AmpliVox Half-Mile Hailers S610A User manual

Outdoor Portable Sound Systems
The Hailer family is great for use in high noise areas and large open spaces. Use it to direct emergency crews and
alert crowds. It covers a football field! And unlike megaphones which cover your face, the Half-Mile Hailer lets you see
and be seen. Great for crowd control, public safety, law enforcement, athletic events, band practice,field days, outdoor
marketing events, auctioneers, political campaigns, missionaries - any outdoor event.
HALF-MILE HAILER Outdoor portable horn; S805A 50-watt multimedia stereo amplifier with built-in tripod mount; S2080
dynamic handheld microphone with 5-ft. coil cord and adjustable shoulder strap.
WIRELESS HALF-MILE HAILER Outdoor portable horn; SW805A 50-watt multimedia stereo amplifier with built-in wireless
receiver and built in tripod mount; wireless headset & lapel microphones and transmitter. Includes a shoulder strap.
WIRELESS HANDHELD HALF-MILE HAILER Outdoor portable horn; SW805A 50-watt multimedia stereo amplifier with built-in
wireless receiver and built in tripod mount; wireless handheld microphone with built in transmitter. Includes a shoulder strap.
The Half-Mile Hailer series
helps schools meet the
security requirements of the
No Child Left Behind Act,
which mandates schools to
oer secure, safe learning
environments for their students.
Quick Look:
Audience Size: 100 - 5,000
Coverage: 1,000 - 30,000 sq. ft.
SPL 108 dB - 112 dB
Tapered Weather Resistant Horns
Amplivox Wireless Mics
UL & CE Listing
Made in USA
6 Year Warranty
Dual wireless capability!
Carry on your
shoulder with
included strap!
Tapered weather
resistant horn
Power rating:
60 Watts
SPL 108 dB
Portable PA Systems
HALF-MILE HAILERS
Features & Specs
Amplifier Exclusive built-in 50-watt
multimedia stereo amplifier.
Power Controls On-off switch with
LED power indicator light. Jack
for optional, external AC adapter/
recharger.
Power Source 110/240V AC
Adapter/recharger available (S1460).
10 fresh D-cell Alkaline batteries (not
included) provide up to 200 hrs. of
operation for up to a full year’s use.
Sold Separately.
Auxiliary Input Auxiliary input with
separate volume and tone controls
for a Computer Projector, CD or tape
player. Capture your audience’s atten-
tion with a mixed media presentation
by adding music.
Line Out Jack You can record your
presentation as it is happening
Microphone Model S2080.
Professional low-impedance, cardioid
pattern, dynamic microphone, steel
case, frequency response 50–15,000
Hz; with 5-ft. coiled cord.
Microphone Jacks 1 each dynamic,
condenser with phantom power and
wireless. Microphone volume control
adjusts all mics together. All 3 mic
inputs and auxiliary input can be used
at the same time.
Dual Wireless Capability Two pre-
senters can be wireless with purchase
of additional wireless mic kit.
Speakers Tapered Horn 11W x 6.5H
x 8.25D
Speaker Jacks 2 jacks; 1 per line
input channel. Each jack can drive
4- or 8-ohm speakers. Mic inputs
are added equally to left and right
channels. Output driver is placed into
standby mode when its output jack
is empty, reducing power drain and
prolonging battery life.
Easy to Use! Just plug and speak!
Updated 11.11
SW610A WIRELESS HALF-MILE HAILERS610A HALF-MILE HAILER SW615A WIRELESS
HALF-MILE HAILER
WITH HANDHELD MIC
S610A Half-
Mile Hailer
shown with
optional
S1090 tripod
Model # Shp. Wt. MSRP
S610A 13 lbs. 532.00
SW610A 13 lbs. 799.00
SW615A 13 lbs. 856.00
3995 Commercial Ave., Northbrook, IL 60062 PHONE: [phone] FAX: [phone] WWW.AMPLI.COM [e-mail]

Portable PA Systems
HALF-MILE HAILERS
WIRELESS HALF-MILE HAILER KIT Includes SW610A, additional S1264 horn speaker; 40-ft. cable, two S1090 tripods,
S1960 rugged reinforced nylon carrying case with luggage handle & wheels.
DELUXE WIRELESS HALF-MILE HAILER KIT Includes SW610A, additional S1264 horn speaker; 40-ft. cable, two S1080
heavy duty tripods, rugged reinforced nylon carrying case with luggage handle & wheels.
WIRELESS HANDHELD HALF-MILE HAILER KIT Includes SW615A, additional S1264 horn speaker; 40-ft. cable, two S1090
tripods, S1960 rugged reinforced nylon carrying case with luggage handle & wheels.
DELUXE WIRELESS HANDHELD HALF-MILE HAILER KIT Includes SW615A, additional S1264 horn speaker; 40-ft. cable, two
S1080 heavy duty tripods, rugged reinforced nylon carrying case with luggage handle & wheels.
WIRELESS SPEAKER HALF-MILE HAILER KIT includes SW610A; S1244-70; two S1090 tripods; one S1960 rolling case;
Mic storage pouch; 40 ft cable.
DELUXE WIRELESS SPEAKER HALF-MILE HAILER KIT includes one SW610A; S1244-70; two S1080 heavy duty tripods; 1
S1960 rolling case; Mic storage pouch; 40 ft cable.
WIRELESS QUAD HORN HALF-MILE HAILER KIT includes one SW805A amp on a compact tripod, with two pairs of wired
horn speakers on two compact stands, adjustable from 28-in. to 49-in. high, 27-in. folded; two 40-ft. cords, two 'Y' adapters,
wireless lapel & headset mics. This comes with a large nylon carrying case with luggage handle & wheels.
DELUXE WIRELESS QUAD HORN HALF-MILE HAILER KIT includes one SW805A amp on compact tripod, with four horn
speakers mounted in two pairs on two tall tripods, adjustable from 44-in. to 84-in. high, 43-in. folded; two 40-ft. cords, two 'Y'
adapters; wireless lapel & headset mics. This comes with a large nylon carrying case with luggage handle & wheels.
SW630 37 lbs. 1,316.00
SW632 40 lbs. 1,481.00
SW635 37 lbs. 1,373.00
SW637 37 lbs. 1,538.00
SW640 55 lbs. 1,644.00
SW642 70 lbs. 1,809.00
SW660 73 lbs. 1,601.00
SW662 83 lbs. 1,755.00
Model # Shp. Wt. MSRP
New! Quad Horn Hailer Kits
Our Most Popular Kit!
New! Wireless Speaker Hailer Kits
SW630 Wireless Half-Mile Hailer Kit
SW660 ADJUSTABLE COMPACT TRIPODS
28-49 INCHES! HEAVY GAUGE STEEL
SW662 ADJUSTABLE HEAVY DUTY TRIPODS
44-84 INCHES! HEAVY GAUGE STEEL
USED BY SWAT TEAMS
SW640 WIRELESS SPEAKER HALF-MILE HAILER
KIT This package includes SW610A; S1244-70; two
S1090 tripods, adjustable from 28-in. to 49-in high;
one S1960 rolling case; Mic storage pouch; 40 ft
cable. (shown)
SW642 DELUXE WIRELESS SPEAKER HALF-MILE
HAILER KIT This package includes one SW610A;
S1244-70; two S1080 heavy duty tripods adjustable
from 44-in. to 84-in. high; 1 S1960 rolling case; Mic
storage pouch; 40 ft cable.
Wireless Speakers - You can
place the speakers up to 500
feet apart! No Messy Cables!
Quick Look:
Audience Size: 100 - 5,000
Coverage: 1,000 - 30,000 sq. ft.
SPL 108 dB - 112 dB
Tapered Weather Resistant Horns
Amplivox Wireless Mics
UL & CE Listing
Made in USA
6 Year Warranty
The Half-Mile Hailer series
helps schools meet the
security requirements of the
No Child Left Behind Act,
which mandates schools to
oer secure, safe learning
environments for their students.
