Amc Speaker box d12 User manual

IMPORTANT SAFETY INSTRUCTIONS

When using this electronic device, basic precautions should always be taken, including the

following:

1. Read all instructions before using the product.

2. Do not use this product near water (e.g., near a bathtub, washbowl, kitchen sink, in a wet

basement or near a swimming pool etc).

3. se this device when you are sure that the loudspeaker has a stable base and it is fixed securely.

4. This product may be capable of producing sound levels that could cause permanent

hearing loss. Do not operate for a long period of time at a high volume level or at a level

that is uncomfortable. If you experience any hearing loss or ringing in the ears, you should

consult with otorhinolaryngologists. The product should be positioned so that proper

ventilation is maintained.

5. The product should be located away from heat sources such as radiators, heat vents, or

other devices (including amplifiers) that produce heat.

6. The product should be connected to a power amplifier that is described in the operating

instructions or are marked on the product.

7. The speaker cable should be undamaged.

8. Care should be taken so that objects do not fall into, and liquids would not be spilled

through, the enclosure's openings.

9. The product should be serviced by qualified service personnel if:

•The speakon cord or the plug has been damaged.

•Objects have fallen into or liquid has been spilled on the product.

•The product has been exposed to rain.

•The product has been dropped or the enclosure damaged.

All the other servicing should be referred to qualified service personnel too.

CONTENTS:

Before you start

What's in the box 4

Features 4

Hints on installation 4

Controls and connections

Rear panel 5

Specifications

Specifications 6

Congratulations on your choice of a passive loudspeaker Speaker B x D12. You will find that your

Speaker B x D12 has a superior performance and greater flexibility than any other active loudspeakers in

it’s price range. Please read this manual carefully to get the most important information about your new

unit. Thanks for selecting Speaker B x D12.

What’s in the box?

Items those are included in the box:

•Speaker Box D12 loudspeaker

•Instruction manual

Features

•12” woofer and 1.5” tweeter.

•Pole socket for use with speaker stands.

•Light cabinet with hanging holes.

•Internal 2-way crossover.

•LINK connector.

Hints on Installation

This user manual contains an important information on operating Speaker B x D12 loudspeaker correctly

and safety. Please read it carefully before operating your loudspeaker.

INSPECTION

Your Speaker B x D12 was carefully packed at the factory and packaging is designed to protect the units

in shipment. Before installing and using your unit, carefully examine the packaging and all contents for

any signs of physical damage. If you find any damage, notify the shipping company immediately. Be sure

to save the carton and all packing materials for carrier inspection.

MO NTING

The Speaker B x D12 is designed to use with speaker stands as well as stand alone. There are several

mounting holes in plastic cabinet for the easy and safety rigging. Because of the cabinet design

loudspeaker can by use as floor monitor too. Pay attention to the safety requirements when loudspeaker

is rigging or using with speaker stand. nconcern of safety requirements may cause serious injury.

LO DSPEAKERS COOLING

Also pay attention to the cooling requirements. Do not install the loudspeaker in a location that is

exposed to direct rays of the sun or near the hot appliance or radiators.

Rear panel

1. INPUT CONNECTOR

Connector is used to connect loudspeaker to the power amplifier. +1 pin and -1 pin of SPEAKON

connector's are used to connect audio signal.

2. LINK CONNECTOR

Connector is used to connect additional loudspeaker, to the same power amplifier’s output. +1 pin

and -1 pin of SPEAKON connector's are used to connect audio signal. Please take attention to the

impedance, before the connecting signal into additional loudspeaker.

Specifications

Output power 230 W

Impedance 8 Ω

Sensitivity 96 dB (1W/1m)

Dispersion 180° (H) x 120° (V)

Driver dimensions 12” (300 mm) woofer, 1.5” (38 mm) tweeter

Frequency response 50 Hz – 18 KHz

Connectors 4 pin Speakon

Dimensions 615 mm x 400 mm x 320 mm

Weight 13 kg

The specifications above are correct at the time of printing of this manual. For improvement purposes, all

specifications for this unit, including design and appearance, are subject to change without prior notice.

NOTES:

______________________________________________________________

AMC is a registered trademark of AMC Baltic www.amcpro.eu

AMC Speaker Box D12 User manual
