ZWM 626 W

To review the section on troubleshooting Tips
will help you to solve some common problems
by yourself .
The manufacturer, following a policy of constant
development and updating of the product, may
make modifications without giving prior notice.
If you can not solve the problems by yourself ,
please ask for the help of professional technicians.
Dishwasher Features............................ ........ ...3.
A、Water Softener...........................................4
Attention before or after loading the Dishwasher
Baskets...................................................... ....9..
Filtering System.............................................15
Caring for the Dishwasher...............................16
B、Loading the Salt into the Softener........... ......5.
C、Fill the Rinse Aid Dispenser................. ........5 .
D、Function of Detergent ........................ .........7.
Loading the upper Basket............................ .....9..
Loading the Lower Basket....................... .......10...
Cutlery Basket........................................... ..11...
Wash Cycle Table...........................................13
Turning on the Appliance................................14
Change the Programme...................... ...........14..
At the End of the Wash Cycle...................... .....14.
Before calling for service.................................20
Error codes...................................................21
Technical information.....................................22
Control Panel...................................................3
Positioning the Appliance.............................. ..........19.
Start of Dishwasher .....................19....................
Water Connection...................................... .....18.
Dear Customer,
Please carefully readthismanualbefore usingthe
dishwasher,it will help you to use and maintain the
dishwasher properly.
Pass it on toany subsequentowner ofthe appliance.
Thismanual contains sections on safety Instructions,
Operating Instructions, InstallationInstructionsand
Troubleshooting Tips, etc.
Keep it as a refer in the laterdays.
This appliance is intended tobe usedin household
andsimilar applications suchas:
-staff kitchen areas in shops,offices and other
working environments;
-farm houses;
-byclients inhotels,motels and otherresidential
type environments;
-bed and breakfast type environments.

1
This appliance must be grounded. In the event of a
malfunction or breakdown, grounding will reduce
theriskof anelectricshockbyprovidingapathof
least resistance of electric current. This appliance
is equipped with a cord having an equipment-
grounding conductor and a grounding plug.
The plug must be plugged into an appropriate outlet
that is installed and grounded in accordance with
all local codes and ordinances.
Keep children away from detergent and rinse aid, keep
children away from the open door of the dishwasher,
there could still be some detergent left inside.
Do not abuse, sit on, or stand on the door or dish
rack of the dishwasher.
Do not touch the heating element during or
immediately after use.
(This instruction is only applicable to machines
with a visual heating element.)
Do not wash plastic items unless they are marked
dishwasher safe or the equivalent. For plastic items
not so marked, check the manufacturer's
recommendations.
Use only detergent and rinse additives
designed for an automatic dishwasher.
Never use soap, laundry detergent, or hand
washing detergent in your dishwasher. Keep
these products out of the reach of children.
During installation, the power supply must not
be excessively or dangerously bent or flattened.
Do not tamper with controls.
Do not place any heavy objects on or stand on the
door when it is open. The appliance could tip
forward.
When loading items to be washed:
1) Locate sharp items so that they are not likely
to damage the door seal;
2) Warning: Knives and other utensils with
sharp points must be loaded in the basket
with their points down or placed in a
horizontal position.
When using your dishwasher, you should
prevent plastic items from coming into contact
with the heating element.(This instruction is only
applicable to machines with a visual heating
element.)
If the supply cord is damaged, it must be replaced
by the manufacturer or its service agent or a
similarly qualified person in order to avoid a
hazard.
Please dispose of packing materials properly.
Use the dishwasher only for its intended function.
Remove the door to the washing compartment when
removing an old dishwasher from service or discarding it.
Dishwasher detergents are strongly alkaline, they
can be extremely dangerous if swallowed. Avoid
contact with skin and eyes and keep children away
from the dishwasher when the door is open.
Check that the detergent comparment is empty
after completion of the wash cycle.
The appliance is to be connected to the water
mains using new hose sets and that old hose-sets
should not be reused.
The maximum number of place settings to be
washed is 12.
The maximum permissible inlet water pressure is
1Mpa.
The minimum permissible inlet water pressure is
0.04Mpa.
Children should be supervised to ensure that they do
not play with the appliance.
This appliance is not intended for use by persons
(including children )with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge ,unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
When using your dishwasher, follow the precautions listed below:
WARNING!
The door should not be left open,
since this could increase the risk of tripping.
Do not operate your dishwasher unless all
enclosure panels are properly in place. Open
the door very carefully if the dishwasher is
operating, there is a risk of water squirting out.
Improper connection of the equipment-grounding
conductor can result in the risk of an electric shock.
Check with a qualified electrician or service
representative if you are in doubt whether the
appliance is properly grounded. Do not modify the
plug provided with the appliance; If it does not fit
the outlet. Have a proper outlet installed by a
qualified electrician.

2
Dispose of the dishwasher packaging material correctly.
All packaging materials can be recycled.
Plastic parts are marked with the standard international abbreviations:
PE for polyethylene, e.g. sheet wrapping material
PS for polystyrene, e.g. padding material
POM polyoxymethylene, e.g. plastic clips
PP polypropylene, e.g. Salt filler
ABS Acrylonitrile Butadiene Styrene, e.g. Control Panel .
Packaging material could be dangerous for children!
For disposing of package and the appliance please go to a recycling centre. Therefore cut
off the power supply cable and make the door closing device unusable.
Cardboard packaging is manufactured from recycled paper and should be disposed in the
waste paper collection for recycling.
By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused
by inappropriate waste handling of this product.
For more detailed information about recycling of this product, please contact your local
city office and your household waste disposal service.
DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such
waste separately for special treatment is necessary.
WARNING!

To get the best performance from your dishwasher, read all
operating instructions before using it for the first time.
3
11 12
Back View
1
2
3
4
5
6
7
8
9
10
on
Of f
Front view
Main Filter
Detergent Dispenser
Cup Shelf
Cutlery Basket
Coarse Filter
Rinse Aid Dispenser
Inlet pipe connector
Drain pipe connector
Lower Basket
Spray Arms
Upper Basket
1
Salt Container
5
6
7
8
9
10
12
11
3
2
4
2 Power Light : To come on when the ON/OFF Button is
Pressed down.
3 Door Handle: Pull it to open the door.
1 On/Off Key-press: To turn On/Off the power supply.
9&10 Press both of the buttons simultaneity to select the
program:Rapid
10 Half load button:To select half washing function.
6~9 Program Button: To select washing program when press
the button, and the correspond light above it will display.
4
Salt and rinse aidwarning lights: Toshow when
the salt container or dispenser need to be refilled.
5 Half washing Light : To come on when half washing
67
10
8
9
Power
1
2
3
45

4
Before using your dishwasher for the first time:
The water softener must be set manually, usingthe water hardness dial.
The water softener is designed to remove minerals andsalts from the water, which would have
a detrimentalor adverse effect on the operation of the appliance.The higherthe
content of these mineralsand salts,the harder your water is. The softener should be
adjusted accordingtothe hardness ofthe water in yourarea. Your localWaterAuthority
can adviseyou onthehardness ofthewaterinyourarea.
Adjusting Salt Consumption
The dishwasher isdesigned toallow for adjustment in the amount of salt consumed based onthe hardness of
thewaterused.This is intended to optimiseand customisethelevel of salt consumption.
1. Unscrew the cap from the salt container.
2. There is a ring on the container with an arrow on it (see figure
ontheside),ifnecessary, rotate thering in the anticlockwise
direction from the "-" Setting toward the"+"sign, basedon the
hardness ofthe water being used.
It is recommendedthat adjustments should be made in
accordance withthe following scheme:
WATER SOFTENER
Thehardness ofthe watervariesfrom place to place. If hard water is used inthe dishwasher, deposits will
form on the dishesand utensils.
The appliance isequipped with aspecial softener that uses asalt container specifically designed to eliminate
lime and minerals from the water.
Contact your local water board for information on the hardnessof your water supply.
dH mmol/l
0~140~8 0~1.4 /0/
14~398~22 1.4~3.9 - 20 50
39~8022~45 3.9~8 Mid 40 25
+60 16
fH
0~10
10~28
28~56
Clarke
WATER HARDNESS
SelectorPosition Salt consumption
(gram/cycle) Auto nomy
(cycles/1kgs)
Please follow the steps below for adjustment in salt consumption.
""/
"-"
"+"
"Mid"
Settingtowardthe"+"sign
Settingtowardthe"-"sign
Settingtowardbetween
the "-" sign and "+" sign
No salt need added
45~60 80~107 56~75 8~11
If your model does not have any water softener, you mayskip this section.
A. Set the watersoftener
B. Add 1.5Kgdishwasher salt and then full fillthe salt container with water
C. Filltherinseaiddispenser
D. Fill in detergent
°Clark: British degree
°fH: French degree
°DH: German degree
dH=1.25Clarke=1.78fH=0.178mmol/l
°°°
1

5
1. The salt container must only be refilled when the salt warning light in the control panel comes on.
Depending on how well thesalt dissolves, thesalt warninglight may stillbe on even though the
salt container is filled.
If there is no salt warning light in the control panel (for some Models),you can estimate when to fill
the salt into the softener by the cycles that the dishwasher has run.
2. Ifthere are spills ofthe salt,a soakor a rapid programshould be run to removethe excessive salt.
Always use the salt intended for use with dishwasher.
The salt container is located beneath the lowerbasket and shouldbefilledasexplained
inthe following:
Attention!
Only use salt specifically designed forthe use indishwashers! Every other type of
salt not specifically designed for theuse in adishwasher, especially table salt, will
damage thewater softener. In case of damages caused by the use of unsuitable
salt the manufacturerdoes not give any warranty nor is liable forany damagescaused.
Only fill withsalt just before starting one of thecomplete washingprograms.
This will prevent any grains of salt or salty water, which may have been spilled,
remaining on the bottom ofthe machine for any periodof time, which maycause
corrosion.
The rinse aid isreleasedduring the final rinseto prevent water from forming droplets onyour dishes, which can
leave spots andstreaks. It also improvesdryingby allowing watertoroll offthe dishes. Your dishwasher is
designed to use liquid rinseaids.The rinseaiddispenser islocated inside thedoor next to the detergentdispenser.
To fill the dispenser, open the cap and pour the rinse aid into the dispenser until the level indicator turns completely
black. The volume ofthe rinseaidcontaineris about 110ml.
RinseAid Dispenser
Function of RinseAid
Rinse aid is automatically addedduring the last rinse, ensuring thorough rinsing, and spotandstreakfree drying.
Attention!
Only use branded rinse aid for dishwasher. Never fill the rinse aid dispenser withanyother substances
(e.g. Dishwasher cleaning agent, liquid detergent). This would damage the appliance.
ARemove the lower basket and then unscrew andremove the cap from the saltcontainer.
BPlace the end of thefunnel(supplied)into thehole andintroduce about 1.5kg of dishwashersalt.
CFullfill the saltcontainerwithwater.It isnormal for a small amount of water to comeout ofthe salt container.
DAfter filling the container , screw the cap tightly back clockwise.
EUsually, the salt warning light willstop being illuminated within 2-6 days afterthesalt containerhasbeen filled with
salt.
FImmediately after filling the salt into the salt container, a washing program should be started
program Otherwise the filter system, pump or other important parts of the machine may be damaged
bysalty water.This is outof warranty.
(Wesuggest to use the
soak orrapid ).

6
RINSE AID DISPENSER
To open the dispenser, turn the cap to the "open" (left) arrow and lift it out.
Pour the rinse aid into the dispenser, being careful not to overfill.
Replace the cap by inserting it aligned with "open" arrow and turning it to the closed (right) arrow.
Be careful not to overfill the dispenser, because this could cause over sudsing. Wipe away any spills
with a damp cloth. Don't forget to replace the cap before you close dishwasher door.
Attention!
Clean up any rinse aid split during filling with an absorbent cloth to avoid excess foaming
during the next wash.
Adjusting Rinse Aid Dispenser
1
2
3
As the rinse aid diminishes, the size of the black dot
on the rinse aid level indicator changes, as illustrated below.
Full
3/4full
1/2full
1 / 4 full - Should refill to eliminate spotting
Empty
If there is no rinse-aid warning light in the control panel, you can judge the amount of rinse-aid by the color of the optical level
indicator "C" located next to the cap. When the rinse-aid container is full, the whole indicator will be dark .As the rinse-aid
diminishes, the size of the dark dot decreases. You should never let the rinse aid get below 1 / 4 full.
The rinse aid dispenser has six scales. Always start with the dispenser set on "4".
If spots and poor drying are a problem, increase the amount of rinse aid dispensed
by removing the dispenser lid and rotating the dial to "5". If the dishes still are not
drying properly or are show spots, adjust the dialto the next higher lever until your
dishes are spot-free. The recommended setting is "4". (Factory value is "4".)
Increase the dose if there are drops of water or lime spots on the dishes afterwashing.
Reduce it if there are sticky whitish stains on your dishes or a bluish film on glassware or
knife blades.
NOTE:
When to Refill the Rinse Aid Dispenser

7
Amount of Detergent to Use
Proper Use of Detergent
Use only detergent specifically made for the use in dishwashers. Keep your detergent fresh and dry.
Don't put powdered detergent into the dispenser until you're ready to wash dishes.
Dishwasher detergent is corrosive! Take care to keep it out of reach of children.
WARNING!
Based on their chemical composition, detergents can be split in two basic types:
Detergent tablets of different brands dissolve at different speeds. For this reason some
detergent tablets cannot dissolve and develop their full cleaning power during short
programs. Therefore please use long programs when using detergent tablets, to
ensure the complete removal of detergent residuals.
The dispenser must be refilled before the start of each wash cycle following the instructions
provided in the wash cycle table . Your dishwasher uses less detergent and rinse aid than
Conventional dishwasher. Generally, only one tablespoon of detergent is needed for
a normal wash load. More heavily soiled items need more detergent. Always add the
detergent just before starting the dishwasher, otherwise it could get dampandwillnot
dissolve properly.
Concentrated Detergent
Detergent Tablets
Detergent Dispenser
Always add the detergent just before starting each wash cycle.
Only use branded detergent aid for dishwasher.
If the lid is closed: press release button. The lid will spring open.
conventional, alkaline detergents with caustic components
low alkaline concentrated detergents with natural enzymes
Detergents with its chemical ingredients are necessary to remove dirt, crush dirt and transport it out of the dishwasher.
Most of the commercial quality detergents are suitable for this purpose.

8
Fill the detergent dispenserwith detergent.
The marking indicates the dosing levels , as
illustrated on the right:
Theplace of main wash cycle detergent placed.
Theplace of pre-wash cycle detergent placed.
Please observe themanufacturers dosing and storage
Recommendationsas statedonthedetergent packaging.
Close the lid and press untilit locks in place.
If the dishes are heavily soiled, place anadditional
detergent dosein the pre-wash detergent chamber. This detergent will take effectduring the pre-wash phase.
A
B
Fill in Detergent
You find information about the amount of detergent for the single programme onthe last page.
Pleaseaware, thataccording tothe levelsoiling and the specific hardnessof water differencesarepossible.
Pleaseobservethemanufacturer's recommendations onthe detergent packaging.
AB

9
For best performance of the dishwasher, follow these loading guidelines. Features and
appearance of baskets and cutlery baskets may vary from your model.
Attention before or after Loading the Dishwasher Baskets
Scrape off any large amounts of leftover food. Soften remnants of burnt foodinpans.
It is not necessary to rinse the dishes under running water.
Place objects in the dishwasher in following way:
1.Items such as cups, glasses, pots/pans, etc. are faced downwards.
2.Curved items, or ones with recesses, should be loaded aslant so that water can run off.
3.All utensils are stacked securely and can not tip over.
4.All utensils are placed in the way that the spray arms can rotate freely during washing.
Very small items should not be washed in the dishwasher as they could easily fall out of the baskets.
Removing the Dishes
To prevent water dripping from the upper basket into the lower back, we recommend that you
empty the lower basket first and then the upper basket.
Loading the Upper Basket
The upper basket is designed to hold more delicate and lighter dishware such as glasses, coffee
and tea cup and saucers, as well as plates, small bowls and shallow pans (as long as they are
not too dirty).
Position the dishes and cookware so that they do not get moved by the spray of water.
Adjusting the Upper Basket
The height of the upper basket can be adjusted in order to create more space for large utensils
both for the upper/lower basket. The height of the upper basket can be adjusted by placing the
wheels on different height of the rails. Long items, serving cutlery, salad servers and knives
should be placed on the shelf so that they do not obstruct the rotation of the spray arms.
The shelf can be folded back or be removed when not required for use.
1
Cups
2
Small serving bowl
3
Large serving bowl
4 Glasses
Saucers
5
6
Dish
Dessert dishes
7
1
1
4
1
7
2
3
5
6
1
4
1
4
1

10
Loading the Lower Basket
We recommend that you place large items which are most difficult to clean into the lower basket:
pots, pans, lids, serving dishes and bowls, as shown in the figure to the right.
It is preferable to place serving dishes and lids on the side of the racks in order to avoid blocking
the rotation of the top spray arm.
Pots, serving bowls, etc. must always be placed top down.
Deep pots should be slanted to allow water to flow out.
Thebottom basket feature fold down tine rows so that larger or more pots and pans can be loaded.
Folding spikes
Forbetter stacking of pots and pans, thespikes can be folded down as
show in the picture right.
8
Oval platter
10
Soup plates
Dessert dishes
7
9
Dinner plates
11
Silverware basket
1010
8
99
77
7

Cutlery Basket
For washing in the dishwasher the following cutlery/dishes
Cutlery with wooden, horn china or
mother-of-pearl handles
Plastic items that are not heat resistant
Older cutlery with glued parts that are not
temperature resistant
Bonded cutlery items or dishes
Pewter or cooper items
Crystal glass
Steel items subject to rusting
Wooden platters
Items made from synthetic fibres
Do not put in items that are dirty of cigarette ash, candle wax, lacquer or paint.
If you buy new dishes please make sure that they are suitable for dishwashers.
Some types of glasses can become
dull after a large number of washes
Silver and aluminum parts have a
tendency to discolour during washing
Glazed patterns may fade if machine
washed frequently
Please do not overload your dishwasher. Do not use dish that is not suitable for
dishwashers. This is important for good results and for reasonable energy
consume.
Before loading the dishes, you should:
Remove large left-over
Soften remnants of burnt food in pans
Dishes and cutlery must not impede the rotation of the spray arms
Load hollow items such as cups, glasses, pans etc. with the opening downwards so that
water cannot collect in the container or a deep base
11
NOTE:
NOTE:
Are not suitable Are of limited suitability
Loading cutlery and dishes
When loading the dishes and cutlery, please note:
Cutlery should be placed in the cutlery basket with the handles at the bottom. If the rack has side baskets, the
spoons should be loaded separately into the appropriate slots, especially long utensils should be placed in the
horizontal position at the front of the upper basket as shown in the picture.
Do not let any item extend through the bottom.
Always load sharp utensils with the sharp point down!
Teaspoons
4
Soup spoons
2
Forks
1
Serving forks
8
Serving spoons
6
Knives
5
3
Dessert spoons
7
Gravy ladles
2
452
5
32
3
2
1
1
1
1
1
5554
555
4
632367 3
2
3
4555
1
1
1
1
1
5
4
2
2
3
33
332
2
3
2
2
1
4
4
4
4
8
4
4
4
1

12
Di
To
T
shes and items of cutlery must not lie inside one another, or cover each other
avoid damage to glasses, they must not touch
Load large items which are most difficult to clean into the lower rack
he upper rack is desi gned to hold more delicate and lighter dishware such as glasses, coffee
and tea cups
Attention!
Long bladed knives stored in an upright position are a potential hazard!
Long and/or sharp items of cutlery such as carving knives must be positioned
horizontally in the upper basket.
Damage to glassware and other dishes
Possible causes:
Type of glass or manufacturing process. Chemical composition of detergent.
Water temperature and duration of dishwasher programme.
Suggested remedy:
Use glassware or porcelain dishes that have been marked dishwasher-proof by the
manufacturer
Use a mild detergent that is described as kind of dishes If necessary, seek further
information from detergent manufacturers.
Select a programme with as low a temperature.
To prevent damage, take glass and cutlery out of the dishwasher as soon as possible
afterthe programme has ended.

13
Intensive
125 1.36
19.5
5/25g
5/25g
For heaviest soiled crockery,
and normally soiled pots、pans、
dishes etc with dried on soiling
Pre-wash(50 )
Wash (65 )
Rinse
Rinse
Rinse (55 )
Drying
℃
℃
℃
Normal
Pre-wash(50 )
Wash (55 )
Rinse
Rinse(65 )
Drying
℃
℃
℃160 1.30 16.0
For normally soiled loads,
such as pots、plates、glasses
and lightly soiled pans.
Eco.
(*EN 50242)
Wash (50 )
Rinse (65 )
Drying
Pre-wash℃
℃
5/25g
165 1.02 12.0
Standard daily cycle for
normally soiled loads,such as
pots、plates、glasses
1Hour
60 0.95 12.0
30 g.
For lightly soiled load that
do notneed excellentdrying
efficiency.
Rapid
Wash (40 )℃
Rinse
Rinse (40 )℃20 g. 30 0.50 11.0
A shorter wash for lightly
soiled loads and quick wash
Rinse (50 )
Drying ℃
Wash(60 )
Rinse ℃
*EN 50242 : This programme is the test cycle. The information for comparability test
in accordance with EN 50242, as follows:
Capacity: 12 setting
PositionUpper basket: upper wheels on rails
Rinse aid setting: 6
The power consumptionof off-modeis 0W
left-on modeis0.4W.

14
A forgotten dish can be added at any time before the detergent cup opens.
Open the door a little to stop the washing.
After the spray arms stop working, you can open the door
completely.
Load the forgotten dishes.
Close the door, the dishwasher will start running again
after 10 seconds.
4
3
2
1
It is dangerous to open the door when washing,because the hot water may scaldyou.
When the working cycle has finished, the buzzer of the dishwasher will sound for 8 seconds, then stop. Turn off
the appliance using the ON/OFF button, shut off the water supply and open the door of the dishwasher.
Wait for a few minutes before unloading the dishwasher to avoid handling the dishes and utensils while they
are still hot and more susceptible to breakage. They will also dry better.
TurningontheAppliance
1 Draw out the lower and upper basket, load the dishes and push them back.
It is commended That loading the lower basket first, than the upper one (see the section entitled
Loading the Dishwasher ).
2 Pour in the detergent (see the section entitled Salt, Detergent and Rinse Aid ).
3 Insert the plug into the socket. The power supply is 220-240 VAC /50 HZ, the specification of the
socket is 10 A 250 VAC. Make sure that the water supply is turned on to full pressure.
“”
”
4 Close the door, press the ON/OFF button, and the ON/OFF light will turn on.
Press the Program Button to select a desired Wash cycle, the machine will work after 3 seconds.
Starting a cycle wash
NOTE:
If you open the door when washing, the machine will pause. The program light will stop blinking
and the buzzer will mooing every minute unless you close the door. After you close the door , the
machine will keep on working after 10 seconds.
ll of the program lights cut of f
)some of the program lights fast blinking -->error
The program lights shows the state of the dishwasher:
a) A --> stand by
b) One of the program lights on --> pause
c) One of the program lights blinking slowly --> run
d
If some of the program lights begin to fast blinking after a warning sound
(page 21th "ERROR CODES"), that indicates the machine is out of order, please
turn off the main power and water supply before calling a service.
NOTE:
PREMISE:
Otherwise, the detergent may have already been released,
and the appliance may have already drained the wash water. If this is the case,
the detergent dispenser must be refilled (see the section entitled " Loading the
Detergent " ).
There are two ways of changing the programme :
1. Press the button of running prog. more than 3 seconds to cancel it, then push the button of desired prog.
and it will run after 10 seconds.(see the section entitled " Starting a wash cycle...").
2. Press Button of desired prog. (except buttom of running pro.) more than 3 seconds to change
the running prog. into the prog. which you press, it will run after 10 seconds.
You can modified the washing program, just the dishwasher has been
running for a short time.

15
The filter prevents larger remnants of food or other objects from getting inside the pump.
The residues may block the filter, in this case they must be removed.
The filter system consists of a coarse filter, a flat (Main filter)
And a microfilter (Fine filter).
Main filter
Food and soil particles trapped in this filter are pulverized by a
special jet on the lower spray arm and washed down the
drain.
Coarse filter
Larger items, such as pieces of bones or glass, that could clog
the drain are trapped in the coarse filter. To remove an item
caught in this filter, gently squeeze the taps on the top of this
filter and lift it out.
Fine filter
This filter holds soil and food residues in the sump area and
prevents it from being redeposit on the dishes during a cycle.
2
3
1
2
3
1
- Inspect the filters for blocking after every time the dishwasher has been used.
- By unscrewing the coarse filter. you can remove the filter system. Remove any food remnants and clean the
filters under running water.
step１：Turn the filter in anti-clockwise direction,
then lift it up
step２：lift the Main filter up
NOTE：
step 3： lift the Fine filter up
Switch Off the Dishwasher
1.Switch off the dishwasher by pressing the ON/OFF button.
2.Turn off the water tap!
Open the door carefully.
Hot dishes are sensitive to knocks. The dishes should therefore be allowed to cool down around 15 minutes
before removing from the appliance.
Open the dishwasher's door, leave it ajar and wait a few minutes before removing the dishes. In this way they
will be cooler and the drying will be improved.
Unloading the dishwasher
It is normal that the dishwasher is wet inside.
Empty the lower basket first and then the upper one. This will avoid water dripping from the upper Basket onto
the dishes in the lower one.
When following this procedure from step1 to step 3, the filter system will beremoved;
whenfollowingitfromStep3toStep1,thefiltersystemwillbeinstalled.
1
2
3

16
Caring for the Dishwasher
Protect Against Freezing
Filter assembly
To clean the coarse filter and the fine filter, use a cleaning brush. Then, reassemble the filter
parts as shown in the figures left and reinsert the entire assembly in the dishwasher, positioning
in its seat and pressing downward.
The dishwasher must never be used without the filters. Improper replacement of the filter may
reduce the performance level of the appliance and damage dishes and utensils.
For best performance and results, the filter assembly must be cleaned. The filter efficiently removes food
particles from the wash water, allowing it to be recycled during the cycle. For best performance and results,
the filter must be cleaned regularly. For this reason, it is a good idea to remove the larger food particles
trapped in the filter after each wash cycle by rinsing the semicircular filter and cup under running water.
To remove the filter device, pull the cup handle in the upward direction. The entire filter assembly should be
cleaned once a week.
The dishwasher must never be used without the filters.
Improper replacement of the filter may reduce the performance level of the appliance and
damage dishes and utensils.
1.Cut off the electrical power to the dishwasher.
2.Turn off the water supply and disconnect the water inlet pipe from the water valve.
3.Drain the water from the inlet pipe and water valve. (Use a pan to catch the water)
4.Reconnect the water inlet pipe to the water valve.
5.Remove the filter at the bottom of the tub and use a sponge to soak up water inthesump.
please take frost protection measures on the dishwasher in winter. Every time after washing cycles,
please operate as follows：
The control panel can be cleaned by using a lightly dampened cloth.
After cleaning, make sure to dry it thoroughly.
For the exterior, use a good appliance polish wax.
Never use sharp objects, scouring pads or harsh cleaners on any part of the dishwasher.
Cleaning the Spray Arms
It is necessary to clean the spray arms regularly for hard water chemicals will clog the spray arm jets and bearings.
To remove the upper spray arms, screw off the nut clockwise to take out
the washer on top of the spray arm and remove the arm.
Remove the upper spray arms
To remove the lower spray arm, pull out the spray arm upward.
Remove the lower spray arms
Wash the arms
Wash the arms in soapy and warm water and use a soft brush to clean
the jets. Replace them after rinsing them thoroughly.
upper
lower

17
After every wash, turn off the water supply to the
appliance and leave the door slightly ajar so that
moisture and odours are not trapped inside.
Before cleaning or performing maintenance, always
remove the plug from the socket. Do not run risks.
To clean the exterior and rubber parts of the dishwasher,
do not use solvents or abrasive cleaning products.
Rather, use only a cloth and warm soapy water.
To remove spots or stains from the surface of the
interior, use a cloth dampened with water and a little
vinegar, or a cleaning product made specifically for
dishwashers.
When you go on holiday, it is recommend that you run a
wash cycle with the dishwasher empty and then remove
the plug from the socket, turn off the water supply and
leave the door of the appliance slightly ajar. This will help
the seals to last longer and prevent odours from forming
within the appliance.
If the appliance must be moved, try to keep it in the vertical
position. If absolutely necessary, it can be positioned on
its back.
One of the factors that cause odours to form in the
dishwasher is food that remains trapped in the seals.
Periodic cleaning with a damp sponge will prevent this
from occurring.
To clean the edge around the door, you should use only a soft warm, damp cloth.
To avoid penetration of water into the door lock and electrical components,donot
use a spray cleaner of any kind.
Never use a spray cleaner to clean the door panel as it may damage the door lock and electrical components.
Abrasive agents or some paper towels should not be used because of the risk of scratching or leaving spots
on the stainless steel surface.
Ensure the voltage and frequency of the power being corresponds to
those on the rating plate. Only insert the plug into an electrical socket which is earthed
properly. Ifthe electrical socket to which the appliance must be connectedisnot
appropriate for the plug , replace the socket, rather than using a adaptors or the like as
they could cause overheating and burns.
Please look at the rating label to know the rating voltage and connect the dishwasher to the appropriate power supply.
Use the required fuse 10 amp, time delay fuse or circuit breaker recommended and provide separate circuit serving
only this appliance.
This appliance must be earthed. In the event of a malfunction or breakdown, earthing will reduce the risk of
electric shock by providing a path of least resistance for the electric current. This appliance is equipped with a
cord having an equipment-earthing conductor and an earthing plug. The plugmustbepluggedintoan
appropriate outlet that is installed and earthed in accordance with all local standards and requirements.
WARNING!
For personal safety:
DO NOT USE AN EXTENSION CORD OR AN ADAPTER PLUG WITH THIS APPLIANCE.
DO NOT, UNDER ANY CIRCUMSTANCES, CUT OR REMOVE THE EARTHING
CONNECTION FROM THE POWER CORD.
