NC377 Paging Interface Adapter
Installation & Operating Instructions
IL871
Section E
Rev.4 -06/2011
Contents
Chapter 1—Introduction..................................................... 1
About This Manual .........................................................1
Theory of Operation ........................................................2
What's in the Box ............................................................2
Features ...........................................................................2
Chapter 2—Installation ...................................................... 3
Mounting & Cable Routing .............................................3
Nurce Call Wire Connections ..........................................3
Power Up Sequence.........................................................3
Chapter 3—Programming Plan ..........................................3
Chapter 4—Programming.................................................. 4
Default User Name & Password ......................................4
LoggingOn,LoadingProgramming Screen .....................4
GlobalSettings Programming ..........................................4
Contact Input Programming.............................................6
Print Database Button .....................................................7
Finishing Up ....................................................................7
Chapter 5—Reporting ........................................................ 8
Log On.............................................................................8
Report Types ...................................................................8
Appendix ........................................................................... 10
Changing a PC’s IP Subnet............................................10
Changing the NC377’s User Name & Password ............10
SD Card Use ..................................................................10
Cables ............................................................................10
Troubleshooting............................................................11
ComPPageLicenseAgreement ......................................11
A Word about ESD (Electrostatic Discharge) ................. 12
Illustrations
Figure1—NC377/32 PagingInterfaceAdapter ................1
Figure2—NC377 CableRouting......................................2
Figure 3—Nurse CallLamp Select Line Wiring ................2
Figure4—Port NameDrawing, Front ..............................2
Figure5—NC377 ProgrammingWelcome Screen ............5
Figure6—NC377 ProgrammingLog-On Screen...............5
Figure7—Global SettingsProgramming Screen ..............5
Figure 8—Contact Input Programming Screen ................6
Figure 9—Assigning Shift & Escalation Pagers..............7
Figure 10—Report Options Screen..................................8
Figure11—ReportExamples ............................................9
Figure 12—SD Card Maintenance .................................10
Figure13—8P8C CableTerminations ............................11
Chapter1—Introduction
The NC377 Paging Interface Adapter is used with TekTone®
NC110, NC150 and NC200 hard-wired nurse call systems to
add radio pocket paging. The interface is connected between
the nurse call system and the radio pocket pager transmitter.
The NC377 Paging InterfaceAdapter detects calls, determines
priority, and then sends information to the NC369 Paging
Transmitter. Program call points so that calls are sent to the
appropriatepager.Information sentincludes calltype androom
number. The pager stamps the time and date.
About This Manual
This manual is designed to assist with installation of this
TekTone®product. Each component of the system is described
withstep-by-step instructionsto facilitatehardware installation
and software configuration.
1. Important: Please take all precautions against high
voltage shock.
2. UseanESDwriststrapwhenworkingwiththeSDor
Contact Input Cards.
3. RemovepowerfromtheunitbeforeSDorinputcard
removalorreplacement,andforwireinstallation.
Figure 1—NC377/32 Paging Interface Adapter

Page2•IL871NC377PagingInterfaceAdapterManual Copyright©TekToneSound &Signal Mfg., Inc.AllRightsReserved.
1. Important: Please use proper splicing techniques.
There will be many splices made to install this unit.
2. Verify proper polarity of input wires (should be +).
3. Use protective eye wear when clipping leads.
Theory of Operation
TekTone®NC110,NC150and NC200nursecall systemsutilize
a lamp select line (wire) to indicate a call on the system. When
idle, these lamp select wires show a +24VDC potential, and
when a call is placed they show a voltage drop of at least
12VDC. This drop, and whether it remains low or pulses, is
used by the interface to determine the call type and priority.
The unit will indicate whether it is a routine level call or a
prioritycall.
Figure4—PortName Drawing, Front
Figure2—NC377CableRouting Figure 3—Nurse Call Lamp Select Line Wiring
What’s in the Box
• NC377-series Paging Interface Adapter (see Figure 1).
• Mounting hardware.
• CA377gray crossover cable with 8P8C connectors.
• CA132 red patch cable with 8P8C connectors (used to
connect slave to slave).
Features
• Programmingviawebbrowser.
• Programmableoutput protocol.
• Programmable up to 3 shifts.
• GlobalPagerID;twoavailable.
• System Health Check and Time Period (2, 5, 15 minutes;
1 or 2 hours).
• 576 total contact inputs.
• Storage:Logallalarmscreated.Alllogsstoredinfilesof24
hours.
• Reports: Database, by Room, Type of Call, and Elapsed
Time.
• Approvals: FCC part15, UL®1069, CSA and RoHS
compliant.

IL871NC377PagingInterfaceAdapterManual• Page 3
Copyright© TekToneSound &SignalMfg., Inc.AllRightsReserved.
Chapter3—Programming Plan
This section outlines the overall programming plan. Refer to
Chapter 4—Programming for step-by-step programming
instructions. (Note: The terms zone and input are used
interchangeablyinthismanual and onthe programmingscreens.)
Before use, perform Global Settings Programming on each
NC377. The NC377 Paging InterfaceAdapter may be ordered
with either 32 or 64 points. Configure each NC377 as either a
master or a slave. There must always be one master, but there
may be up to eight slaves.
1. Each NC377 Paging Interface Adapter will be connected
separately for the global settings programming. After pro-
gramming, they will be connected together for system
operation.
2. The gray crossover cable is used to connect the PC/laptop
totheNC377forprogramming.
3. IfmultipleNC377swillbeconnectedtogether,programthe
slaves first. Only these four fields are programmed on the
slave units:
• Host System (TekTone®)
• UnitID:Slave
• Slave #
• TotalNumber of Contacts(32or 64)
4. LabeleachNC377withitsSlave#orastheMastersoitcan
be identified in the future.
5. Program the master NC377 after all slaves have been pro-
grammed.Contactinputprogrammingisperformedonlyon
themasterNC377.
6. Select TekTone®as the host system on both masters and
slaves.
7. EachNC377hasamaximumcapacityof64inputs,withatotal
576 when all 8 slaves are connected. The contact numbers
run in sequence:
Master 1–64
Slave1 65–128
Slave2 129–192
Slave3 193–256
Slave4 257–320
Slave5 321–384
Slave6 385–448
Slave7 449–512
Slave8 513–576
If an NC377 has fewer than 64 inputs connected, program
only the inputs that are connected. The contacts can be
connectedin anyorder, i.e.1–16 or32–48.
After global settings programming is complete, perform
Contact Input Programming on the master NC377 to program
the inputs being used.
Chapter2—Installation
Mounting & Cable Routing
Verifythat power tothe unitisdisconnectedbefore proceeding.
Please follow these steps. (Note: The terms zone and input are
used interchangeably in this manual and on the programming
screens.)
1. Remove thefour Phillips-headscrews located ontop ofthe
NC377PagingInterfaceAdapter.
2. Remove the top cover and set aside.
3. Using the hardware supplied, mount the NC377.
4. Ifthecableyouareusinghasbundledwires,striptheoutside
covering back 24 inches.
5. LoopthecableinaUshapeandattachittotheNC377using
the tie-wraps provided. (See Figure 2.)
6. Route thewires throughthe accessholes onthe backof the
unit.
7. With thefrontofthe unitfacing you,inputs 1–32are onthe
left and 33–64 are on the right. (See Figure 3.)
8. Route your cables so that they do not cross over the board
inside the NC377 Paging Interface Adapter.
Nurse Call Wire Connections
Referring to Figure 3, route and connect the individual lamp
select wires.
1. If all the inputs have a common ground, it is not necessary
to attach individual grounds to each input on the terminal
block.Simplyattachthecommongroundtoterminalnumber
2(–) and place an internal jumper on the other terminals
(negativeterminals2,4,6,8,etc.).
2. AttachthefirstLampSelectWire(positivewire)toterminal
1(+).
3. Continue until all inputs are connected.
4. Replace the top cover and the four Phillips-head screws.
Power Up Sequence
Referring to Figure 4 and the following steps, connect all the
required cables.
1. Connect the power lead to the rear of the unit, and apply
power.
2. On the front panel, turn on the power switch. The green
powerLEDindicatorwilllight.
4. Connect the RS232 serial cable from the NC377 Paging
Interface Adapter to the paging transmitter’s input. (The
RS232cableisprovidedwiththepagingtransmitter.Tobuild
a longer cable or a new cable, see the paging transmitter’s
manual.)
5. Apply power to the paging transmitter.
6. The NC377is nowready tobe programmed.

Page4•IL871NC377PagingInterfaceAdapterManual Copyright©TekToneSound &Signal Mfg., Inc.AllRightsReserved.
Chapter4—Programming
Default User Name & Password
The NC377 is shipped with the following default user name
and password:
UserName: comppage
Password: pia3264
TekTone®suggests you keep these defaults. (See Changing
the NC377’s User Name & Password in the Appendix to
change the user name and password.)
Logging On, Loading Programming Screen
1. ForthePCtocommunicatewiththeNC377PagingInterface
Adapter,theymustbothbeonthe192.168.1.____IPsubnet.
TekTone®suggestsusing192.168.1.235.Temporarilychange
the IP address of your PC or laptop. (See Changing a PC’s
IP Subnet in the Appendix for instructions.)
2. Connect the PC/laptop to the NC377 using the gray cross-
over cable.
3. Apply power to the NC377 Paging Interface Adapter and
turniton;thegreenpowerlightwilllight.TheNC377willbe
operational approximately 40 seconds after power up.
4. Openabrowser,suchasInternetExplorer,onthePC/laptop.
5. LocatetheNC377PagingInterfaceAdapter’sIPaddresson
the label attached to its main circuit board.
Inthebrowser’s addressline,type the IPaddress,followed
by /default.zhtml in lower case letters. (For example,
192.168.1.239/default.zhtml)
6. The Welcome screen will appear (see Figure 5). Click on
ConfigurationSettings.
7. The Logon screen will appear (see Figure 6). Enter the
default user name and password:
UserName: comppage
Password: pia3264
8. ClickOK.
9. The Global Settings screen will appear (seeFigure 7).
Global Settings Programming
Referring to the Figure 7, while logged on to the interface,
configure the following:
DateandTime—(MasterNC377only.)TheNC377hasanRTC
(realtimeclock).Settheclocktothecurrenttimesoalllogs
and reports will reflect the correct date and time.
• Type the date in mm/dd/yyyy format, including slash
marks(09/01/2009).
• TheNC377usesa24-hourclock.Enteralldigits,includ-
ingcolons,inhh:mm:ssformat(12:15:00).
IPAddress—(Donotchange.)The addressofthis NC377.
Host System—Select TekTone as the Host Nurse Call System
youwillconnecttothisunit.Theprogramwillautomatically
set the correct sample rate for the Slow and Fast pulse rate.
Unit ID—Select the type of unit to be programmed. Each unit
must be identified as a Master, or as Slave1–Slave8.
• Master
• Slave 0 (no slaves), or
• Slave1–Slave8
NumberofSlaves—(MasterNC377only.)Selectthenumber
of slaves (0–8) that will be attached to the master.
Master/Slave Port Setup—(Do not change unless you are
directed to by TekTone®Technical Support.) This setting
controls the data speed on the RS485 bus. It is factory set.
Protocol—(MasterNC377only.)SelectScopewhenusingthe
TekTone®NC369PagingTransmitter.
DataType—(MasterNC377only.)SelectAlphanumeric.
BaudRate—(MasterNC377only.)Select512.
DevicetoTransmitterPortSetup—(MasterNC377only.)This
setting must match the port settings of the paging encoder
installed.Select9600-N-8-1fortheTekTone®NC369Paging
Transmitter.
Total Number of Contacts—Select the number of inputs that
areinstalledintheNC377beingprogrammed(32or64).
MonitoringPagers—(MasterNC377only.)Allalarmnotifica-
tionswillbesenttotheMonitoringPagers(inadditiontothe
Pager IDs assigned to specific alarms in contact input
programming).Enter Pager ID and Alert type (A, B or C).
Use this formula to convert the pager’s CAP code to its
correspondingPagerID(addleadingzerostomake7digits):
PagerID=[(pager’sCAPcode×8)+10000].
SystemOKCheck—(Master NC377only.) Select a pager ID
and time interval for the system to transmit a System OK
check-in message. Enter Pager ID, Alert Type and Time
Interval. (After the screen has refreshed, the Pager ID’s
leading zeros will not display; this is normal.)

IL871NC377PagingInterfaceAdapterManual• Page 5
Copyright© TekToneSound &SignalMfg., Inc.AllRightsReserved.
Shift Schedule—(Master NC377 only.) This option enables
automatic shift change paging.
1. Check theShift Schedulebox.
2. TypethestartandendtimesofShift1,forexample07:30
to15:30.
3. Continue forShift 2and Shift3.Theendand starttimes
of shifts will overlap. Any call activated within one
minuteof theoverlap willbesent tobothshifts’ pagers.
4. If Shift 3 does not complete the 24-hour period, the
unusedtimeallocatedtoShift3,andanypageduringthat
time will be sent to Shift 3 pagers.
Save Database—After selecting all the Global Settings, click
SaveDatabasetosavetheprogrammingtomemory.Changes
are not effective until they are saved to the database.
Figure7—GlobalSettings ProgrammingScreen
Figure 6—NC377 Programming Log-On Screen
Figure 5—NC377 Programming Welcome Screen

Page6•IL871NC377PagingInterfaceAdapterManual Copyright©TekToneSound &Signal Mfg., Inc.AllRightsReserved.
Contact Input Programming
Click on the Contact Settings button at the bottom of the
Global Settings programming screen. The screen shown in
Figure 8 will appear.
Contact inputs must be programmed in order to respond
properly. The master NC377 knows which contacts are on the
slave and which are on the master.
Example: a master with 64 inputs, and 1 attached slave with 16
inputs used. Using the Contact Input programming screen,
programthe first64 contactswiththe informationfor theinputs
connected to the master. Program the next 16 contacts (65–80)
with the information for the inputs connected to the slave.
Programming Contacts for Elapsed Time Reports
If Elapsed Time reports are required, use the room number
and bed identifier as part of the Active, Reset, Pulse 1 and
Pulse 2 messages. The system will compare the time the
input was activated to the time it was reset. It must have
somemethod todetermineone inputfrom another.Since the
room number and bed identifier will not always be the same
as the zone/input number, TekTone®recommends including
the room number and bed identifier in all message types.
Programming Contact Inputs
Start with Zone (input) # 1. Include room number and bed
identifier in all four message types (marked *).
InputAlertType—SelectVoltageAlert-Low.
Room #—Select (1–9999), if applicable. If the nurse call
system uses bed identifiers, also select that (A–E).
ActiveMessage*—Thismessageissenttothepagerwhenthe
zone/inputisactivated.(Example:Room0123A Routine.)
ResetMessage*—This message is sent to the pager when
the zone/input is reset. (Example: Room 1234B Reset,
Room 1234B Cancelled, or Room 1234B Cleared.)
SlowPulsing&FastPulsing—Youmustcheckoneorboth
of these so that the correct message will be sent to the
pager when a slow or fast pulse is detected.
Pulse1Message*—Thismessageissenttothepagerwhen
Pulse1(slowpulse)isactivated.(Example:Room2345C
Emergency.) You must also check Slow Pulsing.
Pulse2Message*—Thismessageissenttothepagerwhen
Pulse2(fastpulse)isactivated.(Example:Room3456D
Smoke Detector.) You must also check Fast Pulsing.
Figure 8—Contact Input Programming Screen

IL871NC377PagingInterfaceAdapterManual• Page 7
Copyright© TekToneSound &SignalMfg., Inc.AllRightsReserved.
Shift 1, Shift 2 and Shift 3 Pagers (Figure 9)
Enter a Pager ID for each of the message types and
shifts being used. Each shift has three Pager IDs:
• The Active message is sent to the first Pager ID.
• The Pulse 1 (slow pulse) message is sent to the
second(middle)PagerID.
• The Pulse 2 (fast pulse) message is sent to the third
PagerID.
The Shift Schedule checkbox in the Global Settings
screen determines which shifts must have Pager IDs
assigned:
• Ifyouchecked ShiftSchedule inthe GlobalSettings
screen, fill in Shift 1, Shift 2 and Shift 3 Pagers.
• If you did not check Shift Schedule in the Global
Settings screen, fill in Shift 1 Pager.
Use this formula to convert the pager’s CAP code to its
corresponding Pager ID (add leading zeros to make 7
digits): PagerID =[(pager’s CAPcode ×8)+10000]
If a shift’s message type is not being used, enter 7 zeros
as its Pager ID.
EscalationPagers(Figure9)—Thesepagersaresentacall
ifitisnotresetwithinacertainperiodoftime.Checkthe
boxandenteraPagerIDforeachoftheshiftsbeingused.
ThefirstPagerIDisforshift1,thesecondPagerIDisfor
shift 2, and the third Pager ID is for shift 3.
Use this formula to convert the pager’s CAP code to its
corresponding Pager ID (add leading zeros to make 7
digits): PagerID =[(pager’s CAPcode ×8)+10000]
If a shift is not being used, enter 7 zeros as its Pager ID.
Repeat—Choices are 0–5. Do not use the RUR setting
(Repeat until Reset), because it cancels escalations.
Interval—Choices are 2, 5, 10, 15, 20 or 30 minutes; and
1 or 2 hours.
SaveZonebutton—Afterallthefieldshavebeencompleted
for the zone/input, click the Save Zone button at the top
right of the screen. Then begin programming the next
zone/input.
Figure9—Assigning
Shift & Escalation Pagers
Simplified Contact Input Programming
Create one zone/input and click Save Zone. Then make a
copy of that zone/input using Save to Zone, and modify
just the fields that vary from zone/input to zone/input.
1. Inthefirstfield,enterthezone/inputnumbertobecopied.
In the second field, enter the zone/input number to be
created.For example,SavetoZone2to32copies alldata
fromzone/input2tozone/input32.
2. Click Save to Zone. The screen will refresh and display
the newly created zone/input.
3. Make any changes necessary, and click Save Zone.
ModifyingContact Inputs—To modify existing zones/inputs:
1. Enterthezone/inputnumberyouwanttoeditintheFind
Zonebox,andclickFindZone.Thecontactprogramming
information for the zone/input you entered will appear.
2. Make any changes necessary, and click Save Zone.
3. To modify the next zone/input, click Next to display it,
make any changes necessary, and click Save Zone.
Continue until all zones/inputs have been modified.
Print Database Button
The database report is a complete record of all currently
programmed zones/inputs on the master and attached slaves.
To create it, click the Print Database button at the bottom of
the Contact Input Programming screen. All the active zones/
inputs will be displayed in your web browser. Select File >
Print in the web browser to print the report.
Finishing up
1. ReplacethecoversonallNC377PagingInterfaceAdapters.
2. Connectthemastertothepagingtransmitterusingtheserial
cable supplied with the paging transmitter. Connect the
masterandfirstslaveusingthegraycrossovercable.Connect
all slaves together using the red patch cables.
3. Power upallNC377 Paging InterfaceAdapters.
4. Place calls from rooms to test all zones/inputs.

Page8•IL871NC377PagingInterfaceAdapterManual Copyright©TekToneSound &Signal Mfg., Inc.AllRightsReserved.
Chapter 5—Reporting
TheNC377 canstore multipledays ofdata logson the1GB SD
card located on the processor board. Copy the logs to a PC
periodically. See SD Card Use in theAppendixfor instructions
on copying files. If the card fills up, the oldest log will be
overwritten and lost.
A variety of report types can be produced by entering different
search parameters. Refer to Figure 10 while performing the
following steps to create a report.
Log On
Log onto the NC377 using the following procedure:
1. ForthePCtocommunicatewiththeNC377PagingInterface
Adapter,theymustbothbeonthe192.168.1.____IPsubnet.
TekTone®suggestsusing192.168.1.235.Temporarilychange
the IP address of your PC or laptop. (See Changing a PC’s
IP Subnet in the Appendix for instructions.)
2. Disconnect the gray crossover cable from the first NC377
slave, and use the cable to connect the PC/laptop to the
masterNC377.(Reportingisnotavailablefromslaves.)
3. Openabrowser,suchasInternetExplorer,onthePC/laptop.
4. LocatetheNC377PagingInterfaceAdapter’sIPaddresson
the label attached to its main circuit board.
Inthebrowser’s addressline,type the IPaddress,followed
by /default.zhtml in lower case letters. (For example,
192.168.1.239/default.zhtml)
5. The Welcome screen will appear (see Figure 5). Click on
Reports.
6. The Logon screen will appear (see Figure 6). Enter the
default user name and password:
UserName: default
Password: pia3264
7. ClickOK.
8. The Report Options screen will appear (see Figure 10).
Report Types
Reports can be created without entering a date, room number
or type of call. Because this type of report is very general and
includes a large amount of data, it takes a considerable amount
of time to produce. Therefore,TekTone®recommends limiting
the amount of data in a single report. Here are a few suggested
report types:
RoomNumber&Date—showsa list ofallcalls placedfroma
specific room on one date or range of dates (Figure 11a).
1. ChecktheDateboxandenterthedesiredFromDateand
To Dates for the report.
2. ChecktheFromRoombox.TypetheFromRoomnumber
and bed identifier (if used). Leave the To Room blank.
3. ClickViewReport.
Room Number, Date & Call Type—shows a list of calls of a
single call type placed from a specific room on one date or
range of dates (Figure 11b).
1. ChecktheDateboxandenterthedesiredFromDateand
To Dates for the report.
2. ChecktheFromRoombox.TypetheFromRoomnumber
and bed identifier (if used). Leave the To Room blank.
3. ChecktheTypebox.Clickonthecalltypetohighlightit
(Active,Pulse1orPulse2).
4. ClickViewReport.
Figure10—Report OptionsScreen

IL871NC377PagingInterfaceAdapterManual• Page 9
Copyright© TekToneSound &SignalMfg., Inc.AllRightsReserved.
Figure11—ReportExamples
RoomNumber,Date,CallType&ElapsedTime—showsalist
of calls of a single call type placed from a specific room on
onedateorrangeofdates.Thisreportalsoincludesthetime
elapsed from call placement to call reset (Figure 11c).
1. ChecktheDateboxandenterthedesiredFromDateand
To Dates for the report.
2. ChecktheFromRoombox.TypetheFromRoomnumber
and bed identifier (if used). Leave the To Room blank.
3. Check the Elapsed Time box.
4. ChecktheTypebox.Clickonthecalltypetohighlightit
(Active, Pulse1 or Pulse2). Or, leave the Type box
unchecked to list all call types.
5. ClickViewReport.
Range of Room Numbers & Date—shows a list of all calls
placedfrom arangeof roomsonone dateorrange ofdates.
1. ChecktheDateboxandenterthedesiredFromDateand
To Dates for the report.
2. ChecktheFromRoombox.TypetheFromRoomnumber
and bed identifier (if used). Type the To Room number
and bed identifier (if used).
3. ClickViewReport.
RoomNumber,Date&Shift—showsalistofcallsplacedfrom
aspecificroomononedateorrangeofdatesduringasingle
shift.
1. ChecktheDateboxandenterthedesiredFromDateand
To Dates for the report.
2. ChecktheFromRoombox.TypetheFromRoomnumber
and bed identifier (if used). Leave the To Room blank.
3. Check the Shift box. Click on the Shift to highlight it
(Shift1,Shift2orShift3).
4. ClickViewReport.
Figure 11c—Room Number, Date, Called Type &
Elapsed Time
Figure 11b—Room Number, Date & Call Type
Figure 11a—Room Number & Date

Page10•IL871NC377PagingInterfaceAdapterManual Copyright©TekToneSound &Signal Mfg., Inc.AllRightsReserved.
Figure 12—SD Card Maintenance
Appendix
Changing a PC’s IP Subnet
1. You must be the administrator on the PC/laptop.
2. On your PC/laptop,selectStart>ControlPanel>Network
Connections.
3. Right-click your Local Area Connection and select
Properties.
4. Click Internet Protocol (TCP/IP) and click Properties.
5. Select Use the following IP address (This will deselect
Obtain an IP address automatically).
6. To the right of the IP address, enter the new IP address:
192.168.1.235.
7. Press tab.Thesubnet mask willshowas 255.255.255.0.
8. ClickOKtoexitthewindow.
9. Reboot thePC/laptop ifnecessary.The PC/laptopcan now
logonto theNC377.
Changing the NC377’s User Name & Password
TheNC377’s usernameand passwordare alphanumericwith a
maximum length of 11 characters and no spaces.
1. Select the Change Programming Authentication Settings
buttonatthebottomoftheNC377’sGlobalSettingsscreen.
2. The Change User Name / Password screen will appear.
3. Enter the new user name and password. Then click Set
Programming Authentication Settings.
4. The new user name and password will take effect the next
time you log onto the NC377.
5. Savethisinformationinasecureplace.Ifitislost,itwillbe
impossible to log onto the NC377.
The same procedure is used to change the Reporting screen’s
user name and password.
SD Card Use
Removing the SD Card from the NC377
1. RemovepowerfromtheNC377.
2. Removethefourscrewsholdingthetopcoveronandset
the cover and screws aside.
3. Locate the main processor board in the middle of the
motherboard.
4. Gently push the card in. It will snap back out, and then
you can remove it.
Copying Files from the SD Card
Copying files from the SD card to a PC is for storage only.
Do not use a PC to read or modify the files.
1. The PCmusthave anSDcard reader.Ifthe PC doesnot
include one, purchase one locally and connect it to the
PCviaUSB.
2. Insert the SD card in the card reader. Microsoft Win-
dows®will recognize the card as a removable drive and
assign it a drive letter.
3. Create a directory on the PC. Then drag and drop the
directoriesfromtheSDcardintothenewdirectoryonthe
PC.
Reinstalling the SD Card into the NC377 (Figure 12)
1. After all directories have been copied, remove the SD
cardfrom thePC’s SDcardreader.
2. Insert the SD card into the holder on the NC377’s main
processor board with the contacts facing up. Gently
push the SD card in until you feel the card click in.
3. Replace the cover and four screws. Apply power to the
NC377.
Cables
• Tobuildacrossovercable,wireoneendT568Aandwirethe
other end T568B, using 8P8C connectors (see Figure 13).
• To build a straight-through cable, wire both ends T568B,
using 8P8C connectors (see Figure 13).
• Refertoyourpagingtransmittermanualfor instructions on
buildinganRS232cable,ifneeded.

IL871NC377PagingInterfaceAdapterManual• Page 11
Copyright© TekToneSound &SignalMfg., Inc.AllRightsReserved.
Figure13—8P8C CableTerminations
Troubleshooting
If a master or master–slave configuration is not sending data
to the paging transmitter, check the following.
Master’s Power LED is on,
Slave’s Power & Data LEDs are on solid:
• Check the RS232 cable to the paging transmitter.
• Checkthat thecorrectpaging protocolisselected inthe
master’sprogramming.
Slave’s Power, Data & Program LEDs are all on:
• Slave(s) are not connected to master.
• Check interconnecting crossover and patch cables.
Master or Slave Power LED is off:
• No12VDCinput.
• Check AC adapter in rear of slave or master.
ComPPage License Agreement
General
Information in this document is subject to change without
notice.Companies, names,anddata usedinexamples herein
are fictitious unless otherwise noted. No part of this
document may be reproduced or transmitted in any form or
by any means, electronic or mechanical, for any purpose,
without the express written permission of comPPage, Inc.
All rights reserved. Printed in the United States. Microsoft,
MS,MicrosoftWindowsXPareall trademarksofMicrosoft
Corporation.
Notification of Copyright
This software package associated with the Paging Interface
Adapter(“software”) isa proprietaryproduct ofcomPPage,
Inc. and is protected by copyright laws and international
treaty.You musttreatthe softwarelikeanyother copyrighted
material,except thatyou mayplace thesoftware ona single
hard disk, provided that you keep the original software
solely for backup or archival purposes. Copyright laws
prohibit making additional copies of the software for any
other reason.
Software License Agreement
Read this License Agreement before using the software.
This agreement is a legal contract between you, the end
user, and comPPage, Inc. governing your use of the
Software. This agreement shall also be binding on any
subsequent,authorized licensee.If youdo notwish toagree
tothe termsofthisAgreement, promptlyreturnthe complete
package to the distributor from whom you obtained this
product.You will receive a full refund provided you return
the equipment in its original packaging. If you have any
questions concerning this Agreement, contact:
comPPage,Inc.
Attn:Customer Service(561) 969-7124)
6801Lake WorthRoad, Suite308
LakeWorth, Florida33467
License
1. comPPage, Inc.R grants you the right to use the Paging
Interface Adapter and software.
2. You may notsublicense,rent,orlease thesoftware,but
you may permanently transfer your license to use the
software and accompanying materials by delivering to
anotherpartytheoriginalmaterialscomprisingthesoft-
ware package, including the title page of the reference
manual.Youmustalsosimultaneouslydestroyallcopies
oftheaccompanyingmaterialsinyourpossession.Such
transferterminatesyourlicensetousethesoftware.The
new recipient of the software and accompanying mate-
rials accepts this agreement and is licensed under the
termsofthisagreementuponinitiallyusingtheSoftware.
3. Youmaynotde-compile,disassemble,reverseengineer,
copy, transfer, or otherwise use the software except as
stated in this Agreement.

Page12•IL871NC377PagingInterfaceAdapterManual Copyright©TekToneSound &Signal Mfg., Inc.AllRightsReserved.
AWord about ESD(Electrostatic Discharge)
What Is It?
Static electricity is a result of triboelectric charging of two
dissimilar non-conductive materials that are rubbed together,
such as rubbing your feet on a carpet on a cold winter day or in
a dry climate. The resulting charge is detected when you reach
out to touch a doorknob or some other metallic object. The
resulting discharge may only be startling or, in severe cases, it
may even be painful. The actual electrical charge is dependant
on the materials being rubbed together, humidity, the rate of
separation, and other factors.
What Can It Do?
While this effect may be disturbing to humans, the effect on
electronic equipment is often more serious, ranging from
operational disruption to actual component damage. These
effects result from the high voltages that may be developed.
The simple act of walking across a carpet may develop as
much as 30,000 volts, and changing a bed sheet may create a
charge of 100,000 volts or more. Such voltages readily cause
arcing (the spark that can be observed when you grab a
doorknob after walking across a carpet, etc.). The arcing is
evidence of the discharge path. Due to the high voltage
involved,the dischargecurrent canjumpto anynearby metallic
or non-metallic object. If the discharge is to or through an
electronic device, such as the nurse call system, the operation
of the device may be affected. If the discharge current passes
through internal components, these components may be
damaged or their operation degraded.
What Can We Do About It?
Themanufacturer ofthe nursecallequipment hasalready taken
steps to protect the equipment from electrostatic discharge
(ESD) effects. Our peripheral equipment has been tested and
listed by ULR to withstand discharges of up to 30K volts.
However, since the cause is not in the equipment, but in the
environment, further measures are required of the installer and
the user to achieve complete protection.
What The Installer Can Do
In humid climates or in places where the relative humidity is
kept at 65% or greater, there will likely be few problems with
ESD. Where problems may occur the following measures can
be taken.
• Groundallexposedmetalsurfaces.Groundingshouldbeto
a #16 gauge or larger conductor.
• Install nurse call system wiring in metal conduit. This
conduit may be used to ground panels.
• Use shielded cable for nurse call system station-to-station
wiring. The use of open conductors invites inductive cou-
pling of discharge currents, which can cause the same
problems as direct discharge currents.
• Ground your body before handling system components.
This can be done by using a wrist strap, or simply by
contacting a grounded metal surface. Use caution to avoid
hazardous voltages while grounded.
What The User Can Do
The most common generation of ESD in hospitals is due to
changing linen on hospital beds while the patient call cord or
pillow speaker is still connected to the nurse call system. The
followingprecautions willhelp. Removethe callcordor pillow
speaker from the bed before changing the linen. It will be
necessary for the nursing staff to discharge themselves by
contacting a grounded metal object before placing the call
cord or pillow speaker back on the bed; otherwise a spark will
jump to the nurse call equipment, causing the very damage
they are trying to avoid. To avoid a shock while discharging
static electricity on the body, hold a metal object, such as a
key, and use that object to contact the grounded surface.
This information is provided to make you aware of ESD
problems so that precautions may be taken to avoid damage
and disruption of system operation.
