Alienware Aurora Ryzen Edition D23M Operation and maintenance manual

Alienware Aurora Ryzen Edition
Setup and Specifications
Regulatory Model: D23M
Regulatory Type: D23M004

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the
problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2019 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its
subsidiaries. Other trademarks may be trademarks of their respective owners.
2019 - 11
Rev. A00

Contents
1 Set up your computer.............................................................................................................................4
2 Views of Alienware Aurora Ryzen Edition...........................................................................................7
Front...................................................................................................................................................................................... 7
Back.......................................................................................................................................................................................8
Back panel............................................................................................................................................................................ 9
3 Specifications of Alienware Aurora Ryzen Edition.............................................................................11
Dimensions and weight....................................................................................................................................................... 11
Processors.............................................................................................................................................................................11
Chipset.................................................................................................................................................................................11
Operating system................................................................................................................................................................12
Memory................................................................................................................................................................................12
Ports and connectors.......................................................................................................................................................... 12
Communications..................................................................................................................................................................13
Video...................................................................................................................................................................................14
Audio...................................................................................................................................................................................14
Storage................................................................................................................................................................................ 14
Power ratings...................................................................................................................................................................... 15
Computer environment...................................................................................................................................................... 15
4 Alienware Command Center...............................................................................................................16
5 Getting help and contacting Alienware..............................................................................................17
3

Set up your computer
1. Connect the keyboard and mouse.
2. Connect to your network using a cable, or connect to a wireless network.
3. Connect the display.
4

NOTE: The DisplayPort on the back panel of your computer is covered. Connect the display to the discrete graphics
card of your computer.
NOTE: If you have two graphics cards, the card installed in PCI-Express X16 (graphics slot 1) is the primary graphics
card.
4. Connect the power cable.
5. Press the power button.
5

6

Views of Alienware Aurora Ryzen Edition
Front
1. Power button (Alienhead)
Press to turn on the computer if it is turned off, in sleep state, or in hibernate state.
Press to put the computer in sleep state if it is turned on.
Press and hold for 4 seconds to force shut-down the computer.
NOTE: You can customize the power-button behavior in Power Options.
2. USB 3.1 Gen 1 ports (2)
Connect peripherals such as external storage devices and printers. Provides data transfer speeds up to 5 Gbps.
3. USB 3.1 Gen 1 port with PowerShare
Connect peripherals such as external storage devices and printers.
Provides data transfer speeds up to 5 Gbps. PowerShare enables you to charge connected USB devices.
NOTE: Connected USB devices will not charge when the computer is turned off or in sleep state. To start charging
connected devices, turn on the computer.
4. USB 3.1 Gen 1 (Type-C) port
Connect peripherals such as external storage devices, printers, and external displays.
7

Provides data transfer speeds up to 5 Gbps. Supports Power Delivery that enables two-way power supply between devices.
Provides up to 7.5 W power output that enables faster charging.
5. Headphone port
Connect a headphone or speakers.
6. Microphone port
Connect an external microphone to provide sound input.
Back
1. Back panel
Connect USB, audio, video, and other devices.
2. PCI-Express X16 (graphics slot 1)
Connect a PCI-Express card such as graphics, audio, or network card to enhance the capabilities of your computer.
For optimal graphics performance, use a PCI-Express X16 slot for connecting the graphics card.
NOTE: The PCI-Express X16 slot works at X8 lanes only.
NOTE: If you have two graphics cards, the card installed in PCI-Express X16 (graphics slot 1) is the primary graphics
card.
3. PCI-Express X4 slots (2)
Connect a PCI-Express card such as graphics, audio, or network card to enhance the capabilities of your computer.
NOTE: The PCI-Express X4 slot 3 works at X2 lanes only.
8

4. PCI-Express X16 (graphics slot 2)
Connect a PCI-Express card such as graphics, audio, or network card to enhance the capabilities of your computer.
For optimal graphics performance, use a PCI-Express X16 slot for connecting the graphics card.
NOTE: The PCI-Express X16 slot works at X8 lanes only.
5. Power-supply cage release-latches (2)
Allows you to remove the power supply unit from your computer.
6. Power-supply diagnostics button
Press to check the power‑supply state.
7. Power-supply diagnostics light
Indicates the power-supply state.
8. Power port
Connect a power cable to provide power to your computer.
9. Service Tag label
The Service Tag is a unique alphanumeric identifier that enables Dell service technicians to identify the hardware components in
your computer and access warranty information.
10.Side panel release latch
Allows you to remove the side panel from your computer.
11. Security-cable slot (wedge-shaped)
Connect a security cable to prevent unauthorized movement of your computer.
Back panel
1. Coaxial S/PDIF port
Connect an amplifier, speakers, or a TV for digital audio output through a coaxial cable.
2. Optical S/PDIF port
Connect an amplifier, speakers, or a TV for digital audio output through an optical cable.
3. USB 2.0 ports (6)
9

Connect peripherals such as external storage devices and printers. Provides data transfer speeds up to 480 Mbps.
4. USB 3.1 Gen 2 Type-C port
Connect peripherals, such as external storage devices and printers. Provides data transfer speeds up to 10 Gbps.
NOTE: This port does not support video/audio streaming or power delivery.
5. USB 3.1 Gen 2 port
Connect peripherals, such as external storage devices and printers. Provides data transfer speeds up to 10 Gbps.
6. Side L/R surround port
Connect audio-output devices such as speakers and amplifiers. In a 7.1 speaker channel setup, connect the side-left and side-
right speakers.
7. Microphone port
Connect an external microphone to provide sound input.
8. Front L/R surround line-out port
Connect audio-output devices such as speakers and amplifiers. In a 2.1 speaker channel setup, connect the left and right
speakers. In a 5.1 or a 7.1 speaker channel setup, connect the front-left and front-right speakers.
9. Line-in port
Connect recording or playback devices such as a microphone or CD player.
10.Center/subwoofer LFE surround port
Connect the center speaker or the subwoofer.
NOTE: For more information about the speaker setup, refer the documentation that shipped with the speakers.
11. Rear L/R surround port
Connect audio-output devices such as speakers and amplifiers. In a 5.1 or a 7.1 speaker channel setup, connect the rear-left and
rear-right speakers.
12. USB 3.1 Gen 1 ports (3)
Connect peripherals such as external storage devices and printers. Provides data transfer speeds up to 5 Gbps.
13. Network port (with lights)
Connect an Ethernet (RJ45) cable from a router or a broadband modem for network or Internet access.
The two lights next to the connector indicate the connectivity status and network activity.
10

Specifications of Alienware Aurora Ryzen Edition
Dimensions and weight
Table 1. Dimensions and weight
Description Values
Height:
Front 441.80 mm (17.39 in.)
Rear 481.60 mm (18.96 in.)
Width 222.80 mm (8.77 in.)
Depth 431.90 mm (17 in.)
Weight (maximum) 17.80 kg (39.24 lb)
NOTE: The weight of your computer depends on the configuration
ordered and the manufacturing variability.
Processors
Table 2. Processors
Processors Wattage Core count Thread count Speed Cache
AMD Ryzen 9
3950X
105 W 16 32 4.7/3.5 GHz 64 MB
AMD Ryzen 9
3900X
105 W 12 24 4.6/3.8 GHz 64 MB
AMD Ryzen 9 3900 65 W 12 24 4.3/3.1 GHz 64 MB
AMD Ryzen 7
3800X
105 W 8 16 4.5/3.9 GHz 32 MB
AMD Ryzen 7
3700X
65 W 8 16 4.4/3.6 GHz 32 MB
AMD Ryzen 5
3600X
95 W 6 12 4.4/3.8 GHz 32 MB
AMD Ryzen 5 3600 65 W 6 12 4.2/3.6 GHz 32 MB
AMD Ryzen 5 3500 65 W 6 6 4.1/3.6 GHz 16 MB
Chipset
Table 3. Chipset
Description Values
Chipset B550A
Processor AMD Ryzen 9/ AMD Ryzen 7/ AMD Ryzen 5
DRAM bus width 64 bits
Flash EPROM 128 MB
PCIe bus PCIe Gen4
11

Operating system
• Windows 10 Home (64-bit)
• Windows 10 Professional (64-bit)
Memory
Table 4. Memory specifications
Description Values
Slots Four UDIMM
Type DDR4
Speed 2666 MHz up to 3200 MHz (XMP memory)
Maximum memory 64 GB
Minimum memory 8 GB
Memory per slot 8 GB and 16 GB
Configurations supported: • 8 GB XMP at 2666 MHz
• 16 GB XMP at 2666 MHz
• 32 GB XMP at 2666 MHz
• 16 GB XMP at 2933 MHz
• 32 GB XMP at 2933 MHz
• 16 GB XMP at 3200 MHz
• 32 GB XMP at 3200 MHz
• 64 GB XMP at 2666 MHz
• 64 GB XMP at 2933 MHz
• 64 GB XMP at 3200 MHz
Ports and connectors
Table 5. Ports and connectors
Description Values
External:
Network One RJ-45 port
USB • Six USB 2.0 ports
• Five USB 3.1 Gen 1 ports
• One USB 3.1 Gen 1 Type-C port
• One USB 3.1 Gen 2 port
• One USB 3.1 Gen 2 Type-C port
• One USB 3.1 Gen 1 port with PowerShare
Audio • One audio output/headphone port (supports 2 channel
audio)
• One audio input/microphone port
• One optical S/PDIF port
• One coaxial S/PDIF port
• One front L/R surround line-out port
• One side L/R surround port
• One rear L/R surround port
12

Description Values
• One center/subwoofer LFE surround port
• One line-in port
Video Not supported
NOTE: Connect the display to the discrete graphics card
of your computer.
Memory card reader Not supported
Power port Not applicable
Security One security-slot (Wedge-shaped lock)
Internal:
PCIe expansion card slots • Two PCIe x16 slots
• Two PCIe x4 slots
mSATA Not supported
SATA Four
M.2 • One M.2 card slot for WLAN and Bluetooth
• One PCIe/SATA M.2 card slot for 2230/2280 solid-state
drive
NOTE: To learn more about the features of different types
of M.2 cards, see the knowledge base article SLN301626.
Communications
Ethernet
Table 6. Ethernet specifications
Description Values
Model number Killer E2600 Ethernet controller integrated on system board
Transfer rate 10/100/1000 Mbps
Wireless module
Table 7. Wireless module specifications
Description Values
Model number Qualcomm DW1810 Qualcomm DW1820 Killer AX1650
Transfer rate Up to 433 Mbps Up to 867 Mbps Up to 2.4 Gbps
Frequency bands supported Dual band 2.4 GHz/5 GHz Dual band 2.4 GHz/5 GHz Dual band 2.4 GHz/5 GHz
Wireless standards Wi-Fi 5 (WiFi 802.11ac) Wi-Fi 5 (WiFi 802.11ac) Wi-Fi 6 (WiFi 802.11ax)
Encryption • 64-bit/128-bit WEP
• AES-CCMP
• CKIP
• TKIP
• 64-bit/128-bit WEP
• AES-CCMP
• CKIP
• TKIP
• 64-bit/128-bit WEP
• AES-CCMP
• CKIP
• TKIP
13

Description Values
Bluetooth Bluetooth 5.0 Bluetooth 5.0 Bluetooth 5.0
Video
Table 8. Discrete graphics specifications
Discrete graphics
Controller External display support Memory size Memory Type
AMD RX 5700 One HDMI port, Three DisplayPort 8 GB GDDR6
AMD RX 5700 XT One HDMI port, Three DisplayPort 8 GB GDDR6
AMD Vega 20 One HDMI port, Three DisplayPort 16 GB GDDR6
NVIDIA GTX 1650 One DVI port, One HDMI port 4 GB GDDR6
NVIDIA GTX 1660 One DVI port, One HDMI port, One DisplayPort 6 GB GDDR6
NVIDIA GTX 1660Ti One DVI port, One HDMI port, One DisplayPort 6 GB GDDR6
NVIDIA RTX 2060SI One DVI port, One HDMI port, One DisplayPort 6 GB GDDR6
NVIDIA RTX 2060 Super One DVI port, One HDMI port, One DisplayPort 8 GB GDDR6
NVIDIA RTX 2070 B One DVI port, One HDMI port, Two DisplayPort 8 GB GDDR6
NVIDIA RTX 2070 Super One HDMI port, Three DisplayPort 8 GB GDDR6
NVIDIA RTX 2080 Super One HDMI port, Three DisplayPort 8 GB GDDR6
NVIDIA RTX 2080Ti One HDMI port, Three DisplayPort, One USB Type-C
port
11 GB GDDR6
Audio
Table 9. Audio specifications
Description Values
Type Integrated 7.1 channel audio with S/PDIF port
Controller Realtek ALC3861
Internal interface High-definition audio
External interface 7.1 channel output, Microphone-in, stereo headphones, and
headset combo connector
Storage
Your computer supports one of the following configurations:
• One M.2 2230/2280 solid-state drive, one 3.5-inch hard drive, and two 2.5-inch hard drives
• One U.2 drive and two 2.5-inch hard drives
• One 3.5-inch hard drive and two 2.5-inch hard drives
NOTE: The primary drive of your computer varies depending on the storage configuration.
Table 10. Storage specifications
Form factor Interface type Capacity
Two 2.5-inch hard drives SATA AHCI 6 Gbps Up to 2 TB
One 3.5-inch hard drive SATA AHCI 6 Gbps Up to 2 TB
14

Form factor Interface type Capacity
One M.2 2230/2280 solid-state drive PCIe NVMe up to 32 Gbps Up to 2 TB
Power ratings
Table 11. Power ratings specifications
Type 460 W 850 W
Input voltage 90 VAC to 264 VAC 90 VAC to 264 VAC
Input frequency 47 Hz to 63 Hz 47 Hz to 63 Hz
Input current (maximum) 8 A 10 A
Output current (continuous) 5 V/25 A, 12 VA/18 A, 12 VB/16 A, 12 VC/8 A,
3.3 V/17 A, 5 Vaux/3 A
5 V/20 A, 12VA/32 A, 12
VB/48 A, 12 VD/16 A, -12
V/0.5 A, 3.3 V /20 A, 5
Vaux/4 A
Rated output voltage 5 V, 12 VA, 12 VB, 12 VC, 3.3 V, 5 Vaux 5 V, 12 VA, 12 VB, 12 VD, 3.3
V, -12 V, 5 Vaux
Temperature range
Operating 5°C to 50°C (41°F to 122°F) 5°C to 50°C (41°F to 122°F)
Storage -40°C to 70°C (-40°F to 158°F) -40°C to 70°C (-40°F to
158°F)
Computer environment
Airborne contaminant level: G1 as defined by ISA-S71.04-1985
Table 12. Computer environment
Description Operating Storage
Temperature range 10°C to 35°C (50°F to 95°F) –40°C to 65°C (–40°F to 149°F)
Relative humidity (maximum) 20% to 90% (non-condensing) 5% to 95% (non-condensing)
Vibration (maximum)*0.26 GRMS 1.37 GRMS
Shock (maximum) 40 G for 2 ms with a change in velocity of
20 in/s (51 cm/s)†
105 G for 2 ms with a change in velocity
of 52.5 in/s (133 cm/s)‡
Altitude (maximum) –15.2 m to 3,048 m (–50 ft to 10,000 ft) –15.2 m to 10,668 m (–50 ft to 35,000
ft)
* Measured using a random vibration spectrum that simulates user environment.
† Measured using a 2 ms half-sine pulse when the hard drive is in use.
15

Alienware Command Center
Alienware Command Center (AWCC) provides a single interface to customize and enhance the gaming experience. The AWCC
dashboard displays most recently played or added games, and provides game-specific information, themes, profiles, and access to
computer settings. You can quickly access settings such as game-specific profiles and themes, lighting, macros, and audio that are
critical to the gaming experience.
AWCC also supports AlienFX 2.0. AlienFX enables you to create, assign, and share game-specific lighting maps to enhance the
gaming experience. It also enables you to create your own individual lighting effects and apply them to the computer or attached
peripherals. AWCC embeds Peripheral Controls to ensure a unified experience and the ability to link these settings to your computer
or game.
AWCC supports the following features:
• FX: Create and manage the AlienFX zones.
• Fusion: Includes the ability to adjust game-specific Power Management, Sound Management, and Thermal Management features.
• Peripheral Management: Enables peripherals to appear in and be managed in Alienware Command Center. Supports key
peripheral settings and associates with other functions such as profiles, macros, AlienFX, and game library.
AWCC also supports Sound Management, Thermal Controls, CPU, GPU, Memory (RAM) monitoring. For more information about
AWCC, see the Alienware Command Center Online Help.
16

Getting help and contacting Alienware
Self-help resources
You can get information and help on Alienware products and services using these online self-help resources:
Table 13. Alienware products and online self-help resources
Self-help resources Resource location
Information about Alienware products and services www.alienware.com
My Dell
Tips
Contact Support In Windows search, type Contact Support, and press Enter.
Online help for operating system www.dell.com/support/windows
www.dell.com/support/linux
Troubleshooting information, user manuals, setup instructions,
product specifications, technical help blogs, drivers, software
updates, and so on
www.alienware.com/gamingservices
VR Support www.dell.com/VRsupport
Videos providing step-by-step instructions to service your
computer
www.youtube.com/alienwareservices
Contacting Alienware
To contact Alienware for sales, technical support, or customer service issues, see www.alienware.com.
NOTE: Availability varies by country/region and product, and some services may not be available in your country/region.
NOTE: If you do not have an active Internet connection, you can find contact information about your purchase invoice,
packing slip, bill, or Dell product catalog.
17
