Alldaq ADQ-42 User manual

ADQ-42/44/48 Rev. 1.0 ENXXXXX
1
ADQ-42/44/48 Manual
Rev. 1.0 EN
Programmable Electronic Load/Current Sink

ADQ-42/44/48 Rev. 1.0 ENXXXXX
2
Imprint
Manual ADQ-42/44/48
Rev. 1.0
Manufacturer and support
ALLNET® and ALLDAQ® are registered trademarks of ALLNET® GmbH Computersysteme. For ques-
tions, problems and product information please contact the manufacturer directly:
ALLNET®GmbH Computersysteme
Division ALLDAQ
Maistrasse 2
D-82110 Germering
Support
E-Mail: suppor[email protected]
Phone: +49 (0)89 894 222 – 474
Fax: +49 (0)89 894 222 – 33
Internet: www.alldaq.com/support
© Copyright 2020 ALLNET GmbH Computersysteme. All rights reserved.
All information contained in this manual has been compiled with the greatest care and to the best of
our knowledge. Nevertheless, errors cannot be completely ruled out. Specications and contents of
this manual are subject to change without notice.
We are always grateful for the notication of any errors.
Mentioned trademarks are registered trademarks of the respective companies.

ADQ-42/44/48 Rev. 1.0 ENXXXXX
3
Content
1. Introduction 4
1.1 Scope of delivery 4
1.2 Safety instructions 5
1.3 Installation and assembly site 6
1.4 Brief description 6
1.5 Control 6
2. Start of operation 7
2.1 Connection 7
3. Function groups 8
3.1 Block diagram 8
3.2 LED display status 8
3.3 Control options 9
3.3.1 ALLDAQ ADQ-LINK Bus 9
3.3.2 Integrated potentiometer 10
3.3.3 External control line 10
4. Pin assignments 11
4.1 Connector positions 11
4.2 Pin assignments 12
4.2.1 Würth 5-pin 12
4.2.2 Würth 2-pin 12
4.2.3 Würth 6-pin 12
4.2.4 MMCX 13
5. Annex 14
5.1 Specications 14
5.2 Manufacturer and support 16
5.3 Packaging ordinance 16
5.4 Recycling advice and RoHS conformity 16
5.5 CE identication 17
5.6 Warranty 17

ADQ-42/44/48 Rev. 1.0 ENXXXXX
4
1. Introduction
Please check the packaging and contents for damage and completeness before commissioning.
Should any defects occur, please inform us immediately.
• Does anything on the packaging indicate that anything was damaged during transport?
• Are there any signs of use on the device?
Under no circumstances may you operate the device if it is damaged. If in doubt, contact our technical
service department.
Please read this manual carefully before installing the appliance!
1.1 Scope of delivery
• ALLDAQ card of the ADQ-40 series incl. mating connector

ADQ-42/44/48 Rev. 1.0 ENXXXXX
5
1.2 Safety instructions
Be sure to observe the following instructions:
• Never expose the appliance to direct sunlight when operating.
• Never operate the appliance near heat sources.
• Protect the device from moisture, dust, liquids and vapours.
• Do not use the device in damp rooms and under no circumstances in potentially explosive areas.
• Repairs may only be carried out by trained, authorized personnel.
• Please observe the installation regulations and all relevant standards (including VDE standards)
when commissioning the instrument, especially when operating with voltages greater than 42 V.
• We recommend to always connect unused inputs to the corresponding reference ground to
avoid crosstalk between the input channels.
• Always disconnect your eld wiring from the voltage source before you make or break cable
connections to the card.
• When handling the card, make sure that no static discharge can occur through the device. Follow
standard ESD protection measures.
• Never connect the devices to live parts, especially not to mains voltage.
• Precautions to avoid unpredictable misuse must be taken by the user.
ALLNET® GmbH Computersysteme is not liable for improper use and resulting
damage.
Make sure that the unit is very well ventilated, as the cooler can be-
come as hot as 170°C at full load.

ADQ-42/44/48 Rev. 1.0 ENXXXXX
6
Introduction
1.3 Installation and assembly site
The ADQ-40 series is designed for industrial use. The board may only be used in dry rooms.
Ensure adequate ventilation. Make sure that the connection cables are securely attached.
1.5 Control
• ALLDAQ ADQ-LINK-BUS
• For control please use the ALLDAQ ADQ-SCU or ADQ-153.
1.4 Brief description
The programmable current sinks of the ADQ-40 series are suitable for use in industrial automation
and measurement technology. The board is supplied in a trough, which allows mounting on a DIN-
rail according to EN50022. Load programming can be implemented either by ADQ-LINK data bus, by
external analog control signal or by integrated potentiometer.
Depending on the version, 2, 4 or 8 potential-free sink channels are available.
Features:
• Potential-free sink channels (connectable in parallel)
• Isolating relay in main current path
• AUX paths (switchable base load 120Ohm) protected by polyfuse
• Individual temperature emergency shutdown per channel
• Voltage (Usense and Usense) up to 20.48V (opt. 40.96V)
• Max. 25W Continous (Usink x Isink <= 25W; max Isink = 5A)
• Max. 100W peak power (max 5sec.)
• Internal current measurement from Isink is measured via a 20mO Shunt
• MMCX connector for external measurement of Usink and Isink (over 20mOhm shunt)
• Channel-specic alert function for Usink, Isink and temperature shutdown per channel
• Fan output (12V/1A) controllable by software
• Heat sink temperature readable via software

ADQ-42/44/48 Rev. 1.0 ENXXXXX
7
Start of operation
2. Start of operation
2.1 Connection
The box should be handled with care to ensure that the device is not damaged by electrostatic
discharge (ESD), mechanical stress or excessive current surges. Precautions should also be taken to
avoid electric shock. Follow standard ESD protection measures.

ADQ-42/44/48 Rev. 1.0 ENXXXXX
8
Funktion groups
3.1 Block diagram
3.2 LED display status
• Green = 5V supply
• Blue = 12V supply
• Red = Relay status
3. Function groups
Timer and
control logic
EEPROM
Channels 0..7
Temperature
sensor
+ Sense
Adjusting resistor
-
+
+
+
- Sense
12V
5V
GND
ADQ-LINK
(via cable)
Fan
ADQ-4X
A
D
6
5
4
3
2
1
A
D
A
D
120R
120R
Temperature
emergency
shutdown
Settings group
Jumper
Potentiometer
Isink =
Setpoint setting

ADQ-42/44/48 Rev. 1.0 ENXXXXX
9
Funktion groups
3.3 Control options
When switching to a manual control option, make sure that the main relays are switched via jumper J1
before powering up or sinking the current. If this is not done, there is a risk of damageing the relays.
3.3.1 ALLDAQ ADQ-LINK Bus
Control via the ALLDAQ ADQ-LINK Bus is the recommended method of control for the ADQ-40 series.
To do this, use the ADQ-4X app from the ALLDAQ driver. In addition to this APP, control via an API
library is also possible. It allows full control over all functions of the ADQ-40 series.
To activate this option, jumper J1 must be in the left position and the channel jumper must be in the
lower position.
J1
Main jumper
Channel jumper

ADQ-42/44/48 Rev. 1.0 ENXXXXX
10
Funktion groups
3.3.2 Integrated potentiometer
With the analog control of the ADQ-40 series via the integrated potentiometers, the range of
functions is limited to the simple setting of a current. The temperature emergency stop is also active
to protect the hardware. All other functions cannot be operated in this control option.
To activate this option, the jumper J1 must be in the right position and the channel jumper in the
upper position.
3.3.3 External control line
With analog control of the ADQ-40 series via an external control line, the range of functions is limited
to the simple setting of a current. The temperature emergency shutdown remains active to protect
the hardware. It is also possible to measure the shunt voltage and the sense voltage via external
measuring devices. All other functions are not available in this control option.
The control voltage is in the range of 0V - 4.096V. The sense current results from the following cal-
culation:
Ucontrol = 2.048 + 0.00038*Sink (sink in mA)
To activate this option, jumper J1 must be in the right position and the channel jumper must be
removed.

ADQ-42/44/48 Rev. 1.0 ENXXXXX
11
Pin assignments
4. Pin assignments
4.1 Connector positions

ADQ-42/44/48 Rev. 1.0 ENXXXXX
12
Pin assignments
4.2 Pin assignments
4.2.1 Würth 5-pin
4.2.2 Würth 2-pin
4.2.3 Würth 6-pin
54321
ADQ-LINK GND 5V ADQ-LINK 12V
Pos ST8A / ST8B
1ADQ-LINK
2GND
35V
4ADQ-LINK
512V
Pos ST0 … ST7
1 Sense +
2 Sense -
3 IN_CH
4AUX 0
5AUX 1
6GND_CH
Pos ST9
1Fan 12V
2 Fan GND (switched)

ADQ-42/44/48 Rev. 1.0 ENXXXXX
13
Pin assignments
4.2.4 MMCX
Pos MMCX0 MMCX1 MMCX2
1 Shunt_CH - Sense_CH - GND_CH
2 Shunt_CH + Sense_CH + Ext_Analog_Control

ADQ-42/44/48 Rev. 1.0 ENXXXXX
14
Annex
5. Annex
5.1 Specications
Element Condition Specication
Channels 2, 4, or 8 potential-free current measu-
ring channels
Resolution/Sampling rate 16bit / 7kHz
Shunt-Type 20mΩ precision shunt
Isenke measuring ranges 0 mA – 4000mA (125uA - 1LSB)
Usense measuring ranges 0 V – 20.48V (625uV - 1 LSB)
Power rating constant load
max. 5 s after min. 10 s pause
25W
100W
Isolation voltage channel to PC ground
channel to channel
500 VDC / 500 VACeff (60 Hz)
500 VDC / 500 VACeff (60 Hz)
Total accuracy Isenke max. ±0.02% at full deection
Isenk as a function of the
Tcase temperature
(temperature drift)
2A < Isink < 4A
30º < tcase < 150º
tcase = temp. Mosfet
max. 0.6%
Input impedance Usense 3 MΩ
Ground reference (sink) Potential-separated channels (see pin
assignment)
Ground reference
(I2C interface)
GND of the control unit
Channel relays Quantity/Type 3 normally open relays (SPST)/ channel,
Type: Finder Series 34
Contact material silver/nickel
Switching time Response time max. 5 ms
Release time max. 3 ms
Switching cycles min. 10.000.000 (mechanical)
Switching current DC1 max. 6 A / 36 VDC, here max. 5 A due
to maximum current of power measu-
rement via INA226
Min. switching load 500mW (12V/10mA) must not be fallen
below, whereby at 24V a minimum cur-
rent of 21mA or at 10mA a minimum
voltage of 50V should be given

ADQ-42/44/48 Rev. 1.0 ENXXXXX
15
Annex
Temperature range Operation 0..70 °C (standard), extended
temperature range on request
Humidity Operation
Storage
20%..55%
(non-condensing)
20%..55%
(non-condensing)
-40..100 °C
Dimensions Top-hat rail according to
DIN EN50022
ADQ-42: 105x120x75mm (LxWxH)
ADQ-44: 175x120x75mm (LxWxH)
ADQ-48: 315x120x75mm (LxWxH)
Certications EC Directive 2004/108/EC,
Emission EN 55022,
Interference immunity EN 50082-2,
RoHS
Manufacturer warranty 36 months

ADQ-42/44/48 Rev. 1.0 ENXXXXX
16
Annex
5.2 Manufacturer and support
ALLNET® is a registered trademark of ALLNET® GmbH Computersysteme. For questions, problems
and for product information of all kinds please contact the manufacturer directly:
ALLNET® GmbH Computersysteme
Division ALLDAQ
Maistraße 2, D-82110 Germering
E-mail: support@alldaq.com
Phone: +49 (0)89 894 222 - 474
Fax: +49 (0)89 894 222 - 33
Internet: www.alldaq.com
5.3 Packaging ordinance
„Both manufacturers and distributors are basically obliged to ensure that sales packaging is taken
back from the nal consumer after use and is reused or recycled. (according to § 4 sentence 1 of the
Packaging ordinance). If you as a customer have problems with the disposal of packaging and shipping
materials, please write an e-mail to info@allnet.de.
5.4 Recycling advice and RoHS conformity
Please note that parts of the products of ALLNET® GmbH should be handed in at recycling centres or
may not be disposed of with household waste (printed circuit boards, power supply unit, etc.).
ALLNET® products are manufactured RoHs compliant (RoHS = Restriction of the use of
certain hazardous substances).

ADQ-42/44/48 Rev. 1.0 ENXXXXX
17
Annex
5.5 CE identication
The ADQ-SCU bears the CE marking.
This device meets the requirements of the EU Directive 2004/108/EC, Directive on Electromagnetic
Compatibility and Mutual Recognition of Conformity. Conformity with the above directive is conrmed
by the CE mark on the device.
5.6 Warranty
Within the warranty period, we will eliminate manufacturing and material defects free of charge. You
will nd the warranty conditions valid for your country on the homepage of your distributor. If you have
any questions or problems concerning the application, you can reach us during our normal opening
hours at the following telephone number +49 (0)89 894 222 - 474 or by e-mail to: support@alldaq.com.

ALLNET® GmbH Computersysteme
Division ALLDAQ
Maistrasse 2, D-82110 Germering
E-Mail: support@alldaq.com
Phone: +49 (0)89 894 222 – 474
Fax: +49 (0)89 894 222 – 33
Internet: www.alldaq.com
This manual suits for next models
2
Table of contents
Popular Industrial Electrical manuals by other brands

Hellermann Tyton
Hellermann Tyton Autotool 2000 CPK operating instructions

Promax
Promax Prolite-41 Quick reference guide

Itec
Itec POWERMIX 6/3 DIGITAL user manual

Hitachi
Hitachi E-102SN installation manual

Murata
Murata GRM0225C1E7R3WA03 Series Reference sheet

Murata
Murata GRM188R71C474KA88 Series Reference sheet
