COMBINATION OVEN/STEAMERS

COMBITHERM®INSTALLATION
#6002 COMBITHERM ELECTRIC INSTALLATION AND MAINTENANCE MANUAL
PG. 1
RECEIVING & TRANSPORTATION
Upon receipt of the Combitherm combination
oven/steamer, check the exterior of the shipping
carton for any physical damage that could result in
damage to the contents. If the oven was not
received from the carrier in an upright position,
there is a stronger possibility of concealed damage.
Remove the carton or uncrate the unit carefully
and inspect for any transit damage. Immediately
report any damage to the delivering freight carrier.
The oven must remain on the pallet
while being moved to the installation site
by fork lift or pallet lift truck.
Note dimensions required for doorways and aisles
for access of the oven and pallet to the installation
site. Transport the oven in an upright and level
position only. Do not tilt the oven.
With the oven on the original pallet, remove the
carton and all packaging materials. Open the oven
door and remove all documents and other
materials from the oven interior. Remove the
roll-in cart if so equipped.
®

#6002 COMBITHERM ELECTRIC INSTALLATION AND MAINTENANCE MANUAL
PG. 2
BASIC INSTALLATION SITE REQUIREMENTS
HOOD INSTALLATION IS REQUIRED
• Installation surface must be level.
• Do not install adjacent to flammable surfaces.
• Deep fat fryers or similar heat producing equipment must not be installed in
the immediate vicinity of the hand shower.
• Installation surface must be non-combustible (unable to burn).
The oven must remain on the pallet while being moved
to the installation site with fork lift or pallet lift truck.
Do not tilt the oven.
VENTILATION
A steam ventilation hood is mandatory for the operation of the oven. The ventilation hood must be installed
in accordance with local building codes for steam exhaust and must protrude 12-inches to 20-inches
(300mm to 500mm) over the front side of the oven. A grease filter must be located in the protruding area of
the hood. Grease filters should be thoroughly cleaned on a regular basis following manufacturer's
instructions. Ventilation hoods must ensure an adequate amount of incoming air during operation and must
be operated whenever the combination oven/steamer is used in order to avoid the accumulation of
condensation in the hood area.
If a ventless hood is to be installed, we recommend
the Combitherm Ventless Hood for the appropriate
model oven.
VHML-5
Combitherm model 6•05, 6•10iNML, and 10•10iN
VHML-10
Combitherm model 7•14i
MODEL
Air Movement
Drain Connection
Electrical
Ship Weight
Replacement
Filters GREASE
CHARCOAL
VHML-5
530 CFM
100 watts, .50 amps
100 lb (45 kg)
FI-24113
FI-24114
VHML-10
1200 CFM
240 watts, 1.0 Amps
126 lb (57 kg)
FI-23062
FI-24102
3/4" (19,1mm) NPT
208-240 V.A.C. — 50/60 Hz, 1 ph
COMBITHERM®INSTALLATION

#6002 COMBITHERM ELECTRIC INSTALLATION AND MAINTENANCE MANUAL
PG. 3
POSITIONING ON SITE
Before removing the oven from the pallet for
positioning on site, it is important to remove the drip
tray to prevent damage to the tray caused by the
lifting forks. The drip tray is fastened to the bottom of
the oven with three sheet metal screws as illustrated.
This requirement pertains to the following models.
Lift the oven from the pallet
with a fork lift or pallet lift
truck positioned at the front
of the oven. To avoid
damage, position the lift forks
to the left of the condenser as
indicated in one of the two
diagrams shown below. For
additional damage protection,
the use of two wooden boards,
placed between the bottom of
the oven and the lifting forks,
is strongly recommended.
After the oven is correctly positioned
on site, reattach the drip tray.
MODEL
6•05
6•10iN
10•10iN
7•14i
NET WEIGHT
180 lb (82 kg)
285 lb (129 kg)
385 lb (175 kg)
405 lb (184 kg)
8"
(203mm)
CONDENSER
MODELS 6•05
6•10iNML
10•10iN
7•14i
COMBITHERM®INSTALLATION
➤

#6002 COMBITHERM ELECTRIC INSTALLATION AND MAINTENANCE MANUAL
PG. 4
INSTALLATION REQUIREMENTS
■■
■■Do not install oven adjacent to flammable
surfaces. Strictly observe all local fire
safety regulations.
■■
■■In order to ensure proper ventilation, a
minimum distance of at least 6-inches
(152mm) must be kept from the control
panel side [LEFT] of the oven and any
adjoining surfaces.
NOTE: In addition to ventilation
requirements, additional clearance
is needed for service access. A
minimum distance of 18-inches
(457mm) is strongly recommended.
■■
■■Allow a minimum of 4-inches (102mm) from
the right side of the oven to allow the door
to open to at least a 90° angle. Fully opened,
the door will extend up to a 225° angle. If
the oven is furnished with the retractable
door option, allow a minimum clearance of
6-1/2-inches (16cm).
■■
■■Allow a minimum clearance of 4-inches
(102mm) from the back of the oven for
plumbing connections.
■■
■■Allow a 20-inch (50cm) clearance at the top of
the oven for free air movement and for the
steam vent(s) located at the top [RIGHT-REAR].
■■
■■Do not install the oven adjacent to heat
producing equipment such as fryers,
broilers, etc. Minimum clearance
recommended: 20-inches (50cm).
Place the Combitherm oven on a stable, non-
combustible LEVEL horizontal surface. For
counter-top models, the oven stand must be level.
In addition, the overall height of the oven should
be positioned so the operating controls and
shelves may be conveniently reached from
the front.
ALL INSTALLATION INSTRUCTIONS
AND REQUIREMENTS MUST BE
STRICTLY OBSERVED.
IMPROPER CONNECTION
OF THIS APPLIANCE
NULLIFIES ALL WARRANTIES.
18"
(46cm)
4"
(102mm)
4" (102mm)
RETRACTABLE
DOOR OPTION:
6-1/2" (165mm)
20"
(50cm)
MINIMUM
20"
(50cm)

#6002 COMBITHERM ELECTRIC INSTALLATION AND MAINTENANCE MANUAL
PG. 5
WATER SUPPLY
CONNECT TO POTABLE (DRINKABLE) COLD WATER ONLY
WATER PRESSURE REQUIREMENTS:MINIMUM 30 PSI (2 BAR)
MAXIMUM 90 PSI (6 BAR)
Flush the water line at the installation site before connecting the oven to the water supply. A shut-off valve
and approved back-flow preventer must be installed when connecting the oven to the cold water intake.
The water supply line must be a minimum of 3/4-inch NPT (19mm). A water conditioning system is
recommended if the water supply is between 6 and 8 grains of hardness. If water tests over 14 grains of
hardness, the installation of a water softener is strongly recommended. Install the line filter at the cold
water intake connection point.
PIPE SEALING TAPE (TEFLON®)MUST BE USED AT ALL CONNECTION POINTS.
The use of a pipe sealing compound is not recommended.
THE MAIN WATER SHUT-OFF VALVE MUST BE IN THE
OPEN POSITION WHEN THE OVEN IS BEING USED.
The hand shower spray hose is installed adjacent to the cold water
intake connection. A ball valve is installed on the oven for hose
connection to the COLD water source. Assemble the washer and
the flexible hose on the ball valve and hang the spray handle on the
holder previously installed on the oven.
COMBITHERM®INSTALLATION
ELBOW
ASSEMBLY REQUIREMENTS
HAND SHOWER HOLDER
Fasten the hand shower holder in the holes
provided on the oven using the three (3)
screws packaged
with the holder.
DRIP TRAY INSTALLATION
Hang the drip tray at the front of the oven
as indicated on the drawing.

COMBITHERM®INSTALLATION
#6002 COMBITHERM ELECTRIC INSTALLATION AND MAINTENANCE MANUAL
PG. 6
WATER DRAINAGE
The oven must discharge through an indirect
waste pipe by means of an air gap. The drain
thread is 1-1/4-inch (32mm) NPT.
A union is required. Install a 1-1/4-inch
(32mm) diameter drain line. The drain line
must always be a positive gradient away
from the Combitherm oven and not more than
12-inches (305mm) before an air gap.
NOTE: In the U.S.A., this equipment is to be
installed to comply with the Basic
Plumbing Code of the Building
Officials and Code Administrators
International, Inc. [BOCA], and the
Food Service Sanitation Manual of the
Food & Drug Administration [FDA].
If several units are to be connected to one
drain pipe, the dimensions of the pipe must be
sufficient to allow an unobstructed water drain system.
1-1/4" (32mm) diameter NPT
WASTE PIPE
1-1/2" to 2" minimum diameter
(c. 38mm to 51mm)
2" (51mm)
Air Gap
Type of Oven counter counter counter counter
oven stand oven stand oven stand oven stand
Pan INCHES 6: 12" x 10" 6: 12" x 20" 10: 12" x 20" 14: 12" x 20"
Capacity 12: 12" x 6" 6: 18" x 13" 10: 18" x 13" 7: 18" x 26"
12: 12" x 10"
GASTRONORM 6: GN 1/2 6: GN 1/1 10: GN 1/1 14: GN 1/1
12: GN 1/3 18: GN 1/3
Side Rack INCHES 2-5/8 2-5/8 2-5/8 2-5/8
Spacing (MILLIMETERS)(65mm) (65mm) (65mm) (65mm)
Interior INCHES 15-1/4 13-1/4 13-1/4 23-1/2
Width (MILLIMETERS)(596) (387) (387) (596)
Interior INCHES 17-7/8 26-1/4 26-1/4 28-7/16
Depth (MILLIMETERS)(455) (665) (665) (722)
Interior INCHES 17-3/4 17-3/4 27 20-5/16
Height (MILLIMETERS)(450) (450) (685) (515)
Noise
Level
Spray Hose 81-inches 81-inches 81-inches 81-inches
Length (2050mm) (2050mm) (2050mm) (2050mm)
Water Consumption 3 - 5 gal/hr 4 - 6 gal/hr
(APPROX.) (12 - 20 l/hr) (15 - 25 l/hr)
ADDITIONAL TECHNICAL DATA
6•05ML 6•10-iNML 10•10iN 7•14i
MODEL ➜➜
The noise emission level related to the workplace is lower than: 70 dBA
AVERAGE
DRAIN WATER
TEMPERATURE
149°F (65°C)

#6002 COMBITHERM ELECTRIC INSTALLATION AND MAINTENANCE MANUAL
PG. 7
ELECTRICAL INSTALLATION
ELECTRICAL CONNECTIONS MUST BE
MADE BY A QUALIFIED ELECTRICIAN IN
ACCORDANCE WITH APPLICABLE
ELECTRICAL CODES.
An electrical wiring diagram is located behind
the control panel on the left side of the oven.
The oven must be installed by a qualified
electrician. This appliance must be branch
circuit protected with proper ampacities, in
accordance with the wiring diagram located in
the electrical compartment of the oven. The
oven must be properly grounded in accordance
with the National Electrical Code and applicable
local codes.
CAUTION
ENSURE THE AVAILABLE POWER
SOURCE MATCHES THE
VOLTAGE STAMPED ON THE
NAMEPLATE OF THE OVEN.
Wire size for the main incoming power to the
unit must match the minimum size listed in the
specifications applicable to the specific oven
model. For supply connections, locate the wire size posted on the label located on the electrical control box
cover, behind the service panel or elsewhere listed in this manual.
When connecting to a Delta-B (wild leg) on a 3-phase system, the wild leg must be connected to line 3.
Before operating the oven, check all cable
connections in the electrical connection area
for tightness since connections can loosen
during transport.
NOTE: After both water and electrical
connections have been completed,
operate the oven in any cooking
mode for a period of 15 minutes and
recheck the main power connections
at the terminal block to make
certain they remain tight.
FOLLOWING ELECTRICAL
CONNECTION, THE FAN
MUST ROTATE IN THE
SAME DIRECTION AS
THE ARROW
LOCATED ON THE
OVEN FAN MOTOR.
THIS APPLIANCE WILL NOT
FUNCTION PROPERLY AND DAMAGE
CAN OCCUR IF THE MOTOR
ROTATION IS NOT CORRECT.
Electrical
Panel
Terminal
Block
Electrical
Connection
MOTOR
with
Rotation Direction
Ground
TO CHANGE MOTOR DIRECTION,
EXCHANGE TWO OF THE
INCOMING PHASES.
COMBITHERM®INSTALLATION

#6002 COMBITHERM ELECTRIC INSTALLATION AND MAINTENANCE MANUAL
PG. 8
COMBITHERM®INSTALLATION
3/4"
(19mm)
1"
(25,4mm)
UNION
UNION
Intake
1" (25,4mm)
VENT
15" (381mm)
1-1/4"
(32mm)
1-1/2" (38mm)
STACKING INSTALLATION
Stacking Combitherm ovens require two (2) water connections, two (2) drain connections, and two (2)
electrical connections.
If local code allo
If local code allows ws, ,
the water and drain may be manifolded as long as the size of the water inlet is increased to
1-inch (25,4mm) and the drains include an external vent. The drawing illustrates one
suggested method of a manifold installation.
WATER INTAKE DRAIN

COMBITHERM ELECTRIC INSTALLATION AND MAINTENANCE MANUAL
PG. 9
POST-INSTALLATION CHECK LIST
In order for this oven to operate properly, installation must conform with the instructions provided in this
manual. Following full installation the following list is provided as a final check to help assure conformance.
INSTALLER REQUIREMENTS INITIALS/DATE
■■
■■Bottom of oven has been checked for damage due to improper positioning on site.
■■
■■Proper clearances have been allowed at the top of the oven and from all adjacent surfaces
with allowance of free air access to all vents.
■■
■■Clearance has been provided at the left of the oven for service access.
■■
■■A minimum distance of 20-inches (1/2 meter) has been provided between the oven and any
heat producing equipment such as fryers, broilers, etc.
■■
■■The oven has been leveled on a stable non-combustible surface.
■■
■■The oven has been connected to COLD water on a single water connection.
■■
■■Incoming water pressure is between a minimum of 30 PSI (2 BAR) and a maximum
of 90 PSI (6 BAR).
■■
■■A water conditioner is highly recommended, especially if the water grains of hardness
is NOT within the range of pH5 and 9. Contact factory for assistance.
■■
■■Installation of drain is at a minimum of 1-1/4" (32mm) with a positive descending slope.
■■
■■2" (51mm) air gap at drain is free of obstructions.
■■
■■Motor direction correctly corresponds with the direction of the arrow on the motor.
■■
■■Electrical safety devices and phase rotation have been checked.
INSTRUCTIONS TO OWNER/OPERATOR INITIALS/DATE
■■
■■Owner/operator has been instructed on the importance of cleaning the oven along with
proper cleaning procedures with regard to daily cleaning of the interior.
■■
■■Owner/operator has been advised to use authorized Combitherm oven cleaner only.
■■
■■Owner/operator has been informed of the safety warnings located in the operation guide
including the warning not to handle pans containing liquid or semi liquid products
positioned above eye level of the operator.
Damage directly attributed to improper set up, installation, or cleaning can invalidate warranty claims.
COMBITHERM®INSTALLATION
