AmazonBasics B07TWLF9Z2 User manual

Compound Binocular Microscope
Microscopio Binocular Compuesto
Microscope Composé Binoculaire
B07TWLF9Z2
180
140
120
100
8 0
160
0
170
160
150
140
130
120
110
100
180
190
0
10
20
30
40
50
10
0
60
70
65
75

English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Español . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Français . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

3
180
140
120
100
8 0
160
0
170
160
150
140
130
120
110
100
180
190
0
10
20
30
40
50
10
0
60
70
65
75
J
H
I
G
F
C
D
E
A
B
K
L
M
P
N
Q
R
S
U
O
T
AH
AG

4
V
Z
W X Y
AA
AB
AC
AD
AE
AF

5
EN
Parts Description
AEyepiece cover RPower switch
BDiopter adjustment SLocking set
CInterpupillary distance
adjustment TCondenser diaphragm
DHead UCondenser vertical
adjustment knob
ENose piece V4x objective lens
FStage clip W10x objective lens
GStage X40x objective lens
HCondenser Y100x objective lens
ITransmitted light lamp Z10x eyepiece x2
JBase AA 20x eyepiece x2
KArm AB Color filter (green)
LCoarse adjustment knob AC Dust cover
MFine adjustment knob AD Mirror
NX-axis translation control AE Mirror stand
OY-axis translation control AF
Detachable power cord with
plug
PPower socket AG Condenser locking screw
QBrightness adjustment wheel AH Stage clip locking screws

6
EN
IMPORTANT SAFEGUARDS
Read these instructions carefully and retain them for future use.
If this product is passed to a third party, then these instructions
must be included.
When using electrical appliances, basic safety precautions should always
be followed to reduce the risk of fire, electric shock, and/or injury to
persons including the following:
WARNING It is prohibited to disassemble the machine.
WARNING Risk of serious injury! Dyes are harmful by inhalation,
harmful in contact with skin, harmful if swallowed.
Methylene Blue Dye: Avoid eye and skin contact. Causes serious eye
irritation. Do not swallow. Do not inhale.
First aid in case of eye contact: Immediately flush eyes with
excess water for 15 minutes, lifting lower and upper eyelids
occasionally. Remove contact lenses if wearing any. Get
medical attention if irritation develops.
First aid in case of skin contact: Immediately flush skin with
excess water for 15 minutes while removing contaminated
clothing. Get medical attention if irritation develops.
First aid in case of ingestion: Do not induce vomiting
without medical advice. Consult a physician if necessary.
NOTICE Methylene Blue dye has been classified by the International
Agency for Research on Cancer (IARC) as Group 3: Not classifiable as
carcinogenic to humans.
NOTICE Use the product within the correct ambient conditions to
avoid mildewing and damage.
• Keep the work area clean, clear and away from any food storage.
Prepare the slides in a well-lit area and close to a water supply. Use a
solid table with a heat-resistant top.
• Do not allow dyes to come into contact with any part of the body
particularly mouth and eyes.
• Do not eat, drink or smoke in the work area.
• Clean all the accessories and the work area after each use.
Wash hands thoroughly after handling and carrying out
experiments.

7
EN
• A separate tin or bucket should be used for the disposal of specimen
samples and dyes. Any wasted solution should be poured directly
down a drain, but never into a sink basin.
• Dispose of used specimen samples a household trash immediately
after use.
• Do not discard any equipment into the fire to avoid violent
combustion or explosion.
• If the product has to be moved, carry with one hand holding the
product at the arm and another hand supporting it at the base.
• Examine the set regularly for potentially unsafe conditions, such as
damaged housing, or parts. In the event of such damage, the set
should not be used until it is properly repaired.
• Store the set in its original packaging out of reach of children and
animals.
Grounding Instructions
This product must be grounded while in use to protect the operator
from electrical shock. The appliance is equipped with a 3-conductor
cord and a 3-prong grounding-type plug to fit the proper grounding-type
receptacle. The appliance has a plug that looks like sketch A in the figure
below. An adapter, sketch B, should be used for connecting sketch-A
plugs to two-prong receptacles. The grounding tab which extends
from the adapter must be connected to a permanent ground such as a
properly grounded outlet box as shown in sketch C using a metal screw.
Grounding prong
Circuit grounding conductor
connected properly
Metal
mounting
screw
Cover of grounded outlet box
Adapter
Grounding means
A
B
C

8
EN
Symbols Explanation
~Alternating current (AC).
Health advice for emergencies.
Wash hands before and after experiments.
Safety warning. Improper use of the product could result
in injury or death.
Intended Use
• This product is for private use, home schooling, school applications
and teaching demonstrations. It is not for commercial use.
• This product is intended to be used in dry indoor areas only.
• No liability will be accepted for damages resulting from improper use
or non-compliance with these instructions.
Before First Use
• Check the product for transport damages.
DANGER Risk of suffocation! Keep any packaging materials away
from children – these materials are a potential source of danger, e.g.
suffocation.
Assembly
180
140
120
100
8 0
160
0
170
160
150
140
130
120
110
100
180
190
0
10
20
30
40
50
10
0
60
70
65
75
170
160
150
140
130
180
190
D
K

9
EN
• Remove the cover on the base of the head (D).
• Remove the cover on the top of the arm (K).
• Connect the two pieces together.
• Fasten the head (D) using the screw on the arm (K).
20
180
1 6 0
140
120
0
10
170
160
150
140
130
120
110
100
180
190
0
10
20
30
40
50
10
0
60
70
65
75
E
X
W
Y
V
• Attach the objective lenses (V, W, X, Y) in a clockwise sequence
according to increasing magnification power onto the nose piece (E).
Light source option
20
180
1 6 0
140
1 2 0
0
10
170
160
150
140
130
120
110
100
180
190
0
10
20
30
40
50
10
0
60
70
65
75
AD
AE
I

10
EN
To use the mirror instead of the transmitted light lamp (I):
• Attach the mirror (AD) onto the mirror stand (AE)
• Unscrew the diffuser of the transmitted light lamp (I) from the base.
• Screw the mirror stand (AE) onto the base.
NOTICE Using the mirror does not require electrical connection.
Operation
Switching on/off
• Connect the power cord (AF) to a power outlet and the other end to
the power socket (P).
NOTICE To prevent the bulb in the lamp (I) from burning, turn the
brightness adjustment wheel (Q) setting to the lowest before turning on
or off.
• Flip the power switch (R) to “I” to turn on the lamp (I).
• After use, flip the power switch (R) to “O” to turn off.
Calculating magnification power
Total magnification power is calculated by multiplying the magnification
power of the eyepiece and the objective lens.
Eyepiece
magnification power
Objective lens
magnification power
Total magnification
power
10x (Z)
4x (V) 40x
10x (W) 100x
40x (X) 400x
100x (Y) 1000x
20x (AA)
4x (V) 80x
10x (W) 200x
40x (X) 800x
100x (Y) 2000x

11
EN
Observing through the microscope
20
180
1 6 0
140
1 2 0
0
10
170
160
150
140
130
120
110
100
180
190
0
10
20
30
40
50
10
0
60
70
65
75
20
180
1 6 0
140
1 2 0
0
10
170
160
150
140
130
120
110
100
180
190
0
10
20
30
40
50
10
0
60
70
65
75
Z
L
O
Q
N
L
AA
G
F
• Remove the eyepiece covers (A) and place in eyepieces (Z/AA).
• Turn the coarse focus knob (L) to adjust the height of the stage (G) to
the lowest position.
• Rotate the nose piece (E) to the lowest magnification power setting.
NOTICE Start with the lowest magnification power every time a
new slide is placed on the stage (G). Most observations are made at low
magnification power.
• Clip a slide (not included) onto the stage (G), securing with the stage
clip (F).
• Without looking into the eyepiece (Z/AA), turn the coarse focus knob
(L) until the objective lens is close to the slide. The objective lens
should not touch the slide.
• Adjust the position of the slide using the X and Y translation controls
(N, O).
NOTICE If the lamp (I) is used, adjust the brightness of the lamp (I)
using the brightness adjustment wheel (Q).

12
EN
H
AB
NOTICE To use the color filter (AB), slide open the base of the
condenser (H) and place the color filter (AB) inside.
• Look into the left eyepiece (Z/AA), rotate the fine focus knob (M) and
the left diopter adjustment (B) slowly until the image is clear. Adjust
the position of the slide if needed.
CAUTION Risk of damage! Never force the adjustment knobs
(M), (L) and, (U) to turn further once the knob is already restrained from
turning. It may cause friction and scratch the lenses.
• The condenser (H) is adjusted to focus the light unto the specimen.
Tinker around with the condenser (H)’s vertical knob (U), diaphragm
(T), and the locking screw (AG) to achieve the sharpest image.
NOTICE The condenser diaphragm (T) gathers the available light
and concentrates it to illuminate over the specimen with uniform intensity.
• Look into the right eyepiece (Z/AA), rotate the right diopter
adjustment (B) until the image is clear.
60
50
40
30
55 70 75
60
50
40
30
65 70 75
C

13
EN
• Look into both eyepieces (Z/AA), adjust the distance of the
interpupillary distance adjustment (C) until the two images merge
intoone.
NOTICE After focusing, there is an option to push up the locking set
(S) to keep the adjustment knobs (L, M) in place.
• Rotate the nose piece (E) to the next objective lens, increasing in
magnification power. Re-adjust the focus using the fine focus knob
(M) if needed.
• After using the microscope, remove the slide from the stage (G), take
off the eyepieces (Z/AA) and place the eyepiece covers (A) back on.
• Turn to minimum the adjustment wheel (Q).
• Switch off (R) and disconnect the power cord (AF) from the power
outlet.
• Clean the work area and dispose of the used specimens.
Cleaning and Maintenance
CAUTION Risk of electric shock! To prevent electric shock,
unplug the product before cleaning.
CAUTION Risk of electric shock! During cleaning do not immerse
the product in water or other liquids. Never hold the product under
running water.
Cleaning
• To clean the lenses (V, W, X, Y, Z, AA), only use lens cleaning tissues.
Do not use cloth, paper or hands. Rotate the objective lenses (V, W,
X, Y) counter-clockwise to remove them from the nose piece (E).
• To clean the product, wipe with a soft, slightly moist cloth.
• Never use corrosive detergents, wire brushes, abrasive scourers,
metal or sharp utensils to clean the product.
Maintenance
• After each use, place the dust cover (AC) on the microscope. Place
the accessories back into their respective plastic bags to prevent
dust from collecting.
• Slight greasing or putting oil may be needed for the mechanical
moving parts. Apply the appropriate oil discreetly.
• Keep the product and its accessories within the required ambient
temperature and humidity to avoid mildewing.

14
EN
FCC – Supplier’s Declaration of Conformity
Unique Identifier B07TWLF9Z2 - Compound Binocular
Microscope
Responsible Party Amazon.com Services, Inc
U.S. Contact Information 410 Terry Ave N.
Seattle, WA
98109, United States
Telephone Number [phone]
FCC Compliance Statement
1. This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
2. Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
FCC Interference Statement
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio / TV technician for help.
Canada IC Notice
• This Class B digital apparatus complies with Canadian
CANICES-3(B) / NMB-3(B) standard.

15
EN
Specifications
Voltage input: 100-240V~, 50/60Hz
Fuse rating: T250V 500mA
LED lamp S-LED W1
Magnification power range: 40x to 2000x
Objective conjugate distance: 7.6" (195 mm)
Stage movement range: 2.95 x 1.96" (75 × 50 mm)
Coarse focusing range: 1.1" (28 mm)
Fine focusing range: 1.1" (28 mm)
Fine division step: 0.002 mm
Condenser N.A.: Abbe 1.2
Diameter of filter: Ø 1.25" (32 mm)
Working temperature: 50 to 104°F (10 to 40°C)
R.H. range: 30 to 75%
Net weight: approx. 24.2 lbs (11 kg)
Dimensions (W x H x D): approx. 9.53 x 14.76 x 7.09"
(24 x 37.5 x 18cm)
Feedback and Help
Love it? Hate it? Let us know with a customer review.
AmazonBasics is committed to delivering customer-driven products
that live up to your high standards. We encourage you to write a review
sharing your experiences with the product.
amazon.com/review/review‑your‑purchases#
amazon.com/gp/help/customer/contact‑us

amazon.com/AmazonBasics
V01-08/19
MADE IN CHINA
HECHO EN CHINA
FABRIQUÉ EN CHINE
