American Acoustic Development THE CUB User manual

THE CUB
OWNER’S MANUAL

CONTENTS
Read First ------------------------------------------------------------------Page 2
General Overview & Introduction-------------------------------------Page 3
Panel Overview------------------------------------------------------------Page 4
Panel Description---------------------------------------------------------Page 5
Operation & Positioning-----------------------------------------------Page 6
Transporting and storing of the CUB-------------------------------Page 6
Specifications--------------------------------------------------------------Page7
Service/Warranty information-----------------------------------------Page 9
1

Thank you for purchasing the AAD CUB Acoustic Guitar Amplifier. A
great deal of dedication and passion went into designing and building this
no compromise, high performance compact-combo amplifier. It was
conceived to be a dedicated amplifier for the “connoisseur” guitarist.
Reading this manual will enable you to get the best performance from it so that
you may enjoy many years of service.
READ THIS FIRST
•Before using the CUB please read ALL theinstructions.
•On receipt of product, check for any signs ofphysicaldamagearising
from shipping. If any damage is visible contactyourdealer.
•Keep all original packing.
•Never use this product in the vicinity of water. IftheCUBweretoget wet,
it could kill you by electrocution.
•Do not use this amplifier in a way that would compromise its ventilation
system. When operating, never covertheheatsinkonrearpanel.
•Do not locate this amplifiernear anyheat source.
•This amplifier must be connected only to apowersource specifiedin this
manual.
•For safety do not leave the amplifier plugged intoapowersourcefor
long periods of time when not in use.
•Do not let any liquid or foreign objects fallintoanyopeningsonthe
amplifier.
•Never use this amplifier if it has:
1. Suffered any physical damage.
2. Been subjected to any liquids, rain or moisture.
3. Damaged cables connected to it.
If any of the above occurs, the amplifier should beexaminedby
qualified service personnel.
•Always operate this amplifier with the correctly rated fuse.
•Never use this amplifier without proper grounding.
2

OVERVIEW OF THE CUB
The CUB is not your usual combo amp. On first appearance it may be mistaken for what it is
because of its diminutive size. Don’t let this fool you, this is a very high performance amplifier
designed to give the utmost fidelity for acoustic guitar or any other lead musical instrument
where clean sound and absolute fidelity are paramount. AAD has pushed the envelope in
creating what is the smallest serious guitar amplifier currently available.
Rather than cram it with gimmicky features to enhance marketing, we decided to go all out on
making the best small amplifier money can buy. Nothing this small, with this performance has
ever been created before. To the working musician this amplifier will not only give sound
quality beyond expectations but in practical terms of transportation and storage; this amplifier
will be invaluable.
FEATURES
•Switchable high impedance/high gain input OR low impedance/low gain stage.
•3 Band EQ designated for guitar.
•FX Send Return sockets.
•Tuner out.
•Pre-amp Output.
•Balanced Line Output with ground lift.
•Smart power sensing that allows amplifier to work on any AC voltage worldwide. Just
plug in, no switching required.
•Sophisticated amplifier protection circuitry
•Special “Soft-Clipping” 100watt Amplifier
•Ultra low noise pre amplifier circuit.
3

PANEL OVERVIEW
I
O
AC~INPUT LINE OUT TUNER
LIFT
GROUND
CUB - GUITAR AMPLIFIER
110 WATTS/4 OHMS
SERIAL#: N00001
American Acoustic Development LLC
100 - 240V~ 50 / 60Hz
Fuse: T2.5AL 250V
OFF
ON
POWER
DI OUT
TREBLE
000
+15dB-15dB-15dB +15dB+15dB-15dB MIDBASS
INPUT
LEVEL
0 dB
-10 dB
FX
RETURN
SEND
4

PANEL DESCRIPTION
1. Input Socket
Accepts standard mono ¼ inch guitar instrument cable.
2. Input level switch
This switches the input sensitivity. 0db with passive pickups or -10dB: output from an
additional pre amp.
3. Level Control
Controls volume of amplifier.
4. Bass Control.
5. Mid Range Control
6. Treble Control
7. FX Send
Connect the FX send to auxiliary FX unit input.
This can also be used as an additional line out if necessary.
8. FX Return
Connect the FX Return to auxiliary FX unit output.
9. Line Out
These are used for driving a second amplifier.
10. Tuner Out
Connect to instrument tuner. This output can also be used as an additional line out.
11.XLR Balanced Line Out.
This is an ultra-low impedance (200ohm) balanced line out for use with recording or PA mixing
consoles.
12. Ground lift Switch
When there is a difference in grounding between audio equipment, it can cause what is
known as a ground loop. This will cause an audible hum or buzz through the speakers or
main PA speakers. Using this switch will break the ground loop and therefore eliminate
any hum.
13. AC Power On/Off Switch.
14. AC Power input and AC fuse holder.
Connects the amplifier to AC power supply. Always use a grounded plug and make sure
5

the AC cable is more than 3A rating at 250-volt AC. If you require a longer AC power cord,
we recommend you use the AAD heavy-duty 20 foot power cords. These are available as
an accessory. Use a slow blow ¾ inch fuse rated at 2.5 amps.
OPERATION & POSITIONING
TURN THE VOLUME DOWN on the CUB before plugging in your instrument.
Positioning the CUB for Best Sound
It is recommended that you place the cub on a solid object or dedicated stand for best sound
and projection. Do not place on a high microphone stand as it will be unstable and easily
topple over.
TRANSPORTING AND STORING THE CUB
When transporting in a vehicle, it is recommended that you use an external case or heavy-duty
cover to prevent it being damaged by falling over or other objects falling on it. The Cub has an
optional padded carrying bag as an available accessory.
When Storing:
•Keep the CUB in a dry location preferably at room temperature.
•Do not store the CUB in temperatures below -20 Degrees C or above 40 Degrees C.
•Do not allow it to get wet. If this occurs, never turn it on in this condition.
•Do not leave the CUB connected to a power source for long periods of time.
6

SPECIFICATIONS
Speaker
Computer Optimized Enclosure
Speaker Frequency Response: 80Hz –15KHz
Speaker Compliment: 2x 5inch proprietary NEO-POWER, extended-range drivers
Speaker Sensitivity: 95dB/W/M
Internal Speaker Impedance: 4 Ohms
Dimensions (HxWxD): 170x300x320mm
6.5x11.8x12.5inch
Weight: 5.2 Kg / 11.5 Lbs
Amplifier
PJB 100watt Solid State class AB amplifier with soft clip feature
Signal to Noise Ratio
Better than 95 dB
Impedance
0dB Input: >4MΩ/22pF
-10dB Input: >100KΩ/22pF
Pre Amp Out: < 2KΩ
Bal. Line Out: <200Ω
Levels
0dB Input: 10mV-2.5V
-10dB Input: 20mV-5V
Pre Amp Out: 1.2V
FX send: 250mV
Bal. Line Out: Typical 100mV
Protection Circuits
1. AC line filter.
2. Slow-blow Fuse: 2.5A / 250V.
3. Smart Thermal Protection: auto turn down the output power to about 50% when the heat
sink temperature over 65º C.
4. Loudspeaker Short-Circuit Protection.
5. DC Output Protection.
Included Parts
12 ft AC Power Cord
7

8

SERVICE/WARRANTY INFORMATION
The CUB has a warranty period of 2 years, starting from the date of purchase. The buyer
must complete and return the enclosed warranty card within 14 days of purchase.
This warranty covers defect in materials or workmanship that occurs in normal use. Within
warranty period AAD will repair or replace the defect unit free of labor and parts charge. It is
the buyer’s responsibility to use the unit strictly according to instructions written in this
manual and amplifier manual.
This warranty is not transferable; it is provided to original owner only. Damage/defects caused
by the following conditions are not covered by this warranty:
•Improper handling, neglect or failure to operate the unit in compliance with the
instructions given in user manual;
•Connection or operation of the speakers in any way that does not comply with the technical
or safely regulations applicable in the country where the product is used;
•Repairs or modifications by anyone other than authorized AAD service agent;
•Damages/defects caused by force majeure or any other condition that is beyond the
control of AAD.
Should you need any warranty service, please bring the CUB back to the dealer from whom
you purchased, along with your sales receipt. Depending on the complexity of the repair work,
your dealer may return the defect unit to AAD service center for repair or replacement.
American Acoustic Development LLC
8559 Page Avenue St. Louis, MO 63114 USA
Phone: [phone] or 314 814 1264 Fax: 314
628 9941
www.aadsound.com
[email protected]
