American Fireglass SS-AFPPKIT-24-N User manual

American Fireglass Outdoor Fire pit kit information
General instructions/warnings for outdoor gas pan and burner systems
We strongly recommend that our burner products be installed by a
licensed and certified gas contractor or an NFI Certified Gas Specialist.
http://nficertified.org/
Installation must conform with all local state and national codes. In the
absence of local or state codes refer to National Fuel Gas Code, ANSI Z223.1.
Caution
It is recommended that outdoor fire features not be operated when wind exceeds 25 mph
Prior to turning appliance on visually inspect fire feature to ensure debris such as leaves or
other combustible material has not collected inside the feature which could burn and emit
embers once the fire feature is turned. Also ensure any person standing close to the fire
feature is aware you will be turning the fire feature on prior to actually turning it on.
WARNING: NEVER leave an operating fire feature unattended by an adult.
WARNING: If the information in these instructions is not followed exactly, a fire may result
causing property damage, personal injury or death
Inspect the Appliance and Components

Warning
Do NOT install damaged components
Do NOT install incomplete components
Do NOT install substitute components
Clearances
Below is a general fire feature structure clearance guideline. Be sure to check for fire
feature clearance guidelines, codes, or ordinances specifically for your area.
Drop-in style pans must be mounted on non-combustible surfaces. All enclosures must be
well ventilated with a minimum of (2) vents of at least 18 square inches on opposing sides.
WARNING
Never operate an open flame fire feature under any type of overhang or cover.

Installation and service should be performed by a qualified installer, service
agency or the gas supplier.
WARNING: Improper installation, adjustment, alteration, service or maintenance can cause
injury or property damage.
Prior to turning appliance on visually inspect fire feature to ensure debris such as leaves or other
combustible material has not collected inside the feature which could burn and emit embers once
the fire feature is turned. Also ensure any person standing close to the fire feature is aware you
will be turning the fire feature on prior to actually turning it on.
WARNING: These fire feature components are for outdoor use only
** For use with NATURAL or LP GAS Only **
** Not to be used with solid fuels. **
- Do not store or use gasoline or other flammable liquids in the vicinity of this appliance.
Gas Information
Fuel –Before making gas connections ensure appliance being installed is compatible with the
available gas type.
Gas Pressure –Proper Input Pressures are required for optimum appliance performance. Gas
line sizing requirements need to be made following NFPA51.
Gas Connection –Have the gas supply line installed in accordance with local building codes, if
any. If not, follow ANSI (Z)223.1. Installation should be done by a qualified installer approved
and/or licensed as required by the locality.
Note: A listed manual gas shutoff device must be installed prior to the location of the
appliance
Startup –A small amount of air will be in the gas supply lines. When first lighting appliance it
will take a short time for air to purge from lines. Subsequent lighting of the appliance will not
require such purging.
WARNING

Check for Gas Leaks after installation complete
Check all fittings and connections
Do not use open flame to check for leaks
Check for leaks with a commercially available, non-corrosive leak check
solution
- WHAT TO DO IF YOU SMELL GAS
- Do not try to light any appliance.
- Do not touch any electrical switch; do not use any phone in your building.
- Immediately call your gas supplier. Follow the gas supplier’s instructions.
- If you cannot reach your gas supplier, call the fire department.
LP Gas Installation Considerations
Due to the fact LP (Propane) Gas is different (heavier) from natural gas there are some slight
differences in the installation procedures. These differences are listed here:
1. Installation of an Air Mixer. Propane is a much more volatile fuel when compared to
natural gas. For this reason an Air Mixer is installed in the inlet of the burner element to lean out
the gas, of which minimized propane soot as well.
2. Drainage/Venting of the bottom of the Fire Feature. Unlike natural gas, LP gas is heavier
than air. Because it is heavier than air any ‘unburned’ LP gas will likely go to the bottom of the
fire feature. Without proper drainage/venting at the bottom of the fire feature LP gas will collect
in the bottom of the fire feature and WILL cause a very hazardous situation. For this reason
venting at the bottom of the fire feature MUST be installed to allow any unburned LP gas to
escape from the bottom of the fire feature thereby eliminating the hazard. Be sure to install two
vents on opposing sides, each with 18 Square inches of ventilation per side.
3. Fire glass media on top of the Fire Pit Ring. It is recommended to use no more than a 2"
thick layer of fire glass media ON TOP of the Burner Element in an LP gas fire feature. The less
media there is on top of the burner element the less obstructions there are which could prevent
LP gas from being ignited at the top of the fire feature. By reducing the depth of the media you
have reduced the chance of unburned LP gas from going to the bottom of the fire feature.
WARNING
Fire Risk / Burn Risk / HOT! DO NOT TOUCH

SEVERE BURNS MAY RESULT - CLOTHING IGNITION MAY RESULT
Keep Children away.
CAREFULLY SUPERVISE children in same area as the appliance.
Alert children and adults to hazards of high temperatures.
Clothing or other flammable materials should not be hung from the
appliance or placed on or near the appliance.
WARNING: NEVER leave an operating fire feature unattended by an adult.
Basic information & dimensions:
SS-AFPPKIT-24-N (Natural Gas)
The pan measures 24" x 8" x 2" deep with a 1 1/4" lip on all four sides
H-Style burner is built in to the pan.
The recommended surface rough opening for mounting the pan is: 25" x 9"
We recommend that this unit be mounted on a non-combustible surface.
Approximate BTU potential: 120,000 BTU/HR
The kit includes:
(1) Stainless steel pan and built in H-burner
(1) AAA push button spark ignites kit
(1) AFG-AFPIK-N installation kit: Regulator, key valve, 1/2" gas hoses and misc fittings.
