AMD DIrect SSRFR-21S User manual

21” REFRIGERATOR
USER MANUAL

AMD DIRECT REFRIGERATOR
INSTALLATION INSTRUCTIONS & OWNERS MANUAL
21” 4.5 COMPACT REFRIGERATOR W/ REVERSIBLE DOOR
21” 4.5 DELUXE COMPACT REFRIGERATOR W/ REVERSIBLE DOOR
NAME:
SSRFR21S
SSRFR21D / SSRFR21DR
PART #:
THANK YOU
Thank you for your purchase. We’d like to welcome you to the AMD Direct family of luxury
outdoor kitchen products and look forward to being a part of your home for years to
come. As a family business with over 20 years of industry experience, we aim to deliver
exceptional quality and personal service. Welcome to the AMD Direct family and we hope
you love your new refrigerator!
INSTALLER
Please leave this manual for the owner
Serial Number:
Model:
Date of Purchase:
Place of Purchase:
To view on your phone, scan the QR code on your camera app.
camera app. (For Android devices, use Google Lens)
For warranty information and to register your refrigerator visit,
AMDDirect.com/register

421” REFRIGERATOR USER MANUAL 5
SAFETY AND INSTALLATION INSTRUCTIONS GENERAL SAFETY REQUIREMENTS
• The appliance should be located in the
coolest area of the room or outdoor
location, away from heat producing
appliances and out of direct sunlight.
• Ensure that the unit is adequately
ventilated. Never cover air vents.
• Do not keep the door open any longer
than necessary.
• Let hot foods cool to room temperature
before placing in the unit. Overloading the
unit forces the compressor to run longer.
• Be sure to wrap foods properly and wipe
containers dry when placing them in the
unit. This cuts down on frost build up in
side the unit.
• Unit drawer should not be lined with
aluminum foil, wax paper or paper
toweling.
• Liners interfere with cold air circulation,
making the unit less ecient.
• Organize and label stored items reduce
door openings and extend searches.
• Remove as many items as needed at
one time and close the door as soon as
possible.
ENERGY SAVING TIPS
FOLLOW WARNING CALLOUTS BELOW
ONLY WHEN APPLICABLE TO YOUR
MODEL
• Use two or more people to move and install
appliance. Failure to do so can result in back
or other injury.
• To ensure proper ventilation for your
appliance, the front of the unit must be
completely unobstructed.
• Choose a well-ventilated area with
temperatures above 60°F (16°C) and below
90°F (32°C).
• The appliance should not be located next to
ovens, grills or other sources of high heat.
• The appliance must be installed with all
electrical, water and drain connections in
accordance with state and local codes. A
standard electrical supply (115 V AC only,
60HZ), properly grounded in accordance with
the National Electrical Code and local codes
and ordinances is required.
• Do not kink or pinch the power supply cord of
the appliance.
• The size of the fuse (or circuit breaker) should
be 1.3 amperes.
• It is important that the appliance be leveled in
order to work properly. You may need to make
several adjustments to level it.
• All installations must be in accordance with
local plumbing code requirements.
• Make certain that the pipes are not pinched,
kinked or damaged during installation.
• Check for leaks after connection.
• Never allow children to operate, play with or
crawl inside the appliance.
• Improper use of the grounded plug can result
in the risk of electrical shock. If the power
record is cord is damaged, have it replaced by
a qualified or authorized service dealer.
1. Child entrapment and suocation are not
problems of the past. Junked or abandoned
appliances are still dangerous, even if they
will “just sit for a few days.”
2. Before discarding your old refrigerator,
Take out the drawers.
3. Before you throw away your old
refrigerator: Take o the doors. Leave the
shelves in place so that children may not
easily climb inside.
RISK OF CHILD ENTRAPMENT
• Plug into a grounded 3-prong outlet, do not
remove prong, do not use an adapter and do
not use an extension cord.
• Replace all panels before operating.
• It is recommended that a separate circuit
serving only your appliance be provided. Use
receptacles that cannot be turned o by a
switch or pull chain.
• Never clean appliance parts with flammable
fluids. These fumes can create a fire hazard or
explosion.
• Do not store or use gasolines or other
flammable vapors and liquids in the vicinity
of this or any other appliance. The fumes can
create a fire hazard or explosion.
• Do not connect or disconnect the electric plug
when your hands are wet.
• Unplug the appliance or disconnect power
before cleaning or servicing. Failure to do so
can result in electrical shock or death.
• Do not attempt to repair or replace any part
or your appliance unless it is specifically
recommended in this manual. All other
servicing should be referred to a qualified
technician.
Before the appliance is used, it must be properly
positioned and installed as described in this
manual, so read the manual carefully. To reduce
the risk of fire, electrical shock or injury when
using the appliance, follow basic precautions,
including the following:
WARNING WARNING WARNING
WARNING

621” REFRIGERATOR USER MANUAL 7
21” REFRIGERATOR
USER MANUAL
TABLE OF CONTENTS
BEFORE OPERATING
CARE & MAINTENANCE
TROUBLESHOOTING
INSTALLATION
WARRANTY
1
3
4
5
6

121” REFRIGERATOR USER MANUAL 2
BEFORE OPERATING BEFORE OPERATING
Shipment Arriving Damaged: Parts & Features
BEFORE INSTALLING YOUR UNIT
INSTALLING YOUR UNIT
SETTING THE TEMPURATURE CONTROL
Important Notes:
VISIBLE DAMAGE
If your shipment arrives with visible damage to the
box/carton, be sure the damage is noted on the
bill of freight or express receipt and signed by the
person making the delivery. File a claim for damages
immediately, regardless of the extent of damage.
CONCEALED DAMAGES
If damages are unnoticed until the refrigerator is
unpacked, notify the transportation company or
carrier immediately and file a concealed damage
claim with them. This should be done within (5)
days of the delivery date. Be sure to hold on to
the box/carton for inspection. We cannot assume
responsibility for damage or loss incurred in transit.
BEFORE USING YOUR APPLIANCE
REVERSING THE DOOR SWING OF
YOUR APPLIANCE
FIGURE 1 (NORMAL POSITION)
FIGURE 2 (POSITION AFTER DOOR REVERSAL)
Remove the exterior and interior packing.
Before connecting the appliance to the power
source, let it stand upright for approximately
24 hours. This will reduce the possibility of a
malfunction in the cooling system from handling
during transportation. Clean the interior surface with
lukewarm water using a soft cloth. Install the handle
on the door if not already attached.
It is recommended that you install the appliance
in a place where the ambient temperature is
between 60°F and 90°F (16°C-32°C). If the ambient
temperature is above or below recommended
temperatures, the performance of the unit may
be aected. For example, placing your unit in
extremely cold or hot conditions may cause interior
temperatures to fluctuate. The operating temperature
range may not be reached.
• Locate the unit away from direct sunlight and
sources of heat (stove, heater, radiator, etc.).
Direct sunlight may aect the acrylic coating and
heat sources may increase electrical consumption.
Extreme cold ambient temperatures may also
cause the unit not to perform properly.
• Avoid locating the unit in moist areas.
• Plug the unit into an exclusive, properly
installed-grounded wall outlet. Do not under any
circumstances cut or remove the third (ground)
prong from the power cord. Any questions
concerning power and/or grounding should
be directed toward a certified electrician or an
authorized Products service center.
• After plugging the appliance into a wall outlet,
allow the unit to cool down for 2-3 hours before
placing food in the refrigerator compartment.
This refrigerator can be opened either from the left
or right side. The default way of opening the zdoor is
from the right side. If you want to open the door from
the left side, please follow the instructions below.
NOTE: All the removed parts must be well kept for
the re-installation of the door
• Remove the three Screws (6) that hold the Lower
Door Hinge (5), keep the hinge for later use.
• Remove the Door from the Upper Pin (3), and
keep the padded surface upwards to prevent the
scratching
• Remove the Upper Hinge Cover (1), remove the
two Screws (2), hold the Upper Hinge (3), save the
hinge for later use.
• Remove the Hole Cover (1) and transfer it to the
same location on the opposite side.
NOTE:
1. Turning the temperature control to “OFF” position
stops the cooling cycle but does not shut o the
power to the unit.
2. If the unit is unplugged, has lost power, or is
turned o, you must wait 3 to 5 minutes before
starting the unit. If you attempt to restart before
this time delay, the unit will not start.
• Remove the exterior and interior packing.
• Check to be sure you have all of the following
parts:
• 3 Shelves
• 1 Glass Lid
• 1 Crisper
• 1 Instruction Manual
• Before connecting the unit to the power source,
let it stand upright for approximately 2 hours.
This will reduce the possibility of a malfunction
in the cooling system from handling during
transportation.
• Clean the interior surface with lukewarm water
using a soft cloth.
• Insert the Lower Door Hinge in the right side, fix
the lower right hinge by tightening all the screws.
• Remove the Pin Cap (9) from the right side of the
upper frame of the door, and then transfer it to the
same location on the opposite side.
• Put the door on the Lower Door Hinge (5), keep the
door level , and then fix the Upper Hinge (3) to the
Door (4) by the screws
• Put on the Upper Hinge Cover (1).
• This appliance is designed to be freestanding
only, and should not be recessed or built-in.
• Allow 5 inches of space between the back
and sides of the unit. This ensures proper
air circulation to cool the compressor and
condenser.
• Place your unit on a floor that is strong enough
to support the unit when it is fully loaded. To
level your unit, adjust the two leveling legs at
the bottom of the unit.
• Your unit has only one control for regulating the
temperature in the compartment. The temperature
control is located on the upper right hand side of
the compartment.
• The first time you turn the unit on, set the
temperature control to “6”.
• The range of the temperature control is from
position “OFF” to “6”. After 24 to 48 hours, adjust
the temperature control to the setting that best
suits your needs.
• To turn the appliance o, turn the temperature
control to ”OFF”.
1. Interior Light Cover
2. Temperature Control Knob
3. Wire Shelves
4. Glass Shelf
5. Drawer
6. Leveling Leg
7. Door Bar (2)
8. Can Dispenser
9. Condiment Bar
10. Door
11. Bottom Hinge
12. Top Hinge
13. Top Hinge Cover
1. Upper Hinge Cover
2. Screw
3. Upper Hinge
4. Door
5. Lower Door Hinge
6. Screw
7. Hole Cover
8. Cabinet
9. Pin Cap

321” REFRIGERATOR USER MANUAL 4
Most power failures are corrected within a few hours
and should not aect temperature of your appliance
if you minimize the number of times the door is
opened. If the power is going to be o for a longer
period of time, you need to take the proper steps to
protect the contents.
• The unit should be located in the coolest area of
the room, away from heat producing appliances,
and out of the direct sunlight.
• Let hot foods cool to room temperature before
placing in the unit. Overloading the unit forces the
compressor to run longer.
• Be sure to wrap foods properly, and wipe
containers dry before placing them in the unit.
This cuts down on frost build-up inside the unit.
• Unit storage bin should not be lined with
aluminum foil, wax paper, or paper toweling.
Liners interfere with cold air circulation, making
the unit less ecient.
• Organize and label food to reduce door openings
and extended searches. Remove as many items as
needed at one time, and close the door as soon
as possible.
• Turn the temperature control to “OFF”, unplug the
unit, and remove the food, shelf, and tray.
• Wash the inside surfaces with a warm water and
baking soda solution. The solution should be
about 2 tablespoons of baking soda to a quart
of water.
• Wash the shelf and tray with a mild detergent
solution.
• The outside of the unit should be cleaned with
mild detergent and warm water.
• Wring excess water out of the sponge or cloth
before cleaning the area of the controls, or any
electrical parts.
• Wash the outside cabinet with warm water and
mild liquid detergent. Rinse well and wipe dry with
a clean soft cloth.
Short Vacations: Leave the appliance operating
during vacations of less than three weeks.
Long Vacations: If the appliance will not be used for
several months, remove all items and turn o the
appliance. Clean and dry the interior thoroughly. To
prevent odor and mold growth, leave the door open
slightly, blocking it open if necessary.
• Remove all items.
• Securely tape down all loose items inside your
appliance.
• Turn the adjustable legs up to the base to
avoid damage.
• Tape the door shut.
• Be sure the appliance stays secure in the
upright position during transportation. Also
protect the outside of the appliance with a
blanket or similar item.
VACATION TIME
MOVING YOUR APPLIANCE
POWER FAILURE
ENERGY SAVING TIPS
WIRING DIAGRAM
CLEANING YOUR UNIT
TROUBLESHOOTING
CARE & MAINTINANCE
Do not use boiling water because it may damage
the plastic parts. In addition, never use a sharp
or metallic instrument to remove frost as it may
damage the cooling system and will void the
warranty. We recommend using a plastic scraper.
Failure to unplug the unit could result in
electrical shock or personal injury.
CAUTION
CAUTION
Many common problems can be solved easily, saving you the time spent communicating with customer service.
Try the suggestions below to see if the issue has a simple solution.
PROBLEM POSSIBLE CAUSE REMEDY
Appliance does not operate Appliance is not connected to a power
supply.
The appliance is turned o.
Tripped circuit breaker or a blown fuse.
Connect the appliance.
Switch on the appliance.
Switch on the circuit breaker or replace
fuse.
Appliance is not cold enough The temperature is not set correctly.
Temperature could require a lower
temperature setting.
The drawer was not closed completely.
Drawer is not hermetically sealed.
The condenser is too dirty.
The ventilation opening is blocked or too
dusty.
Check the set temperature.
Set a lower temperature.
Do not open the drawer more often than
necessary.
Close drawer properly.
Check the drawer seal and clean/
replace.
Clean the condenser when necessary.
Clear the obstructions, clean the dust.
Appliance turns itself on and o
frequently
The room temperature is higher than
average.
A large amount of food has been added to
the unit.
The drawer is open too often.
The drawer is not closed completely.
The drawer gasket does not seal properly.
Put the appliance in a cooler place.
Leave the appliance to work for a while
until the set temperature has been
reached.
Do not open more than necessary.
Close drawer properly.
Check the drawer seal and clean/
replace.
The light does not work Appliance is not connected to a power
supply.
Tripped circuit break or blown a fuse.
The light was switched o on the control
panel.
Connect the appliance.
Switch on circuit breaker or replace
fuse.
Switch on the light.
Vibrations The appliance is not properly leveled. Level the appliance with the adjustable
feet.
The appliance seems to make
too much noise
The rattling may come from the flow of the
refrigerant, which is normal. As each cycle
ends, you may hear gurgling sounds caused
by the flow of refrigerant in your appliance.
If the temperature fluctuations occur, the
contraction and expansion of the inner walls
may cause popping and cracking noises.
The appliance is not properly level.
Level the appliance with the adjustable
feet.
The drawer will not close
properly
The appliance is not properly level.
The drawer was reversed and not properly
installed.
The shelves are out of position
Level the appliance with the adjustable
feet.
Check the drawer hinge and reassemble
correctly.
Check the shelves and refit correctly.

521” REFRIGERATOR USER MANUAL 6
The appliance should always be plugged into
its own individual electrical outlet which has a
voltage rating that matches the rating label on the
appliance. This provides the best performance and
also prevents overloading house wiring circuits that
could cause a fire hazard from over heating. Never
unplug the appliance by puling on the power cord,
always grip the plug firmly and pull straight out from
the receptacle. Repair or replace immediately all
power cords that have become frayed or otherwise
damaged. Do not use a cord that shows cracks
or abrasion damage along its length or at either
end. When moving the appliance, be careful not to
damage the power cord.
Because of potential safety hazards under certain
conditions, it is strongly recommended that you
do not use an extension cord with this appliance.
However, if you must use an extension cord it is
absolutely necessary that it be a UL/CUL-Listed,
3-wire grounding type appliance extension cord
having a ground type plug and outlet and that the
electrical rating of the cord be 115 volts and at least
1.3 amperes.
EXTENSION CORD
INSTALLATION
This appliance should be properly grounded for your
safety. The power cord of this appliance is equipped
with a three-prong plug which mates with a standard
three-prong wall outlet to minimize the possibility of
electrical shock.
Do not under any circumstance cut or remove the
third (ground) prong from the power cord supplied.
For personal safety, this appliance must be properly
grounded. Any questions concerning power and/
or grounding should be directed toward a certified
electrician or an authorized service center.
The appliance requires a standard 115/220 Volt AC-
60HZ three-prong grounded electrical outlet. Have
the wall outlet and circuit checked by a qualified
electrician to make sure the outlet is properly
grounded. When a standard 2-prong wall outlet is
encountered, it is your responsibility and obligation
to have it replaced with a properly grounded 3-prong
wall outlet.
To prevent accidental injury, the cord should be
secured behind the appliance and not left exposed
dangling.
21” REFRIGERATION LINE DRAWINGS
ELECTRICAL CONNECTION
NOTES
21 inch Refrigerator
SKU: SSRFR-21S - SSRFR-21D
SUMMERSETGRIILLS.COM 17322 GOTHARD ST., HUNTINGTON BEACH, CA 92647 800.966.8126
THIS PAGE INTENTIONALLY LEFT BLANK

721” REFRIGERATOR USER MANUAL 8
GOLD STANDARD WARRANTY
Your investment in AMD Direct product is backed by the strongest warranty in
the industry. In addition to precision engineering and outstanding performance,
AMD Direct products include our GOLD STANDARD LIFETIME WARRANTY with
all replacement parts 100% non-prorated. Eective with purchases 8/1/21.
AMD Direct Warranty is valid for original purchaser at original site of delivery with
proof of purchase and photo documentation only. Registration form must be
submitted online within 30 days of the purchase date to validate the warranty.
Warranty is void upon transfer of ownership. Warranty does not apply to products
installed in any commercial, rental, or nonresidential application (exception of the
Resort Grill, Alturi, & TRL). Warranty covers replacement parts only. Manufacturer
is not responsible for labor or labor-related costs. Warranty does not cover
discoloration, surface rust, corrosion, or oxidation, which may occur due to harsh
environments, chemicals, or overheating. Warranty will not apply for damage
resulting from improper installations, abuse, extreme environments, grease fires,
or misuse. Proof of regular and proper maintenance is required. Coastal, humid,
and/or salt environments are subject to manufacturer review. All out-of-box claims
must be made within 30 days of purchase and must be made prior to installation.
Any product installed damaged will be considered damaged during installation
and not covered under warranty. Warranty and registration forms are available at
www.amddirect.com/register. Please be advised - all display models are sold “as
is” and the warranty covers the following items only: main burners (Gold Standard
Lifetime Warranty), grates (Gold Standard Lifetime Warranty), burner covers (Gold
Standard Lifetime Warranty). All warranties are subject to the review and approval
of the manufacturer.
14520 DELTA LANE SUITE 105,
HUNTINGTON BEACH, CA 92647
800.966.8126
AMDDIRECT.COM
AMD DIRECT GAS APPLIANCES
(GRILLS, SIDE/POWER BURNERS, & OVEN)
• Gold Standard Lifetime Warranty on construction and
manufacturer defects
• Gold Standard Lifetime Warranty on stainless steel construction
• Gold Standard Lifetime Warranty on cooking grates, burners, burner covers, valves,
flame tamers, and heatzone separators, temperature gauges, & hood springs
• Gold Standard Lifetime Warranty on briquette systems
• 3 YEAR Warranty on all other parts, components, & electrical, including: LED bulbs,
wire harness, & switches; power source wire; transformer; interior halogen light
wire & bulb
DRAWERS, DOORS, GRILL LINERS, & CARTS
• Gold Standard Lifetime Warranty on construction, workmanship and materials for all stainless
steel parts, including doors, drawers, grill liners, & carts
• 3 year on electrical (Warming Drawers)
COVERS
• Gold Standard Lifetime Warranty on covers, including grills,
carts, side/power burners & oven
MADERA PRODUCTS
• Gold Standard Lifetime Warranty on construction, workmanship and materials for all stainless
steel parts, hinges, drawer slides, gasket, & magnets
COMMERCIAL APPLICATIONS
RESORT, ALTURI & TRL GRILLS
• Gold Standard Lifetime Warranty on workmanship, construction, & manufacturer
defects for all commercial and/or hospitality applications
• Warranty is void upon misuse, including lack of regular cleaning, vandalism, or theft
• Warranty is valid only if regular maintenance is exercised. Due to the nature of
commercial applications (multiple users, lack of control of use, etc.) regular
maintenance is mandatory
VENT HOODS, REFRIGERATION,
COLD STORAGE & SINKS
VENT HOODS
• 5 Year Warranty on all Stainless Steel Construction
• 3 year Warranty on blowers, LED Lighting, wiring harness and switches
15" & 24" REFRIGERATION MODELS
• 3 year Warranty on all construction including compressors
• 1 year Warranty on transformer, LED bulbs, LED harness, power source wire, LED
switches, interior halogen light wire/bulbs
21" REFRIGERATION MODELS
• 1 year Warranty on all construction & electrical components including compressor,
transformer, LED bulbs, LED harness, power source wire, LED switches, interior
halogen light wire/bulbs
COLD STORAGE & SINKS
• Gold Standard Lifetime Warranty on Ice Chests
• Gold Standard Lifetime Warranty on drains & faucets
GOLD STANDARD
LIFETIME
WARRANTY

VER.41622
CONTACT US
14520 Delta Ln,
Suite 105
Huntington Beach, CA 92647
AMDDirect.com
[phone]
M–F 8:30 am – 5:00 pm (PST)
