altimo MMW701W User manual

Instruction Manual
Microwave Oven
MMW701W

2
Contents
1 Safety information
Important Safeguards 3
2 Installing your microwave
Installation Instructions 5
3 Getting to know your microwave
Product Overview 6
4 Using your microwave
Control Panel 7
Operating your Microwave 8
Containers and Utensils Guide 9
General Cooking Tips 10
5 Care and maintenance
Cleaning 11
Servicing and Repairs 12
6 Product support
Help and Assistance 13
Your Appliance Guarantee 14
Disposal 15

3
Safety information – Domestic use only
IMPORTANT SAFETY INSTRUCTIONS READ
CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING: If the door or door seals are damaged, the oven must not be operated until
repaired by a suitably trained person.
WARNING: It is hazardous for anyone other than a suitably trained person to carry out any
service or repair involving the removal of any cover. Such covers give protection against
exposure to microwave energy.
WARNING: Liquids or other food must not be heated in sealed containers as they are liable
to explode.
1. Only use vessels that are suitable for use in microwave ovens.
2. Metallic containers must not be used during microwave cooking.
3. Exercise increased caution when heating food in plastic or paper containers, due to the
possibility of ignition.
4. The microwave oven is intended for heating food and beverages only. Drying of food or
clothing or heating of warming pads, slippers, sponges, damp cloth and similar may
lead to risk of injury, ignition or fire.
5. If you see smoke, switch off or unplug the appliance and keep the door closed in order
to stifle any flames. Microwave heating of beverages can result in delayed eruptive
boiling; therefore, care has to be taken when handling all containers.
6. The contents of feeding bottles and baby food jars should be stirred or shaken, and the
temperature checked carefully before consumption, in order to avoid burns.
7. Eggs in their shell including whole hard-boiled eggs should not be heated in microwave
oven as they may explode, even after the microwave heating process has ended.
8. Failure to maintain the oven in a clean condition could lead to deterioration of the
surfaces and adversely affect the life of the appliance with increased risk of a hazardous
situation.
9. The microwave oven is intended to be used freestanding and must not be placed in a
cabinet.
10. Take care when removing hot containers from the oven.
11. Do not clean this appliance with a steam cleaner.
12. To avoid the risk of burns by spillage it is highly recommended that this appliance is
sited at a safe working height. For example, not higher than 1300mm or lower than
500mm from floor level.
13. Allow a minimum of 200mm free space above the top surface of the unit.
Warning: Children should only use the oven under adult supervision due to the high
temperatures generated.
CAUTION: HOT SURFACE

4
Safety information – Domestic use only
IMPORTANT SAFETY INSTRUCTIONS READ
CAREFULLY AND KEEP FOR FUTURE REFERENCE
14. If the power supply cord is damaged in any way, it must be replaced by the
manufacturer, an authorised service agent or an adequately qualified person in order to
avoid a hazard.
15. This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities if they have been given supervision or
instruction concerning its use, safe working and full understanding of the hazards
involved.
16. Children should not play with the appliance.
17. Cleaning and user maintenance should not be attempted by children without
supervision.
18. Group 2 Class B Appliance
Group 2 ISM equipment: Group 2 contains all ISM equipment in which radio-frequency
energy is intentionally generated and/or used in the form of electromagnetic radiation for
the treatment of material, and EDM and arc welding equipment. Class B equipment is
equipment suitable for use in domestic establishments and in establishments directly
connected to a low voltage power supply network which supplies buildings used for
domestic purposes.

5
Installation
1. Remove all packaging. If there is a protective film over any part of the oven, tear it off
before use. Check carefully for damage. If there is any damage do not use the
microwave and immediately notify the retailer or contact support on 03300 417 490 or
[email protected]
2. Microwave ovens must be placed under dry and non-corrosive environments and kept
away from heat and humidity, such as a gas burner or water tank.
3. To ensure enough ventilation, the distance of the back of microwave to the wall should
be at least 100mm, the side to the wall should be at least 50mm and the free distance
above the top surface should be at least 200mm.
4. Microwave ovens can disturb TV, radio or antenna signals when in use, it is
recommended place the unit 5m away from such equipment.
5. The appliance must be earthed and is supplied with a standard UK 3 pin plug to ensure
a good grounding in case of malfunction so a ground loop can be formed to avoid
electric shock. Ensure the plug is accessible in case power needs to be isolated.
6. The microwave oven must be operated with the door closed.
7. The microwave oven must not be placed in a cabinet. The microwave oven is intended
to be used freestanding.
8. Odours and/or some smoke can be expected for the first couple of uses as
manufacturing residue or oil that may be present near the heating element is burnt
away. This is normal and will not occur after the first few uses.
It is strongly recommended that you place a cup of water in the cavity and use the
microwave a few times on high power to remove the odour. Also, during this process to
keep the door or window open to ensure good ventilation.

6
Getting to know your microwave
Product Overview
1) Door lock
Microwave oven door must be properly closed in order for it to operate.
2) Viewing window
Allows the user to see the cooking status.
3) Rotating wheeled ring
The glass turntable sits on these wheels to support the turntable and provide stability
when rotating. Do not use your oven without this rotating wheeled ring.
4) Rotating axis
The glass turntable sits on the rotating axis driven from beneath.
5) Turntable
The cooking vessel sits on the rotating turntable to help it heat evenly
CAUTION Place the glass platter on the rotating wheeled ring ensuring a good fit onto
the rotating axis. It is essential that the turntable turns properly for correct operation.
6) Control panel
See operating information on page 7
(the control panel minor design is subject to change without prior notice).
7) Outer cover
Used to cover the machine, to protect the internal structural parts and electrical
components of the machine and provide a safe microwave oven.
8) Waveguide cover
This is inside the microwave oven, beside the control panel.
Never remove the waveguide cover.

7
Product Overview
Control Panel
CLOCK TIMER SETTING
The maximum setting is 35 minutes, there is a
notification noise (ding) at the end, and the knob returns
to the “0” position.
MICROWAVE FUNCTIONS
There are five power levels:
LOW
17% power output
Keep warm
Defrost /
M. Low
30% power output
Defrost food
Soups and drinks
Med
55% power output
Slow cooking
M.High
80% power output
Normal cooking
HIGH
100% power output
Quick cooking
Below are some food defrosting time guides:
Type.
Weight
Defrost time
Meat
0.1~1.0kg
1:30~26:00
Poultry
0.2~1.0kg
2:30~22:00
Seafood
0.1~0.9kg
1:30~14:00

8
Product Overview
Operating your microwave
1) Prepare the unit, connect and turn on the power
Before connecting the power cord, make sure the timer is set to the “0” position.
Ensure nothing is blocking the ventilation area around the appliance and the turntable is
seated correctly on the wheeled ring and located correctly on the rotating axis.
2) Place the food on the glass turntable and close the door
Food must be in a microwave-safe plate or container. Do not place food directly onto
the turntable.
3) Select the desired power level
4) Select the desired time on the timer
If the cooking time is less than 10 minutes, turn the timer knob past the 10-minute mark
and then turn back to the chosen time setting.
5) Once the desired time is set, the cooking begins
If you need to pause cooking (to check or stir) just open the door at any time and when
you are ready to re-start close the door to resume operation.
6) When the timer finishes and cooking ends, the microwave oven produces a
notification noise (ding) and the inside lamp will automatically turn off
If the food is removed before timer ends turn the timer anticlockwise back to the “0”
position to prevent the microwave from operating empty.

9
Product Overview
Containers and utensils guide
It is strongly recommended only to use containers which are suitable and safe for
microwave cooking. Containers made of heat-resistant ceramic, glass or plastic are
generally suitable for microwave cooking and you can check compatibility by looking out for
the microwave safe logo on the base of intended vessels.
Never use metal containers for microwave cooking or combination cooking as sparks are
likely to occur. Please take note of the reference table below.
Container Material
Microwave
compatible
Notes
Heat-resistant ceramic
Yes
Never use the ceramics which are
decorated with a metal rim or glaze.
Look for microwave safe logo.
Heat-resistant plastic
Yes
This should not be used microwave cooking
for long time intervals.
Look for Microwave safe logo.
Heat-resistant glass
Yes
Look for microwave safe logo.
Plastic film
Yes
This should not be used when cooking meat
or chops as the oven-temperature may
damage the film.
Grill rack
No
Metal
No
Foil
No

10
Product Overview
Cooking Tips
Here are some tips when using your new microwave:
Food arrangement
Place thicker/dense areas towards the outside of the dish, the thinner/less dense parts
towards the centre and spread the food out evenly. Do not overlap food if possible.
Cooking time length
Start cooking with a shorter time setting and check periodically, it is better to add a bit
more time than to overcook your food. Over-cooking may even result in smoke or burning.
Cooking food evenly
Foods such as chicken, hamburgers or steaks should be turned once during cooking.
Depending on the type of food, it may benefit from stirring from the outside to the centre of
dish once or even twice during cooking.
Allow standing time
After cooking has finished, leave the food inside the oven for a short period. This allows
cooking to complete and a calming of the cooking process.
Checking if the food is cooked
The appearance and texture of the food helps determine if it is ready, these include:
- Steam coming out from all parts of the food, not just the edges
- Joints of poultry can be moved easily
- Pork or poultry show no signs of blood
- Fish is opaque and can be sliced easily with a fork
Browning dish
When using a browning dish or self-heating container, it is best to place a heat-resistant
insulator such as a porcelain plate under it to prevent damage to the turntable.
Microwave-safe cling film
When cooking food with a high fat content, do not allow the cling film to touch the food as it
could melt.
Microwave-safe plastic cookware
Some microwave-safe plastic cookware might not be suitable for cooking foods with a high
fat and sugar content due to the high temperatures reached. Do not exceed the preheating
time specified in the instruction of the dish.

11
Cleaning
Microwave Oven Care
CAUTION The oven should be cleaned regularly, and any food deposits removed.
WARNING
a. Isolate or remove the plug from the socket before cleaning. Allow to cool before
cleaning. Do not immerse the unit or use excessive water or other fluids when cleaning.
b. Failure to maintain the oven in a clean condition could lead to deterioration of the
surface and could adversely affect the life of the appliance, and possibly result in a
hazardous situation.
c. Never use hard detergent, gasoline, abrasive powder or a metal brush to clean any part
of the appliance.
d. Do not remove the waveguide cover.
e. After a long period of not using the microwave one of the following three methods can
help remove strange odours:
1. Place a cup of water with lemon slices and heat on High Power for 2-3 minutes.
2. Place a cup of red tea and heat on High Micro Power for 2-3 minutes.
3. Place some orange peel on a plate and heat on High Power for 1 minute.
f. Between use, keep your microwave clean and in as dry and ventilated an area as
possible.
To clean surfaces which have been in contact with food, wipe the waveguide cover with a
damp cloth after use, followed by a dry cloth to remove any food splashes and grease. Built-
up grease may overheat and begin to smoke with risk of catching fire.
TIPS FOR CLEANING
Details for cleaning door seals, cavity and adjacent parts:
Exterior:
Wipe the enclosure with a damp soft cloth.
Door:
Using a damp soft cloth, wipe the door and window clean.
Wipe the door seals and adjacent parts to remove any spill or spatter.
Wipe the control panel with a slightly damp soft cloth.
Interior walls:
Wipe the interior surfaces and waveguide cover clean with a damp soft cloth.
Turntable / Rotation ring / Rotation axis:
Wash with mild soap water, rinse with clean water, allow to dry thoroughly and replace.

12
Maintenance
Servicing and Repairs
Please check the following before calling for servicing:
1. Place one cup of water (at least 150ml) in a mug inside the oven and close the
door securely. The oven lamp should go off when the door is closed properly.
Turn the timer round to 1 min and let the oven work.
2. Does the oven lamp light?
3. Does the cooling fan work?
(Put your hand over the rear ventilation openings.)
4. Does the turntable rotate?
(The turntable can rotate clockwise or anti-clockwise, both are normal)
5. Has the water inside the mug got hot?
If the answer is “NO” to any of the above questions, please check your wall socket
and the fuse are working normally. If they are:
CONTACT ALTIMO PRODUCT SUPPORT TEAM ON 0330 041 7490.
Servicing Safeguards
TRAINED PERSONS ONLY
Caution: MICROWAVE RADIATION
1. The high voltage capacitor remains charged after disconnection; short the
negative terminal of H. V capacitor to the oven chassis (use a screwdriver) to
discharge before touching.
2. During servicing, the parts listed below are liable to be removed and give access
to potentials above 250V to earth.
● Magnetron
● High voltage transformer
● High voltage capacitor
● High voltage diode
● High voltage fuse
3. The following conditions may cause undue microwave exposure during servicing.
●Improper fitting of magnetron;
● Improper matching of door interlock, door hinge and door;
● Improper fitting of switch support;
● Door, door seal or enclosure has been damaged.

13
Product support
Help and assistance
If you require any technical guidance or find that your microwave oven is not operating
as intended, please call one of our experts on 0330 041 7490.
To help us give you a fast and efficient service, please have the following information
ready:
Model reference:
Serial number:
Date of purchase:
Local call rates apply*
Lines open 9.00am – 5.00pm Monday to Friday.
*Calls to support enquiry lines may attract a charge and set up fee from residential lines depending on your call plan/tariff.
Mobile and other providers costs may vary, see www.bt.com/pricing for details.
For Security and training purposes, telephone calls to and from customer service centres maybe recorded and monitored. Calls
from Republic of Ireland will attract international call charges.

14
Your Appliance Guarantee
Guarantee Details (UK only)
Your appliance has the benefit of a comprehensive manufacturer's guarantee which
covers the cost of repair due to mechanical or electrical breakdown.
Any claim during the period of the guarantee must be accompanied by proof of
purchase.
The appliance must be correctly installed and operated in accordance with the
manufacturer's instructions.
Your appliance is intended for normal domestic use and not for commercial operations.
This guarantee does not cover cosmetic issues with the appliance or failures caused
by accidental damage, misuse or alternations which are likely to affect the appliance.
The guarantee is invalid if the product is tampered with or repaired by any
unauthorised person.
What to do if you need to report a problem:
1. Please ensure you have ready:
• The product model and serial number
• Your full contact details
2. Call the specialist Service Line for your product: 0330 041 7490
This guarantee in no way affects your statutory or legal rights.
Any information provided to us for the purposes of product support is subject to our
privacy policy, which can be viewed online at www.altimo.co.uk/privacy-policy

15
Disposal
Correct disposal of this product
This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible harm
to the environment or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the return and
collection systems or contact the retailer where the product was
purchased. They can take this product for environmentally safe
recycling.

www.altimo.co.uk
For customer service call: 0330 041 7490
