Amana ALW880QAW User manual

BUILT BETTER THAN IT HAS TO BE
Owner's Manual
Top Loading Washer
Keep instructions for future reference. Be sure
manual stays with washer.
Contents
Important Safety Information ................ 3
Starting the Wash ............................... 4
Cycles ................................................ 6
Dispensers .......................................... 7
Features, Hints, and Care ................... 8
Moving and Storage ............................. 9
Trouble Shooting ................................. 10
Warranty ............................................. 12

Thank you for buying an Amana washer!
Please take the time to complete the registration card and return promptly. If
registration card is missing, call Amana Consumer Affairs Department, When
contacting Amana, provide product information from serial plate found on lower
right hand corner of inner lid:
Model Number
Manufacturing (P) Number
Serial Number (S/N)
Purchase Date
Dealer Name
Dealer Address
Dealer Phone
Keep this manual and your sales receipt together in a safe place for
future reference or if warranty service is required,
For answers to questions or to locate an authorized servicer, call 1-800-NAT-
LSVC (1-800-628-5782) inside USA or 319-622-5511 outside USA. Warranty
service must be performed by an authorized servicer. Amana Appliances also
recommends contacting an authorized servicer if service is required after
warranty expires.
For more information on this and other Amana
products, visit our Web site
www.amana.com
or
call Consumer Affairs Department at
1-800-843-0304
Asure" Extended
Service Plan
Amana Appliances ollcrs long-term
service protection for this new washer.
Asure'" Extended Service Plan,
covering functional pans. labor, and
travel charges, is specially designed to
supplement a sm)ng warranty. Call 1-
800-528-2682 for information.
Parts and Accessories
Purchase replacement parts and
additional acccssories by phone.
To order accessories for your Amana
product, call 1-800-843-0304 inside
USA or 319-622 5511 outside USA.
Save Time and Money
If something seems unusual, please
check "'TroubleShooting" section,
which is designed to help you solve
problems before calling service. If you
have aquestion, write or call us
(include model number and phone
number) at:
Consumer Affairs DepartmentAmana
Appliances
2800 - 220th Trail
Amana, Iowa 52204
Ph# 1-800-843-0304
What You Need to Know
about Safety Instructions
Warningand Important Safety
Instructions appearing in this manual
are not meant to cover all possible
conditions and situations that may
occur. Common sense, caution, and care
must be exercised when installing,
maintaining, or operating washer.
Always contact your dealer, distributor,
service agent, or manufacturer about
problems or conditions you do not
understand.
Recognize Safety Symbols, Words, Labels
I_lb DANGER I
DANGER--Immediate hazards whichWILL resultin severe personal injury
or death.
I,_ WARNING I
WARNING--Hazards or unsafe practices which COULD result in severe
personal injury or death.
I _k CAUTION I
CAUTION--Hazards or unsafe practices whichCOULD result in miner
personal injury or productor property damage.
2

Important Safety Information
[WARNING
To reduce risk of fire, electric shock, serious injury, or death when using your
washer, follow these basic precautions;
1. Read all instructions before 11. Do not repair or replace any part
using washer.
2. Be sure washer is properly
grounded.
3. Do not wash articles that have
been cleaned in, washed in,
soaked in, or spotted with
gasoline, dry-cleaning solvents,
or other flammable or explosive
substances. Vapors could
ignite or explode.
4. Do not add gasoline, dry-
cleaning solvents, or other
flammable or explosive
substances to wash water.
Vapors could ignite or explode.
5. Do not store or use gasoline or
other flammable vapors and
liquids near this or any other
appliance.
6. Do not allow children to play on
or in washer. Close supervision
of children is necessary when
washer is used near children, a
safety rule for all appliances.
7. Before washer is removed from
service or discarded, remove
door to washing compartment
8. Do not reach into washer if
wash tub is moving.
9. Do not install or store washer
where it will be exposed to
water and/or weather.
f 0. Do not tamper with washer
controls.
of washer or attempt any service,
unless specifically recommended
in user-maintenance instructions
or in published user-repair
instructions that you understand
and have skills to carry out.
12. To reduce risk of electric shock
or fire, do not use extension
cords or adapters to connect
washer to electrical power
source.
13. Use your washer only for its
intended purpose: non-
commercial clothes washing.
14. Always disconnect washer from
electrical supply before
attempting any service.
Disconnect power cord by
grasping the plug, not the cord.
15. Install washer according to
Installation Instructions. All
connections for water, drain,
electrical power, and grounding
must comply with local codes
and be made by licensed
personnel when required.
16. To reduce risk of fire, do not use
washer to launder clothes which
have traces of any flammable
substance, such as vegetable
oil, cooking oil, machine oil,
flammable chemicals, thinner,
etc., or anything containing wax
or chemicals, such as mops and
cleaning cloths. Flammable
substances may cause fabric to
catch fire by itself.
]
17. Use only fabric softeners or
products to eliminate static that
are appropriate for automatic
washers.
18. Keep your washer in good
condition. Bumping or dropping
washer can damage safety
features. If damage occurs,
have washer checked by
qualified service technician.
19. Replace worn power cords and/
or loose plugs.
20. Loading door must be closed
whenever washer is agitating or
spinning. Do not bypass loading
door switch by permitting
washer to operate with loading
door open.
21. Always read and follow
manufacturer's instructions on
packages of laundry and
cleaning aids. Heed all
warnings or precautions. To
reduce risk of poisoning or
chemical burns, keep products
away from children at all times,
preferably, in a locked cabinet.
22. Never operate washer with
guards and/or panels removed.
23. Do not operate washer with
missing or broken parts.
24. Do not bypass safety devices.
Save These Instructions
3

Starting the Wash
If These Controls
are Different from
Yours
These controls are intended to
show the variety of features that are
available in the product line. If your
washer does not have all the options
that are shown, it is not a mistake. The
information provided applies to several
of the models in the product line.
TEMPERATURE
WASH/RINSE
WARM WARM
WARM COLD
HOT
COLD COLD
COLD
ENERGYSAVER
1. Prepare clothes for washing
For best wash results:
•Remove items from pockets and cuffs
• Close zippers and fasteners; mend rips and tears
• Sort items into separate loads
• Pre-treat stains and heavily soiled areas
2. Select WASH/RINSE temperature
Always follow garment manufacturer's care labels for each fabric. See
chart below.
WASH /RINSE TYPE OF CLOTHING
Hot/Cold Sturdy whites and colorfast items;
work clothes, soiled items, and cloth
diapers
Warm/Warm Delicate or colorfast items
Available on
some models
Warm/Cold - Moderately soiled permanent press,
silks, woolens, nylon, acrylic
Rinsing of some items
Cold/Cold - Non-colorfast items
Extra-delicate clothing
Rinsing of most items
NOTE: Energy Saver settings, marked with a dash (-), show
temperature settings that use the least energy.
LOAD SIZE
WATERLEVEL
MEDIUM LARGE
3. Select LOAD SIZE /WATER LEVEL
Variable control allows you to select the most appropriate setting for each
wash load. Do not fill above top row of holes in tub with clothes. Use Water
Level chart below to determine setting.
IMPORTANT: Do not hold knob at RESET for extended periods or washer
flooding may result.
QUICK WASH i
, SUPER
PLUS
RESET
LOAD SIZE WATER
LEVEL
Super Plus Max. Fill
Large 3/4- Full
Medium 1/2 - 3/4 Full
Small 1/2 Full
QUICK WASH
If you change your mind
and the LOAD SIZE
SETTING
If the tub is filling and you decide to
change the LOAD SIZE SETTING, you
must turn the knob to RESET before
changing the load size. The tub can
overfill it"you do not turn to RESET
first,
4

Starting the Wash (cont'd)
4. Select WASH/SPIN speed
Select wash/spin speed most appropriate to type of fabric in wash load.
See chart below.
WASH/SPIN LOAD TYPE
SPEED
Regular/Fast Sturdy fabrics needing maximum water extraction
Regular/Slow Sturdy fabrics needing slower spinspeed to reduce
wrinkling
Gentle/Fast Heavyloads of delicate fabdcs needing fast spin for
better water extraction
Gentle/Slow Delicatefabrics needing slower spin to protect fabric and
clothing
SPEED
WASH S_N
REG
REG GENTLE
SLOW FAST
5. Select wash cycle and time
Push timer knob in and turn to desired cycle and wash time. Timer knob
can be turned in either direction. Wash cycle and time selection depends
upon type of fabric and amount of soil. For best results when cleaning
heavily soiled items, use longer wash time, up to 15 minute maximum.
Lightly soiled items require less wash time. See "Cycles" section for
more information.
6. Select EXTRA RINSE, if desired
EXTRA RINSE is useful for people with detergent sensitive skin. It
provides a second rinse to more completely remove laundry additives,
suds, and perfumes in REGULAR, PERMANENT PRESS/KNITS, and
DELICATE cycles. To select, set switch to ON. Set switch to OFF if not
desired. EXTRA RINSE adds 10-15 minutes to total cycle time.
EXTRA RINSE
ON
--I
i '!
i ;
OFF
EXTRA SPIN (some models) should be used when washing heavier
items, like towels, that retain water. The extra spin extracts additional
water from the clothing and shortens drying times. To select, set switch to
ON. Set switch to OFF if not desired. EXTRA SPIN adds approximately 3
minutes to your total wash time.
7. Pull OUT timer knob to start
Water fill begins. Stop washer by pushing knob in.
Measure and add detergent to washtub
Use only detergent recommended for top-
loadingwashers.
Add clothing to water in washtub
• Clothes should fill wash tub but should
net be packed. Loosely fill tub with
clothes no higher than top row of
holes. Items must move freely through
wash/rinse water.
• Bulky fabrics may need more water
added after agitation begins. Turn Load
Size knob to RESET and back to
desired setting.
Close washer lid
Washer will not operate when lid is open.
SOAK
OFF
RINSE
HAND WASH
HEAVY NoRMAL
DOUBLE WASH t5 LIGHT
OFF REGULAR
RINSE
EXTRA RINSE
OFF
9 NORMAL
6 LIGHT
OFF _ IINSE
O;F
XTRA R_NSE
RINSE OFF
6 9 NORMAL
DELICATE LIGHT ....
PERMANENT
PRESS'KNITS
pULL KNO_, TO.START pUSH TO STOp
5

Cycles
If These Controls
are Different from
Yours
These controls arc intended
to show the variety of features that
are available in the product line. If
your washer does not have all the
options that are shown, it is not a
mistake. The intormation provided
applies to several of the models in
the product line.
What do the little
numbers mean?
Numbers next to cycle setting shows
the approximate total agitation time.
The total wash time includes periods
of soaking and is longer than the
agitation time.
SOAK (SOME MODELS)
Use for heavily soiled or stained
items. Washtub fills with water,
pauses approximately 12 minutes for
soaking, and spins water out to
complete cycle.
HAND WASH
(SOME MODELS)
Use for fine fabrics normally washed
by hand. To protect fragile fabrics,
washer speed automatically runs at
Gentle/Slow, regardless of position of
speed selector switch.
HEAVY NORMAL
OOUBLE WASH 15 9 _ LIGHT REGULAR
OFF
RtNSE
SOAK. _ bo_
OFF_ EXTRARINSE
R_NSE _ OFg
9 NORMAL
6 LIGHT
DELICATE
OFF
6
LfGHT
Pi_ R!',IANENT
PRE._b, KNITS
EXTRA RINSE
PUrL KNOB TOSTART PUSH TOSTOP
QUICK WASH
(SOME MODELS)
OFF Use for a small load of lightly soiled items that
needs to be washed quickly. QUICK WASH has
a shortened cycle with a light period of agitation.
It then automatically sets to a fast spin speed to
help shorten drying times. The total cycle time is
approximately 15-20 minutes.
REGULAR
Use for sturdy items, like play or
work clothes, towels, T-shirts, etc.
DOUBLE WASH
DOUBLE WASH automatically
advances into the REGULAR wash
cycle. Use to wash heavily soiled
clothes twice with detergent in
each cycle.
Todeliver extra detergent,
•LIQUID DETERGENT: place in
fabric softener dispenser for use
in second wash. DO NOT use
dispenser for fabric softener.
• POWDER DETERGENT: place
extra detergent in tub for use in
first wash; recommend
approximately 1V2times normal
amount.
PERMANENT
PRESS/KNITS
Use for clothes that recommend a
permanent press cycle and other
synthetics.
DELICATE
Use to wash delicate items often
washed by hand. Even with small
loads, full tub of water is recom-
mended so items can move freely
for more complete cleaning. More
water also helps reduce fabric wear
and wrinkling. To protect delicate
fabrics, washer speed automati-
cally runs at Gentle/Slow, regard-
less of position of speed selector
switch.

Dispensers
Bleach Dispenser
Bleach dispenser is located in left
front corner under loading door.
Bleach
dispenser
I
Use only liquid bleach in
dispenser. To use powdered
bleach, add to wash tub with
detergent.
Carefully pour recommended amount
of bleach into dispenser during first
washer fill. See table.
Be careful not to spill undiluted
bleach. It is a strong chemical and
can damage cabinet finishes and
some fabrics if not properly diluted.
Follow bleach manufacturer's label for
proper use.
LOAD SIZE BLEACH
(Max Amt.)
SUPER PLUS 1 cup
LARGE 1 cup
MEDIUM 3/4 cup
SMALL 1/2 cup
Fabric Softener
Dispenser
Fabric softener dispenser is
located on top of agitator.
Dispenser automatically releases
liquid fabric softener at proper time
during rinse cycle.
To use dispenser, follow these steps:
1. Pour liquid fabric softener into dispenser, using amount recommended
on package.
Fabric
so_ener
dispenser
2,
Fabric Softener Use Tips
•Liquid fabric softeners are
dispensed during final rinse. Do
not combine with bleach, bluing,
starch, detergents, soaps, or
packaged water conditioners
during rinse.
• Do not use fabric softener in
dispenser during DOUBLE WASH
cycle.
• Do not mix powdered detergent
with liquid softener in dispenser or
softener will become gummy.
,
Add water up to fill level, but do not exceed tip of fill arrow indicator.
FABRIC SOFTENER MUST BE DILUTED FOR USE.
•Do not stop washer during first spin or dispenser will empty too
soon.
• Never pour fabric softener directly onto clothes or spots and stains
may result. To remove softener stains, soak in soapy solution of
Sard TM Wonder Soap or IvoryTM soap, or rub stain with bar of Sard TM or
Ivory TM soap and wash garment as usual.
• For best softener performance, set water level to medium or higher.
Clean softener dispenser after
each use. Remove dispenser
housing from agitator by
squeezing lower part ofdispenser
and pulling up on housing while
tilting slightly to expose
dispenser cup. Rinse dispenser
housing and cup in hot soapy
water.
Clean funnel shape in top of
agitator and inside of agitator. Use small brush on hole and slots in two
funnel rings for thorough cleaning.
After cleaning, re-install dispenser cup. Push dispenser housing
directly down onto top of agitator until firmly snapped together.
To prevent build-up, fill dispenser with clean water inwash cycles when
not using softener.
7

Features, Hints, and Care
Follow the Colors
Your washer control pane[ is color
coordinated fur your convenience
When yon set your was controls, notict,
which colors are the same. They will
help guide you through setting the
controls.
Need more Time? Reset
the Timer Knob.
Although wash cycles are automatic,
timer may be reset to lengthen, shorten,
or repeat a portion of a cycle.
To set or reset timer, push in timer knob
to stop washer. Hold in timer knob
firmly while slowly turning it to desired
setting. Pull out timer knob to start
washer.
Stops and Starts
Wash action consists of periods of
agitation, with pauses or periods of
soaking. For best results, do not turn
timer through pauses, which are normal
part of wash cycles.
Cleaner Clothes
Water temperature affects how clean
clothes become. If your clothes are not
as clean as you would like, check your
water heater temperature. You may need
to turn your water temperature up to
140°E Also, check that your water
hoses are hooked up correctly. If they
are switched you might be getting cold
water in your warm and hot cycles.
Hard water does not remove soil as
well as soft water. Check with your local
water company to see if you have hard
water. If you have hard water, try
softening it with a packaged
conditioner or use a little more
detergent,
Risers
Risers or air cushions may be installed
if pipes knock or pound when flow of
water stops. Risers are more efficient
when installed as close as possible to
water supply faucets.
Lint Filter
Amana's self cleaning lint filter works throughout the wash cycle to constantly
remove lint and other residue from the water. Located between the outer and
inner tub, the lint filter removes lint as water passes from the bottom of the
outer tub back to the inner tub. As water passes from the outer tub to the
inner tub, water is forced through the bottom of the lint filter. The filter traps
lint under the filter until the spin cycle begins. During the spin cycle
centrifugal force removes the lint by pulling it off the bottom of the filter and
washing it down the drain.
Motor Overload Protector
Internal overload protector automatically stops motor in event of overload.
Overload protector resets in approximately 3 minutes and motor automatically
restarts. If overload protector stops motor again, stop using washer and call
service technician. Loading wash tub too full may result in motor overload.
Automatic Balance System
Your new washer will automatically adjust to unbalanced loads without
shutting down or interrupting the cycle. The cycle will automatically complete
at the fastest spin speed possible.
In a severe out-of-balance condition, clothes may
contain excessive moisture. If this should happen,
simply redistribute the clothes, and reset the control to
the spin mark after the rinse setting in the regular cycle. Spin mark
Safety Lid Switch
The washer will not spin when the lid is open for any reason. This is for your
personal safety. If the lid is opened mid-cycle, operation will automatically
start when lid is closed.
General Washer Care
•Use only damp or sudsy cloth for cleaning control panel. Some cleaning
product sprays may harm control panel finish or may damage interior of
hood.
• Wipe washer cabinet as needed. If detergent, bleach, or other washing
products are spilled on cabinet, wipe immediately. Some products will
cause permanent damage if spilled on cabinet.
• Top of washer should not be used for removing garment stains. Some stain
removers, such as rust remover, may damage cabinet finish.
• Do not use scouring pads or abrasive cleansers.
• Do not lay sharp or rough objects on or against washer. Finish could be
damaged.
• Remove pins, buckles, or other sharp objects from clothes to prevent
scratching interior parts.
• Leave lid open after use to allow inside of washer to dry, and to help
prevent musty odors from developing.
•Do not allow small children to play on or around washer.
• Do not move washer without reinstalling shipping brace (Part #39365) and
shipping plug (Part #38149). See Moving Washer to New Location section.

Moving and Storage
Cold Storage and Non-Use Periods
1WARNING
Explosive hydrogen gas may be produced in a hot water system that
has not been used for two weeks or more. Before using washer, if
hot water system has not been used for such a period, turn on all hot
water faucets and let water flow for several minutes to release
accumulated hydrogen gas. Hydrogen gas is flammable: Do not
smoke or use an open flame when flushing water lines.
Cold Weather Care
Vacations and
Extended Non-Use
IMPORTANT: To avoid possible
property damage from flooding, turn
off water supply to washer during
extended periods of non-use.
To prevent mold or mildew, leave lid
open so moisture inside machine can
evaporate.
When closing your home for extended
periods, have service technician drain
washer to avoid stagnant water.
Unplug cord from electrical outlet.
Disconnect hoses from faucets.
ifwasher is delivered when outside temperature is below freezing or if washer
is stored in unheated room or area during cold months, do not operate until
washer has warmed to room temperature. Do not install or operate
washer where temperatures will drop below freezing.
Cold Weather Storage
If washer must be stored in seasonal home or storage building, use one of the
following storage methods.
METHOD 1
1. Turn off water supply faucets and disconnect hoses. Drain water from
both hoses.
2. Add one gallon of non-toxic RV antifreeze (available from hardware or
recreational vehicle dealers) to washer tub.
3. Push in cycle selector knob and turn to SPIN.
4. Pull knob out and let washer spin for 1-2 minutes to drain water. Some
antifreeze will also be lost. (If you have a septic system, contact
antifreeze manufacturer and make sure it will not harm system.)
5. Push in cycle selector knob to stop washer. Dry inner wash tub,
disconnect electrical plug, and close washer lid. If moving washer,
disconnect drain hose. Move and store washer ONLY in upright position.
To remove antifreeze after storage, run washer through a complete cycle
using 1/2cup of detergent. DO NOT ADD CLOTHES TO CYCLE.
METHOD 2
1. Push in cycle selector knob and turn to SPIN. Run through complete
spin cycle to remove excess water.
2. When spin cycle is complete, push in cycle selector knob to stop
washer.
3. Turn off water supply faucets and disconnect hoses. Drain water from
both hoses.
4. Dry inner wash tub, disconnect electrical plug, and close washer lid. If
moving washer, disconnect drain hose. Move and store washer ONLY in
upright position.
5. It is normal for some water to remain inside pump. To prevent damage to
washer and pump if remaining water freezes, allow washer to warm to 24
to 48 hours after removing from storage, so water can thaw before use.
Moving Washer to
New Location
Replace shipping plug under motor
and shipping brace in tub. Refer to
Installation Instructions for proper
procedures whenever washer is
moved. See illustration.
Shipping
brace
Shipping
plug and
location
in washer
Tilt washer back slightly
and slide shipping
plug into position
under washer

Trouble Shooting
You may save time and money by checking items below before calling for service. List includes common concerns that
are not the result of defective workmanship or materials. If your question is not explained below, contact Amana
Consumer Affairs Department at 800-843-0304.
TOPIC POSSIBLE CAUSE SOLUTION
NO,SE
Gear sounds or a low hum Normal mechanical sounds in commercial- Normal operation,
quality washer
Rattling and clanking noise Loose objects, such as coins or pins, in tub Stop washer and check tub. Remove loose objects. If noise
or pump continues after washer is restarted, objects may be in
pump: call your authorized servicer.
Belt buckles, metal fasteners hitting wash tub Close zippers, buttons, and fasteners, Clothing with
buckles must be turned inside out.
Squealing sound or hot Overloaded wash tub Do not overload washer, Stop washer and reduce size of
rubber odor load.
Thumping sound Heaw wash loads; unbalanced loads Usually normal, but unbalanced loads should be
redistributed. Stop washer and rearrange load.
Vibrating noise Washer not resting firmly on floor Make sure floor is strong enough for washer. Adjust
leveling legs so washer rests firmly on floor See
Installation Instructions for leveling details.
Wash load distributed unevenly in tub Stop washer and rearrange load.
Shipping plug not removed during installation See Installation Instructions for details on removing
shipping plug.
Water splashing or slapping Spray rinse Normal operation. Washer sprays water inside tub while
noise running at high speed during rinse and spin.
Whistling or whirring noise Drum spinning without cloths Normal operation. Holes in the tub can cause this sound.
OPERATION _
Washer does not start Electrical power cord may not be plugged in, Make sure plug from power cord fits tightly into wall outlet.
or connection may be loose
Fuse blown, circuit breaker tripped, or power Replace fuse or reset circuit breaker. De NOT increase
outage occurred fuse capacity. Call qualified electrician to correct circuit
ovadoed problem. Call local utilitycompany to correct
power outage.
Water supply faucets not turned on Tum on water supply faucets.
Timer knob/cycle selector set incorrectly Move indicator slightly clockwise. Pull out on timer knob.
Motor overheated Internal overload protector automatically stops motor in
event of overload. Protector resets in approximately 3
minutes and motor automatically restarts. If ovedoad
protector stops motor again, quit using washer and call
service technician.
Do not overload washer. Largest dry load level should not
be higher than bottom of fabric softener dispenser or top of
agitator.
Washer won't spin Lid partially open Close lid completely.
Residue left In tub Heavily soiled items Wipe tub with non-abrasive household cleaner and dnse.
Before washing, shake or brush excess dirt and sand from
items.
10

Trouble Shooting (cont'd)
TOPIC
WATER
POSSIBLE CAUSE SOLUTION
Wash load too wet after spin Overloaded wash tub Do not overload washer.
Unbalanced load Rearrange load to allow proper spin.
Kinked drain hose Straighten drain hose.
Water enters slowly or does Inadequate main water supply Check water pressure at another faucet in house. Wait for
not enter washer water supply and pressure to increase.
Water supply faucets partly closed Fully open hot and cold water supply faucets.
Water being used elsewhere in house Water pressure must be at least 20 psi (138 kPa). Avoid
running water elsewhere when washer is filling.
Clogged water inlet filters Disconnect water fill hoses from faucet. Clean and
reposition screen filters. Reconnect water fill hoses,
Kinked water inlet hoses Straighten hoses.
Water level does not cover Incorrect water leveFIoad size selection Select higher water level/load size. Add water by turning
clothes selector to RESET and back to larger load size.
Overloaded wash tub Do not overload washer. Largest dry load level should not
be higher than bottom of fabric softener dispenser or top of
agitator.
Warm or hot water not hot Water heater temperature set too low; water Use candy/meat thermometer to measure hot water
enough heater too far from washer temperature at nearby faucet. Water temperature should
be at least 140°F (60°C) Adjust water heater as
necessary.
Hot water being used elsewhere in house Avoid using hot water elsewhere before or during washer
use, or there may not be enough hot water for proper
cleaning. If problem continues, enlarge capacity of hot
water system, or use for only one application at a time.
Water drains slowly or does Drain hose kinked or clogged Clean and straighten drain hose.
not drain
Water leaks Loose fill hose connections Check and tighten all hose/faucet connections. Install
rubber sealing washers provided.
Clogged drain pipes Unclog drain pipes. Call plumber if necessary.
Changed water levels dudng fill Always use RESET on water level switch when changing
water level. Do not hold switch at RESET; return switch to
desired load size,
Oversudsing Use less detergent.
Incorrect wash and rinse Hot and cold water hoses connected to Check hose connections. Connect hot water hose to hot
temperatures wrong supply faucets water faucet; connect cold water hose to cold water faucet.
Water enters washer, but tub Incorrect standpipe height for drain hose Recommended standpipe height is 36" (91.44 cm); for low
does not fill standpipes, install Siphon Break Kit (part #562P3). See
/nsta//ation Instructions for details.
11

Amana Washer Warranty
Full ONE Year Warranty
For one (1) year from the date of original retail purchase, Amana will repair or replace any part that fails due to a
defect in materials or workmanship.
Limited Warranty
After one year from the date of original retail purchase, Amana will provide a free part, as listed below, to replace
any part that fails due to a defect in materials or workmanship. The owner will be responsible for paying all other
costs including labor, mileage, and transportation.
Second through Third Year
Amana will provide any part.
Third through Fifth Year
Amana will provide the drive motor or timer.
Third through Tenth Year
Amana will provide the transmission assembly and seal kit.
Amana will provide the outer tub assembly.
Amana will provide the cabinet assembly should the part rust through.
Amana will provide the outer wash tub should the part fail to contain water.
Lifetime
Amana will provide the inner wash basket.
What is not covered by these
warranties
•Replacement of household fuses, resetting of circuit
breakers, or correction to household wiring
or plumbing.
Products with original serial numbers removed,
altered, or not readily determined.
Products purchased for commercial, industrial,
rental, or leased use.
• Products located outside of the United States
or Canada.
Premium service charges, if the servicer is
requested to perform service in addition to normal
service or outside normal service hours or area.
• Adjustments after the first year.
• Damage to clothing.
Repairs resulting from the following:
• Improper installation or maintenance.
• Any modification, alteration, or adjustment not
authorized byAmana.
• Accident, misuse, abuse, fire, flood, or
acts of nature.
•Connections to improper electrical current,
voltage, or supply.
To Receive Warranty Service
Service must be performed by an authorized Amana
service representative. To schedule service, contact the
Amana dealer where you purchased your appliance or
contact Amana Appliances Factory Service.
Amana Appliances Factory Service
1-800-628-5782 inside USA
For more information,
Amana Appliances Consumer Services
Amana Appliances
2800 220th Trial
Amana, Iowa 52204
1-800-843-0304 inside USA
[phone] worldwide
When contacting Amana Appliances please
include the following information:
• Your name, address, and telephone number.
• Model number and serial number of your appliance
(found on inside of lidin the bottom right corner).
• The name and address of your dealer and the date
of purchase.
• A clear description of the problem.
• Proof of purchase (sales receipt).
IN NO EVENT SHALL AMANA BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES.
This warranty gives you specific legal rights, and you may have others which vary from state to state. For example, some states
do not allow the exclusion or limitation of incidental or consequential damages, so this exclusion may not apply to you.
Amana Appliances Online • http:/Iwww.amana.Com
Part No. 40068302 © 1999 Amana Appliances
Printed in U.S.A. 8/99 Amana, Iowa 52204
