AmazonBasics AB2019MW001 User manual

Read this manual carefully before installing or operating your new refrigerator.
Make sure to save this manual for future reference.
Important Note:
Microwave Oven - 20 L Solo
AB2019MW001
INSTRUCTION MANUAL

Table of Contents
Precautions to avoid possible exposure
to excessive microwave energy 04
Addendum 04
Important safety instructions warning 05
To reduce the risk of injury to persons 06
Grounding Installation 06
Important safety instructions warning 07
Utensils 07
Caution! 07
Materials you can use in microwave oven 08
Materials to be avoided in microwave oven 09
Setting up your oven 09
Names of oven Parts and Accessories 09
Turnable Installation 10
Countertop Installation 10
Installation 11
Operation 12
Control Panel and Features | Operation Instructions 12
Troubleshooting 13
AmazonBasics e-waste Program 14

Precautions to avoid possible exposure
to excessive microwave energy
5
(a) Do not attempt to operate this oven with the door open since this can result in harmful exposure to microwave energy. It is
important not to break or tamper with the safety interlocks.
(b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on
sealing surfaces.
(c) WARNING: If the door or door seals are damaged, the oven must not be operated until it has been repaired by a
competent person.
Specifications
Precautions to avoid possible exposure to excessive microwave energy
Addendum
If the apparatus is not maintained in a good state of cleanliness, its surface could be degraded and affect the lifespan of the
apparatus and lead to a dangerous situation.
Addendum
Model:
Rated Voltage:
Rated Input Power(Microwave):
Rated Output Power(Microwave):
Oven Capacity:
Turntable Diameter:
External Dimensions:
Net Weight:
AB2019MW001
230 V~ 50 Hz
1050 W
700 W
20 L
Ø255 mm
440x330x259 mm
Approx. 9.74 kg

Important safety instructions warning
5
Important safety instructions warning
To reduce the risk of fire, electric shock, injury to persons or exposure to excessive microwave oven energy when using your
appliance, follow basic precautions, including the following:
1. Read and follow the specific:"PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY".
2. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children unless they are older than 8 and supervised. Children less than 8 years of age shall
be kept away unless continuously supervised.
3. Keep the appliance and its cord out of reach of children less than 8 years.
4. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to
avoid a hazard.( For appliance with type Y attachment)
5. WARNING: Ensure that the appliance is switched off before replacing the lamp to avoid the possibility of electric shock.
6. WARNING: It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves
the removal of a cover which gives protection against exposure to microwave energy.
7. WARNING: Liquids and other foods must not be heated in sealed containers since they are liable to explode.
8. When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition.
9. Only use utensils that are suitable for use in microwave ovens.
10. If smoke is emitted, switch off or unplug the appliance and keep the door closed in order to stifle any flames.
11. Microwave heating of beverages can result in delayed eruptive boiling, therefore care must be taken when handling the container.
12. The contents of feeding bottles and baby food jars shall be stirred or shaken and the temperature checked before consumption,
in order to avoid burns.
13. Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they may explode, even after
microwave heating has ended.
14. The oven should be cleaned regularly and any food deposits removed.
15. Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the life of
the appliance and possibly result in a hazardous situation.
16. The appliance must not be installed behind a decorative door in order to avoid overheating. (This is not applicable for appliances
with decorative door.)
17. Only use the temperature probe recommended for this oven.(for ovens provided with a facility to use a temperature-
sensing probe.)
18. The microwave oven shall not be placed in a cabinet unless it has been tested in a cabinet.
19. The microwave oven must be operated with the decorative door open. (for ovens with a decorative door.)
20. This appliance is intended to be used in household and similar applications such as:
-staff kitchen areas in shops, offices and other working environments;
-by clients in hotels, motels and other residential type environments;
-farm houses;
-bed and breakfast type environments.

Important safety instructions warning
Important safety instructions warning
21. The microwave oven is intended for heating food and beverages. Drying of food or clothing and heating of warming pads,
slippers, sponges, damp cloth and similar may lead to risk of injury, ignition or fire.
22. Metallic containers for food and beverages are not allowed during microwave cooking.
23. The appliance shall not be cleaned with a steam cleaner.
24. The appliance is intended to be used freestanding.
25. The rear surface of appliances shall be placed against a wall.
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
To reduce the risk of injury to persons
To reduce the risk of injury to persons
DANGER
Electric Shock Hazard
Touching some of the internal components can cause serious personal injury or death. Do not disassemble this appliance.
WARNING
Electric Shock Hazard
Improper use of the grounding can result in electric shock. Do not plug into an outlet until appliance is properly installed and grounded.
This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an
escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug
must be plugged into an outlet that is properly installed and grounded.
Consult a qualified electrician or serviceman if the grounding instructions are not completely understood or if doubt exists as to
whether the appliance is properly grounded. If it is necessary to use an extension cord, use only a 3-wire extension cord.
1. A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer cord.
2. If a long cord set or extention cord is used:
1) The marked electrical rating of the cord set or extension cord should be at least as great as the electrical rating of the appliance.
2) The extension cord must be a grounding-type 3-wire cord.
3) The long cord should be arranged so that it will not drape over the counter top or tabletop where it can be pulled on by children
or tripped over unintentionally.
6
Grounding Installation

To reduce the risk of injury to personsUtensils
7
Important safety instructions warning
CLEANING
Be sure to unplug the appliance from the power supply.
1. Clean the cavity of the oven after using with a slightly damp cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighbouring parts must be cleaned carefully with a damp cloth when they are dirty.
4. Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface,
which may result in shattering of the glass.
5. Cleaning Tip---For easier cleaning of the cavity walls that the food cooked can touch: Place half a lemon in a bowl, add 300ml
(1/2 pint) water and heat on 100% microwave power for 10 minutes. Wipe the oven clean using a soft, dry cloth.
Utensils
Personal Injury Hazard
It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal ofa
cover which gives protection against exposure to microwave energy.
See the instructions on "Materials you can use in microwave oven or to be avoided in microwave oven." There may be certain non-
metallic utensils that are not safe to use for microwaving. If in doubt, you can test the utensil in question following the procedure below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.
Caution

Materials you can use in
microwave oven
Materials you can use in microwave oven
8
Utensils
Browning dish
Dinnerware
Glass jars
Glassware
Oven cooking bags
Paper plates and cups
Paper towels
Parchment paper
Plastic
Plastic wrap
Thermometers
Wax paper
Remarks
Follow manufacturer’s instructions. The bottom of browning dish must be
at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause
the turntable to break.
Microwave-safe only. Follow manufacturer's instructions. Do not use
cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm. Most glass jars
are not heat resistant and may break.
Heat-resistant oven glassware only. Make sure there is no metallic trim.
Do not use cracked or chipped dishes.
Follow manufacturer’s instructions. Do not close with metal tie. Make
slits to allow steam to escape.
Use for short–term cooking/warming only. Do not leave oven unattended
while cooking.
Use to cover food for reheating and absorbing fat. Use with supervision
for a short-term cooking only.
Use as a cover to prevent splattering or a wrap for steaming.
Microwave-safe only. Follow the manufacturer’s instructions. Should be
labeled "Microwave Safe". Some plastic containers soften, as the food
inside gets hot. "Boiling bags" and tightly closed plastic bags should be
slit, pierced or vented as directed by package.
Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Microwave-safe only (meat and candy thermometers).
Use as a cover to prevent splattering and retain moisture.

Materials to be avoided in
microwave oven
9
Materials to be avoided in microwave oven
Utensils
Aluminum tray
Food carton with metal handle
Metal or metal-trimmed utensils
Metal twist ties
Paper bags
Plastic foam
Wood
Remarks
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
Metal shields the food from microwave energy. Metal trim may
cause arcing.
May cause arcing and could cause a fire in the oven.
May cause a fire in the oven.
Plastic foam may melt or contaminate the liquid inside when exposed
to high temperature.
Wood will dry out when used in the microwave oven and may split
or crack.
Setting up your oven
Setting up your oven
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity. Your oven comes with the following accessories:
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
F
G
A
C B
ED

Turntable Installation
Turntable Installation
10
Countertop Installation
Countertop Installation
Remove all packing material and accessories.
Examine the oven for any damage such as dents or broken door. Do not install if oven is damaged.
Cabinet:
Remove any protective film found on the microwave oven cabinet surface.
Do not remove the light brown Mica cover that is attached to the oven cavity to protect the magnetron.
a. Never place the glass tray upside down. The glass
tray should never be restricted.
b. Both glass tray and turntable ring assembly must
always be used during cooking.
c. All food and containers of food are always placed
on the glass tray for cooking.
d. If glass tray or turntable ring assembly cracks or
breaks, contact your nearest authorized service center.
Hub (underside)
Glass tray
Turntable ring assembly
Turntable shaft

Installation
11
Installation
1. Select a level surface that provide enough open space for the intake and/or outlet vents.
(1) The minimum installation height is 85cm.
(2) The rear surface of appliance shall be placed against a wall. Leave a minimum clearance of 30cm above the oven, a minimum
clearance of 20cm is required between the oven and any adjacent walls.
(3) Do not remove the legs from the bottom of the oven.
(4) Blocking the intake and/or outlet openings can damage the oven.
(5) Place the oven as far away from radios and TV as possible. Operation of microwave oven may cause interference to your radio
or TV reception.
2. Plug your oven into a standard household outlet. Be sure the voltage and the frequency is the same as the voltage and the
frequency on the rating label.
WARNING: Do not install oven over a range cooktop or other heat-producing appliance. If installed near or over a heat source, the
oven could be damaged and the warranty would be void.
The accessible surface may be hot during operation.
20cm
30cm
20cm
min85cm
0cm

Operation
Operation
12
Control Panel and Features
Operation Instructions
1. To set cooking power by turning the
power knob to desired level.
2. To set the time of cooking by turning
the timer knob to desired time per
your food cooking guide.
3. The microwave oven will
automatically start cooking after
power level and time are set.
4. After the cooking time is up, the unit
will "Dong" to stop.
5. If the unit is not in use, always set
time to "0"
Function/Power
Low
Med. Low (Defrost)
Med.
Med. High
High
Output
17% micro.
33% micro.
55% micro.
77% micro.
100% micro.
Application
Soften ice cream
Soup stew, soften butter or defrost
Stew, fish
Rice, fish, chicken, ground meat
Reheat, milk, boil water, vegetables, beverage
Notice: When removing food from the oven, please ensure that the ovenpower is switched off by turning the timer switch to 0 (zero).
Failure to do so, and operating the microwave oven without food in it, can result in overheating and damage to the magnetron.
Timer
Power
Low
M.Low
Med
M.High
High

Troubleshooting
13
Troubleshooting
Microwave oven interfering
TV reception
Dim oven light
Steam accumulating on door,
hot air out of vents
Oven started accidentally
with no food in.
Radio and TV reception may be interfered when microwave oven
operating. It is similar to the interference of small electrical appliances,
like mixer, vacuum cleaner, and electric fan.It is normal.
In low power microwave cooking, oven light may become dim.
It is normal.
In cooking, steam may come out of food. Most will get out from vents.
But some may accumulate on cool place like oven door. It is normal.
It is forbidden to run the unit without any food inside.
It is very dangerous.
Remarks
Oven can not be started.
Oven does not heat.
(1) Power cord not plugged
in tightly.
(2) Fuse blowing or circuit
breaker works.
(3) Trouble with outlet.
(4) Door not closed well.
Unplug. Then plug again after
10 seconds.
Replace fuse or reset circuit
breaker (repaired by professional
personnel of our company)
Test outlet with other
electrical appliances
Close door well.
Possible Cause RemedyTrouble

AmazonBasics e-waste Program
Consequences of Improper E-Waste Handling & Recycling:
Recycle your old AmazonBasics products and help protect the environment.
E-waste when disposed or recycled improperly, can cause severe environmental pollution and adversely affect the human body as
they contain excess of toxic chemicals like mercury, polybrominated flame retardants, barium, lithium and PVC. The common
process of burning of e-waste in informal e-waste recycling and disposal facilities releases toxic gases into the atmosphere, causing
severe air pollution. Besides that, poor recycling and improper disposal of e-waste leads to a lot of pollutants such as heavy metals
like cadmium, lead and persistent organic pollutants to be released into the atmosphere, which further pollutes the eco-system and
causes health hazards.
Alternately the practice of dumping of e-waste into landfills as followed by the informal e-waste recycling and disposal facilities
eventually makes the hazardous and toxic components of e-waste seep into the eco-system including the regional water tables,
causing soil pollution and contaminating the water table. Such contamination will affect nearby communities in an adverse manner
for much longer time.
Accidental breakage and damage of electronics and e-waste can pose a threat to the environment. As long as the toxic
components in electronics are enclosed within the original manufacturer’s designed outer-shell of the gadget, they don’t pose much
of a danger as they have been engineered to contain any such effects. However, accidental breakage or damage of such electronics
or e-waste can lead to toxic elements leaking and contaminating their immediate environment. Damage to the environment due to
accidental breakage of e-waste is a major concern in informal e-waste disposal and recycling facilities, so consumers need to ensure
that their e-waste is being disposed only through authorized recycling centres.
AmazonBasics Recycling Program:
Reteck Envirotech Private Limited (“Reteck”), a recycling company, has been authorized to provide e-waste disposal service to all
customers of Cloudtail who have purchased AmazonBasics products. Reteck has a PAN-India collection mechanism for collecting
e-waste from customers and for further disposal of such e-waste as per the E-Waste (Management & Handling) Rules, 2016
effective October 1, 2016.
Cloudtail through Reteck will provide e-waste drop off centres and ensure environmentally sound management of electronics that
have reached their end of life phase. Reteck has all the necessary authorizations from the appropriate governmental agencies for
their processing facilities. Reteck ensures proper recycling and disposal of e-waste, and does not incinerate, send e-waste to landfill
or export hazardous e-waste to other countries. This helps us protect the environment from any hazardous consequences, which
would be otherwise caused by the inappropriate waste management of e-waste.
To know more about Reteck collection centres and how to recycle your AmazonBasics product -
(i) Log on to https://www.reteck.co/recycling or
(ii) Call up Reteck’s Toll Free Number: 1800-123-1714 or
(iiI) Write to - [e-mail]
14
AmazonBasics e-waste Program

Instructions of handling the product during and after its use and Do’s and Don’ts
with respect to handling the product:
Do’s:
a) Always look for information in the product’s user’s guide for end-of-life equipment handling.
b) Ensure that only authorized recyclers handle your electronic products.
c) Always call local authorized e-waste collection centers to dispose products that have reached end-of life phase.
d) When your used electronic products, batteries or accessories reach the end of their life, always dispose them at your nearest
authorized e-waste collection center.
e) Wherever possible or as instructed, separate the packaging material according to responsible waste disposal options and
sorting for recycling.
f) Always ensure any glass surface is protected against breakage.
g) Kindly ensure that the product is properly packaged as per instructions before handing it over to the authorized Recycler.
Be a Responsible User. Recycle your E-Waste for a Greener Planet.
Don’ts:
Information about hazardous constituents of the product, viz., concentration
value of substances such as lead, mercury, hexavalent chromium,
polybrominated biphenyls, polybrominated diphenyl ethers and cadmium.
a) Do not dismantle your electronic products on your own.
b) Do not throw electronics having “Do not Dispose” symbol on the product package in your regular garbage bins along with
municipal waste since it will ultimately reach a landfill.
c) Do not give e-waste to informal and unorganized sectors like local scrap dealers.
AmazonBasics e-waste Program
15
AmazonBasics e-waste Program

Any updates to the manual will be uploaded to the website,
www.amazon.in/basics, please check for the latest version.
