FEATURES
American Dynamics now offers three new flat
panel monitors providing high-resolution
display of analog computer signals and stereo
audio (19 inch model only). With bright, active
matrix displays offering up to 1280 x 1024
resolution, these monitors provide high quality
viewing that automatically adapts to the
appropriate input resolution.
Using 100/240 VAC, each monitor includes an
external power supply and a detachable base. In
addition, each includes VESA compliant
mounting holes on their desktop stands that
are easily adapted to the available wall or pole
mounts.
Ideal companions to the Intellex®or other DVR,
American Dynamics’ family of analog LCD flat
panel monitors offer superior image quality.
15, 17 and 19-inch LCD
Flat Panel Monitors
WITH ANALOG VGA (D-SUB) INPUT
•VGA (D-sub) connector
•Detachable desk base
stand included
•Supports up to 1280 x
1024 (SXGA) resolution
•Up to 700:1 Contrast
ratio
•Brightness: 250cd/m2
•Stereo speakers (19 inch
model only)
•Response time 25 ms
•Low power consumption
(45 watts)
•100/240 VAC 60/50 Hz
universal power supply

AMERICAN DYNAMICS 15, 17 AND 19-INCH LCD FLAT PANEL MONITORS WITH ANALOG VGA (D-SUB INPUT)
VS327-02 03/04 A4
©2004 Sensormatic Electronics Corporation
Product specifications and availability subject to
change without notice.
Certain product names mentioned herein may be trade
names and/or registered trademarks of other companies.
SPECIFICATIONS
Model Number
ADMNC1LCD19 . . . . . . . . . . . . . . . . . . . . . . . . .19-inch LCD Flat Panel
Monitor With Analog VGA
(D-Sub Input)
ADMNC1LCD17 . . . . . . . . . . . . . . . . . . . . . . . . .17-inch LCD Flat Panel
Monitor With
Analog VGA (D-Sub Input)
ADMNC1LCD15 . . . . . . . . . . . . . . . . . . . . . . . . . .15-inch LCD Flat Panel
Monitor With Analog VGA
(D-Sub Input)
Accessories
ADMNMTLCDW . . . . . . . . . . . . . . . . . . . . . . . . .Wall Mount Kit
ADMNMTLCDWA . . . . . . . . . . . . . . . . . . . . . . . .Wall Mount Kit with
adjustable arms
ADMNMTLCDP . . . . . . . . . . . . . . . . . . . . . . . . . .Pole Mount Kit
General
LCD Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TFT Power Management
Energy Star compliant VESA
DPMS compatible
Displayable Resolution
ADMNC1LCD19-SXGA . . . . . . . . . . . . . . . . .1280 x 1024 (max) 75 Hz
ADMNC1LCD17-SXGA . . . . . . . . . . . . . . . . .1280 x 1024 (max) 75 Hz
ADMNC1LCD15-SXGA . . . . . . . . . . . . . . . . .1024 x 768 (max) 75 Hz
Pixel Dimension
ADMNC1LCD19 . . . . . . . . . . . . . . . . . . . . . . .0.294 (H) x 0.294 (V) mm
ADMNC1LCD17 . . . . . . . . . . . . . . . . . . . . . . .0.264 (H) x 0.264 (V) mm
ADMNC1LCD15 . . . . . . . . . . . . . . . . . . . . . . .0.264 (H) x 0.264 (V) mm
LCD Display Color . . . . . . . . . . . . . . . . . . . . . . . .16.7 million (max)
Viewing Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..± 85° (H) ± 85° (V)
Tilt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5°to 20°
Contrast Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . .700:1
Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .250 cd/m2
Response Time . . . . . . . . . . . . . . . . . . . . . . . . . . . ..25 ms (Tr+Tf) (typical)
Audio (ADMNC1LCD19 only)
Line Input Connection . . . . . . . . . . . . . . . . . . . . .3.5 mm stereo jack
Power Output (Electric) . . . . . . . . . . . . . . . . . . . .2 x 2
Frequency Response . . . . . . . . . . . . . . . . . . . . . . .100 Hz -18 kHz
Total Harmonic Distortion . . . . . . . . . . . . . . . . .<5%
Electrical
Power Input Voltage . . . . . . . . . . . . . . . . . . . . . .100/240 VAC
Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . .45 watts (max)
Mechanical
Dimensions (H x W x D)
ADMNC1LCD19 . . . . . . . . . . . . . . . . . . . . . . .418 x 442 x 200 mm
(16.5 x 17.4 x 7.87 in)
ADMNC1LCD17 . . . . . . . . . . . . . . . . . . . . . . .403 x 387 x 192 mm
(15.2 x 15.8 x 7.5 in)
ADMNC1LCD15 . . . . . . . . . . . . . . . . . . . . . . .341 x 319 x 140 mm
(12.6 x 13.4 x 3.9 in)
Unit Weight
ADMNC1LCD19 . . . . . . . . . . . . . . . . . . . . . . .5.7 kg (12.5 lbs)
ADMNC1LCD17 . . . . . . . . . . . . . . . . . . . . . . .5.0 kg (11.0 lbs)
ADMNC1LCD15 . . . . . . . . . . . . . . . . . . . . . . .3.6 kg (8.0 lbs)
Shipping Information
Dimensions (H x W x D)
ADMNC1LCD19 . . . . . . . . . . . . . . . . . . . . . . .559 x 534 x 203 mm
(22.0 x 21.0 x 8.0 in)
ADMNC1LCD17 . . . . . . . . . . . . . . . . . . . . . . .508 x 483 x 152 mm
(20.0 x 19.0 x 6.0 in)
ADMNC1LCD15 . . . . . . . . . . . . . . . . . . . . . . .432 x 406 x 127 mm
(17.0 x 16.0 x 5.0 in)
Unit Weight
ADMNC1LCD19 . . . . . . . . . . . . . . . . . . . . . . .7.1 kg (16.0 lbs)
ADMNC1LCD17 . . . . . . . . . . . . . . . . . . . . . . .6.4 kg (14.0 lbs)
ADMNC1LCD15 . . . . . . . . . . . . . . . . . . . . . . .4.8 kg (10.5 lbs)
Environmental
Temperature
Operating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5° to 40° C (41° to 104° F)
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .-20° to 60° C (-4° to 140° F)
Inputs/Outputs
1 Analog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .D-Sub 15 pin
Audio Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3.5 mm stereo jack
(ADMNC1LCD19 only)
Regulatory
Emissions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .EN50081-1, FCC Class B
Immunity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .EN50082-1
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .EN6095, UL1950, CSA 950
Supporting Models
VESA 640 x 480 @ 60 Hz, 25.17 MHz
MAC 640 x 480 @ 67 Hz, 30.24 MHz
VESA 640 x 480 @ 72 Hz, 31.50 MHz
VESA 640 x 480 @ 75 Hz, 31.50 MHz
VESA 720 x 400 @ 70 Hz, 28.32 MHz
VESA 800 x 600 @ 56 Hz, 36.00 MHz
VESA 800 x 600 @ 60 Hz, 40.00 MHz
VESA 800 x 600 @ 72 Hz, 50.00 MHz
VESA 800 x 600 @ 75 Hz, 49.50 MHz
MAC 832 x 624 @ 75 Hz, 57.28 MHz
VESA 1024 x 768 @ 60 Hz, 65.00 MHz
VESA 1024 x 768 @ 70 Hz, 75.00 MHz
VESA 1024 x 768 @ 75 Hz, 78.75 MHz
VESA 1280 x 1024 @ 60 Hz, 108.00 MHz
(ADMNC1LCD17 and ADMNC1LCD19)
VESA 1280 x 1024 @ 75 Hz, 135.00 MHz
(ADMNC1LCD17 and ADMNC1LCD19)
