Allview VISUAL360 User manual

1
VISUAL360
User manual ......................... 4
Instrukcja obsługi……….... 25
Manual de utilizare ............. 47
EN
PL
RO

2

3
EN
LCD display
Power button
/Mode button
Wi-Fi indicator (red)
Power indicator（red
/Charging indicator (blue)
Wi-Fi button/MENU button
Busy indicator (red)
Shutter button
/OK button
Lens×2
Triangle nut
Interface cover (USB/TF)
Speaker
Microphone
Rope hole
Reset hole
1
2
3
4
5
6
7
8
9
10
11
12
13
14
PL
Wyświetlacz LCD
Przycisk zasilania
/zmiany trybu
Wskaźnik Wi-Fi (czerwony)
Wskaźnik zasilania
/ładowania (niebieski)
Przycisk Wi-Fi/MENU
Przetwarzanie (czerwony)
Spust Migawki
/przycisk OK
Soczewka ×2
Miejsce mocowania statywu
Osłona interfejsu (USB/TF)
Głośnik
Mikrofon
Otwór na sznurek
Przycisk resetowania
RO
Afișaj LCD
Buton pornire
/oprire
Indicator Wi-Fi (roșu)
Indicator nivel baterie (rosu)
/ Indicator încărcare (albastru)
Buton Wi-Fi//Meniu principal
Procesare în curs (roșu)
Butonul Declanşare
/OK
Lentile×2
Lăcaș înșurubare trepied
Capac interfață (USB/TF)
Difuzor
Microfon
Gaură șnur
Orificiu resetare dispozitiv
En

4
Overview
Thank you for purchasing this product!
VISUAL360 is adigital panoramic camerawith two lenses. Through the application of up-
to-date technologies, it enables you to get panoramic videos and photos, creating an
experience of brand new panoramic world.
Important
Before using this product, please carefully read this Manual
The product comes without internal memory,therefore, you need to have prepared
aMicroSDcard up to 32GB(Class 6~Class 10);
Check thecamera power. A full charging is recommended beforeuse (Until the
charging indicator goes out)
Scan the QR Code on nextpage, or search for “VISUAL360” on Google Play™,
and then download and install it
The product is equipped with abuilt-in battery. Do not put it directly into fire, or it
may cause explosion or other dangers.
The product may radiate heat due to long-time use or exposure to direct sunlight.
This is normal.
Ifthecamera stopsworking or fails to respond to any operation during use, use a
needle to press and hold Reset button for about 3 seconds to restarttheproduct.
Do not use the camera under any environment with temperaturelower than 0°Cor
En

5
higher than 40°C;or else it may not turn on normally.
The provider recommends theusage of acharger with thevoltage between 5V/0.5A
~ 5V/2.0A.
Do not use thecamera in humid place, for thehumidity may damage important parts
of thecamera.
Do not put thecameradirectly into water.
Do not use thecamera during charging, for it may cause system halt or other failure
due to improper heat radiation.
Do not contact thelens with hardarticles to avoid any damage.
Notices for the use of device
CAUTION! Please read carefully this instructions and follow them, in the case of dangerous
situations.
Driving safety: It is recommended notto use the device while driving.
Approved service: Only approved repair shopscan repair this device. Ifyou open the
device and try to fix it yourself you will void thewarranty of theproduct.
Accesories and batteries: Only accesories and batteries approved by the producer can be
used.
The battery and charging thebattery: Itis recommended to fully charge before first use of
thedevice. Do not expose the battery to temperatures above 40ºC. Do not dispose the
battery in fire or drop anywhere. Return defective batteries in special centersor to the
supplier center.
Warning: We take no responsibility for situations where thedevice is used other than as
En

6
Our company reserves theright to make changes in thecontent of themanual without
making this public. These changes will be posted on the company website to theproduct
it amends.
The contents of this manual may be different from that in theproduct. In this last case will
be considered.
To avoid the problems that mightoccur with theservice shopsapproved by Visual Fan
Ltd. (because Visual Fan reserves therightto stop thecollaboration with anyservice shop
which was previously approved and mentioned in thewaranty card on thedate on which
theproduct batch was sold on the market), before taking aproduct to the service shop,
please check theupdated list of approved service shopson Allview website at the section:
“Support&Service – Approved service”.
For more product details visit www.allviewmobile.com.
All applications provided by third parties and installed in this device, may be modified
and/or stopped at any moment. Visual Fan Ltd will not be responsible in any way for
modifications of theservices or content of these applications. Any request or question
regarding third party applications may be addressed to owners of these applications.
En

7
Quick start guide
1. Install SD card:
InserttheMicroSDcard you prepareinto the slot as
indicated, as shown on the right.
Important:
A high-speed MicroSDcard between Class 6~Class 10 is amust; or else, this
product may not work normally.
Always turn off thecamera beforeinserting or pulling out of thecard.
2. Power-on/off
Power-on: Press and hold Power button/Mode button for about 2 seconds and release,
until it beeps. The display screen will be lighted, as shown below, indicating theproduct
is ready to work (thedefault work mode after power-on is Shooting mode).
Micro
SD
En

8
Important:
Ifpower-on fails, charge thecamera first, and see whether theblue indicator lights
up during charging.If yes, it indicates theproduct is being charged.
Power-off: After shooting stops, press and hold Power button for about 3 seconds and
release. TheDisplay will display “GOODBYE” and turns off. No operation on mainframe
for 1 minutes under Power-save mode (default), thecamera will automatically power off.
Ifyou simply wish to shut down thedevice, press and hold 3 seconds the Power
button/Mode button. Themessage “GOODBYE” will be displayed and afterwards, the
device will shut down.
3. Charging
Use data cable included in theproduct pack for cameracharging. During charging, the
indicator displays in blue and lights constantly; when charging completed, the blue
indicator goes out.
Important:
The provider recommends theusage of acharger with thevoltage between 5V/0.5A
~ 5V/2.0A.
En

9
4. Recording or shooting
This camera has Recordingmode and Shooting mode. After power-on, press MODE
(Power button/Mode button) to switch between different modes, and thecorresponding
mode icon will be displayed on thescreen.
Video:InRecording mode, press Shutter button, and thecamera
get started to work. Thedisplay screen displays thevideo
recording timing.
Stop recording: During recording, press Shutter button tostop it.
The video will automatically be saved on yourcamerastorage
card. Atthat moment, thedisplay screen will show remaining time
available for recording as below:
Shooting:InShooting mode, press Shooting button to take photos.
After shooting, thedisplay screen will display thenumber
(estimated value) of pictures theavailable space on you camera
storage cardcan save.
En

10
5. Menu setting
To operate Menu, press and hold Wi-Fi button for about 2 seconds to enter menu setting
(as shown below):
Menu operation:
InMenu mode, press Wi-Fi button to move cursor.
Press Shutter button to confirm.
Press and hold Wi-Fi button to back to previous menu or exit Menu mode.
Explanation of menu functions:
Power Save: Set Power-save mode. You may set the camera to enter Power-save
mode after acertain period of time. The available options are1min/3min/5min or Power-
save mode off.
Date & Time: Set system time for thecamera manually.
Language: Set system language forhthecamera, with Romanian as its default language.
Factory Reset: Restore factory default settings.
System: Check system and storage card information.
Format: After formatting, all existing data on thestorage card will be lost due to such
formatting. Please be cautious to this operation!
En

11
6. How to use accessories properly
Itis strongly recommended to use theaccessories originally provided by the
manufacturer. Ithelpscreate abetter product use experience and better
shooting/recording effect.
Tripod: Screw the tripod nut attached into the screw hole on thebottom of thecamera. It
serves both as ahand-held or fixed device.
Fix to use tripod Hold to use tripod
En

12
7. Use of watch remoter (optional accesory)
1. Power button
2. Shooting button
3. Recording button
Activating the remote: First activate the Wi-Fi of the
camera, then long
press thePower button to connect theremote to thecamera.
To deactivate theremote, you need to long press on thePower button.
Shooting button: Inorder to capture frames using the remote, press the
Shooting button
Recording button: To be able to created videoclipsusing the remote, short
press on button 3 fromtheimage above
Play panoramic video or picture
Note: Thevideos or pictures may be played in rightpanoramic effect only on smart
mobile phone, panel computer or PCprocedures.
En

13
1. Use mobile phone or panel computer to play
Follow these steps to play panoramic videos or pictures on mobile phone or tablet.
Download APP: Scan QR Code from below or search for
“VISUAL360” on Google Play™ to download and install the
product APP.
QR Code:
Please scan this QR Code toget access to Google Play to
download and install
“VISUAL360”
Install
En

14
Connect mobile phone and camera: Connect mobile phone and camera through Wi-Fi
connection
i. Turn on camera Wi-Fi: Press camera Wi-Fi button, and thedisplay screen will display
“WI-FI ON”,and then “VISUAL360”,and initial password is “1234567890”.
ii. Turn on mobile phone Wi-Fi, search for “VISUAL360” and
select Connect.
iii. If connected, thecameradisplay screen will display as
below picture.
Wi-Fi name
Wi-Fi name
Wi-Fi name
En

15
Opening app: Activate “VISUAL360” APP on mobile phone or tablet, and click theupper
right corner to“Search for Camera”.
Download: Enter camera folder, select thefile to be downloaded and click to download.
Play: Select thefile on mobile phone and click to play.
VISUAL360
2016-07-15
2016-07-15
En

16
Important
The video recordings/photographscreated with VISUAL360 will be
automatically saved, by default, on themicro SDmemory card. Inorder to save
them on aphone/tablet, you need to download them from themicro SDcard.
They will be automatically saved on the following path: File manager – DCIM–
VISUAL360. You can move afterwards thefiles wherever you would choose.
Itis recommended to follow theabove stepsin order to achieve thebest HD
video orpictureplaying effect.
Before connection, remember to make surethe SDcard properly inserted into
camera.
Do not use the player of mobile phone or panel computer to play videos or
pictures taken by this camera, or else theeffect will be like this:
En

17
Effect of panoramic playing
The following effects areavailable if played on APP player
Planet mode
Panoramic mode
VR mode
En
17

18
2. Use PC or notebook to play
You may use your PCto acquireabetter playing experience, or edit/sharevideos.Itcan
be completed by following thestepsas shown below:
Download and install player: Open PCbrowser and visit
www.allviewmobile.com/VISUAL360/app to download and install “VISUAL360 video
converter”.
Download video or picture onto PC:
Use theUSBdata cable attached to this product to connect thecamera and PC.
After connection, thecameradisplay screen will display “MSDC”.
Open “My computer” to select “VIDEO” OR “JPG” folder under “Removable disks”.
Select file to be downloaded and download it into location specified on PC.
En
18

19
Run player: Open thevideo or picture downloaded and stored on PCin the player.
Click theicon ,choose thevideo which you want to play.
En

20
Whenplaying thevideo, move themouse to top rightcone, it will show some different
mode(Plane/Planet/Invert). Clip it and will show different effects. Please clip and move
themouse, you could enjoy the video with full angle 360 degree.
En
