Aluratek ADMPF118F Operating and maintenance manual

18.5” Digital Photo Frame
Instructional Manual
mnl M10344 Copyright © 2014 Aluratek, Inc. All Rights Reserved.
aluratek.com
ADMPF118F

04
05
06
06
07
08
09
10
10
11
12
13
14
Table of Contents
Frame Close-up ......................................................................................................
Remote Control Close-up .......................................................................................
Package Contents ..................................................................................................
Getting Started .......................................................................................................
Operations
Main Menu .........................................................................................................
Transferring Files from your PC/Mac to the Frame’s Internal Memory ..............
Managing Files in the Digital Frame’s Internal Memory .....................................
Photo Function
Setup a Photo Slideshow ...................................................................................
Photo Set-up ......................................................................................................
Video Function
Playing Videos ...................................................................................................
Video Set-up ......................................................................................................
Music Function
Playing Music ....................................................................................................
Music Set-up ......................................................................................................

15
16
17
18
20
21
22
Table of Contents
Calendar Function
Calendar Set-up ................................................................................................
Auto On / Off Function .........................................................................................
Alarm Function .....................................................................................................
System Settings ...................................................................................................
Technical Support ...................................................................................................
Radio and TV Interference Statement ....................................................................
Warranty .................................................................................................................

4
Frame Close-Up
1. 18.5” viewing area
2. Built-in speakers
3. Menu selection buttons
4. Power On / Off switch
5. USB ports
6. Power adapter port
7. SD Memory card slot
8. Adjustable frame stand
9. Wall / VESA mount
10. Security slot
2
6
4
7
5
9
10
1
3
8

PHOTO MUSIC
MENU
VOL+
VOL-
ENTER
SETUP
CALE
NDAR
ROTATE
+
5
Remote Control Close-Up
1
7
2
9
4
10
3
5
13
1. Power On/Off
2. Mode - Select between photo, music and video
modes
3. Return / Esc / Exit
4. Enter
5. Volume + / Volume -
6. Zoom In
7. Setup
8. Menu - Takes you to the main menu
9. Calendar
10. Up, Down, Left, Right Arrows - Use arrow keys
to navigate your way throught various menus
11. Fast Forward / Rewind
12. Rotate
13. Advance to Next / Advance to Previous
8
6
11
12
MOVIE

Getting Started
• Remove the protective lm covering the LCD.
• Remove the plastic insulator from the battery on the remote control.
6
Package Contents
Your order has been carefully packaged and inspected. The following should be included in
your package. Please inspect the contents of the package to ensure that you have received
all items and that nothing has been damaged. If you discover a problem, please contact us
immediately for assistance.
• Digital Photo Frame
• Remote Control
• USB 2.0 Cable (Type A to mini-B)
• Power Adapter
• Instructional Manual
• Warranty / Registration Card

7
Operating Instructions
Main Menu
• Turn on the digital frame using the power switch in the back of the frame or press and
hold the power button until the Aluratek startup screen is displayed if the switch is already
in the ON position.
• The On-screen Display (OSD) will show the Main Menu. Each icon represents the various
functions available on the device: Photo, Music, Video, Calendar, File and Setting.
• Browse the different functions using the ◄ or ► arrow buttons and select a function by
pressing the Enter button.
• Press the arrow to browse the various storage options, use the ◄ or ► arrow buttons
and select the option by pressing the Enter button.

8
Operating Instructions
Transferring Files from your PC/Mac to the Frame’s Internal Memory
• A USB cable is included with your digital frame to connect it to your PC/ MAC. Connect
the small connector to your digital frame and the larger connector to your PC / MAC.
• Once connected, the frame will display Connected to PC. On a PC, the frame’s
internal memory will appear as a removable drive when viewed in My Computer.
On a Mac, the frame will appear as a drive icon on the desktop.
• Copy your photo, video and music les from your PC / MAC into the icon representing
the frame’s internal memory. When nished disconnect the USB cable from the PC or
MAC. (Note: For a Mac, eject the drive icon before disconnecting the USB cable.)
• The frame will return to normal operation once it is disconnected from your PC / MAC.

9
Operating Instructions
Managing Files in the Digital Frame’s Internal Memory
1. Select File from the main menu.
2. A list of the les or folders contained on the storage source will be displayed. Browse
the les using the ▲ or ▼ buttons. Once the desired le is highlighted, press the
◄ or ► buttons to Copy / Delete the le.

10
Photo Function
Setup a Photo Slideshow
• Select the source of the photos you wish to present in the slideshow by selecting Memory
(Internal Memory), SD and USB storage options and pressing the Enter button.
• Navigate to the Photo function using the ◄ or ► arrow buttons and press the Enter
button to start the slideshow.
• During slideshow, press Setup button. This will provide you with the various options
to customize your slideshow. Browse the options using the ▲ or ▼ arrow buttons and
Enter button to conrm.
Photo Setup
• In Slideshow mode, you can enter the Photo menu by pressing the Setup button to set
the background music, display ratio, slideshow speed, slideshow effect, slide mode and
photo play sequence
• To exit, press the Menu button.

11
Video Function
Playing Videos
• Select the source of the videos you wish to play by selecting Memory (Internal Memory),
SD and USB storage options and pressing the Enter button.
• Navigate to the Video function using the ◄ or ► arrow buttons and press the Enter button.
• Select the video that you wish to view and press the Enter button.
• To skip to the next video, press the ▼ arrow button. To skip to the previous video, press
the ▲ arrow button.
• Adjust the volume of the video playing using the VOL+ or VOL- buttons.
• To exit, press the Menu button.

12
Video Function
Video Setup
• To customize how videos are played back, press the Setup button while a video is
playing. You may also access the menu by selecting Setup in the Main Menu. Browse
the options Display Ratio and Repeat Mode using the ▲ or ▼ arrow
buttons and Enter button to conrm.
• To exit, press the Menu button.

13
Music Function
Playing Music
• Select the source of the music les you wish to play by selecting Memory (Internal
Memory), SD and USB storage options and pressing the Enter button.
• Navigate to the Music function using the ◄ or ► arrow buttons and press the Enter button.
• Select the song that you wish to play and press the Enter button.
• To skip to the next song, press the ►►Iarrow button. To skip to the previous song,
press the I◄◄ arrow button.
• Adjust the volume of the song playing using the Vol+ or Vol- buttons.
• To exit, press the Menu button.

14
Music Function
Music Setup
• To customize how music played back, press the Setup button while the music is playing.
You may change the Repeat Mode by using the ▲ or ▼ arrow buttons.
• To exit, press the Menu button.

15
Calendar Function
Calendar Setup
• To congure custom settings for the Calendar, select the Setting function in the Main
Menu and press the Enter button. Then navigate to Time Setup using the ▲ or ▼
arrow buttons and press the Enter button.
• Use the arrow buttons to set the correct date, time and 12 / 24 mode.
• To exit, press the Menu button.

16
Auto On / Off Function
Auto On / Off Setup
• To congure Auto On / Off feature, select the Setting function in the Main Menu and
press the Enter button. Then navigate to Time Setup using the ▲ or ▼ arrow buttons
and press the Enter button.
• Use the arrow buttons to set the On / Off time and frequency.
• To exit, press the Menu button.

17
Alarm Function
Alarm Setup
• To set the Alarm, select the Setting function in the Main Menu and press the Enter button.
Then navigate to Time Setup using the ▲ or ▼ arrow buttons and press the Enter button.
• Use the arrow buttons to set the status, time of the alarm, the sound and the frequency.
• To exit, press the Menu button.

18
System Settings
Select the Setting functions on the Main Menu and press the Enter button. Then
navigate to System Settings using the ▲ or ▼ arrow buttons and press the Enter button.
• Use the arrow buttons to set the language, brightness, contrast, saturation, volume
and Start Up mode.
• To exit, press the Menu button.

19

20
If you need further assistance, please contact Aluratek support department prior to returning
this device.
E-mail: [email protected]
Web: www.aluratek.com/support
Local (Irvine, CA): 714-586-8730
Toll free: 1-866-580-1978
Technical Support
