1 Introduction
The adapter board allows an easy and fast evaluation of the AS5601 rotary magnetic position
sensor in the lab or together with an existing system. This small factor board is fully assembled with
AS5601 position sensor and its necessary external components. All relevant signals are available
on a dual-row 2.54mm 4-pin header footprint and can be easily wired to an existing application.
The AS5601 is an easy-to-program magnetic rotary position sensor with incremental quadrature
(A/B) and 12-bit digital outputs. Additionally, the PUSH output indicates fast airgap changes
between the AS5601 and magnet which can be used to implement a contactless pushbutton
function in which the knob can be pressed to move the magnet toward the AS5601.
The I²C interface is used for configuration and user programming of non-volatile parameters in the
AS5601.
2 Kit Content
This kit contains following material listed in Table 1. Additional material can be found on our
webpage.
Table 1:
Kit Content
No.
Item
Description
Info
1
AS5601-SO_EK_AB
2
AS5000-MD6H-1
Reference Magnet
Find the datasheet online at
http://ams.com/eng/AS5000-MD6H-1
3 Getting Started
The AS5601 adapter board is ideal for rapid setup of a contactless encoder knob. Additionally to the
adapter board, a sensor magnet in a mechanical setup is required. A reference magnet comes with
the kit.
3.1 Adapter Board Pin-Out
The pin-out of the adapter board is shown in Table 2. For additional information on the AS5601 pins
refer to the product datasheet.
Table 2:
Adapter Board Pin-Out
Header
Pin
Symbol
Description
Info
J3
1
SCL
I2C Clock
Use R3 if pull-up is required
J3
2
SDA
I2C Data
Use R4 if pull-up is required
J3
3
GND
Ground
J3
4
VDD
Positive Power
Supply
J2
1
VRG
LDO Pin in 5V
Leave open in 5V mode. Pull to VDD using

AS5601 Adapter Board
ams Eval Kit Manual, Confidential
Page 4
[v1-00] 2014-Jul-31
Document Feedback
Header
Pin
Symbol
Description
Info
Mode
J1 in 3.3V Mode
J2
2
B
Output Pin
Quadrature incremental signal B
J2
3
A
Output Pin
Quadrature incremental signal A
J2
4
PUSH
Output Pin
Contactless pushbutton function output
4 Adapter Board Description
The AS5601 is connected over the dual-row 2.54mm 4-pin header footprint. Connect the desired
pins of the AS5601 using the headers and resistors.
Figure 1:
Adapterboard Description
5 Mechanical Setup
To set up a contactless potentiometer a magnet holder and a magnet are needed to be used with
the AS5601 position sensor on a PCB. The configuration is shown in Figure 2.
I2C pull-up
resistors
Short J1 to
operate in
3.3V mode

AS5601 Adapter Board
ams Eval Kit Manual, Confidential
Page 5
[v1-00] 2014-Jul-31
Document Feedback
Figure 2:
Mechanical Configuration
The magnet should be aligned by reading the output of the AGC register of the AS5601. For optimal
alignment, the AGC value is in the middle of the AGC range.
Note: If the magnetic field seen by the AS5601 is below 8mT, the output is disconnected and
permanent angle programming is not possible. The AB output will not show any change until the
magnet is present again.
5.1 Electrical Setup
The Adapterboard can be used in 5V or in 3.3V mode in the configurations shown below. Short J1
to operate in 3.3V mode.
5.1.1 I2C Mode
Using the I2C Interface, all functions of the AS5601 can be configured and permanently
programmed. Additionally the output and a raw angle (unmodified value) can be read from the
output registers.
Figure 3:
Using the board in I2C mode
Magnet Holder (non-magnetic)
Sensor Magnet (d6x2,5)
AS5601
PCB
airgap
0.5 - 2.5mm
µC
+
-
SDA
SCL

AS5601 Adapter Board
ams Eval Kit Manual, Confidential
Page 6
[v1-00] 2014-Jul-31
Document Feedback
5.1.2 Incremental Mode
The incremental mode is used to set up a contactless encoder knob. In addition to the incremental
output, a push button output is available to integrate a contactless push-button.
Figure 4:
Using the board in incremental mode
Note: The grid and grid offset must be configured.
Note: To use the push-button functionality
6 AS5601 Configuration
All options to configure the AS5601 are shown below. To use the AS5601 in incremental mode for a
contactless rotary knob, the electrical signal must be aligned with the mechanical grid. As well the
push-button threshold must be configured for the mechanical setup.
6.1 Configuring the grid offset
An ideal mechanical grid and the electrical output are shown below in Figure 5 for a 3-bit encoder.
The transition of electrical signal should ideally be in the middle between two mechanical positions.
µC
+
-
A
B
Push

AS5601 Adapter Board
ams Eval Kit Manual, Confidential
Page 7
[v1-00] 2014-Jul-31
Document Feedback
Figure 5:
Aligning electrical and mechanical grid
Mechanical
position 1
Mechanical
position 2
Mechanical
position 8
Mechanical
position 3
Mechanical
position 4
Mechanical
position 6
Mechanical
position 5
Electric al
position 1
Electrical
pos ition 2
Electrical
pos ition 3
Electrical
pos ition 4
Electric al
pos ition 5
Electric al
position 6
Electric al
position 7
Electric al
pos ition 8
Mechanical
position 7
If the electrical are mechanical grid are not aligned due to production, it can easily be configured
using a grid offset. The grid offset is calculated as shown below:
𝐺𝑟𝑖𝑑𝑂𝑓𝑓𝑠𝑒𝑡𝑆𝑒𝑔𝑚𝑒𝑛𝑡 = 𝑀𝑂𝐷(𝐶𝑢𝑟𝑟𝑒𝑛𝑡𝐴𝑛𝑔𝑙𝑒; 360°
2𝑛 )− 360° 2∗2𝑛
𝑛…𝑅𝑒𝑠𝑜𝑙𝑢𝑡𝑖𝑜𝑛[𝑏𝑖𝑡]
𝐶𝑢𝑟𝑟𝑒𝑛𝑡𝐴𝑛𝑔𝑙𝑒 …𝐶𝑢𝑟𝑟𝑒𝑛𝑡 𝑂𝑢𝑡𝑝𝑢𝑡 𝐴𝑛𝑔𝑙𝑒 [°]
Note: To configure the grid offset, the offset value in degrees must be converted and written into
the ZPOS register.
6.2 Configuring the grid push button threshold
The push-button threshold must be configured for optimal output. Therefor the threshold must be
determined and written into the PUSHTHR register.
The swing of the pushbutton function can be found by subtracting the AGC value of the pressed
button from the AGC value of the released button. The threshold value for the contactless
pushbutton should be half of the swing.
6.3 Permanently programming a configuration
A configuration is written using the I2C interface. The Burn_Setting command (Write 0x40 into
register 0xFF) can be used to permanently program a configuration.
6.3.1 Low Power Mode
Three low power modes are available to reduce the power consumption down to 1,5mA max.

AS5601 Adapter Board
ams Eval Kit Manual, Confidential
Page 8
[v1-00] 2014-Jul-31
Document Feedback
6.3.2 Hysteresis
A 1 to 3 LSB hysteresis of the 12-bit resolution can be enabled.
6.3.3 Slow Filter
The slow filter allows improving the output noise. The default setting for the Slow Filter is 16x and
can be reduced for faster response.
6.3.4 Fast Filter
The fast filter is active by selecting a Fast Filter Threshold. If the output value remains below the
threshold, the output noise is defined by the slow filter setting. When exceeding the threshold, the
output noise is defined from the fast filter for fast output response. The output noise is again defined
by the slow filter as soon as the output stays in the threshold again.
6.3.5 Watchdog
If the watchdog is active, the AS5601 automatically enters Low Power Mode 3 after one minute if
the output value stays within a threshold of 4 LSB.
7 Board Schematics, Layout and BOM
The schematic, layout and BOM of the adapterboard are shown below for reference.
7.1 Schematics
