IP SpeedDome Ultra 8 is a new IP edge device that includes the
innovative features of the SpeedDome Ultra 8 Programmable
Dome series.
IP SpeedDome Ultra 8 is compatible with either Intellex IP or
VideoEdge NVR systems. This creates an integrated environment
that allows you to access and control video remotely over a
network, whether your surveillance system is small or large.
IP SpeedDome Ultra 8 includes an integrated encoder that
utilizes American Dynamics ACC technology. ACC is a highly
efficient video compression format developed to address the
specific demands of the security industry for low bandwidth
and hard drive consumption. It compresses data up to nine
times more efficiently than comparable MPEG-4 and MJPEG
compression technologies. Video streams from IP SpeedDome
Ultra 8 can be viewed via a Microsoft
®
Internet Explorer
®
browser, Intellex IP system, Network Client, Browser Client or
VideoEdge NVR solution.
IP SpeedDome Ultra 8 offers network bandwidth management to
monitor the single IP stream and limit the amount of compressed
data to a user-controlled threshold. Sophisticated features like
watchdog system monitoring with auto reset and video loss
detection further enhance the system’s performance.
An intuitive control interface lets you adjust images per
second and resolution based upon specific viewing/recording
requirements. In addition, you can easily access presets,
patterns, and other programmable features.
Three versatile housing options are available: indoor drop ceiling,
indoor pendant, and outdoor pendant. SpeedDome Ultra 8
camera assembly and mounting accessories can be ordered
separately depending upon your application requirements. An
IP SpeedDome Ultra housing can also be ordered separately
to upgrade an existing analog-based SpeedDome Ultra 8
installation.
IP SpeedDome Ultra 8 is fully compliant with applicable safety
and regulatory requirements for North American, European
Union, Australian, and New Zealand markets.
IP SpeedDome Ultra 8
Programmable Dome Camera Series
Features That Make a Difference:
Architecture leverages Active Content Compression (ACC)
technology
Manage network bandwidth through user-defined data stream limit
Up to 30 ips NTSC/25 ips PAL at 4CIF
Access and control from web browser or latest versions of
VideoEdge
®
NVR or Intellex
®
IP
1
Incorporates SpeedDome Ultra 8 (22x or 35x) camera assemblies
Indoor drop ceiling, indoor pendant or outdoor pendant
housing options
Watchdog system monitoring with auto reset
Multiple level password protected user access
10/100Base-T network support
Indoor Pendant Housing
Outdoor Pendant Housing
Drop Ceiling Housing
(2' x 2' mounting plate
sold separately)
(1) Intellex IP v4.2 or higher

SPECIFICATIONS
Product offerings and specifications are subject to change without notice. Actual products may vary from photos. Not all products include all features.
Availability varies by region; contact your sales representative. Certain product names mentioned herein may be trade names and/or registered trademarks of
other companies.
© 2008 Tyco International Ltd. and its respective companies. All rights reserved. AD0135-DS-200806-R01-LT-EN
www.americandynamics.net
Step 1: Choose an Indoor or Outdoor Housing Option Model Below
Description Model
Indoor, Drop Ceiling Housing, Clear Bubble ADSDUIHIDC
Indoor, Drop Ceiling Housing, Smoke Bubble ADSDUIHIDS
Indoor, Pendant Housing, Clear Bubble ADSDUIHIPC
Indoor, Pendant Housing, Smoke Bubble ADSDUIHIPS
Outdoor, Pendant Housing, Clear Bubble ADSDUIHOPC
Outdoor, Pendant Housing, Smoke Bubble ADSDUIHOPS
Step 2: Choose a SpeedDome Ultra 8 Camera Assembly Model Below
Description Model
35x, 540TVL, D/N, WDR, EIS, NTSC ADSDU835N
35x, 540TVL, D/N, WDR, EIS, PAL ADSDU835P
22x, 470TVL, NTSC ADSDU822N
22x, 470TVL, PAL ADSDU822P
Video
Compression..............Active Content Compression (ACC)
Compression Levels ........Three quality settings (Super, Normal, Extended)
and two sensitivity settings (Normal, High)
Frame Rate ...............4CIF NTSC-up to 30 ips1, 4CIF PAL-up to 25 ips2
Resolution (NTSC1).........704 x 480, 704 x 240, 352 x 240; via web browser:
Above plus 640 x 480, 640 x 240, 320 x 240
Resolution (PAL2)...........704 x 576, 704 x 288, 352 x 288; via web browser:
Above plus 640 x 576, 640 x 288, 320 x 288
Programmable Features
Refer to SpeedDome Ultra 8 series data sheet. All features are accessible
through standard onscreen menu display.
Note: The first alarm input is directly connected to the encoder and is not
for use with standard dome alarm programming.
Network
Interface................. Ethernet 10/100Base-T
Ethernet Port .............RJ-45
Supported Protocols ....... HTTP, TCP, DHCP (client)
Concurrent Streams .......Up to ten (total image rate depends on resolution
and content)
Bandwidth Control.........Bandwidth limits can be set
Configuration Management
Configuration Setup........Remote, via web browser
Web Browser ............. MS IE 6.x, MS IE 7.x, Java Script
Security .................Multi-level password protected access
System
Processor ...............720MHz TMS320DM642
Memory .................64 MB SDRAM, 8 MB Flash
Electrical (Note: Includes SpeedDome Ultra 8 camera assembly)
Input Voltage.............24 to 30 VAC, Class 2 LPS
Line Frequency ........... 50/60Hz
Power Consumption
Indoor (Outdoor) Models...1.8A (2.5A)
Power-On In-Rush Current
Indoor (Outdoor) Models...2.0A (3.0A)
Mechanical
Dimensions (H x D)
In-Ceiling Housing
Total .....................300 x 190.5 mm (11.9 x 7.5 in)
Above Ceiling ..............200 x 190.5 mm (8 x 7.5 in)
Below Ceiling ..............92.7 x 178 mm (3.65 x 7.0 in)
Integral Pendant Housing
Total .....................303 x 243.5 mm (11.9 x 9.6 in)
Unit Weight (Note: Does not include SpeedDome Ultra 8 camera assembly)
In-Ceiling Housing ............1.53 kg (3.37 lbs)
Indoor Integral Pendant Housing . . 1.82 kg (4.01 lbs)
Outdoor Integral Pendant Housing . .2.04 kg (4.5 lbs)
Environmental
Weatherproof Standard
Outdoor ..................IP66/NEMA4
Operating Temperature
Indoor....................0° to 45°C (32° to 113°F)
Outdoor ..................-40° to 45°C (-40° to 113°F)
Humidity ..................0 to 95% RH (noncondensing)
Storage Temperature..........-20° to 55°C (-4° to 131°F)
Wind Loading................Sustains winds of 241 kph (150 mph) when
properly installed and mounted (wall, pole,
ceiling, and over-the-roof mount with proper
support) Outdoor Pendant Mount only
Regulatory
Emissions. . . . . . . . . . . . . . . . . . . FCC Part 15 subpart B Class A
ICES 003/NMB 003 Class A
EN 55022:1998 +A1:2000 +A2:2003 Class A
AS/NZS CISPR22
Immunity ...................EN 50130-4:1995+A2:2003
Safety......................60950-1 1st Ed
Mounting Accessories Options
Refer to SpeedDome series mounting accessories data sheet.
(1) When used with ADSDU8xxN camera assemblies
(2) When used with ADSDU8xxP camera assemblies
IP SpeedDome Ultra 8 Configuration
SpeedDome Ultra 8 camera assembly and mounting accessories can be ordered separately depending upon the application requirements.
An IP SpeedDome Ultra housing can also be ordered separately to upgrade an existing analog-based SpeedDome Ultra 8 installation.
IP SpeedDome Ultra 8 Kits
IP SpeedDome Ultra 8 can also be ordered as a complete kit consisting of a SpeedDome Ultra camera assembly and an IP SpeedDome Ultra
housing using the following configuration model:
BRAND IP SPEEDDOME ULTRA HOUSING LENS ZOOM/CAMERA VIDEO FORMAT ENVIRONMENT/HOUSING MOUNT BUBBLE
AD SDUIH XX XXX X
AD SDUIH 35 = 35x, 540 TVL, True Day/Night, WDR, EIS
22 = 22x, 470 TVL N = NTSC P = PAL ID = Indoor Drop Ceiling IP = Indoor Pendant
OP = Outdoor Pendant
C = Clear
S = Smoke
