QUICKSTART GUIDE
RDMS 202 and RDMS 202D
Quick Start Guide
Thank you for purchasing a RDMS 202 or RDMS 202D. The Allegro RDMS 202
and RDMS 202D are DLNA Certified® Digital Media Servers (DMS) that fully
comply with the DLNA Networked Device Interoperability Guidelines Expanded
(Version 1.5). Specifically targeted for use by DLNA Independent Certification
Vendors (ICVs) and Consumer Electronics (CE) manufacturers creating DLNA
enabled products, the RDMS 202 and RDMS 202D are ideal for validating
interoperability with a fully function DMS within the DLNA 3 box model. The
RDMS 202 and RDMS 202D are extremely configurable via a browser interface
with many options including support for Upload, DIDL_S and DIDL_V containers,
and link protection (RDMS 202D only). The RDMS 202D is available to DLNA
Member companies that also have a valid DTLA license agreement.
Service and Support
Should you encounter a problem with your RDMS 202 or RDMS 202D, technical
support can be obtained via the Allegro website. Please complete a Technical
Support Request and our support staff will be in touch to help resolve your support
issue.
www.allegrosoft.com/support_req.html
Getting to Know the RDMS 202
The RDMS 202 and RDMS 202D units are delivered with the following items in the
box:
• RDMS 202 or RDMS 202D Digital Media Server
• RDMS 202/202D Quick Start Guide
• Ethernet Cable
• Power Cable and wall adapter plug
• Allegro PQI USB Memory stick with DLNA Certification Content
Allegro recommends making a backup of the pre-loaded content on the USB
drive. The USB drive is provisioned with DLNA Certification content and then
write protected at the factory. Before content can be added to or deleted from
the USB drive the wirte protect switch must be moved to the unlocked position.
RDMSQuickstartv4.indd1 9/17/201012:19:01PM

Connecting the RDMS 202 or RDMS 202D
1. Connect one end of the included networking cable to the RDMS 202 or RDMS
202D. Connect the other end to your router.
2. Connect the power cord to the RDMS 202 or RDMS 202D if not using the wall
mount plug adapter. Plug the other end of the power cable or plug the entire
unit if using the wall plug adapter into an AC outlet (110-240 Volts 50-60 Hz).
Communicating with the RDMS 202 or RDMS 202D
After ~10 seconds the RDMS 202 or RDMS 202D will appear in “My Network” as
a UPnP Basic Device. Right click on the icon and select “View device webpage”.
This will cause the device Presentation webpage to appear in your browser.
RDMS 202 or RDMS202D Operation
With the Presentation page showing in a browser, the user can select a variety of
Preferences, determine the Status of the unit, browse and delete Content, and Add
Content to the unit.
For detailed discussions regarding the operation of the RDMS 202 or RDMS 202D
please refer to the included manual or download the manual from the Allegro
website.
www.allegrosoft.com/rdms202.html
DLNA®
Network
Wireless Router
M-NCF
Network access
and routing
Laptop
Ethernet
RDMS 202
Camera
M-DMU
Upload photos
HDTV
DMP
Find and Play a
media stream
Amplifier
DMR
Render sound
