AOC LM720 - 17" User manual

Ultra-Thin LCD
TECHNICAL SPECIFICATIONS
•Screen Size:VIS:17”(43.2cm),diagonal
•Panel:TFT Active Matrix LCD,Slim Cabinet Hard Coating (3H),Anti-glareTreatment
•Pixel Pitch: 0,264mm x 0,264mm
•Display Area: 338 x 270mm
•Brightness: 250cd/m2
•Contrast Ratio: 450:1
•ResponseTime: 16ms
•Viewing angle: Horizontal:150º -Vertical:125º
•Compatibility:VESA,SXGA,XGA,SVGA,VGA,Mac® equipped withVGA port
•Scanning Frequency: Horizontal:30K ˜83KHz - Vertical: 55 ˜75Hz
•Pixel Frequency: 135MHz
•Maximum Resolution: 1280 x 1024 @ 75Hz
•Recommended Resolution: 1280 x 1024 @ 60Hz
•Resolutions Supported: 640 x 350 @ 70Hz, 740 x 400 @ 70Hz, 640 x 480 @ 60/75Hz, 800 x 600 @ 60/75Hz,
1024 x 768 @ 60/70/75Hz,1280 x 1024 @ 60/75Hz
•Color: 16,2 m
•Signal Input:Video:0.7Vp-p,RGB Analog
•Connectors: RGB Sinal:15 pin D-sub Male (Attached) Power:Coax Power Jack
•Power Source: DC Input: 12VDC 3.5A Power Adapter Input:Universal 100 ~ 240 VAC, 50/60Hz Power Adapter Output:
12VDC 5A (Max)
•Power Consumption: 45W (Max)
•Plug & Play: DDC1/2B
•EPA Energy Star®:Yes
•User Control:Auto Adjust,Left Key,Right Key,Menu Key,On/Off Key
•OSD Function:Brightness,Contrast,Focus,Clock,H/V Position,Auto-Center,Language,DOS Mode,7800,6500,Recall,Exit,RGB
•Language Supported: English,French,German,Spanish & Italian
•Emissions Standard:TCO99
•Regulations: UL,CSA,FCC,TUV/GS,CE,ISO 13406-2,Windows® XP Logo
•Other Features:VESA 75mm Wall Mount Compliant*,Kensington Security Slot
•Dimensions (W x H x D mm): Monitor:407 x 423 x 215 - Carton:494 x 550 x 214
•Dimensions (W x H x D inches): Monitor:16.0 x 16.7 x 8.5 - Carton:19.4 x 21.7 x 8.4
•Monitor Dimensions w/o Base (W x H x D): 407 x 350 x 53mm;16.0 x 13.8 x 2.1 inches
•Weight: Net:11lbs (5.0kg) - Gross:14.0lbs (6.4kg)
•Loading Qty w/pallet: 20’=572 pcs.;40’Std= 1248pcs.
•Warranty: 3 Years
Monitor LCD 17” (LM720)
UPC Code:685417122240
* Wall Mount arm and bracket not included.Note:Specifications are subject to change without notice.
