All Pond Solutions JY Series User manual

JY & JYS
TANK
RANGE
COLUMN AQUARIUM
INSTRUCTION
MANUAL

To ensure safe enjoyment and understanding of your aquarium please read and
follow all the safety instructions and important notices below before using at
setting up your aquarium. Failure to do so may result in injury or damage to the
unit.
SAFETY
Important! Disconnect the mains electricity supply before carrying out any
installation or maintenance of any kind. Do not attempt to modify this unit in any
way and only use the recommended parts for replacement.
·Prior to set up, carefully inspect the tank to ensure it is not fractured or
cracked.
· If the lighting unit falls into the water, DO NOT touch it! First unplug it and
then retrieve it. If the electrical components of the appliance get wet,
unplug the appliance immediately.
·Inspect the unit carefully after installation. This should not be plugged in if
there is water on parts that are not intended to get wet.
·Do not operate the unit if the plug or cord is damaged; if it is malfunctioning;
or if it has been dropped or damaged in some way.
·Do not yank cord to pull plug from outlet. Grasp the plug and pull to
disconnect. Always unplug from an outlet when not in use.
·The power cord of this appliance cannot be replaced; if the cord is
damaged, the appliance should be discarded. Never cut the cord.
·All connections must be earthed. Do not connect to any voltage other than
that stated.
·If the plug or socket does get wet, DO NOT unplug the cord. Disconnect the
fuse or circuit breaker that supplies power to the appliance. Next, unplug
and inspect for any presence of water in the power socket.
·To avoid the risk of the unit plug, switch or wall socket getting wet, position
the unit to one side of a mounted wall socket to prevent water from dripping
into the socket or plug.

· A “drip loop” should be arranged to the socket. The “drip loop” is that part of
the cord below the level of the socket (or the connector if an extension cord
is used), to avoid water travelling along the cord and coming into contact
with the wall socket.
·Do not attempt to modify this unit in any way and only use the
recommended parts for replacement.
·ALWAYS disconnect from the power supply before removing the hood.
·If an extension cord is required, a cord with a suitable rating should be used. A
cord rated for less amperes or watts than the appliance rating may cause the
unit to overheat. Care should be taken to position the cord so that it will not be
pulled or cause a trip hazard.
·If the unit shows any signs of water leakage, disconnect the power supply
cord from the wall socket and consult All Pond Solutions or the retailer you
purchased this unit from for further advice.
CAUTION
·NEVER place any object(s) on the LED strip light. Make sure there is
adequate air space around the light. The safety and correct functioning of
your aquarium is only guaranteed if the lighting and all other equipment has
been correctly installed.
·Ensure supplied powerhead is fully submerged at all times to avoid
overheating damage.
·To prevent injury, do not touch moving parts or hot parts such as heaters or
LED devices.
·Always unplug or disconnect equipment from the electricity supply before
placing hands into your aquarium water and before installing or removing
parts. Always unplug equipment from the mains when not in use.
·Do not use any equipment other than for its intended purpose (i.e. for
outdoor pools, ponds, household use, etc.). Do not use attachments or
spare parts other than those recommended or sold by the unit
manufacturer.

·Do not attempt to repair any product component yourself: if any damage
has occurred, replace the damaged component with original spare parts, or
contact the manufacturer for further advice.
·This equipment can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or
instruction concerning use of the equipment in a safe way and understand
the hazards involved.
·Children should not play with the equipment. Cleaning and user
maintenance shall not be made by children without supervision.
·Read and observe all the important notices on the aquarium.
IMPORTANT! For aquariums with an in-built strip lighting, please note that these
are suitable for INDOOR USE ONLY. For fresh and saltwater aquariums with a
maximum water temperature of 35 °C, do not set up or store the tank in any location
where temperatures may drop below freezing.
ELECTRIC
This aquarium comes complete with a generous supply of 3 core cable,
however should any additional cable be required, the use of an approved
waterproof cable connector with a proper rating is essential. A cord rated for
less amperes or watts than the appliance rating may overheat.
Please Ensure:
·The power supply must be earthed and fused at 3amps.
·You regularly inspect the cable for damage and deterioration.
·Do not connect to any voltage other than that stated.
·You consult a qualified electrician if in doubt about any aspects of wiring.
Please Ensure: The power supply must be earthed and fused at 3amps.
Regularly inspect the cable for damage and deterioration. Consult a qualified
electrician if in doubt about any aspects of wiring.

ADDING WATER TO YOUR TANK
Fill your aquarium with water up to the level indicated on the label located
on the inside of the aquarium's top frame.
IMPORTANT! DO NOT OVER FILL YOUR AQUARIUM. Overfilling the tank can
cause water to pass under the top frame which then runs down the inside of the
aquarium.
AQUARIUM GLASS TANK INSTRUCTIONS
Read thoroughly prior to installation:
·Do not attempt to remove the white acrylic / clear plastic lid that sits on
top of the acrylic tank, This is required for your tank set up and removing, or
attempting to remove it will invalidate your warranty.
·Whilst the aquarium tank has been manufactured with the upmost care and
attention, we would still advice inspecting the tank prior to setting up your unit
to ensure that it has not received any damage during transit.
1. Inspect the acrylic tank for any damage or cracks.
2. Following your visual inspection, if it does not show any damage, fill
your tank with 5cm (2”) of water, wait 10 minutes and test for leaks.
3. Add another 5cm (2”) and repeat this process until you are sure there is
no sign of any leak.
4. If no leak is identified, continue with the normal aquarium set up.
·Always handle your tank with the utmost care. Make sure to carry securely
and always lift it by the base, never by the top frame.
·Make sure to ONLY move or transport the tank if it is COMPLETELY empty
of water or any other material.
·To avoid injury, potential damage and ensure a safe transit, make sure you
have assistance to help you lift the unit before you attempt to move your
aquarium.
·Caution – take care not to damage the seals at the edges of the tank
panels when maintaining or cleaning your aquarium, for example with
planters or algae scrapers. Make sure any equipment or products used are
not abrasive and will not scratch the tank.

·Never use toxic or inappropriate substances to clean your aquarium, such
as household or garden detergents.
IMPORTANT! It is ESSENTIAL to place the aquarium on the corresponding
cabinet which was designed with the correct dimensions and structure to bear
the weight of the aquarium full of water. Placing your tank on a different
cabinet, piece of furniture, stand, etc. WILL invalidate your warranty.
POSITIONING YOUR AQUARIUM
NOTE – Selecting a suitable location for your aquarium is very
important.
·This aquarium is suitable for indoor use only.
·Position your aquarium away from direct sunlight to reduce excess algae
build-up and prevent your aquarium from overheating. Locate your
aquarium away from other draft and heat sources (air ducts, radiators, etc.)
to help regulate and maintain a suitable temperature. Do not locate your
aquarium in a location or on a surface where water spills will cause
damage.
·Position your aquarium close to an electrical outlet.
·Make sure that your chosen location for your aquarium has an even and
level surface which will be able to support the total weight of the
aquarium and cabinet when filled with water. Once the tank is positioned,
ensure that it is completely level by using an adequate spirit level.
·NEVER insert any lining (e.g. polystyrene) between the cabinet and
aquarium tank. Position the aquarium directly onto the cabinet without any
additional support or cushioning in between.
IMPORTANT! It is ESSENTIAL to place the aquarium on the corresponding
cabinet which was designed with the correct dimensions and structure to bear
the weight of the aquarium full of water. Placing your tank on a different
cabinet, piece of furniture, stand, etc. WILL invalidate your warranty.

PARTS DIAGRAM
Bottom filter tray & foam
Bio balls
Water filter pump
Air pump
Glass cover
Top filter tray & spray bar
T piece for air pump
Non-return valve
Inlet strainer
LED light unit
Venturi pipe
Water outlet for filter
Flexi pipe for pump to filter
Filter box lid
Heater
Clear hard tube

INSTALLATION
Before adding any equipment to your tank, first
position the tank in your desired location and fill
with water (see Adding Water to your Tank). Next,
connect the two ends of the T piece (7) to the two
air pump outlets (4) and then connect to the clear
pipe that runs along the back of the tank.
Use the non-return valve (8) to connect the clear
pipe from the back of the tank and the T piece. The
pipe from the back of the tank will need to be cut a
few centimetres down and connect to the non-
return valve (put the black end closest to the air
pump).
Connect the water filter pump (3) to the clear hard
tube (16) and then attach the strainer (9) to the
bottom of the tube.
The black flex pipe (13) attaches to the top of the
water pump and then feeds through a hole in the
top of the tank rim. Slide on the back plate and
position on the inside of the tank rim. Secure the
suction cups to hold in place.
There is an optional venturi pipe (11) that can be
connected to the outlet of the water pump. The
outlet pointing upwards is where the venturi pipe
connects.

Connect the water outlet (12) to the hole in the
underside of the bottom filter tray (1). This allows
the filtered water to be returned into the tank.
Add the black bio balls (2) into the bottom filter
tray on top of the filter foam.
Lay the clear spray bar (6) across the top of the
top filter tray (6) between the two grooves at
either end. The black rubber end piece must sit in
the groove on the right hand side in order to
connect to the flex pipe (13).
Sit the filter box lid (14) on top of the top filter tray.
Carefully lay the glass cover (5) onto the top of the
tank rim. Position the filter trays and the LED light
unit (10) on top of the glass cover. Ensure that the
protective plastic wrap cover has been removed.
Position the switch and all cables to hang outside
the tank.
Replace the filter hood on top of the tank and
feed all cables through the pre-cut slit in the side
of the hood.
5
6
7
8

SET UP ADVICE
CAUTION: Disconnect the mains electricity supply before placing your hands in
your aquarium water or carrying out any installation or maintenance of any kind.
·Once you have installed any outlet/inlet pipework, do not move the tank
and/or cabinet as this can cause damage to the pipework and the acrylic
tank.
·Do not loosen or undue force on any pre-installed fittings on tank openings.
·Position any water jets so they do not cause water to overflow from the tank.
Avoid directing the water jets against any LED strip-lights.
·The height of the intake strainer is high enough to suit the most standard
aquarium decorations.
·When adding decorations to your aquarium, make sure that your intake
strainer remains at least 5cm from the gravel bottom to avoid gravel or sand
from being siphoned up and that no decorations obstruct the water flow.
·Never force Connector Stems sideways, as this may damage the
output/input systems and the glass tank.
IMPORTANT! All Pond Solutions always advises fish keepers to cycle aquarium
water for at least 2-4 weeks before adding any type of fish to a new setup. This
allows adequate time for your filter system to circulate properly and water
readings to stabilise – if fish are added prior to this it is highly likely they will
suffer. This is called 'cycling' your fish tank.
MAINTENANCE ADVICE
To ensure optimal performance and that your aquarium functions correctly,
regular maintenance is essential. Failure to do so may result in damage to your
unit and may invalidate your warranty.
IMPORTANT! - Unplug all appliances in the aquarium before carrying out
maintenance.
We recommend that a regular cleaning and maintenance schedule is followed
to ensure responsible fishkeeping. Depending on water volume and stocking
levels, regular cleaning of the filter media, foams, impeller, inlet/outlet
pipework during a 10-25% water change will help ensure that the product works
efficiently and the aquarium remains healthy.

For further maintenance guidance, please see the table and additional
information below:
1 MONTH
3 MONTHS
6 MONTHS
ANNUALLY
Impeller
Clean & Inspect
Replace
Ceramic Shaft
Clean & Inspect
Replace
All Pipework
Clean & Inspect
Hosing
Clean & Inspect
Heater
Clean & Inspect
O-Rings
Clean & Inspect
Lubricate &
Clean
Replace
Floss Foams* &
Other Media
Clean & Inspect
Replace
* It is important to regularly clean and replace the floss filter foams provided to
avoid water blockages and ensure sufficient water flow through the filter.

·When topping up tank water it is essential to add the appropriate amount of
dechlorinator or water conditioner; not just adding water from a tap.
·Do not leave lights on for more than 6-8 hours as over-usage may result in
hard to tackle algae issues.
·Regularly use a soft algae pad to clean interior of the tank. Magnet cleaners
should not be used as if sand or substrate becomes caught under the pad
this can scratch the acrylic.
In general, it is recommended to disconnect your unit and clean the pipework,
impellers and filter media monthly. Pipework will become blocked with waste
and protein slime over time, so regular cleaning is important for optimal
performance.
To clean the outside of the tank, you can periodically wipe with a damp cloth
(use a cloth dampened with water from your aquarium, never use any chemical
products or detergents). Lemon juice can also be used to removing any
limescale build-up. Rinse thoroughly afterwards to remove any acidic residue.
It is vital that O-rings are regularly inspected and replaced as the rubber
watertight seal will perish over time, which may cause your canister to leak.
Before replacing your o-rings, ensure they are well lubricated.
O-rings
A clogged impeller is often the primary cause of many operational faults, so it
is extremely important to clean and inspect your impellers every month to
ensure they are functioning correctly and remove any debris. Keeping the
impellers clean will improve the performance of your equipment. The impeller
itself is a perishable part and will be subject to wear and tear overtime. As a
result, it is also very important to replace your impeller and ceramic shaft
annually.
To clean, simply wash with your aquarium water (from a water change) - whilst
doing this you will be able to check that the impeller and shaft are both in
good condition. When returning this to the motor head ensure this is seated
correctly with the two rubbers on either end of the shaft (sometimes the
Impellers and Shafts

rubbers stay in the holes that they fit into and will not be obviously evident
when first removing the impeller and shaft).
Note: Handle the ceramic shaft with care as this can break very easily during
the cleaning process.
Filter media is designed for use in filter bays and will help clean circulating
water and maintain essential bacteria.
Always rinse all media thoroughly prior to use until water runs clear to avoid
tank clouding.
We recommend to add media to your filter bays in the following order to give
complete and optimum filtration for your tank. Depending on the amount of
fish you are going to house in your tank, you may need to add additional
media to ensure your tank is filtered sufficiently.
Adding Filter Media
BOTTOM MEDIA
TRAY
Filter Floss Foam
Bio Balls
Mechanic Filtration
Biological Filtration
Removes small
waste particles from
the water.
Creates environment
for nitro-bacteria to
cultivate and help
oxygenate the water.
TOP MEDIA TRAY
Filter Floss Foam
IMPORTANT! Always use water from your fish tank to clean your filter media.
Do not use mains water or any cleaning products to clean your media.
Please remember to change your activated carbon at least every 2-3 months
as after this time it is possible that the carbon can have a negative effect on
your aquarium as the very waste it removes can be released from the carbon
back into the aquarium.
When cleaning mechanical or biological media, NEVER rinse with tap water or
use any soap or detergent, only your aquarium water. The best time to rinse
your filter foams, bio balls and ceramic rings through is when doing a 10 / 20%
water change as you can use this water to wash the media through.

When replacing filter media, do not replace more than 50% of your media at
once. This is to ensure that the nitrifying bacteria present in the old media are
able to repopulate in the newly added filter media.
REPLACEMENT PARTS
Only use spare parts provided by the manufacturer of your aquarium to ensure
continual performance and safety.
IMPORTANT! Perishable parts including impellers, shafts, magnets and rubbers
are not covered by your warranty and a charge may be required for replacements
of these.
For a full listing of replacement parts please visit
www.allpondsolutions.co.uk/spare-parts
WARRANTY
Your aquarium is guaranteed against defects in material or workmanship under
normal aquarium usage and comes with 12 months warranty for all electrical
parts and 6 months warranty for the glass / acrylic tank. The warranty period
commences from the date of purchase. This guarantee is valid with proof of
purchase only.
If you require support on how to use your aquarium, replacement parts or if your
tank develops a fault during the warranty period, please contact the supplier of
your aquarium.
Non-replaceable, non-perishable and non-serviceable parts will be repaired or
replaced free of charge, once the unit is returned with all components along
with a valid proof of purchase and postage paid. We reserve the right to replace
or repair the unit at our discretion.
The guarantee is limited to repair or replacement only and does not cover
consequential loss or damage to animate or inanimate objects. No liability is
assumed with respect to loss or damage to livestock or personal property
irrespective of the cause thereof.
Please be aware that perishable parts that are subject to normal wear and tear,
such as impellers, impeller covers, motor seals, o-rings and bulbs, are not
covered by your warranty and a charge may be required for replacements of

these. The warranty also does not cover wear and tear or any parts which have
not been adequately or correctly maintained.
This guarantee is valid providing the aquarium has been situated in a suitable
location. This location must be flat and level, and has been installed in
consistence with the installation instructions and this document. Where
applicable, it is essential that the aquarium is only placed on a corresponding
cabinet which was designed with the correct dimensions and structure to bear
the weight of the aquarium full of water. Placing your tank on a different cabinet,
piece of furniture, stand, etc. WILL invalidate your warranty.
This warranty does not apply to any unit that has been subjected to
unreasonable use, accidental damage, negligence, tampering, commercial use,
improper installation or customisation, chips, stress cracks resulting from
improper support or any other breakage. It does not apply to units which have
been assembled incorrectly, improperly maintained, or where the instructions
and safety information in this manual has not been followed correctly.
This guarantee is only valid under standard operating conditions for which the
unit is intended.
Before returning your unit under warranty terms, check that all setup and
maintenance instructions have been correctly followed. If you are in doubt,
please contact your local aquatic retailer for further advice before returning the
product.
This does not affect your statutory rights.
RECYCLING
This symbol bears the selective sorting symbol for waste
electrical and electronic equipment (WEEE). This means that
this product must be handled in accordance with European
Directive 2012/19/EU where it must be recycled or
dismantled to minimise its impact on the environment. For
further information, please contact your local or regional
Authorities.
Electronic products not included in the selective sorting
process are potentially dangerous for the environment and
human health due to the presence of hazardous substances.
