Allied Vision Technologies Alvium Series User manual

V1.1.0
Allied Vision Technologies GmbH // Taschenweg 2a, 07646 Stadtroda / Germany 2019-Jul-01
USB CAMERAS
Alvium USB Cameras
User Guide

Alvium USB cameras at a glance
2Alvium USB Cameras User Guide V1.1.0
Alvium USB cameras at a glance
Shipping contents
• Alvium USB camera
• Alvium USB Cameras Quickstart Guide document
What else do you need?
This is a selection of helpful document and software downloads:
Read this document carefully
Learn to avoid damage to your Alvium USB camera and use it in the most safe and
efficient way.
Document Link
Alvium USB Cameras Quickstart Guide (multilingual)
https://www.alliedvision.com/en/support/
technical-documentation/
alvium-documentation.html
Alvium Cameras Accessory Guide
Alvium Cameras Features Reference
Optimum Heat Dissipation for Housed Alvium Cameras
application note
Electromagnetic Compatibility for Open Housing Alvium
Cameras application note
Avoiding Ground Loops in Vision Systems application note
Software Link
Vimba Suite for Windows, Linux, and Linux/Arm,
including Vimba SDK, Vimba Viewer, and Vimba Driver
Installer for Windows
https://www.alliedvision.com/software

Contact us
3Alvium USB Cameras User Guide V1.1.0
Contact us
Connect with Allied Vision by function
https://www.alliedvision.com/en/meta-header/contact
Find an Allied Vision office or distributor
https://www.alliedvision.com/en/about-us/where-we-are
Email
[email protected]
[e-mail]
Sales offices
Europe, Middle East, and Africa: [phone]
North, Central, and South America: +1 877 USA-1394
Asia-Pacific: [phone]
China: [phone]
Headquarters
Allied Vision Technologies GmbH
Taschenweg 2a
07646 Stadtroda
Germany
Tel: [phone]
Fax: [phone]
CEO/Geschäftsführer: Andreas Gerk
Registration Office: AG Jena HRB 208962
Tax ID: DE 184383113
