OWNER’S MANUAL FOR
MONGOLIAN BARBEQUE GRILL
MODEL NUMBERS:
AMBG-36, AMBG-42, AMBG-48, AMBG-50, AMBG-60
PROFESSIONAL QUALITY COOKING EQUIPMENT
13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel [phone] toll free www.americanrange.com
DESIGN CLASS FUNCTION

Installation, Operation and
Maintenance Instructions
Mongolian
Barbeque Grill
Owner’s Manual
13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel [phone] toll free www.americanrange.com
FOR YOUR SAFETY!
Do not store or use gasoline or
other ammable vapors or liquids
in the vicinity of this or any other appliance.
FOR
YOUR
SAFETY
FOR
YOUR
SAFETY
RETAIN THIS MANUAL FOR FUTURE REFERENCE.
WARNING!
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, injury
or death and will void warranty. Read the
installation, operating and maintenance instructions
thoroughly before installing or servicing this equipment.
WARNING
IMPROPER
INSTALLATION
WARNING
IMPROPER
INSTALLATION
Model Number: __________________________________________
Serial Number: ___________________________________________
Purchase Date: ___________________________________________
Installed By: __________________________ Install Date:__________
Gas Type: _______________________________________________
Electrical Information: ______________________________________
This equipment is design engineered for commercial use only.
IMPORTANT SERVICE NOTICE!
Using any part other than genuine American Range factory supplied
parts relieves the manufacturer of all liability.
American Range reserves the right to change product design and
specications without notice. Such revisions do not entitle the buyer
to corresponding changes, improvements, additions or replacements
for the previously purchased equipment.
Instructions to be followed in the event the user smells gas should be posted
in a prominent location. This information should be obtained by
consulting the local gas supplier.

To Our Most Valued Customer:
Congratulations on your purchase of an American Range product. We hope you will enjoy the
design, manufactured quality, innovative features and cooking performance of this product – it
represents our continuing dedication to satisfying the most demanding needs of customers
like you.
Please read this manual and become familiar with important safety information about how
to install and set-up the unit, basic operating instructions, and how to maintain that just-like-
brand-new appearance and performance - over years of day-to-day use.
If you should encounter any sort of problem, turn to the section of the manual entitled,
“Troubleshooting” – for a quick solution or guidance regarding the next step required to get
back to tip-top condition.
Thank you for choosing an American Range product for your kitchen.As you can expect, this
appliance is designed for years of reliable service. If you have any questions or comments,
please contact the dealer from whom you purchased the unit, or contact American Range
Customer Service via email: [e-mail] at www.americanrange.com, or call
888.753.9898.
PROFESSIONAL QUALITY COOKING EQUIPMENT
13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel [phone] toll free www.americanrange.com
Sincerely,
President, American Range Corporation
Shane Demirjian

13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel [phone] toll free www.americanrange.com
Mongolian Barbeque GrillOwner’s Manual
Table of Contents
GENERAL ...................................................................................................... 1
Important Safety Information .......................................................................1
Shipping Damage Claim Procedure..........................................................1
INSTALLATION ........................................................................................1-3
Instructions ..............................................................................................................1
Gas Standards and Codes ..............................................................................2
Gas Connection....................................................................................................2
Manual Shut-Off Valve.......................................................................................2
Rating Plate..............................................................................................................3
Clearances................................................................................................................3
OPERATING ..............................................................................................3-4
Check for Gas Leaks..........................................................................................3
Lighting.......................................................................................................................4
Shut Down ..............................................................................................................4
MAINTENANCE.......................................................................................5-6
AMBG-36, AMBG-42, AMBG-48, AMBG-50, AMBG-60..............5
TroubleShooting Guide.....................................................................................6
Wiring Diagram.....................................................................................................6
EXPLODED VIEW DRAWINGS/PARTS LISTS ..................................... 7
AMBG-36..................................................................................................................7

Owner’s Manual Mongolian Barbeque Grill
13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel [phone] toll free www.americanrange.com
1
Installation of the equipment should be performed by qualied, certied, licensed and/or authorized personnel who are familiar with
the functions of the equipment and experienced with state/local installation codes.
Operation of the equipment should be performed by qualied or authorized personnel who have read this manual and are familiar
with the functions of the equipment.
Service of the equipment should be performed by qualied personnel who are knowledgeable with American Range equipment.
The gas pressure regulator provided with the equipment must be installed when the appliance is connected to the gas supply.
The area around the appliance must be kept free and clear of combustibles such as solvents, cleaning liquids, brooms, rags, etc.
Proper clearances must be provided at the front of the appliances for servicing and proper operation.
Provisions shall be incorporated in the design of the kitchen, to ensure an adequate supply of fresh air and adequate clearance for
air openings into the combustion chamber, for proper combustion and ventilation. For proper operation of the appliance, do not
obstruct the ow of combustion and ventilation air.
The installation must conform with local codes, or in the absence of local codes, with the national fuel gas code, ANSI Z223.1 - 1988
(or latest addenda).
The appliance and its individual shut off valve must be disconnected from the gas supply piping system during any pressure testing of
that system in excess of 1/2 PSI.
The appliance must be isolated from the gas supply piping system by closing its individual manual shut off valve during any pressure
testing of the gas supply piping system at test pressures equal to or less than 1/2 PSI.
The gas supply line must be at least 3/4” NPT.
SHIPPING DAMAGE CLAIM PROCEDURE
The equipment is crafted and inspected carefully by skilled personnel before leaving the factory. The transportation company
assumes full responsibility for the safe delivery upon acceptance of the equipment.
If you receive a damaged product, immediately contact your delivery company, your dealer, your builder or installer. Do not
install or attempt to operate a damaged appliance.
1. Note any visible loss or damage on the freight bill or express delivery and have the note signed by the person making
the delivery.
2. File claim for damages immediately regardless of the extent of damages.
3. For damage noticed after unpacking (concealed loss or damage), notify the transportation company immediately and le
a "Concealed Damage" claim with them. This should be done within fteen (15) days from the date that delivery
is made to you. Retain the shipping container for inspection.
IMPORTANT
INSTALLATION INSTRUCTIONS
CALIFORNIA PROPOSITION 65 WARNING
The burning of gas cooking fuel generates some by-products which are on the list of substances known by the State of California to
cause cancer or reproductive harm. California law requires businesses to warn customers of potential exposure to such substances.
To minimize exposure to these substances, always operate this unit according to the Owners Manual, ensuring you provide proper
ventilation when cooking with gas.

13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel [phone] toll free www.americanrange.com
2
Mongolian Barbeque GrillOwner’s Manual
GAS CONNECTION - The gas inlet line size of this appliance is 3/4” NPT. For proper operation, the gas supply service line
must be the same size or greater than the inlet line size of the appliance. The gas line size must not be reduced at any point along
the supply line.
MANUAL SHUT-OFF VALVE - A gas pressure regulator and a contractor-supplied shut-off valve must be plumbed in the gas
service line ahead of the appliance – in a physical location where it can be reached quickly in the event of an emergency.
Visually double check any installer-supplied intake pipes and/or blow them out using compressed air to clear any dirt or debris,
threading chips, or other foreign matter – before installing a service line. Those particles will clog gas orices when gas pressure is
applied. Compounds used on threaded joints of this appliance piping must be resistant to the action of NG and LP gas and provide
a gas tight seal to prevent leaks.
The gas pressure regulator must be installed in the gas line – failure to install a pressure regulator will void the equipment
warranty. The regulators supplied with ranges have 3/4" NPT connections; the regulator is adjusted at the factory for
5" W.C. (water column) manifold gas pressure (natural gas) or 10" W.C. manifold gas pressure for propane gas operation.
Before connecting the regulator, check the incoming line pressure – as these regulators can only withstand a maximum inlet pressure
of 14" W.C. (1/2 PSI); exceeding this pressure will damage them. If the gas supply line pressure is greater than this amount, a step-
down regulator will be required. A gas ow direction arrow is cast into the body of the regulator to minimize installation error – it
should point downstream to the appliance. The blue air vent cap on the top of the regulator is part of the regulator and should not
be removed.
Any adjustment to the regulator must be made only by qualied and licensed service
personnel with the proper calibrated test equipment. Gas connections should be performed
by a qualied licensed contractor.
INSTALLATION - GAS STANDARDS AND CODES
IMPORTANT - The installation of this appliance must conform to local codes or, in the absence of local codes, with the National Fuel
Gas Code ANSI Z223.1, Natural Gas Installation Code CAN/CGA-B149-1, or the Propane Installation Code CAN/CGA-B149-2
as applicable, including:
1. The appliance and its individual shut off valve must be disconnected from the gas supply piping system during any
pressure testing of that system at test pressure in excess of 1/2 psi (3.45 kPa).
2. The appliance must be isolated from the gas supply piping system by closing the individual manual shut-off
valve during any pressure testing of the gas supply piping system.
When installing the pressure regulator - remember it can only handle 1/2 PSI. In
every LPG installation, you have high source pressures, ranging from 20 PSI to 100
PSI. If the high pressure gas line from the LPG tank is directly connected to the unit
without the proper step-down regulator, it will rupture the diaphragm in the valve,
rendering it useless.
WARNING
!
A
DCE
F
G
C
B B
C
G
F
ECD
A
H
NATURAL GAS LP GAS
A. Gas pressure regulator
B. 90º Street elbow
C. Adapter (must be 3/4" male pipe thread)
D. Flexible connector
E. Manual gas shut-off valve
F. 3/4" gas supply
G. Use pipe-joint compound
A. Gas pressure regulator
B. 90º Street elbow
C. Adapter (must be 3/4" male pipe thread)
D. Flexible connector
E. Manual gas shut-off valve
F. 3/4" gas supply
G. Use pipe-joint compound
H. Step down regulator

Mongolian Barbeque GrillOwner’s Manual
13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel [phone] toll free www.americanrange.com
3
Intertek
3013256
Intertek
MODEL: SERIAL NO.
AMBG
GAS TYPE: NAT MAN. PRESS: IN. W.C.
5.0
INPUT-BTU/HOUR/BURNERC LEARANCES
NON-COMB. COMB.
125,000 BACK
SIDES
0”
0”
X
X
FOR USE ONLY ON NONCOMBUSTIBLE LOCATIONS ONLY.
INTENDED FOR OTHER THAN HOUSEHOLD USE.
ANSI Z83.11a/CSA 1.8a-2007 Food Service Equipment
XXXXXX-XXX
3-RING BURNER
X For installation on a non-combustible counter/oor only.
CLEARANCES
MODEL NON-COMBUSTIBLE WALLS COMBUSTIBLE WALLS
Rear Sides Rear Sides
AMBG-36 0" 0" 7" 8"
AMBG-42 0" 0" 7" 8"
AMBG-48 0" 0" 7" 8"
AMBG-60 0" 0" 7" 8"
Before lighting, check all joints in the gas supply line for leaks. DO NOT USE AN OPEN FLAME TO CHECK FOR LEAKS!
Use soap and water solution.
GAS LEAKS - CHECK OPERATION
1. Turn pilot valves to OFF position by turning adjustment screws clockwise.
2. Turn ON the manual gas valve at the inlet side of the gas supply line.
3. Check for gas leaks at the exible coupling or gas connector tting using a solution of one part soap and three parts water.
4. Sparingly spray or brush the soapy solution at the gas ttings; active bubbling indicates location of gas leak.
5. Turn pilot adjustment screw counter-clockwise, then light standing pilot and
adjust ame 1/4" high.
6. Turn ON gas valve/thermostat to light main burners.
7. For complete shut down, shut off gas valves and turn pilot adjustment screw
clockwise to shut off gas to the pilots.
PILOT ADJUSTMENT SCREW
MORE GAS LESS GAS
+-
Appliances must be connected only to the type of gas specied on the rating plate.
WARNING
!
If a gas leak is detected turn off the manual gas valve at the inlet side of the gas line.
Call your certied and licensed service technician.
Rating Plate
RATING PLATE - The information on the rating plate denes the model, serial
number, gas type (natural or liquid propane), operating pressures and burner BTU
ratings. It is essential for proper identication of the unit when requesting additional
information or factory support.
OPERATING INSTRUCTIONS

Lighting and Shut Down Instructions
Always use the following lighting and shutdown instructions below when operating your Mongolian Barbeque Grill.
A 5 minute complete shut off period is required before lighting or relighting a Mongolian Barbeque Grill. See diagrams on page 5.
1. Beforing allowing gas to ow to the Mongolian Barbeque Grill, ensure all gas valves are OFF by turning each handle clockwise.
Check for leaks using soapy water or another suitable leak detector. Dont use an open ame for testing.
2. Use a gas match to light the burner pilots. See gure 1.
3. Main burner valves shall be in off position. An ignition port is provided for each pilot burner. Use a ashlight to locate each prior
to lighting it is recommended one person light the pilots and the second to locates and holds the red button on each safety
control.
4. Starting at grease drawer access door, insert the ignited lighter through the ignition port and light the pilot burner as you push
and hold the red button on the safety control.
On initial startup, allow 1/2 to 1 minute for air trapped in the gas lines to bleed while holding the safety control ignition
button. A qualied gas service technician can bleed the line from the pressure test port. It is located on the manifold to the
right of the front access door.
Lighting Instructions
1. Before attempting to light this appliance, the door if so equipped, shall be open.
2. Turn the appliance manual gas shut-off valve to the OFF position.
3. Turn the combination gas control knob to the OFF position.
4. Turn the control to the OFF position.
5. Wait 5 minutes.
6. Turn the appliance manual gas shut-off valve to the ON position.
7. Turn the combination gas control knob to the PILOT position.
8. Light the pilot with a match while depressing and holding the combination gas control knob until the pilot remains lit upon
releasing the gas control knob.
9. Turn the combination gas control knob to the ON position
10. Turn the main valve control to the desired setting to turn burners ON.
11. Ensure tha the door if so equipped is closed during operation.
12. For complete shut-down, repeat steps 2,3 and 4.
13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel [phone] toll free www.americanrange.com
4
Mongolian Barbeque GrillOwner’s Manual

IMPORTANT
• The natural gas unit is designed for 5”W.C. operational pressure. A minimum of 7”W.C. must be maintainded or performance
of the unit will not meet specications. The propane unit is designed for 10” W.C. operational gas pressure at the outlet. A
minimum of 12” W.C. must be maintained or performance of the unit will not meet specications.
• There is 1/8” test tap in the front right section of the manifold behind the access door. Using a manometer or similar device,
operating pressure should be veried.
Opeating Instructions
1. The top should come to full operating temperature in approximately 60 minutes after all burners have been lit. Use a high
temperature thermometer to verify the cook surface has reached a minimum operating temperature of 500°F.
2. When the unit reaches operating temperature turn OFF every other burner.The burners on the Mongolian Barbeque Grill
AMBG-36, AMBG-42,AMBG-48 and AMBG-60 are sufficient to maintain operating temperature except during extremly busy
cycles when additional burners may be necessary.
Operational Overview
The Mongolian Barbeque Grill is a high performance griddle-style units. Multiple burners are equally spaced under the top with
individual valves and safety controls. Depending on the size of the top up to four chefs can cook simultaneously as they sautѐ
vegetables, sh, meat and polurty as guests watch. The Mongolian Barbeque Grills are similar to a tepanyaki griddle but much more
powerful.
Seasoning
The rst time you use the unit the top must be seasoned. This must be done while the ventilation system is operating. Wash the
top with soapy water to remove all grease and oil from the manufacturing process. Rinse the top immediately. Using the procedure
described earlier; re up the unit and get the top hot.
Turn down the heat and wipe the surface with a towel coated with cooking oil.With repeated heating and wiping, the top will attain
a non stick nish. Do not use soap again to clean the top but rather a griddle scraper to keep the top free from carbon build-ups.
Cooking
This unit is similar to a high-speed griddle. Intense heat generated by the burners heats the tops to achieve the searing temperatures
of wok-style cooking.Techniques similar to stir-fry are used.
Like a wok or cast iron fry pan the Mongolian Barbeque Grill top must be re-seasoned periodically. Food should not be allowed to
remain on the top as this will cause the top to pit or otherwise deterioate.
13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel [phone] toll free www.americanrange.com
5
Mongolian Barbeque GrillOwner’s Manual
Do not pour cold water on the top while still hot, could damage or warp the cooking surface.
CAUTION
!

TROUBLESHOOTING GUIDE
13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel [phone] toll free www.americanrange.com
6
Mongolian Barbeque GrillOwner’s Manual
Always disconnect the gas service before cleaning or servicing the griddle.
WARNING
!
POSSIBLE CAUSE SUGGESTED ACTION
SYMPTOM: Burners do not come on.
Unit is not connected to gas service Visually check unit is plumbed to gas
Pilot is not burning Light pilot
Burner not burning high Set valve to desired setting
SYMPTOM: Grill not getting hot enough.
Unit may not have been operating long enough Unit preheats to 350ºF in about ten minutes on high setting
Safety valve may be defective Unit will require service
Too little gas pressure, dirty gas line Call for authorized service
SYMPTOM: General cooking problems.
Temperature too low or too high Set unit to desired setting.
Safety valve not working Unit will require service
WIRING DIAGRAM
RED
WHITE
BLACK
GAS VALVE
COMBINATION
TH
THERMOPILE
TP
TP
TH
POWER TO THIS UNIT
EXTERNAL ELECTRICAL
DO NOT CONNECT ANY
WARNING:
RED

7
13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel [phone] toll free www.americanrange.com
Mongolian Barbeque GrillOwner’s Manual
ITEM
NO.
PART
NO. DESCRIPTION
2 A99831 Grease Tray
3 A44003 Nut, Speed #6 Push Black 10601
4 A38000 Name Plate, American Range 8" 10499 Quality Commercial
Chrome
7 A32108 Handle, Gas Valve ARSP-J, ARWR-J 10493
8 A80106 Valve, Gas Ball 1/2" x 1/2" AESP 10492
11 A80102 Valve, Gas AF-Series NAT Gas 11114
A80103 Valve, Gas AF-Series LPG Gas 11114
12 A11103 Pilot, AF 6CH14-6N .018 Nat Gas 11105
A11121 Pilot, AF 6CH14-6 .014 LPG Gas
13 A14034 Burner, Jet 23 Tip #63 Hood Na Gas 10478N
A14035 Burner, Jet 23 Tip #73 Hood LPG Gas 10478L
15 A11102 Thermopile, Power Generator 11109
MONGOLIAN BARBEQUE - PARTS
9
3
SPEED NUT
4
NAME PLATE
812
JET ORIFICE HOOD
14
ASSEMBLY
BULLET FOOT
GAS VALVE (BALL)
PILOT TIP
AMERICAN RANGE THERMOCOUPLE
15
9
3
4
5
6
7
8
13
14
2
1
10
12 11
15

13592 Desmond Street, Pacoima, CA 91331
818.897.0808 888.753.9898 tel
818.897.1670 fax
www.americanrange.com
A70709 04042013
WARRANTY REQUIREMENT
For reliable operation and for your own safety, this professional cooking equipment must
be installed by a certied/licensed contractor.
Failure to comply will void any written or implied warranty.
Should the equipment require service during the standard warranty period, the receipt
proving certied installation must be made available to American Range for verication.
If installation was not performed by a certied/licensed contractor be prepared to submit
a major credit card for payment for proper installation prior to service.
© 2013 American Range
All Rights Reserved
