Amit ALP1A2812/A1 User manual

alp1a2812a1_g_en_102
ALP1A2812/A1
Information LED panel
for rolling stock
Operation manual
Version 1.02

ALP1A2812/A1
alp1a2812a1_g_en_102 2/21
AMiT, spol. s r. o. does not provide any warranty concerning the contents of this
publication and reserves the right to change the documentation without
obligation to inform anybody or authority about it.
This document can be copied and redistributed under following conditions:
1. The whole text (all pages) must be copied without any changes.
2. All redistributed copies must retain the AMiT, spol. s r. o. copyright notice
and any other notices contained in the documentation.
3. This document must not be distributed for purpose making of profit.
The names of products and companies used herein can be trademarks or
registered trademarks of their respective owners.
AMiT is a registered trademark.
Copyright (c) 2018, AMiT, spol. s r. o.
Producer: AMiT, spol. s r. o.
Naskové 1100/3, 150 00 Praha
www.amit-transportation.com
Technical support: [email protected]

ALP1A2812/A1
3/21 alp1a2812a1_g_en_102
Contents History of revisions.........................................................................................4
Related documentation...................................................................................4
1. Introduction..........................................................................................5
2. Technical parameters..........................................................................6
2.1. Dimensions.....................................................................................................8
2.2. Recommended drawing symbol .....................................................................8
2.3. Temperature dependence..............................................................................8
3. Labelling ...............................................................................................9
3.1. Manufacturer type plate..................................................................................9
4. Conformity assessment ....................................................................11
4.1. Other tests....................................................................................................12
5. Power supply......................................................................................13
6. Communication lines and peripherals.............................................14
6.1. Ethernet........................................................................................................14
6.2. Light sensor..................................................................................................15
7. Mounting.............................................................................................16
7.1. Installation rules............................................................................................16
8. Ordering information, Package contents ........................................17
8.1. Package contents.........................................................................................17
8.2. Accessories..................................................................................................17
9. Packaging...........................................................................................18
10. Storage................................................................................................19
11. Maintenance .......................................................................................20
11.1. Cleaning.......................................................................................................20
12. Waste disposal...................................................................................21

ALP1A2812/A1
alp1a2812a1_g_en_102 4/21
History of revisions
Document name: alp1a2812a1_g_en_102.pdf
Revision
Date
Author of change
Changes
100
18. 09. 2017
O. Rott
New document.
101
10. 01. 2018
O. Rott
Changes in chapters 2 Technical parameters 4 Conformity
assessment.
102
18. 01. 2018
M. Uhlář
Ingress protection rate correction IP50 -> IP40
Related documentation
1. ALP1A2812/A1 –Information LED panel for rolling stock –Datasheet
file: alp1a2812a1_d_en_xxx.pdf

ALP1A2812/A1
5/21 alp1a2812a1_g_en_102
1. Introduction
ALP1A2812/A1 is an external information LED panel intended to be built-in to
rolling stock interior. Device is designed in accordance with EN 50155:2007
standard.
LED panel is shipped from production with loader and AMiT software.
▪Viewing area (804 × 124) mm
▪Resolution (200 × 30) pixels
▪LED grid 4 mm
▪LED colour Yellow
▪Brightness 800 cd/m2
▪Ethernet 10 / 100 Mbps interface with M12 connector
▪Power supply 24 V DC
▪Mounting On the wall
▪Colour of mechanics Black
Basic features

ALP1A2812/A1
alp1a2812a1_g_en_102 6/21
2. Technical parameters
Viewing area
(804 × 124) mm
Resolution
(200 × 30) pixels
LED grid
4 mm
LED colour
Yellow, 590 nm typ.
Luminance
Typ. 800 cd/m2
Viewing angle
120 ° *)
*) Luminance drop to 50 % at viewing angle border.
Function
Measuring of ambient illumination
Quantity
1
Data transmission rate
10 / 100 Mbps
Auto MDIX
Yes
Operation indication
LED
Galvanic isolation
Yes
Galvanic isolation strength
500 V AC /1 minute *)
Connection point
M12 connector according to IEC 61375-3-4,
HARTING PushPull compatible
Recommended cabling
STP CAT6
Maximum segment length
100 m
*) Isolation must not be used for unsafe voltage separation.
Nominal power supply voltage
24 V DC
Power supply voltage range
16.8 V to 33.6 V DC
Maximum power consumption
2.65 A at 24 V DC
Peak inrush current
Max. 150 A at 24 V DC *)
Connection point
M12, 4pin, A coded
Inlet wire cross section
0.75 mm2to 2.5 mm2
*) Inrush peak current duration is less than 50 µs.
Viewing zone
Note:
Light sensor
Ethernet
Note
Power supply
Note:

ALP1A2812/A1
7/21 alp1a2812a1_g_en_102
Mechanical design
Metal cover + tempered glass
Surface finish –front panel
–rear cover
Powder coating
Powder coating
Colour –front panel
–rear cover
Black, RAL 9005, fine matte
Black, RAL 9005, fine matte
Mounting
4 × M6 nuts on the sides
4 × M6 nuts on the back cover
Ingress protection rate
IP40
Weight –netto
–brutto
7.00 kg ±5 %
8.00 kg ±5 %
Dimensions (w × h × d)
(852 ×202 × 58) mm
Package dimensions (w × h × d)
(1120 × 285 × 70) mm
Unit overall mass of plastics
633 g
Included mass of self-
extinguishing plastics
633 g
Device does not contain
PUR, PVC, Asbestos
Device conforms
2011/65/EU (ROHS)
1907/2006EU (REACH)
Operating temperature range
-40 °C to 70 °C *)
Storage temperature range
-40 °C to 70 °C
*) With limitation, see chapter 2.3. Temperature dependence.
Maximum ambient humidity
< 95 % non-condensing
Expected MTBF
> 150 000 h
Expected lifetime
15 years
Loader
Yes
Application software
AMiT
Equipment is intended to operate up to 1 400 m above the sea level.
Equipment design meets the requirements of class T3, with temperature lower range
extension.
According to EN 61373:2010 standard, the equipment is classified in terms of
vibrations into Category 1, Class B (mounting to vehicle body).
Permissible supplying voltage drop-outs duration: max. 10 ms (Class S1 and S2
according to Chapter 3.1.1.2 of EN 50155:2007).
For supply voltage switching are permissible conditions of C1 Class.
The equipment is not classified according to EN 50128:2011 Railway applications –
Communications, signalling and processing systems –Software for railway control
and protection systems.
The equipment is not classified according to EN 50129:2003 Railway applications –
Communication, signalling and processing systems –Safety-related electronic
systems for signalling.
Mechanics
Dangerous
materials
Temperatures
Others
Software
Claims of
EN 50155:2007
Safety
classification

ALP1A2812/A1
alp1a2812a1_g_en_102 8/21
2.1. Dimensions
202
857
45
804
124
Fig. 1 - Information panel ALP1A2812/A1 dimensions in mm
2.2. Recommended drawing symbol
Following drawing symbol is recommended for information panel
ALP1A2812/A1.
GND
X1
ALP1A2812/A1
4
Vcc3
GND2
X2
Vcc1
M12
ETH
PWR
Fig. 2 - Recommended drawing symbol for ALP1A2812/A1
2.3. Temperature dependence
Information panel is equipped with internal temperature sensor; depending on
measured temperature is controlled the maximum brightness according to
following table.
Internal temperature
Function
-40 °C to 45 °C
Full brightness
45 °C to 85 °C
Linear brightness decrease
85 °C
50 % brightness
> 85 °C
Brightness is lowered to minimum

ALP1A2812/A1
9/21 alp1a2812a1_g_en_102
3. Labelling
Type identification plate is placed on the back side of the ALP1A2812/A1
information panel.
For exact location of labels see Fig. 3 - Labelling of ALP1A2812/A1 .
TYPE
WEIGHT: x.xxkg
DATE: xx.xx.xxxx
HiPot: HiPot- OK
TEST: OK-VS
SW: APPx.xx / LDR x.xx
POWER: 16.8to 33.6 V DC / 3 A
S/N AB12345
ALP1A2812/A1
1
Fig. 3 - Labelling of ALP1A2812/A1 information panel
Number
Description
1
Type plate
3.1. Manufacturer type plate
Type identification plate is placed on the back side of the information panel.
Identification plate’s information is summarized in the table below, for example
of filled manufacturer type plate see Fig. 4 - Example of manufacturer’s type
plate.
Description
Value
Note
–
AMiT logo
Manufacturers logo
–
QR code
Manufacturer’s QR code
TYPE
ALP1A2812/A1
Computer type
S/N
xxxxxxx
Serial number
MAC
xx-xx-xx-xx-xx-xx
Mac address
FW
APP x.xx / LDR x.xx
Software version
POWER
16.8 to 33.6 V DC / 2.65 A
Power supply / consumption
WEIGHT
x.xx kg
Weight
TEST
OK-xx
Routine test result
HiPot
HiPot-OK
Insulation test result
Date
dd.mm.yyyy
Manufacture date
–
Logo CE
Unit was assessed and complies
with EU legislative requirements
–
Crossed out dustbin logo
with a full stripe
The disposal of electronic
equipment is subject to the
regulations on handling electrical
waste
Legend

ALP1A2812/A1
alp1a2812a1_g_en_102 10/21
TYPE
WEIGHT: x.xx kg
DATE: xx.xx.xxxx
HiPot: HiPot - OK
TEST: OK-VS
FW: APP x.xx / LDR x.xx
POWER: 16.8 to 33.6 V DC / 2.65 A
S/N AB12345
ALP1A2812/A1
MAC: xx-xx-xx-xx-xx-xx
Fig. 4 - Example of manufacturer’s type plate

ALP1A2812/A1
11/21 alp1a2812a1_g_en_102
4. Conformity assessment
The equipment meets the requirements of NV117/2016 Czech governmental
decree. The compliance assessment with NV117/2016 has been performed in
accordance with harmonized standard EN 50121-3-2:2006.
Tested in accordance
with standard
Type of test
Classification
EN 55011:2009
Industrial, scientific and medical
equipment –Radio-frequency
disturbance characteristics –Limits and
methods of measurement
Complies
EN 61000-4-2:2009
Electromagnetic compatibility (EMC) –
Part 4-2: Testing and measurement
techniques –Electrostatic discharge
immunity test
Complies
EN 61000-4-3:2006
Electromagnetic compatibility (EMC) –
Part 4-3: Testing and measurement
techniques –Radiated, radio-frequency,
electromagnetic field immunity test
Complies
EN 61000-4-4:2012
Electromagnetic compatibility (EMC) –
Part 4-4: Testing and measurement
techniques –Electrical fast transient/burst
immunity test
Complies
EN 61000-4-5:2006
Electromagnetic compatibility (EMC) –
Part 4-5: Testing and measurement
techniques –Electrostatic discharge
immunity test
Complies
EN 61000-4-6:2009
Electromagnetic compatibility (EMC) –
Part 4-6: Testing and measurement
techniques –Immunity to conducted
disturbances, induced by radio-frequency
fields
Complies

ALP1A2812/A1
alp1a2812a1_g_en_102 12/21
4.1. Other tests
This product was assessed and approved for use in railway applications
according to standards:
Tested in accordance
with standard
Type of test
Classification
EN 50155:2007
Railway applications –Electronic
equipment used on rolling stock
Complies
S1, S2, C1
EN 50121-3-2:2006
Railway applications –Electromagnetic
compatibility –Part 3-2: Rolling stock –
Apparatus
Complies
EN 61373:2010
Railway applications –Rolling stock
equipment –Shock and vibration tests
Complies
EN 60068-2-1:2007
Environmental testing –Part 2-1: Tests –
Test A: Cold
Complies
EN 60068-2-2:2007
Environmental testing –Part 2-2: Tests –
Test B: Dry heat
Complies
EN 45545-2:2013
Railway applications - Fire protection on
railway vehicles - Part 2: Requirements
for fire behaviour of materials and
components
HL3

ALP1A2812/A1
13/21 alp1a2812a1_g_en_102
5. Power supply
Information panel ALP1A2812/ is equipped with M12 A-coded, 4-pin connector
labelled as PWR. It is used as a power supply connector.
Matching counterpart is contained in package (Conec 43-00421). For proper
contact connection use crimping tool 360X10329X with crimping insert
360X20069X.
1
Fig. 5 - X1 connector location
Number
Description
1
Connector X1 –Power supply
Connector
PIN
Signal
Description
X1
PWR
1
Vcc
Power supply, +24 V
2
GND
Power supply, GND
3
Vcc
Power supply, +24 V
4
GND
Power supply, GND
Shield
Shield
Unit frame
2
3
1
4
Fig. 6 - Power connector wiring
Note
Legend
PWR
connector
pinout

ALP1A2812/A1
alp1a2812a1_g_en_102 14/21
6. Communication lines and peripherals
ALP1A2812/A1 computer contains the following communication interfaces and
peripherals:
▪Ethernet
▪Light sensor
6.1. Ethernet
The 10/100 Mbps Ethernet interface allows connecting of ALP1A2812/A1
computer to LAN network. Panel computer ALP1A2812/A1 is equipped with
one Ethernet interface with M12-4pin Harting push-pull connector.
1
Fig. 7 - Location of Ethernet line connector
On next figure is presented a front view on Ethernet socket.
1
4
3
2
4
1
3
2
Fig. 8 - Ethernet connector wiring
PIN
Signal
Description
1
Tx+
Data transmission, signal +
2
Rx+
Data reception, signal +
3
Tx-
Data transmission, signal -
4
Rx-
Data reception, signal -
M12
connector
pinout

ALP1A2812/A1
15/21 alp1a2812a1_g_en_102
6.2. Light sensor
Information panel is equipped with light sensor that is used for measuring of
ambient light. Thanks to this sensor, information panel can regulate brightness
to optimal value, according to ambient conditions. For panel correct operation
the sensor must be exposed to the ambient light, and must not be covered
anything.
1
181
444
Fig. 9 - Location of light sensor, all dimensions are stated in mm
Number
Description
1
Light sensor
Legend

ALP1A2812/A1
alp1a2812a1_g_en_102 16/21
7. Mounting
Information panel is designed to be mounted onto rail coach interior with four
mounting holes located on the panel sides, or with four mounting holes located
on the panel back. Information panel is attached by bolts, fastened to M6 nuts.
Thread depth in all mounting holes is 9.5 mm.
When mounting information panel on the coach wall, the light sensor must be
exposed to ambient light.
26
150
4 x M6
A
A
max 9,5
A - A
B - B
780
150
38
26
4 x M6
B
B
Fig. 10 - Location of mounting holes, all dimensions are stated in mm
7.1. Installation rules
The PE terminal of the power supply connector must be connected with a local
installation grounding terminal. Although power connector contains PE terminal,
for best connection we strongly recommend to use grounding screw near to X1.
Minimum cross-section of a supplying conductors must be at least 0.75 mm2.
All cabling must be carefully tied by cable ties to avoid the excessive connector
pulling or prying.
Communication line wires must be shielded. Shielding must be connected either
to metal connector caps or to PE terminal of panel computer.

ALP1A2812/A1
17/21 alp1a2812a1_g_en_102
8. Ordering information, Package contents
ALP1A2812/A1
See chapter 8.1 –Package contents
8.1. Package contents
Part
Quantity
Information LED panel
1
Routine testing protocol
1
Insulation testing protocol
1
Certificate of product quality and completeness
1
8.2. Accessories
Following accessories can be ordered:
Part ID
Part description
Quantity
43-00421
Power supply connector counterpart
1
*) For more information about storage sizes please contact technical support at
email address [email protected].
Panel
computer
ALP1A2812/A1
Note

ALP1A2812/A1
alp1a2812a1_g_en_102 18/21
9. Packaging
Display area including front panel is protected by plastic foil against scratches
and dirt. This foil is recommended to stay on the device during mounting to the
vehicle and must be removed before using the device.
The computer together with desiccant pack is sealed in the plastic bag filled
with inert gas to achieve the optimal protection. Sharp edges of cooler corners
and connectors are additionally covered by plastic foil. This foil must be
removed before turning the device on to enable proper cooling.
The computer is placed in the card-box and is protected by shock absorbers.
For card-box dimensions see technical parameters.
Label sticker on the box contains following data:
Item
Description
TYPE
ALP1A2812/A1
NETTO
7.00 kg
BRUTTO
8.00 kg
QTY
1 pc
S/N
Serial number
AMiT logo
–
QR code
–
CE mark
–
TYPE
NETTO
BRUTTO
QTY
S/N ABCD
1 PC
xxx kg
xxx kg
ALP1A2812/A1
WH
D
Fig. 11 - Box dimensions and label appearance
Front panel
protection
Vacuum
packing
Box packing
Label

ALP1A2812/A1
19/21 alp1a2812a1_g_en_102
10. Storage
To prevent any damage to the device please keep the following rules.
The computer in the original box must be stored only under environmental
conditions defined in technical parameters. The device must be kept away from
water, oil or any other liquid which can damage the packing.
The box can be stored in any position. If the boxes are put on the top of each
other, then the weight applied to the box must not exceed 25 kg and the load
must be distributed to the whole top area of the box.
Already unpacked device can be stored only under environmental conditions
defined in technical parameters. The device must be kept away from water, oil
or any other liquid and kept in a clean area without excessive dust, sawdust etc.
The computer can be laid only on the surface which cannot damage the
computer’s parts or its surface finish (e.g. soft cloth, bubble foil, soft protective
rubber sheet etc.).
The computer’s connectors and the front view area must not lean against any
object.
Poor storage conditions can lead to warranty lost.
Packed
computer
Unpacked
computer

ALP1A2812/A1
alp1a2812a1_g_en_102 20/21
11. Maintenance
Maintenance mentioned below can be performed only by manufacturer or
authorized service.
11.1. Cleaning
According to cleanliness of the environment, where the computer is installed, it
is necessary to remove dust and dirt from the panel computer.
Cleaning intervals have to be planned by the vehicle designer.
According to the dust and dirt contamination level, there are cleaning ways as
follows:
Front panel and display screen area have to be cleaned with dry or wet cloth.
It’s necessary to use cleaning agents which cannot cause scratches on screen
area of front panel keyboard.
Front panel cleaning is typically done during periodical cleaning of the vehicle.
Dust settles on panel computers electronics and cooler, so thermal transmission
between computer parts and ambient air is worse. Because of that dust has to
be removed. Without disassembly, the removal can be done by vacuum
cleaner.
Warning
Front panel
cleaning
Electronics
cleaning
