System 600T Owners Guide
Internal Chassis
Controls/Connections
With the chassis removed from the mounting ring, you will notice
connections on the rear panel, next to the battery compartment. The
connection marked (1) OUTPUT is for the signal being sent to the
output jack. There are two INPUT jacks, labeled (2) PIEZO and
(3) AUX. The PIEZO input should already be connected to the under-
saddle bridge pickup. The AUX input is included for use with an
additional sound hole pickup, or internal microphone. A magnetic sound
hole pickup, or a miniature dynamic microphone may be connected to
this INPUT jack. An internal condenser microphone will also work, but
the System 600T does NOT supply phantom power. A separate “in-line”
battery must be used to power a condenser microphone.
On the side of the chassis are two
trim pots, labeled (4) LOW and
(5) HIGH. These trim pots are used
to adjust the gain of the BASS and
TREBLE sliders on the front panel.
These adjustments are used to “fine
tune” the System 600T to the sonic
characteristics of the particular guitar
being used.
(6) BATTERY
COMPARTMENT
The System 600T is powered by
a 9 Volt battery mounted in the
bottom of the control chassis.
Access the battery compartment by
removing the two front panel thumb
screws and lifting the chassis from the
mounting ring.
Refer to the front panel diagram on the next
page to familiarize yourself with the various
control functions of the Alvarez System 600T.
2
Contents
Internal Chassis Controls / Connections............................2
Diagram of System 600T ..................................................3
Digital Tuner Function ......................................................5
Specifications ....................................................................6
Congratulations!
You have choosen the finest acoustic
Preamp/Eq System available.
The Alvarez System 600T Preamp/Eq is designed to offer the finest
acoustic guitar tone reproduction available. The System 600T provides
a broad range of sonic control, mixing capability for different combina-
tions of piezo/magnetic/microphone transducers, and features on-board
digital chromatic tuner. We recommend that you take a few minutes to
read this manual in order to familiarize yourself with the many
advanced features and capabilities of the System 600T.
This guitar is equipped with a piezo pickup mounted under the bridge
saddle. This pickup is connected to the PIEZO input of the System
600T, and the guitar will perform perfectly with this pickup/preamp
combination. The System 600T is capable of mixing an additional
internal microphone or sound hole pickup with the piezo pickup for a
wider range of sonic possibilities. Some features of the System 600T
will only operate when an additional pickup/microphone is used.
1
5
4
5
4
2
3
6
System 600T booklet 6/14/00 4:52 PM Page 3

1) BAT Battery Indicator: When a guitar cable is connected to the
output jack, the BAT LED will light, and the System 600T preamp/Eq
functions are activated. (Please note that the digital tuner function can
be activated without connecting a
cable to the output jack). To prevent
excessive battery consumption,
unplug your cable from the output
jack when the System 600T is not in
use. When the battery is wearing out,
the LED will become dim, and the
signal will become distorted. If the
LED does not light, remove the chas-
sis and replace the battery.
2) PIEZO: This control adjusts the
level of the under-saddle bridge piezo
pickup.
3) AUX: This control adjusts the
level of the auxiliary input, either a
sound hole pickup, or an internally
mounted microphone.
4) LEVEL: This switch adjusts the
input level of the AUX input. When
using a magnetic sound hole pickup,
this switch should be set in the up,
or -20dB position. When an internal
microphone is used, this switch
should be set in the down,
or +20 dB position.
5) PHASE: This switch reverses
the polarity of the PIEZO input
relative to the AUX input. If the
polarities of the different inputs
are “out of phase”, a noticeable loss
of low frequencies (bass) will occur.
If there is a loss of fullness, or low end when two input signals are
mixed, reverse the position of this switch (In/Out) to correct the polarity.
Note: If only one input is used, this switch will have no effect.
6) TREBLE: This slider provides +/- 15 dB of boost/cut at 10kHz. In
its center position, there will be no effect.
7) BASS: This slider provides +/- 15dB of boost/cut at
100Hz. In its center position, there will be no effect.
8) MID: This slider works in conjunction with the MID
FREQ control. It provides +/- 15 dB of boost/cut at the
center frequency determined by the MID FREQ control.
9) MID FREQ: This control adjusts the center frequency
of the MID slider, variable from 600Hz to 1.2kHz. If the
MID slider is set to its center position, no effect will be
heard. Maximum effect of this control can be heard as the
MID slider is set for boost or cut.
Note: The main Eq system (TREBLE/MID/MID
FREQ/BASS) controls will only affect the piezo input signal.
These controls have no effect on the AUX input signal.
10) MASTER: This control is the Master Volume, which
adjusts the overall output of the System 600T, including both
the PIEZO and AUX inputs.
11) NOTCH: This switch engages a notch filter, which is
used to control feedback in live performance applications.
When the switch is in its IN (down) position a deep, narrow
band of frequencies is cut from the signal, depending on the
position of the FREQ control. This notch filter is located
“post Eq” in the circuit and will affect the combined PIEZO
and AUX input signals.
12) FREQ: This control adjusts the center frequency of
the “anti-feedback notch”. With the NOTCH switch engaged,
turn the MASTER control up until feedback is heard. Adjust
the FREQ control until the feedback disappears.
The Alvarez System 600T has been designed to accurately
reproduce the natural sound of an acoustic guitar when used
with a wide variety of sound reinforcement and recording
equipment. Sound is very subjective. We urge you to experiment with
the many control capabilities of the System 600T in order to “dial in”
the sound that is right for you.
8
12
11
10
1
7
3
5
4
2
3 4
System 600T Owners Guide
9
6
Front Panel Controls and Features
System 600T booklet 6/14/00 4:52 PM Page 5

Digital Tuner
The System 600T features a built-in chromatic digital tuner.
The tuning function can be accessed at any time, whether the guitar is
plugged in, or not. To engage the tuner, press the TUNER ON/OFF
switch located between the MID FREQ and MASTER control knobs. A
sequence of note indicator LED’s will light, indicating that the tuner is
functional. Plucking a string will result in a note indicator LED lighting
to represent the nearest pitch. Above the note indicator LED’s are a
center (Green) and left and right (Red) LED’s. When the note is flat
relative to the indicated pitch, the left (Red) LED will blink. If the note
is sharp, the right (Red) LED will blink. When the correct pitch is
achieved, the center (Green) LED will light. Repeat this procedure for
all strings. Pressing the TUNER ON/OFF switch will disengage the
tuner function. To prevent unwanted battery consumption, an automatic
“shut-off” feature will turn the tuner off after 3 minutes of use.
Note: When the guitar is connected to an amplifier, mixer, or PA
system, engaging the tuner will mute the output for silent tuning during
performance.
Specifications
Input Impedance: 2.2 M Ohm
Output Impedance: 1k Ohm
Frequency Response: 40Hz-15kHz, +/- 2 dB w/ Eq at center position
S/N Ratio: Greater than -90 dB
Amplification:
Piezo Input: +8dB
Aux Input: +20 dB (Level switch IN)
+37 dB (Level switch OUT)
Distortion: 0.05%
Power Consumption: 2.2mA (Tuner OFF)
8.5mA - 12.5mA (Tuner ON)
Power Supply: 9V
Controls: Master Volume
Piezo Gain
Aux Gain
Treble: +/- 15dB @ 10kHz
Mid: +/- 15dB
Mid Freq: 600Hz - 1.2kHz, Variable
Bass: +/- 15dB @ 100Hz
Notch Freq: 45 Hz - 2.2kHz, Variable
(Q: 12.5 @ 1kHz, 10 @ 300Hz)
Internal Trim Pots: High: +/- 5dB @ 10kHz
Low: +/- 5dB @ 100Hz
Switches: Tuner ON/OFF (Auto Power OFF in 3 minutes)
Notch IN/OUT
Aux Level IN/OUT
Piezo Phase IN/OUT
Connections: Piezo Input - 2.5mm Phone
Aux Input - 2.5mm Phone
Output - 2.5mm Phone
Dimensions: 106mm H x 58mm W
Weight: 170g w/ battery
