Samsung ME32C User manual

LFD DISPLAY
User Manual
The color and the appearance may differ depending on the
product, and the specifications are subject to change without
prior notice to improve the performance.
ME32C ME40C ME46C ME55C
BN46-00359A-03

Table of contents
Before Using the Product
Copyright 7
Safety Precautions 8
Symbols 8
Cleaning 8
Storage 9
Electricity and Safety 9
Installation 10
Operation 12
Preparations
Checking the Contents 16
Removing the Packaging
(for ME32C ME40C and ME46C models only) 16
Removing the Packaging
(for ME55C models only) 17
Checking the Components 18
Parts 20
Control Panel 20
Anti-theft Lock 23
Remote Control 24
Connection Using an IR Stereo Cable
(sold separately) 27
Before Installing the Product (Installation
Guide) 28
Tilting Angle and Rotation 28
Ventilation 28
Dimensions 29
Installing the Wall Mount 30
Preparing before installing Wall-Mount 30
Installing the Wall Mount Kit 30
Wall Mount Kit Specifications (VESA) 31
Remote Control (RS232C) 32
Cable Connection 32
Connection 35
Control Codes 36
Connecting and Using a Source
Device
Before Connecting 46
Pre-connection Checkpoints 46
Connecting to a PC 47
Connection using the D-SUB cable (Analog type) 47
Connection using a DVI cable (Digital type) 48
Connection Using an HDMI-DVI Cable 48
Connection Using an HDMI Cable 49
Connection Using an DP Cable 49
Changing the Resolution 50
Changing the Resolution on Windows XP 50
Changing the Resolution on Windows Vista 50
Changing the Resolution on Windows 7 51
Changing the Resolution on Windows 8 51
Connecting an External Monitor 52
Connecting to a Video Device 53
Connection Using the AV Cable 53
Connection Using the component Cable 54
Connection Using an HDMI-DVI Cable 54
Connection Using an HDMI Cable 55
Connecting to an Audio System 56
Connecting the antenna 56
Connecting the network box
(Sold separately) 57
MagicInfo 57
Changing the Input source 60
Source 60
Using MDC
Configuring Settings for Multi Control 61
Configuring settings for Multi Control 61
MDC Program Installation/Uninstallation 62
Installation 62
Uninstallation 62
What is MDC? 63
Connecting to MDC 63
Connection Management 66
User Login 67
Auto Set ID 68
Cloning 69
Command Retry 70
Getting Started with MDC 71
2

Table of contents
Main Screen Layout 72
Menus 72
Screen Adjustment 74
Advanced features 77
Sound Adjustment 79
System Setup 79
Tool Settings 88
Other Functions 91
Group Management 92
Schedule Management 94
Troubleshooting Guide 96
Screen Adjustment
Picture Mode 98
If the input source is PC, DVI or DisplayPort 98
If the input source is AV, Component, HDMI1,
HDMI2, or TV 98
Backlight / Contrast / Brightness / Sharpness /
Color / Tint (G/R) 99
Screen Adjustment 100
Picture Size 100
Position 102
Zoom/Position 102
PC Screen Adjustment 103
Resolution Select 103
Auto Adjustment 104
Rotation 104
Aspect Ratio 105
Advanced Settings 106
Dynamic Contrast 107
Black Tone 107
Flesh Tone 107
RGB Only Mode 107
Color Space 107
White Balance 108
10p White Balance 108
Gamma 108
Expert Pattern 109
Motion Lighting 109
Picture Options 110
Color Tone 111
Color Temp. 111
Digital Noise Filter 111
MPEG Noise Filter 111
HDMI Black Level 112
Film Mode 112
Auto Motion Plus (for ME55C models only) 113
Dynamic Backlight 113
Reset Picture 114
Sound Adjustment
Sound Mode 115
Sound Effect 116
Broadcast Audio Options 117
Speaker Settings 118
Reset Sound 119
Channel
Antenna 120
Auto Program 121
Clear Scrambled Channel 122
Fine Tune 123
Crosstalk Noise Reduction 124
3

Table of contents
Network
Network Settings 125
Connecting to a Wired Network 125
Wired Network Settings 127
Connecting to a Wireless Network 129
Wireless Network Setting 130
WPS(PBC) 133
Network Status 134
Wi-Fi Direct 135
Soft AP 136
AllShare Settings 137
Device Name 137
System
Setup 138
Initial settings (Setup) 138
Multi Control 139
Configuring settings for Multi Control 139
Time 140
Clock 140
Sleep Timer 141
On Timer 142
Off Timer 143
Holiday Management 143
Menu Language 144
Rotate Menu 145
Eco Solution 146
Energy Saving 146
Eco Sensor 146
No Signal Power Off 146
Auto Power Off 146
Caption 147
Caption 147
Caption Mode 147
Digital Caption Options 148
Security 149
Safety Lock 149
Button Lock 149
Program Rating Lock 149
Change PIN 151
PIP 152
Auto Protection Time 153
Screen Burn Protection 154
Pixel Shift 154
Timer 155
Immediate Display 156
Side Gray 156
Ticker 157
Video Wall 158
Video Wall 158
Format 158
Horizontal 158
Vertical 159
Screen Position 159
Source AutoSwitch Settings 160
Source AutoSwitch 160
Primary Source Recovery 160
Primary Source 160
Secondary Source 160
General 161
Max. Power Saving 161
Game Mode 161
BD Wise 161
Menu Transparency 161
Sound Feedback 162
Auto Power 162
Standby Control 162
Lamp Schedule 163
OSD Display 163
Power On Adjustment 163
Temperature Control 163
Anynet+ (HDMI-CEC) 164
Anynet+ (HDMI-CEC) 164
Auto Turn Off 165
Troubleshooting for Anynet+ 166
DivX®Video On Demand 168
Player Mode 168
Magic Clone 169
Reset System 169
Reset All 170
PC Module Power 170
4

Table of contents
Synced Power-On 170
Synced Power-Off 170
Support
Software Update 171
By USB 171
Contact Samsung 171
Contents Home 172
Channel List 172
Channel Manager 173
Icons in Channel 173
Adding a channel (Channel) 174
Deleting a channel in Channel 174
Using Tools in Channel 175
Edit Favorites 175
Rename Channel 177
Add / Delete 177
Select All / Deselect All 177
Adding a favorite channel 178
Deleting a Channel from a list of
favorite channels 179
MagicInfo Lite 180
MagicInfo Premium S 180
MagicInfo Videowall S 181
AllShare Play 181
Source 182
AllShare Play
What is AllShare Play? 183
Read the following before using
AllShare Play with a USB device 183
Using a USB device 185
Connecting to a PC over a network 186
Using the AllShare Play features 187
Using the Basic AllShare Play Features 188
Sorting the file lists 188
Playing Selected Files 189
Copying Files 189
Creating a Playlist 189
My List 190
My List options 190
Videos 191
Playing a Video 191
Photos 192
Viewing a Photo (or Slide Show) 192
Music 193
Playing Music 193
Videos / Photos / Music Play Option menu 194
Supported Subtitle and AllShare Play file
formats 196
Subtitle 196
Supported image resolutions 196
Supported music file formats 197
Supported Video Formats 197
MagicInfo Lite
File Formats Compatible with
MagicInfo Lite Player 199
Read before using MagicInfo Lite Player 199
Approving a connected device from
the server 204
MagicInfo Lite 206
MagicInfo Lite Player 206
Local Schedule Manager 209
Content Manager 216
Settings 218
When Content is Running 220
MagicInfo Premium S
File Formats Compatible with
MagicInfo Premium S Player 222
Read before using MagicInfo Premium S Player 222
Approving a connected device from
the server 228
MagicInfo Premium S 230
MagicInfo Premium S Player 230
Local Schedule Manager 233
Template Manager 240
Content Manager 243
Settings 245
When Content is Running 247
5

MagicInfo Videowall S
File Formats Compatible with
MagicInfo Videowall S Player 249
Read before using MagicInfo Videowall S Player 249
MagicInfo Videowall S 252
Settings 252
When Content is Running 253
Troubleshooting Guide
Requirements Before Contacting Samsung
Customer Service Center 254
Testing the Product 254
Checking the Resolution and Frequency 254
Check the followings. 255
Q & A 262
Specifications
General 264
PowerSaver 267
Preset Timing Modes 268
Appendix
Contact SAMSUNG WORLD WIDE 270
Responsibility for the Pay Service
(Cost to Customers) 272
Not a product defect 272
A Product damage caused by customer's fault 272
Others 272
Optimum Picture Quality and Afterimage
Burn-in Prevention 273
Optimum Picture Quality 273
Prevention of Afterimage Burn-in 274
License 276
Terminology 277
Table of contents
6

7
Before Using the Product
Chapter 01
Copyright
The contents of this manual are subject to change without notice to improve quality.
©2013 Samsung Electronics
Samsung Electronics owns the copyright for this manual.
Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited.
Microsoft, Windows are registered trademarks of Microsoft Corporation.
VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.
Ownership of all other trademarks is attributed to their due owner.

8
Safety Precautions
Caution
RISK OF ELECTRIC SHOCK DO NOT OPEN
Caution : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. (OR BACK)
THERE ARE NO USER SERVICEABLE PARTS INSIDE.
REFER ALL SERVICING TO QUALIFIED PERSONNEL.
This symbol indicates that high voltage is present inside.
It is dangerous to make any kind of contact with any internal part of this product.
This symbol alerts you that important literature concerning operation and maintenance has been
included with this product.
Symbols
Warning
A serious or fatal injury may result if instructions are not followed.
Caution
Personal injury or damage to properties may result if instructions are not followed.
Activities marked by this symbol are prohibited.
Instructions marked by this symbol must be followed.
Cleaning
―Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.
―Take the following steps when cleaning.
―The following images are for reference only. Real-life situations may differ from what is shown in the
images.
1
Power off the product and computer.
2
Disconnect the power cord from the product.
―Hold the power cable by the plug and do not touch the cable with wet
hands. Otherwise, an electric shock may result.
!
3
Wipe the product with a clean, soft and dry cloth.
•Do not use detergents that contain alcohol, solvent or
surface-active agents.
•Do not spray water or detergent directly on the product.
4
Wet a soft and dry cloth in water and wring thoroughly to clean the
exterior of the product.
5
Connect the power cord to the product when cleaning is finished.
6
Power on the product and computer.

9
Storage
Due to the characteristics of high-glossy products, using a UV humidifier nearby may create white-
colored stains on the product.
―Contact Customer Service Center if the inside of the product needs cleaning (service fee will be
charged).
Electricity and Safety
―The following images are for reference only. Real-life situations may differ from what is shown in the
images.
Warning
Do not use a damaged power cord or plug, or a loose power socket.
•An electric shock or fire may result.
Do not use multiple products with a single power socket.
•Overheated power sockets may cause a fire.
Do not touch the power plug with wet hands. Otherwise, an electric shock
may result.
!
Insert the power plug all the way in so it is not loose.
•An unsecure connection may cause a fire.
!
Connect the power plug to a grounded power socket (type 1 insulated
devices only).
•An electric shock or injury may result.
Do not bend or pull the power cord with force. Be careful not to leave the
power cord under a heavy object.
•Damage to the cord may result in a fire or electric shock.
Do not place the power cord or product near heat sources.
•A fire or electric shock may result.
!
Clean any dust around the pins of the power plug or the power socket with
a dry cloth.
•A fire may result.

10
Caution
Do not disconnect the power cord while the product is being used.
•The product may become damaged by an electric shock.
!
Only use the power cord provided with your product by Samsung. Do not
use the power cord with other products.
•A fire or electric shock may result.
!
Keep the power socket where the power cord is connected unobstructed.
•The power cord must be disconnected to cut off power to the product
when an issue occurs.
•Note that the product is not completely powered down by using only
the power button on the remote.
!
Hold the plug when disconnecting the power cord from the power socket.
•An electric shock or fire may result.
Installation
Warning
DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP OF
THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.
•A fire may result.
!
Have a technician install the wall-mount hanger.
•Installation by an unqualified person can result in an injury.
•Only use approved cabinets.
Do not install the product in poorly ventilated spaces such as a bookcase or
closet.
•An increased internal temperature may cause a fire.
!
Install the product at least 10cm away from the wall to allow ventilation.
•An increased internal temperature may cause a fire.
!
Keep the plastic packaging out of the reach of children.
•Children may suffocate.

11
!
Bend and keep part of the outdoor TV antenna cable hanging downwards
(the part inside the room) to prevent rainwater from entering the product.
•If rainwater enters the product, a fire or electric shock can occur.
!
When using an outdoor antenna, be sure to install the antenna away from
nearby power lines to prevent the antenna from collapsing onto them in
strong winds.
•A collapsed antenna can cause an electric shock or injury.
Do not install the product on an unstable or vibrating surface (insecure shelf,
sloped surface, etc.)
•The product may fall and become damaged and/or cause an injury.
•Using the product in an area with excess vibration may damage the
product or cause a fire.
!
Do not install the product in a vehicle or a place exposed to dust, moisture
(water drips, etc.), oil, or smoke.
•A fire or electric shock may result.
Do not expose the product to direct sunlight, heat, or a hot object such as a
stove.
•The product lifespan may be reduced or a fire may result.
Do not install the product within the reach of young children.
•The product may fall and injure children.
•As the front is heavy, install the product on a flat and stable surface.
Edible oil, such as soybean oil, can damage or deform the product. Do not
install the product in a kitchen or near a kitchen counter.

12
Caution
!
Do not drop the product while moving.
•Product failure or personal injury may result.
Do not set down the product on its front.
•The screen may become damaged.
When installing the product on a cabinet or shelf, make sure that the
bottom edge of the front of the product is not protruding.
•The product may fall and become damaged and/or cause an injury.
•Install the product only on cabinets or shelves of the right size.
!
Set down the product gently.
•Product failure or personal injury may result.
SAMSUNG
!
Operation
Warning
There is a high voltage inside the product. Never disassemble, repair or
modify the product yourself.
•A fire or electric shock may result.
•Contact Samsung Customer Service Center for repairs.
!
Before moving the product, turn off the power switch and disconnect the
power cord, antenna cable and all other connected cables.
•Damage to the cord may result in a fire or electric shock.
!
If the product generates abnormal sounds, a burning smell or smoke,
disconnect the power cord immediately and contact Samsung Customer
Service Center.
•An electric shock or fire may result.
Do not let children hang from the product or climb on top of it.
•Children may become injured or seriously harmed.
If the product is dropped or the outer case is damaged, turn off the power
switch and disconnect the power cord. Then contact Samsung Customer
Service Center.
•Continued use can result in a fire or electric shock.
Installing the product in an unusual place (a place exposed to a lot of fine
dust, chemical substances, extreme temperatures or a significant presence
of moisture, or a place where the product will operate continuously for an
extended period of time) may seriously affect its performance.
•Be sure to consult Samsung Customer Service Center if you want to
install the product at such a place.

13
Do not leave heavy objects or items that children like (toys, sweets, etc.) on
top of the product.
•The product or heavy objects may fall as children try to reach for the
toys or sweets resulting in a serious injury.
!
During a lightning or thunderstorm, remove the power cable and do not
touch the antenna cable.
•A fire or electric shock may result.
!
Do not drop objects on the product or apply impact.
•A fire or electric shock may result.
Do not move the product by pulling the power cord or any cable.
•Product failure, an electric shock or fire may result from a damaged
cable.
!GAS
If a gas leakage is found, do not touch the product or power plug. Also,
ventilate the area immediately.
•Sparks can cause an explosion or fire.
Do not lift or move the product by pulling the power cord or any cable.
•Product failure, an electric shock or fire may result from a damaged
cable.
!
Do not use or keep combustible spray or an inflammable substance near
the product.
•An explosion or fire may result.
Ensure the vents are not blocked by tablecloths or curtains.
•An increased internal temperature may cause a fire.
100
Do not insert metallic objects (chopsticks, coins, hairpins, etc) or objects
that burn easily (paper, matches, etc) into the product (via the vent or input/
output ports, etc).
•Be sure to power off the product and disconnect the power cord
when water or other foreign substances have entered the product.
Then contact Samsung Customer Service Center.
•Product failure, an electric shock or fire may result.
Do not place objects containing liquid (vases, pots, bottles, etc) or metallic
objects on top of the product.
•Be sure to power off the product and disconnect the power cord
when water or other foreign substances have entered the product.
Then contact Samsung Customer Service Center.
•Product failure, an electric shock or fire may result.

14
Caution
!
Leaving the screen fixed on a stationary image for an extended period of
time may cause afterimage burn-in or defective pixels.
•Activate power-saving mode or a moving-picture screen saver if you
will not be using the product for an extended period of time.
-_-
!
Disconnect the power cord from the power socket if you do not plan on
using the product for an extended period of time (vacation, etc).
•Dust accumulation combined with heat can cause a fire, electric shock
or electric leakage.
!
Use the product at the recommended resolution and frequency.
•Your eyesight may deteriorate.
Do not hold the product upside-down or move it by holding the stand.
•The product may fall and become damaged or cause an injury.
!
Looking at the screen too close for an extended period of time can
deteriorate your eyesight.
Do not use humidifiers or stoves around the product.
•A fire or electric shock may result.
!
Rest your eyes for more than 5 minutes for every 1 hour of product use.
•Eye fatigue will be relieved.
Do not touch the screen when the product has been turned on for an
extended period of time as it will become hot.
!
Store small accessories out of the reach of children.
!
Exercise caution when adjusting the product angle or stand height.
•Your hand or finger may get stuck and injured.
•Tilting the product at an excessive angle may cause the product to fall
and an injury may result.
Do not place heavy objects on the product.
•Product failure or personal injury may result.
When using headphones or earphones, do not turn the volume too high.
•Having the sound too loud may damage your hearing.

15
Be careful that children do not place the battery in their mouths when
removed from the remote control. Place the battery in a location that
children or infants cannot reach.
•If children have had the battery in their mouths, consult your doctor
immediately.
When replacing the battery, insert it with the right polarity (+, -).
•Otherwise, the battery may become damaged or it may cause fire,
personal injury or damage due to leakage of the internal liquid.
!
Use only the specified standardized batteries, and do not use a new battery
and a used battery at the same time.
•Otherwise, the batteries may be damaged or cause fire, personal injury
or damage due to a leakage of the internal liquid.
!
The batteries (and rechargeable batteries) are not ordinary refuse and must
be returned for recycling purposes. The customer is responsible for returning
the used or rechargeable batteries for recycling.
•The customer can return used or rechargeable batteries to a nearby
public recycling center or to a store selling the same type of the
battery or rechargeable battery.

16
Preparations
Chapter 02
Checking the Contents
Removing the Packaging
(for ME32C ME40C and ME46C models only)
―The following images are for reference only. Real-life situations may differ from what is shown in the
images.
1
Remove the black locking device at the bottom of the box.
2
Remove the styrofoam from the product.
3
Check the product and remove the styrofoam and plastic bag.
―The appearance of the actual product may differ from the image shown.
―This image is for reference only.
4
Store the box in a dry area so that it can be used when moving the product in the future.

17
Removing the Packaging (for ME55C models only)
―The following images are for reference only. Real-life situations may differ from what is shown in the
images.
1
Remove the black locking device at the bottom of the box.
321
2
Using the grooves in the box, lift and remove the top of the box.
3
Check the components and remove the styrofoam and plastic bag.
―The appearance of actual components may differ from the image shown.
4
Store the box in a dry area so that it can be used when moving the product in the future.

18
-Contact the vendor where you
purchased the product if any
components are missing.
-The appearance of the components and
items sold separately may differ from the
image shown.
-A stand is not provided with the product.
To install a stand, you can purchase one
separately.
Checking the Components
Components
―Components may differ in different locations.
Quick setup guide
Warranty card
(Not available in some
locations)
User manual MagicInfo Lite Edition Software
CD
+
+
-
-
Batteries (P. 25)
(Not available in some locations)
Remote Control (P. 24)
(AA59-00714A) Power cord D-SUB cable (P. 47)
Holder-Ring (4EA)
(BN61-07295A) RS232C(IN) adapter

19
Items sold separately
-The following items can be purchased
at your nearest retailer.
Wall-mount Kit Stand RS232C-Stereo cable (P. 63) DVI cable (P. 48) HDMI-DVI cable (P. 48)
DP cable (P. 49) HDMI cable (P. 49) Video cable (P. 53) Stereo cable (P. 27) Component cable (P. 54)
RCA stereo cable (P. 56) RCA cable (P. 53) AV/Component adapter (P. 53) AUDIO adapter (P. 53) External sensor Kit (P. 27)
RS232C(OUT) adapter LAN cable Network Box
DP-DVI cable
(Used to connect a network
box)
-The RS232C adapter can be used to
connect to another monitor using the
D-SUB (9-pin) type RS232C cable.
-Ensure you connect each of the adapters
to the correct RS232C IN or OUT port on
the product.

20
Parts
Control Panel
ON
POWER
Panel Key
Speaker
POWER
Remote sensor
―The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve
quality.
Panel Key
Buttons Description
Power on the product.
If you press the button when the product is turned on, the control menu will be
displayed.
―To exit the OSD menu, press and hold the panel key for at least one second.
Move to the upper or lower menu. You can also adjust the value of an option.
Change the channel in TV mode.
Move to the left or right menu.
―You can adjust the volume by moving the panel key left or right when the control
menu is not displayed.
Remote sensor
Press a button on the remote control pointing at the sensor on the front of the
product to perform the corresponding function.
―Using other display devices in the same space as the remote control of this
product can cause the other display devices to be inadvertently controlled.
