Forest garden CSHSL66 User manual

Charlbury 6' x 6’ Summer House
Fixing Pack (OASUM66PTFP) Not to Scale
CSHSL66
REQUIRED TOOLS :
(NOT SUPPLIED)
POZI DRIVE SCREWDRIVER SPIRIT LEVEL
TAPE MEASURE
HAMMER
MUST PRE DRILL
Tower Bolt Qty 1
(supplied with 6 x 20mm screws)
Necked Barrel Bolt
Qty 1
Important :
Assembly of this
building requires
a minimum of two
adults.
SDR651X1645PT
Door Qty 1
B
SHARP KNIFE
FOR ROOFING FELT
3.5 x 30mm Screws Qty 1 (silver)
L’ bracket
Qty 2
Hinge
Qty 2
Felt Tacks Qty 100
ISSUE 0414
Panel Pin Qty 44
80121165PT
Barge Board Qty 4
SASUM66PSPT
Side Panel Qty 2
SASUM66DEPT
Door Panel Qty 1
EC
SUM66FL
Floor Qty 1
D
SASUM66PEPT
Plain End Qty 1
A
J
PW584404
584mm Glaze Qty 2
I
28120585PAII45PT 585mm Beading Qty 4
28120412PPT 28x12x412mm Beading Qty 2
P
Y
X
198510308
OSB Roof Qty 2
QU
F
45281728PPT
45x28x1728mm Batten Qty 1
FIN20010512PT
Finial Qty 2
K
L
M
40120736PPT
40x12x736mm Strip Qty 1
IMPORTANT, RETAIN FOR FUTURE REFERENCE.
-READ CAREFULLY
Check all parts prior to assembly.
This building is pressure treated to ensure longevity of all timber
components and to protect against rot. This may leave a colour
difference on some parts that will even out as the moisture content
stabilises. This will not need additional treatment.
- Timber is a natural material. It will shrink and swell as a result of
varying moisture content.
- Please keep all plastic bags and small parts away from children
- This product must be built on a solid level base.
- The roof of this building is not a load bearing structure.
Technical Help line: 0333 7777 089 8.30 am to 5.00 pm
Monday to Friday.
In line with your statutory rights, please check all parts prior to
assembly, as assembly of damaged parts may be deemed to be
acceptance and this may affect the remedies you are entitled to. If the
product is not constructed in accordance with the instructions, or is
altered in any way (e.g. painted), the manufacturer cannot be held liable
for any resulting damage.
FELT
85062
QTY 3
4.0 x 50mm Screws Qty 34
30mm Nail Qty 81
PW888465
888mm Glaze Qty 2
G
Beading
Turn Button
Qty 1
3.5 x 25mm Screws Qty 32 3.5 x 30mm Screws Qty 38
N
R
S
28280888PPT
28x28x888mm Batten Qty 4
28281985PPT
28x28x1985mm Batten Qty 2
2828904PAI70PT
28x28x904mm Angled Batten Qty 2
40121650PARPTR
40x12x1650mm Strip Qty 2
80121030PPT
80x12x1030mm Barge Board Qty 4
45151710PT
45x15x1710mm Corner Strip Qty 4
40121667PPT
40x12x1667mm Strip Qty 4
O28281728PPT
28x28x1728mm Angled Batten Qty 1
Parts List
H
40120466PNPT
466mm Notched Strip.
Qty 2
T
W
V
15120412PT 15x12x412mm Beading Qty 2
28120404PAII45PT 404mm Beading Qty 4
Forest Garden Ltd, Unit 288 Hartlebury Trading Estate, Hartlebury, Worcestershire, Dy10 4JB

24
B
3
AC
Make sure the panels are tight and sat on the floor correctly before fixing each panel to the floor
using 50mm screws. Make sure that the screws are in line with the floor bearers.
(A) = 3 x 50mm screws (B) = 2 x 50mm screws ( C) = 3 x 50mm screws
1
B
Position the four panels so that they sit on top of the floor as shown making sure that the
bottom board is overhanging the floor. Make sure that the panels are flush before fixing
them to each other using 3 x 50mm screws.
C
K
Fix the two L’ brackets to each end of the 1728mm batten, offset by 28mm, using 2 x 25mm
screws for each.
Place the batten so that it sits between the front and back panels. Make sure that it is tight
before fixing the L’ bracket to the vertical batten using another 2 x 25mm screws for each
end.
Position the Corner Strips so that they are tight and cover up where the panels join. Fix each
strip in place using 4 x 25mm screws.
Place the 1728mm batten against the front and above the entrance. Fix this in place using 4 x
50mm screws. Make sure that the screws are positioned in line with the vertical framing on the
reverse of the panel.
A
offset 28mm
O
B
R

8
6
Place the roof sheet on top of the three patterns shown. The two 2400mm battens
should be flush on the ends and one of them should be offset from the edge 20mm. Fix
the roof sheet to the batten using 10 x 30mm nails (spaced evenly).
Position the 2294mm batten between these spaced as shown and offset on each end
by 50mm. Fix using 9 x 30mm nails. (spaced evenly)
Repeat
ISSUE 0414
57
From inside the building place the two 1650mm Strips (P) on both sides of the door
entrance. Make sure that each strip sits tight and is flush with the framing on the inside.
Fix in place using 30mm nails.
Position the strips (S) and (T) to frame the entrance and fix using 30mm nails. Make sure
that each strip is flush with the framework and leaves a slight lip on the entrance side.
(P) = 5 x 30mm nails (S) = 5 x 30mm nails (T) = 3 x 30mm nails
Place the completed roof sections onto the building so that the angled batten is at the front and
the roof sheet lines up with the apex and eaves. Fix each roof section in place using 30mm
screws.
3 x 30mm screws (short side) 2 x 30mm screws (long side)
Repeat
P
S
(I) (II)
T
N
M
Place a roof sheet on top of the 904mm angled batten (N) and the 1985mm batten (M) as
shown. Batten (M) should be flush be in line with the long edge of the roof sheet and flush
at the ends. Secure it in place using 30mm nails spaced evenly.
Batten (N) should be level with the short end of the roof sheet and the tip of the angle in
line with the edge. (This will be the apex)
(N) = 4 x 30mm Nails (M) = 8 x 30mm Nails.
Nails spaced in
roughly 300mm
intervals
Nails spaced in
roughly 300mm
intervals
F
Angled end
Flush
Flush
G
L
XX
Place the 446mm notched pieces (U) into the bottom of the window openings so that they are
flush on all sides and fix each piece in place using 2 x 25mm screws.
Position a 888mm piece of glazing into the window frame before securing a 888mm batten to
each side with 2 x 50mm screws. Slot the 412mm piece of beading between the two battens at
the bottom 3 x panel pins to secure it..
U
(II)
(I)
Forest Garden Ltd, Unit 288 Hartlebury Trading Estate, Hartlebury, Worcestershire, Dy10 4JB

12
11
9
10
Place the barge boards against the ends of the roof so that they meet at the apex and are
flush on all sides. To secure each barge board in place use 3 x 30mm screws.
Place the finial at the top so that it overlaps the two barge boards and secure the finial in place
using 2 x25mm screws for each.
Eaves
ATTENTION:
TAKE CARE
WHEN TRIMMING
THE ROOF FELT.
Unroll the felt and place each section so that they overlap at the apex and overhang on the
eaves by approximately 50mm. Fix the felt to the roof using felt nails spaced in 150mm intervals
along the edges and the seam. Make sure that the felt nails are positioned so that they locate
into the batten on the eaves.
Cut and fold the corners securing with a single felt nail.
Y
V
I
H
W
Place the sheets in to the door so that each sheet sits on the rebated frame. Place each
piece of beading on top of the sheets makings sure that everything is flush. Fix the
beading in place using 4 x panel pins for each.
From the outside place the remaining beading against the bottom front of the glazing and fix in
place using 3 x panel pins for each.
Repeat
J

ISSUE 0414
13
Position the door into
the door frame and
make sure that the
larger part of the
hinge is sat tight
against the framing
before fixing each
hinge with 3 x 30mm
screws.
The door should be
positioned squarely
and open outwards
without obstruction.
14
From the inside
position the necked
barrel bolt against
top rail. Make sure
that the bolt will close
properly and hold the
door securely. Fix in
place using the
screws provided.
16
Fix a turn button to
the bottom of door
end just below the
door as shown. Make
sure it is positioned
so that it will hold the
door closed Use a
30mm screw. (silver)
Fix the large barrel
bolt across the top rail
making sure that the
bolt will hold the door
closed in its locked
position. Fix using the
screws provided.
15
E
Position two cranked hinges approximately 100mm from the top and bottom of the door frame.
Fix the smaller part of the hinge to the door using 2 x 30mm screws.
Repeat
Forest Garden Ltd, Unit 288 Hartlebury Trading Estate, Hartlebury, Worcestershire, Dy10 4JB

BASE FOOTPRINT
1758mm
1806mm
7ft 7ft
6ft
7ft
Maintenance.
- Regularly check all fixings and parts are secure.
- Visually check for wear and tear.
- Check your roof felt for tears and leaks.
Biocidal Product Regulation (EU 528/2012) Article 58 Information
This article contains timber treated with Celcure AC-500, incorporating biocidal products to give
protection against wood destroying insects & wood rotting fungi.
Contains: Basic copper carbonate (Copper (II) carbonate – Copper (II) hydroxide (1:1)), Boric acid,
Benzalkonium chloride.
Wear gloves when handling freshly treated wood. Avoid breathing dust when cutting treated or
untreated wood. Dispose of off-cuts responsibly – do not burn.
