AmpliVox S1294 User manual

UPDATED 7/22/09
ACCESSORIES
WIRELESS PORTABLE SPEAKERS
S1294(-70), S1297(-70), S1244(-70), S1204(-70)
3995 Commercial Ave., Northbrook, IL 60062 PHONE: [phone] FAX: [phone] WWW.AMPLI.COM [e-mail]
Wireless Powered Speakers
Dynamic Audio Without Wires in Every Presentation Venue
Model S1294-70 Wireless
Powered Speaker - An addition to
the Travel Audio Pro family. It has a
built-in receiver and 100 watt amp
that drives a 10-in. woofer and
4-in. tweeter in a black carpeted
cabinet with a retractable luggage
handle, wheels, and built-in tripod
mount. Its full frequency response
of 35Hz-20,000Hz provides extra
sound reinforcement power to cut
through noisier indoor settings. It
has an SPL of 116dB Voice Mode
and 114dB Music Mode (That’s
as loud as a rock concert!) and is
powered by AC or rechargeable
internal batteries.
Model S1297-70 Wireless
Powered Speaker Model S1297-
70 Wireless Powered Speaker for
Digital Audio Travel Partner is an
addition to the 250 Watt Digital
Audio Travel Partner family. It has a
built-in receiver and 250 watt amp
that drives 2 6 in. NEO woofers
and a dynamic compression
tweeter in a molded plastic case
with a retractable luggage handle,
wheels, and built-in tripod mount.
It is powered by AC or rechargeable
internal batteries.
WIRELESS POWERED DUAL SPEAKER KIT - Includes a built-in 50-watt amp and BUILT IN WIRELESS RECEIVER
for a cordless link between the main PA and the speaker; drives two 6-in. x 8-in. speakers in black carpeted cabinet,
concealed pocket handle, tripod mount, includes transmitter. (14-in. x 10-in. x 6½-in.).
WIRELESS POWERED DUAL SPEAKER - built-in 50-watt amp and wireless receiver, drives two 6-in. x 8-in.
speakers in black carpeted cabinet, concealed pocket handle; built-in tripod mount (14-in. x 10-in. x 6.5-in.).
Links to S1204-70.
WIRELESS POWERED HAILER SPEAKER KIT S1244-70 - Includes separate master transmitter (first or only unit
in a given installation must be an S1244-70.) Has a built-in 50 watt amplifier that drives a 60 watt horn with receiver
for a cordless link between the main PA and the speaker
WIRELESS POWERED COMPANION SPEAKER FOR HAILER FAMILY S1244 - Includes a built-in 50 watt amp
that drives a 60 watt horn and wireless receiver for a cordless link between the main PA and the S1244-70. (Does not
include the transmitter – this model must receive its signal from an S1244-70’s master transmitter.)
WIRELESS POWERED COMPANION SPEAKER KIT FOR TRAVEL AUDIO PRO - 10-in. woofer & 4-in. horn tweeter.
Includes a built-in 100 watt amp and transmitter and receiver for a cordless link between the main PA and the
speaker.
WIRELESS POWERED COMPANION SPEAKER FOR TRAVEL AUDIO PRO - 10-in. woofer & 4-in. horn tweeter.
Includes a built-in 100 watt amp and wireless receiver for a cordless link between the main PA and the S1294.
Links to S1294-70.
WIRELESS POWERED COMPANION SPEAKER KIT FOR DIGITAL AUDIO TRAVEL PARTNER - For SW915 - Two
6.5in. NEO woofers and dynamic compression tweeter. Includes a built-in 250 watt amp and BUILT IN WIRELESS
RECEIVER for a cordless link between the main PA and the speaker.
WIRELESS POWERED COMPANION SPEAKER FOR DIGITAL AUDIO TRAVEL PARTNER - For SW915 - Two 6.5in.
NEO woofers and dynamic compression tweeter with a built-in 250 watt amp and wireless receiver for a cordless link
between the main PA and the S1297. Links to S1297-70.
Model # Shp. Wt. MSRP
S1204-70 19 Ibs. 604.00
S1204 19 Ibs. 517.00
S1244-70 13 lbs. 578.00
S1244 13. lbs 495.00
S1294-70 60 lbs. 1,353.00
S1294 60 Ibs. 1,267.00
S1297-70 35 lbs. 1,525.00
S1297 35 lbs. 1,431.00
S1294-70 S1297-70
S1244-70
S1204-70 Wireless
Powered Dual Speaker Kit
S1204
Model S1244-70 Wireless Powered
Hailer Speaker Model S1244-70 has
a built-in receiver and 50 watt amplifier
that drives a 60 watt horn. Can be
mounted on our tripods, model S1080
or S1090. It can be powered by 10
D-cell alkaline batteries (not included),
Our NiCad rechargeable battery Model
S1465 or Model S1460 AC Adapter
(all sold separately). It has easy access
controls for simple operation and
provides utmost flexibility in getting the
sound where you need to be heard –
for both indoors and outdoor activities.
Any number of S1244 satellite systems
placed within radio range can be used
with one master transmitter (part of
S1244-70.)
Model S1204-70 Wireless Powered
Dual Speaker Model S1204-70 has
a built-in receiver and 50 watt amplifier
that drives two 6-in. x 8-in. Jensen
design speakers in a black carpeted
cabinet with a concealed pocket handle
and built-in tripod mount (S1080 or
S1090). It can be powered by 10 D-cell
alkaline batteries (not included) or
Model S1460 AC Adapter (both sold
separately). It has easy access controls
for simple operation and provides
utmost flexibility in getting the sound
where you need to be heard – for both
indoors and outdoor activities, thanks
to its wireless transmitter operation
plus built-in sound amplification that
sends crystal clear sound to your entire
audience.
