information
Computer model Alienware 13 R3
Processor 6th generation Intel Core i5/i7
Chipset Intel HM170 chipset
Memory
Table 3. Memory specifications
Slots Two SODIMM slots
Type DDR4
Speed Up to 2667 MHz
Configurations supported 8 GB, 16 GB, and 32 GB
11

Ports and connectors
Table 4. Ports and connectors
Network One RJ-45 port
USB • One USB 3.0 port
• One USB 3.0 port with PowerShare
• One USB 3.0 (Type-C) port
• Thunderbolt 3 (USB Type-C) port
Audio/Video • One HDMI port
• One microphone/headphone port
(configurable)
• One headset port
• One Mini DisplayPort
• One external graphics port
Communications
Table 5. Communication specifications
Ethernet 10/100/1000 Mbps Ethernet
controller integrated on system board
Wireless • Wi-Fi 802.11ac
• Bluetooth 4.1
Audio
Table 6. Audio specifications
Controller Realtek ALC 3266 with Alienware
XENOWAVE sound effect
Speakers Stereo
Speaker output • Average: 4 W
12

• Peak: 5 W
Microphone Digital-array microphones
Volume controls Media-control shortcut keys
Storage
Table 7. Storage specifications
Interface PCI Express Gen3 x4 and SATA3 by
auto detect
Solid-state drive (SSD) Two M.2 PCIe/SATA drives
Keyboard
Table 8. Keyboard specifications
Type Backlit keyboard
Shortcut keys Some keys on your keyboard have two
symbols on them. These keys can be
used to type alternate characters or to
perform secondary functions. To type
the alternate character, press Shift and
the desired key. To perform secondary
functions, press Fn and the desired key.
NOTE: You can define the
primary behavior of the function
keys (F1–F12) by changing
Function Key Behavior in BIOS
setup program.
Keyboard shortcuts
13

Camera
Table 9. Camera specifications
Resolution 1280 x 720 (HD)
Diagonal viewing angle 75 degrees
Touch pad
Table 10. Touch pad
Resolution • Horizontal: 1727
• Vertical: 1092
Dimensions • Height: 56 mm (2.20 in)
• Width: 100 mm (3.94 in)
Battery
Table 11. Battery specifications
Type 4-cell “smart” lithium-ion (76 WHr)
Weight (maximum) 0.30 kg (0.66 lb)
Voltage 15.20 VDC
Life span (approximate) 300 discharge/charge cycles
Temperature range • Operating: 0°C to 35°C (32°F to
95°F)
• Storage: –20°C to 60°C (–4°F to
140°F)
Coin-cell battery CR-2032
Dimensions:
Height 7.20 mm (0.28 in)
Width 72.50 mm (2.85 in)
14

Depth 297.10 mm (11.70 in)
Operating time Varies depending on operating
conditions and can significantly reduce
under certain power-intensive
conditions.
Video
Table 12. Video specifications
Integrated Discrete
Controller Intel HD Graphics 530 NVIDIA GeForce GTX
1060
Memory Shared system memory 6 GB GDDR5
Power adapter
Table 13. Power adapter specifications
Type 180 W
Input current (maximum) 2.34 A / 2.50 A
Output current (continuous) 9.23 A
Input voltage 100 VAC–240 VAC
Input frequency 50 Hz–60 Hz
Rated output voltage 19.50 VDC
Temperature range: Operating 0°C to 40°C (32°F to 104°F)
Temperature range: Storage –40°C to 70°C (–40°F to 158°F)
15

Display
Table 14. Display specifications
Type 13.3-inch Touch
QHD OLED
13.3-inch
Nontouch FHD
LCD
13.3-inch
Nontouch HD
LCD
Resolution
(maximum)
2560 x 1440 1920 x 1080 1366 x 768
Viewing angle 85 degrees 80 degrees 40 degrees
Pixel pitch 0.115 mm 0.153 mm 0.215 mm
Height
(including bezel)
165.60 mm (6.52
in)
165.10 mm (6.50
in)
165 mm (6.50 in)
Width
(including bezel)
294.40 mm (12 in) 293.60 mm
(11.56 in)
293.40 mm (11.56
in)
Diagonal
(excluding bezel)
337.82 mm (13.30
in)
337.82 mm (13.30
in)
337.82 mm (13.30
in)
Refresh rate 60 Hz
Controls Brightness can be controlled using shortcut keys
Computer environment
Airborne contaminant level: G2 or lower as defined by ISA-S71.04-1985
Table 15. Computer environment
Operating Storage
Temperature range 5°C to 35°C (41°F to
95°F)
–40°C to 65°C (–40°F to
149°F)
Relative humidity
(maximum)
10% to 90%
(non-condensing)
0% to 95%
(non-condensing)
Vibration (maximum) 0.26 GRMS 1.37 GRMS
16

Operating Storage
Shock (maximum)*40 G for 2 ms with a
change in velocity of 20
in/s (51 cm/s)†
105 G for 2 ms with a
change in velocity of 52.5
in/s (133 cm/s)‡
Altitude (maximum) –15.20 m to 3048 m
(–50 ft to 10,000 ft)
–15.20 m to 10,668 m
(–50 ft to 35,000 ft)
* Measured using a random vibration spectrum that simulates user environment.
† Measured using a 2 ms half-sine pulse when the hard drive is in use.
‡ Measured using a 2 ms half-sine pulse when the hard-drive head is in parked position.
17

Keyboard shortcuts
Table 16. List of keyboard shortcuts
Keys Description
Disconnect Alienware Graphics
Amplifier
Disable/enable wireless
Mute audio
Decrease volume
Increase volume
Toggle integrated/discrete graphics
Switch to external display
Decrease brightness
Increase brightness
Disable/enable touch pad
Disable/enable AlienFX
18

Getting help and contacting
Alienware
Self-help resources
You can get information and help on Alienware products and services using these
online self-help resources:
Table 17. Getting self help resources
Information about Alienware
products and services www.alienware.com
Windows 8.1 and Windows 10 Dell Help & Support app
Windows 10 Get started app
Windows 8.1 Help + Tips app
Accessing help in Windows 8,
Windows 8.1, and Windows 10 In Windows search, type Help and Support, and press Enter.
Accessing help in Windows 7 Click Start → Help and Support.
Online help for operating system www.dell.com/support/windows
www.dell.com/support/linux
Troubleshooting information, user
manuals, setup instructions, product
specifications, technical help blogs,
drivers, software updates, and so on
www.alienware.com/gamingservices
Videos providing step-by-step
instructions to service your computer
www.youtube.com/alienwareservices
19

Contacting Alienware
To contact Alienware for sales, technical support, or customer service issues, see
www.alienware.com.
NOTE: Availability varies by country and product, and some services may
not be available in your country.
NOTE: If you do not have an active internet connection, you can find
contact information on your purchase invoice, packing slip, bill, or Dell
product catalog.
20
