INSTRUCTIONS FOR ASSEMBLY
2355mm x 2355mm Junior Workshop
1 Thomas Burns Street, Dunedin
Phone [phone] www.allans.co.nz

F:\C - E\Christie Garden Products\Sheds\Shed 2355 x 2355 Junior Workshop\Shed 2355 x 2355 Junior Workshop Asse bly
Instructions Rev 2.docx
Congratulations on your purchase of a quality Christie shed. All the parts required
for building your shed are included in the pack you received. Optional extras
include:
•Concrete base fixing brackets
•Timber frame to concrete pad fixing brackets
•Shelving brackets
•Free standing shelving
You will need the following to complete the shed assembly:
•Hammer
•Level
•Tape measure
•Pozi-drive screwdriver
•8mm Spanner
Begin with the base. This can be concrete or timber.
On clear and level ground build the OUTSIDE of the base to the required size.
This MUST be SQUARE and LEVEL.
Timber Base: Peg the timber frame to ground. Include extra bearers if using a
slat floor (as per the picture above).
Concrete base: Include a 750mm long step to sit directly underneath the door
guide as per the dimensions shown.
Note corner orientation
for timber frame
Timber Base
Concrete Base
Concrete step
2

F:\C - E\Christie Garden Products\Sheds\Shed 2355 x 2355 Junior Workshop\Shed 2355 x 2355 Junior Workshop Asse bly
Instructions Rev 2.docx
Starting in the left rear corner, place the Rear Wall and the Left Wall on the base,
with the corners overlapping.
Line up the holes in the corners of the two panels and bolt together. There are four
bolts per corner. Overlap the corners so that the panel edges are not visible from
the front of the shed.
Rear Wall
Wall inside face
Base
Front
Left Wall Right
Wall
Panel edge facing
away from front
Panel edge facing
away from front
Rear Wall
Left Wall
3

F:\C - E\Christie Garden Products\Sheds\Shed 2355 x 2355 Junior Workshop\Shed 2355 x 2355 Junior Workshop Asse bly
Instructions Rev 2.docx
Repeat the process for the Right Wall and then the Front.
Right
Wall
Rear Wall
4
Front

F:\C - E\Christie Garden Products\Sheds\Shed 2355 x 2355 Junior Workshop\Shed 2355 x 2355 Junior Workshop Asse bly
Instructions Rev 2.docx
Bolt the Ridge across the top of the Side Walls.
Place the six Roof Panels on the top, overlapping each panel and bolting them
together. Bolt the Roof Panels to the Ridge, Front Wall and Rear Wall of the
shed. Attach the Spouting as shown.
5

F:\C - E\Christie Garden Products\Sheds\Shed 2355 x 2355 Junior Workshop\Shed 2355 x 2355 Junior Workshop Asse bly
Instructions Rev 2.docx
Join the Left Flashing and Right Flashing with the Flashing Joiner in the centre.
Repeat to make the other Side Flashing. Fit the Side Flashings OVER the roof
panel, but INSIDE the Spouting. Bolt these through the Roof Panels and Side
Walls.
Ridge
Rear Wall
Roof Panel
Spouting
Roof
Panel
Drop bolts through holes in top first,
then tilt Spouting and tighten. Bolt
bottom afterwards
Bolt to
Ridge
6
Right
Flashing
Left Flashing
Flashing Joiner
6

F:\C - E\Christie Garden Products\Sheds\Shed 2355 x 2355 Junior Workshop\Shed 2355 x 2355 Junior Workshop Asse bly
Instructions Rev 2.docx
Flashing fits
OVER roof
panel Flashing fits
INSIDE
spouting
7

F:\C - E\Christie Garden Products\Sheds\Shed 2355 x 2355 Junior Workshop\Shed 2355 x 2355 Junior Workshop Asse bly
Instructions Rev 2.docx
Fold the fixing tabs on the Ridge Cover so they point straight down as shown.
Drop the tabs through the gap in the centre of the Ridge and push the end of the
Ridge Cover hard up against the side of the shed. Fold the tabs up inside the shed
to hold the Ridge Cover in place. Drill through the Ridge Cap and bolt to the
Ridge Cover.
Ridge Cover
Ridge Cover
Roof Panel
Fold tabs hard up
against bottom of
Ridge inside shed
Ridge
8
Ridge Cap
Drill through Ridge Cap
and Ridge Cover in two
places. Bolt Ridge Cap to
Ridge Cover

F:\C - E\Christie Garden Products\Sheds\Shed 2355 x 2355 Junior Workshop\Shed 2355 x 2355 Junior Workshop Asse bly
Instructions Rev 2.docx
Concrete Base:
Fix the walls to the base
with the bracket using
appropriate masonry
fasteners.
Timber Base: Hammer a piece of 50mm x 50mm timber to the timber frame
directly under the door opening to strengthen the door guide. Use at least three
self-drilling screws to drill through the top of the door guide into the 50mm x
50mm timber as shown.
Fixing
bracket
Base
50mm x 50mm timber Door guide
50mm x 50mm timber
Door
Self-drilling screw
Timber
frame
9

F:\C - E\Christie Garden Products\Sheds\Shed 2355 x 2355 Junior Workshop\Shed 2355 x 2355 Junior Workshop Asse bly
Instructions Rev 2.docx
Concrete Base: Drill three holes through the top of the Door Guide to expose the
concrete step. Use suitable masonry fasteners, such as dynabolts, to attach the
Door Guide to the Concrete Base.
Timber Base: Nail the shed to the timber base.
Door guide
Concrete Base
Door
Masonry fastener
Nail all panels to timber
10

F:\C - E\Christie Garden Products\Sheds\Shed 2355 x 2355 Junior Workshop\Shed 2355 x 2355 Junior Workshop Asse bly
Instructions Rev 2.docx
Timber Base on Existing Concrete Pad: Fix brackets to timber. Fix brackets to
existing concrete with suitable masonry fasteners.
Fix bracket
to timber
Fix
bracket to concrete
11

F:\C - E\Christie Garden Products\Sheds\Shed 2355 x 2355 Junior Workshop\Shed 2355 x 2355 Junior Workshop Asse bly
Instructions Rev 2.docx
Timber Base: Nail floor slats to the timber base.
Your Christie Shed is now complete and ready for years of service.
Full warranty terms and conditions available by visiting www.allans.co.nz
12
Front
VIEW FROM TOP
Floor slats sit this way
Right
Wall
Left
Wall
