CNG CONVERSION SYSTEM INSTALLATION MANUAL
2018 FORD F-150 5.0L
COMPLETE BI-FUEL CNG SYSTEM
Updated: 4/19/2018

2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM INSTALLATION INSTRUCTIONS
2018 F-150 5.0L INSTALLATION MANUAL Page 2
TABLE OF CONTENTS
• All Ford original owner information supplied by Ford must remain with the vehicle.
• Compressed natural gas is a combustible fuel, ammable and highly explosive.
• CNG is stored under high pressure (normal working pressure of 3,600 psi) at 70ºF (21ºC).
• Tampering with or improperly maintaining the high pressure fuel system can result in fatality or serious injury.
• All CNG and gasoline maintenance must be performed at an authorized service center with qualied technicians.
• Use extreme caution and follow all related safety guidelines. We have tried to make this installation as safe as possible but we can not predict all scenarios.
• This CNG system requires gasoline in vehicle at all time–ate on CNG. When the low gasoline level indicator light illuminates the CNG system will automatically turn off until additional
gasoline is fueled into the vehicle and the low level light turns off. This is required by Ford to protect the engine from damage.
NOTE: Disconnect the vehicle battery before install (Refer to page 5). This includes partial install, servicing, and or maintenance.
!! WARNING !! Follow instructions as directed in the installation manual and do not attempt shortcuts.
Follow proper safety procedures. Failure to do so can lead to bodily harm or fatality. Tampering with or
improperly maintaining the high pressure fuel system can also result in bodily harm or fatality.
!! WARNING !! Batteries normally produce explosive gas. Therefore, do not allow ames, sparks or lighted
substances to come near the battery. When charging or working near a battery, always shield your face and
protect your eyes. Always provide ventilation. Failure to follow these instructions may result in personal injury.
!! CAUTION !! Be aware that this installation requires the use of High Pressure, Flammable, and Highly
Explosive compressed natural gas. CNG is stored under at maximum of 3,600 psi and at 70ºF (21ºC).
!! CAUTION !! Failure to complete the pre-installation checklist may result in severe engine damage after
installation is complete.
!! CAUTION !! This installation is intended for unmodied vehicles. If the vehicle has been modied, consult
ALTECH-ECO before the beginning install.
DISCLAIMER
ALTECH-ECO assumes no responsibility for damages occurring from accident, misuse, abuse, improper
installation, Improper operation, and lack of reasonable care or all previously stated reasons resulting in
incompatibility with other Manufacturer’s products.
Chemicals and Lubricants:
1. Silicone lubricant spray is required on all o-rings on ttings.
2. Epoxy primer or equivalent to rust proof any exposed metal.
3. Ford approved coolant liquid to top off the reservoir.
INDEX
Page (3) Introduction
Page (4) Q-222 Attaching Accessories to Aluminum Panels and Structure
Page (5) Before Installation
Page (6-10) Cylinder Installation - 5.5’ Short Bed, 6.5’ Short Bed / 8’ Long Bed
Page ( 11-15) Fuel Fill Installation - Side Mount
Page (16-19) Low Pressure Installation
Page (20-22) Wiring - Pig Tail
Page (23) Wiring - CNG Harness
Page (24) Wiring - CNG Harness (Fuse Box)
Page (25-28) Fuel Gauge Routing and Install
Page (29-30) Low Pressure Hose Routing / Quarter Turn Valve
Page (31-32) Coolant Hose Routing
Page (33) Rear Harness Routing
Page (34) Cylinder Cover
Page (35) Cylinder Cover - Tool Box Option
Page (36-37) Decal Placement
Page (38) Leak Checking the System
Page (39) Contact List

2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM INSTALLATION INSTRUCTIONS
2018 F-150 5.0L INSTALLATION MANUAL Page 3
Check List:
1. Conrm packing slip to insure that you have received all components, assemblies, and sub-assemblies.
2. Make sure none of the components and assemblies have been damaged during shipping.
3. Pre-inspect the vehicle following the QVM, Q-185, and NFPA 52 regulations (Contact ALTECH-ECO for the inspection check list).
4. Begin your conversion process.
• Cylinder Installation
• Regulator assembly installation
• Fuel ll installation
• High pressure line installation and routing
• Low pressure and coolant line installation and routing
• Underhood installation
• Wiring (Including switch and gauge) Installation
• Decal placement
• Fill and leak test
• Begin your QC Process
5. Check tire pressure before test driving.
6. Check and ll coolant uid before starting and test driving.
7. Be sure the rear harness is routed properly and that there is no loose hanging wires under the vehicle.
8. Be sure all provided parts are installed.
9. Perform nal test drive.
THIS DOCUMENT CONTAINS PROPRIETARY DATA OF ALTECH-ECO AND
SHALL NOT BE USED OR DISCLOSED IN WHOLE OR IN PART TO DESIGN
OR FABRICATE ANY PRODUCT FOR ANY PURPOSE, OR REPRODUCED
OR TRANSMITTED TO ANY OTHER ORGANIZATION WITHOUT WRITTEN
PERMISSION FROM ALTECH-ECO CORPORATION.

2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM INSTALLATION INSTRUCTIONS
2018 F-150 5.0L INSTALLATION MANUAL Page 4
Attaching Accessories to Aluminum Panels and Structure
Originator: BBAS Page 1 of 2 Date Issued: 07/22/14
Path/Filename: Bulletins/bulletin originals/Q222/Q-222.pdf

Attaching Accessories to Aluminum Panels and Structure
Models Affected: 2015 MY and later F-150
Background:
The high-strength aluminum alloy in the all-new F-150 does not produce red rust like steel. We have gone to great lengths
to develop coatings to inhibit corrosion. However, customers should take note that when installing aftermarket equipment,
aluminum can still corrode if the aluminum is attached to dissimilar metals. This type of corrosion is called “galvanic
corrosion” and it occurs where there is contact between different metals, like steel or stainless steel fasteners.
Protecting against galvanic corrosion
When installing aftermarket equipment, it is necessary that the installer pay special attention when drilling or clamping
dissimilar metals to the aluminum body.
• Anytime the factory paint is damaged, it is recommended that the paint be repaired with a suitable coating prior to
installing aftermarket equipment (i.e. splash guards, bug shields, tool boxes, etc.)
• When installing fasteners into the mounting hole the fastener should not have contact or have an interference fit
with the sheet metal
• For zinc coated steel bolts and screws, an aluminum washer should be used
• For further protection, an isolation layer should be used between the two dissimilar metals
• When clamping onto the truck, a polypropylene or urethane tape can be used as the isolating layer
Paint, Isolator, and Fastener Recommendations
We have tested many combinations of fasteners and coatings that are widely used in the aftermarket and have provided a
list of approved products to help ensure durability, strength and quality.
** For small repair of factory paints around mounting hole. Follow manufacturer’s directions for use.
Approved Anti-Corrosion Coatings**
 Motorcraft PM13-A  NOX-Rust 7703-W  Zinc Rich Primer
Recommended Acrylic Lacquer Touch-up Paints**
 Motorcraft  Duplicolor  Rustoleum
QVM Bulletin: Q
-
222
Date
:
22
July
, 2014
SVE BULLETIN
SPECIAL VEHICLE ENGINEERING – BODY BUILDERS ADVISORY SERVICE
E-Mail via Website: www.fleet.ford.com/truckbbas (click "Contact Us")
Toll-free: [phone]
Q-222
Originator: BBAS Page 2 of 2 Date Issued: 07/22/14
Path/Filename: Bulletins/bulletin originals/Q222/Q-222.pdf
Approved Fasteners

 Aluminum Clamps
 Aluminum Pop Rivets
 Plastic Scrivets
 Plastic Push Pins
 Aluminum Rivnuts
 Zinc coated steel fasteners used with an aluminum washer
Isolator Recommendations
 Aluminum washer  Urethane tape  Polypropylene tape
Examples
In this section we illustrate some best practices to isolate steel from coming in contact with aluminum. Using the
previously listed fasteners and coatings in addition to good isolation techniques will help ensure durability, strength and
quality of your F150.
Note: The following illustrations are not vehicle specific and are intended for reference only.
Figure 1 shows a plastic accessory attached to the aluminum sheet metal and the fastener properly isolated from contact
with the aluminum sheet metal.
Figure 2 shows a steel accessory and steel fastener properly isolated from contact with the aluminum sheet metal.
Note: both figures show the fastener using an aluminum washer and having an oversize hole providing an air gap to the
aluminum sheet metal.



Important: Fasteners or coatings that should be avoided
The items listed below can accelerate galvanic corrosion in aluminum and should be avoided. If a steel fastener must be
used it is necessary to properly isolate from contact with the aluminum.
self-tapping screws
steel rivnut
steel pop rivets
steel spring clips
RTV silicone
stainless steel fastener
If you have any questions, please contact the Ford Truck Body Builders Advisory Service as shown in the header of this
bulletin.
Figure 1 Figure 2

2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM INSTALLATION INSTRUCTIONS
2018 F-150 5.0L INSTALLATION MANUAL Page 5
DISCONNECT THE BATTERY
DISCONNECT THE GASOLINE FUEL PUMP
Gasoline system pressure release:
1. With the vehicle in NEUTRAL, position the truck on the hoist.
2. NOTE: The Fuel Pump Control Module is located on the frame rail above the fuel tank.
3. Disconnect the fuel pump control module electrical connector.
4. Start the engine and allow it to idle until it stalls.
5. After the engine stalls, crank the engine for approximately 5 seconds to make sure the fuel rail pressure has been released.
6. Turn the ignition switch to the OFF position.
7. When the CNG system installation is complete, reconnect the fuel pump control module electrical connector.
8. Cycle the ignition key and wait 3 seconds to pressurize the fuel system.
9. Start the engine and check for leaks.
- Have original Ford vehicle manuals available for additional instructions if needed.
NOTE: Some steps are repeated from section to section, follow instruction until each
of the repeated steps are complete and ignore that step for other sections.
Disconnect the battery:
1. Loosen the nut on negative terminal wire and slid battery wire up and off of post. Place to side.
2. Place a plastic cap on negative terminal post to protect from accidental contact.

2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM INSTALLATION INSTRUCTIONS
2018 F-150 5.0L INSTALLATION MANUAL Page 6
CYLINDER INSTALL - 5.5’ SHORT BED / 6.5’ SHORT BED (18” x 60” CYLINDER)
2015-2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM
15-18F5.0-DRILLTEMP18x60-5.5SB
2015-2018 F-150 5.0L Drill Template - 5.5’ SHORT BED
For 18 x 60 Cylinder.
8 7/8”
2 1/2” hole
Short Bed, 5.5’9/16” hole
OEM hole
Update: 1-16-18
3 1/4”
7 3/4” 46 1/4” 51”
17 1/2”
21 1/2”
2015-2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM
15-18F5.0-DRILLTEMP18x6018x60-6.5SB
2015-2018 F-150 5.0L Drill Template - 6.5’ SHORT BED
For 18 x 60 Cylinder.
1 5/8”
13”
2 1/2” hole
9/16” hole
OEM hole Update: 1-16-18
Short Bed, 6.5’
7 3/4” 46 1/4” 51”
17 1/2”
21 1/2”
1. Use the template layout and measure out each drill point. Mark the holes
in shown locations. Always verify your measurements before drilling.
2. Drill each hole according to the template.
3. De burr and rust proof any exposed metal.
USE ONLY FORD QVM APPROVED ANTI CORROSION PRODUCTS
Note: Always check website installer portal for most up to
date templates at www.altecheco.com

2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM INSTALLATION INSTRUCTIONS
2018 F-150 5.0L INSTALLATION MANUAL Page 7
1. Use the template layout and measure out each drill point.
Mark the holes in shown locations. Always verify your
measurements before drilling.
2. Drill each hole according to the template.
3. De burr and rust proof any exposed metal.
USE ONLY FORD QVM APPROVED ANTI CORROSION
PRODUCTS
Note: Always check website installer portal for
most up to date templates at www.altecheco.com
CYLINDER INSTALL - 6.5’ SHORT BED (21” x 60” CYLINDER)
2016-2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM
16-18F5.0-DRILLTEMP21x60-6.5
Drill Template - 6.5’ SHORT BED - 21 x 60 Cylinder.
26”
26”
26”
26”
2 3/4”
11 3/4”
4 3/4”
19 1/4”
33 1/2”
43 1/4”
3/4” hole
2 1/2” hole
3/4” hole 3/4” hole 3/4” hole
Updated: 1/16/18

2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM INSTALLATION INSTRUCTIONS
2018 F-150 5.0L INSTALLATION MANUAL Page 8
CYLINDER INSTALL - 8’ LONG BED (21” x 60” CYLINDER)
8’ Bed - Use four OEM holes and drill two center holes
as shown.
2016-2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM
16-18F5.0-DRILLTEMP21x60-8
2016-2018 F-150 5.0L Drill Template - 8’ LONG BED
For 21 x 60 Cylinder.
26”
26”
3 5/8”
19 1/4”
33 1/2”
11”
LB OEM hole
LB OEM hole
LB OEM hole
LB OEM hole
2 1/2” hole
3/4” hole 3/4” hole
Drill ONLY these two center holes
Updated: 1/16/18
1. Use the template layout and measure out each drill point.
Mark the holes in shown locations. Always verify your
measurements before drilling.
2. Drill each hole according to the template.
3. De burr and rust proof any exposed metal.
USE ONLY FORD QVM APPROVED ANTI CORROSION
PRODUCTS
Note: Always check website installer portal for
most up to date templates at www.altecheco.com

2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM INSTALLATION INSTRUCTIONS
2018 F-150 5.0L INSTALLATION MANUAL Page 9
1. Install grommet.
2. Remove the two or four Ford front bed bolts and discard.
3. With a hoist, lower the pre-assembled cylinder package in the bed of the truck. Be
careful not to damage the bed walls.
Secure with bolts provided.
• Two or four M12 - 1.75” x 110mm bolts and 1/2” washers into the front cylinder
plate. These two or four bolts replace the two front OEM bolts.
• Two or four 1/2”-13 x 2” bolts into the rear cylinder plate. Secure the rear plate
using the mounting backing plates underneath, combine with 1/2” washers and 1/2”
- 13 nylock nuts. Tighten each bolt to 70-75 ft-lbs of torque.
CYLINDER INSTALL - 6.5’ SHORT BED & 8’ LONG BED
6.5’ Bed 8’ Bed

2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM INSTALLATION INSTRUCTIONS
2018 F-150 5.0L INSTALLATION MANUAL Page 10
• Connect low pressure fuel hose to the regulator. Torque to 30-35 ft-lbs. See low pressure hose install section for details.
• Connect rear wire harness to the high pressure sensor and electric cylinder valve. See wire harness install section for details.
• Connect coolant hoses to the regulator once hoses are routed. See coolant hose install section for details.
Note: Once Low Pressure hose, Rear Harness, and Coolant hoses have been routed, secure them with a zip tie near the grom-
met to eliminate any slack in the lines.
Low pressure connection. Rear harness connection. Coolant hoses connection.
CYLINDER INSTALL - 6.5’ SHORT BED / 8’ LONG BED

2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM INSTALLATION INSTRUCTIONS
2018 F-150 5.0L INSTALLATION MANUAL Page 11
FUEL FILL INSTALLATION - SIDE MOUNT FOR 5.5’ BED
6”
16”
2 3 4 5
Use caution when deburring.
1
1. Measure 6” (horizontal) x 16” (vertical) and mark the drill point.
2. Drill a 1/4” pilot hole rst. Double check your measurements. Then using a hole saw, drill a 2 9/16” hole.
Use caution when drilling so as to not damage surrounding area.
3. Carefully de burr and clean off any debris around the hole. Rust proof the hole to avoid corrosion.
4. Place the Fuel Fill Ring into the hole and use it as a template and to mark the holes that will be used to
secure the ring to the fuel ll cup housing. Position the ring exactly as shown.
5. Drill 3/16” holes through the fuel ll ring.
USE ONLY FORD QVM APPROVED ANTI CORROSION PRODUCTS

2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM INSTALLATION INSTRUCTIONS
2018 F-150 5.0L INSTALLATION MANUAL Page 12
FUEL FILL INSTALLATION - SIDE MOUNT FOR 6.5 FT BED
Use caution when de burring.
16”
16”
2 3 4 5
1
1
2 3 4 5
1. Measure 16” (horizontal) x 16” (vertical) and mark the drill point.
2. Drill a 1/4” pilot hole rst. Double check measurements. Then using a hole saw, drill a 2 9/16” hole. Use
caution when drilling so as to not damage surrounding area.
3. Carefully deburr and clean off any debris around the hole. Rust proof the hole to avoid corrosion.
4. Place the Fuel Fill Ring into the hole and use it as a template and to mark the holes that will be used to
secure the ring to the fuel ll cup housing. Position the ring exactly as shown.
5. Drill 3/16” holes through the fuel ll ring.
USE ONLY FORD QVM APPROVED ANTI CORROSION PRODUCTS

2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM INSTALLATION INSTRUCTIONS
2018 F-150 5.0L INSTALLATION MANUAL Page 13
FUEL FILL INSTALLATION - SIDE MOUNT FOR 8 FT BED
1. Measure 34” (horizontal) x 16” (vertical) and mark the drill point.
2. Drill a 1/4” pilot hole rst. Double check measurements. Then using a hole saw, drill a 2 9/16” hole. Use
caution when drilling so as to not damage surrounding area.
3. Carefully deburr and clean off any debris around the hole. Rust proof the hole to avoid corrosion.
4. Place the Fuel Fill Ring into the hole and use it as a template and to mark the holes that will be used to
secure the ring to the fuel ll cup housing. Position the ring exactly as shown.
5. Drill 3/16” holes through the fuel ll ring.
34”
16”
2 3 4 5
1
Use caution when deburring.
1
2345

2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM INSTALLATION INSTRUCTIONS
2018 F-150 5.0L INSTALLATION MANUAL Page 14
Receptacle, Cup and Fitting Assembly
FUEL FILL INSTALLATION
1. Obtain the fuel ll cup and joining components. Remove the rubber cap
and the nut from the receptacle. Rubber cap is to be re-attached when as-
sembly is completed.
2. Insert receptacle through fuel ll cup housing opening and screw nut on
receptacle.
3. Tighten the nut to receptacle and cup with a torque wrench to 45-50 ft-lbs
of torque.
4. Attached the straight thread end of 90º elbow tting to the receptacle and
tighten nut with torque wrench to 35 ft-lbs of torque. Align tting to point
parallel with drain hole in cup.
1
32
Receptacle Nut
9 0 º E l b o w F i t t i n g
Drain Hole
CNG Receptacle
Fuel Cup
4

2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM INSTALLATION INSTRUCTIONS
2018 F-150 5.0L INSTALLATION MANUAL Page 15
Securing and Making the Connection Points
1. Install the fuel ll cup with tting and drain hole pointing down behind the truck bed wall.
2. Secure the fuel ll cup using the ring and 6 screws. Secure the 6 bolts in a criss-cross
tightening sequence.
3. Connect the high pressure hose to the receptacle tting and check valve located within
the bed. Tighten hose connections with torque wrench to 35 ft-lbs of torque. For 8’ bed,
secure the hose to the channel with a 5/8” p-clamp and a 1” self tapping screw.
Hose lengths by bed size:
5.5’ bed= 27”
6.5’ bed = 24”
8’ bed = 36”
Fuel ll ring screw
Note: Depending on requested order and availability, some
packages may differ slightly on assembly around the valve.
But connections remain the same.
Used with the long bed
Self tapping screw
5/8” P-clamp
Attach the CNG Only sticker inside
the fuel ll cup.
Re-attach the rubber dust
cap over the receptacle.
Attached high pressure
warning sticker to hose.
Connect the high pressure hose
to the check valve located near
cylinder valve.
FUEL FILL INSTALLATION - SIDE MOUNT
3 21
3

2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM INSTALLATION INSTRUCTIONS
2018 F-150 5.0L INSTALLATION MANUAL Page 16
1. Disconnect connections and remove air intake
hose/tube.
Disconnect these three hoses on this end and set aside.
2. Remove foam insulation and discard.
3. Disconnect all OEM connectors from the injectors.
LOW PRESSURE INSTALLATION
DO NOT USE POWER TOOLS!
1123

2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM INSTALLATION INSTRUCTIONS
2018 F-150 5.0L INSTALLATION MANUAL Page 17
LOW PRESSURE INSTALLATION
4. Safely disconnect OEM gasoline line on both sides. One side from
direct injection pump on the left of the rail, and on the right side
disconnect from the fuel pump.
Plug the lines as there is still gasoline in them.
When disconnecting the gasoline line to the left of the manifold, also
include the black OEM hose along with the fuel rails.
5. Remove and save the four OEM fuel rail bolts.
6. Remove OEM fuel rails along with the injectors and discard. Remove
and save OEM pressure temperature sensor.
Note: Rails contain gasoline.
7. Install CNG injectors unto the CNG fuel rails.
CAUTION: Fuel line may be under pressure.
4456
6
7

2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM INSTALLATION INSTRUCTIONS
2018 F-150 5.0L INSTALLATION MANUAL Page 18
8. Install CNG fuel rails unto the engine and into same location as
where OEM injectors t into.
Secure with four OEM bolts.
Torque to 89 in-lbs.
Note: Crossover hose is installed on step 9.
9. Connect both CNG fuel rails with the low pressure crossover hose.
Tighten each end to 30-35 ft-lbs. Also verify other end of each tting
is tightened to 30-35 ft-lbs.
Note: Minor adjustment to the low pressure hose position may be
needed to avoid abrasion with manifold tab. See picture below.
10. Attach OEM temp/pressure sensor unto fuel hose with the “T” tting.
Attach long end to the direct injection port.
Attach the gasoline incoming line unto the 90 degree connector.
Route the hose towards the back of the manifold facing the cabin.
11. Zip tie the temp/pressure sensor, tting, and gasoline port assembly
to the CNG to fuel rail. Tighten zip tie to the fuel rail.
LOW PRESSURE INSTALLATION
8
11
10
10
99
10
10

2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM INSTALLATION INSTRUCTIONS
2018 F-150 5.0L INSTALLATION MANUAL Page 19
12. Connect the CNG connector jumpers to the OEM injector
connectors and to the CNG injectors.
13. Connect OEM harness to the OEM temp/pressure sensor.
14. Connect CNG low pressure hose (once installed) to the fuel rail.
Ensure each end of the hose is labeled with a low pressure sticker.
15. Reconnect all OEM air hoses and place back the air intake hose/
tube.
LOW PRESSURE INSTALLATION
Jumper
11 12 13 14

2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM INSTALLATION INSTRUCTIONS
2018 F-150 5.0L INSTALLATION MANUAL Page 20
1. Remove middle PCM connector.
2. Remove connector back cover and any protective tape near to expose the wire. Save tape for
re-use.
3. Remove front face plate to expose the terminals. This face plate is numbered. Set aside to use as
a reference when locating a terminal.
WIRING - PIG TAIL
1
2 2 3 3
