Amcor NanoMax Series Manual

Before you enjoy your
NanoMax™ Portable Air Conditioner with
Innovative AutoDrain NanoMist Technology™
it’s important to read these easy set-up instructions.
For more information, please see the enclosed Owner’s
Manual, call 1-866-361-2233, or visit
www.amcorgroupusa.com
1. Locate Parts
IMPORTANT:
Leave the
Air Conditioner
in an upright position
for at least two hours
before turning on!
A. Remote Control
B. Exhaust Hose C. Slide Bar Connector
D. Adjustable Slide Bar E. Insulation Strip F. Drain Hose
G. Spiral
water pipe
with connector
2. Assemble AutoDrain NanoMist™ Technology
2
43
Attach Window
Slide Bar
Connector to
Exhaust Hose by
twisting as shown.
Put spiral water
pipe into hot air
flexible hose.
Connect the
female half of the
quick connector
at the end of the
spiral water pipe
to the male part
in the hot air
outlet pipe.
Turn the
connector
90 degrees
clockwise until it
is locked in
place.
1
Continued on Reverse Side
913151000A

65
87
Assemble the
hot air hose on
the unit.
Clip on the
water atomizer
at the end of
the spiral pipe
to the holder.
Unfold flexible
hose with
attached hose
adapter
connector,
and snap into
Window
Slide Bar.
Only
Required For
Dissassembly.
In order to
unlock the quick
connector, push
the tab and turn
the connector
90 degrees
counter-clockwise.
1. Place Adjustable Slide Bar (D) in the window and expand
so it fits tightly.
2. Mark Slide Bar to record width of the window.
3. Apply Insulation Strip (E) on top and bottom of Slide Bar.
4. Reposition Slide Bar Connector in the window.
Expand the Slide Bar to fit tight. Tighten the screws.
5. Lower the window.
6. Make sure Hose has no kinks.
Adjustable
Slide Bar
Hose
Slide Bar
Connector
3. Installation of the Window Kit
4. Turning the Unit On
1. Plug the unit into a working electrical outlet.
2. Press the unit’s ON/OFF Button on the control panel.
It may take a few minutes before cold air is dispersed.
3. If unit doesn’t turn on, press top Reset Button on plug, shown
at right, and plug back in outlet. Green light should be on.
4. Adjust FAN Speed by pressing the FAN Button until
the preferred fan speed is reached.
5. Press the Timer Button to Set.
Reset Button
Green Light
TEST
RESET
913151000A
Continued from Reverse Side
