AmScope HD408N User manual

v0.9.20220809
HD408N, HD428N 4K Mul-Funcon Cameras

HD408N, HD428N User Guide
Safety
Before using your AmScope microscope, please read the following safety precauons carefully to avoid causing damage to
your AmScope product, or injury to yourself or others.
Turn o power if the instrument exhibits unusual or dangerous behavior such as eming smoke or unusual odors. These
can be indicaons of electrical problems, in which case the instrument should be disconnected from any power source if
safe to do so. Other indicators can be a loud buzzing sound or crackling. Contact AmScope to report such behavior.
Do not use around ammable liquids or gases. Electric instruments can ignite ammable substances which could result
in an explosion or re.
Do not use in a wet environment. Electrical components of the instrument can discharge when exposed to water, poten-
ally resulng in damage to the instrument, or injury to yourself or others.
Only use the provided power adapter or authorized replacement. Incompable power sources can cause damage to the
instrument. If you should lose the included power adapter, please contact AmScope for informaon about a replacement.
Do not dismantle. Dismantling can result in damage to the instrument, and potenal exposure to dangerous materials or
electric current.
Noces
AmScope reserves the right to change specicaons of the hardware and soware at any me without noce. Connuous
eorts are made to improve performance and reliability, which can result in changes to design and compability. Please
contact AmScope for any concerns regarding such changes.
Proposion 65 Noce for California Residents
Cables included with the products described in this manual can expose you to chemicals including lead,
which is known by the state of California to cause cancer, birth defects or other reproducve harm. Visit
www.P65Warnings.ca.gov for more informaon.

HD408N, HD428N User Guide
3
amscope.com
Contents
Specicaons.......................................................................................................................................................... 4
What’s In The Box................................................................................................................................................... 5
Setup ...................................................................................................................................................................... 6
Aaching the Camera to a Microscope ................................................................................................................ 6
Stand-Alone Mode ............................................................................................................................................... 7
Using with a PC..................................................................................................................................................... 8
Connecng with USB............................................................................................................................................ 8
Using on a Network.............................................................................................................................................. 9
LAN..................................................................................................................................................................................... 9
WLAN ............................................................................................................................................................................... 10
AP Mode ............................................................................................................................................................................................................... 10
STA Mode.............................................................................................................................................................................................................. 10
User Interface....................................................................................................................................................... 11
The Camera Control Panel ............................................................................................................................................... 12
Image Exposure.............................................................................................................................................................. 13
Manual Exposure .................................................................................................................................................................................................. 13
Auto Exposure....................................................................................................................................................................................................... 13
Color .............................................................................................................................................................................. 13
White Balance....................................................................................................................................................................................................... 13
The Measurement Toolbar............................................................................................................................................... 14
The Camera Control Toolbar ............................................................................................................................................ 16
Sengs .......................................................................................................................................................................... 17
Network ................................................................................................................................................................................................................ 17
Measurement ....................................................................................................................................................................................................... 18
Magnicaon........................................................................................................................................................................................................ 19
Image Format........................................................................................................................................................................................................ 19
Video..................................................................................................................................................................................................................... 20
Storage.................................................................................................................................................................................................................. 20
Language............................................................................................................................................................................................................... 21
Miscellaneous ....................................................................................................................................................................................................... 22

HD408N, HD428N User Guide HD408N, HD428N User Guide
4amscope.com
HD408N Specicaons
Sensor IMX334 (color)
Sensor Type CMOS
Sensor Opcal Format 1/1.8”
Acve Recording Pixels 8.3M (3840 x 2160)
Pixel Size 2µm x 2µm
Acve Sensor Area 7.68mm x 4.32mm
Shuer electronic rolling shuer
Sensivity 505mV @ 1/30s (f/5.6)
Video Resoluons 3840x2160 30fps
File Formats JPEG, TIFF (photo), MP4 (video)
Recording Media Secure Digital up to 128GB
I/O HDMI (video out), USB 2.0 x 2 (PC, external media, wi-), USB (mouse), LAN, SD
Wi-Fi Standard 802.11ac 2.4GHz/5GHz
Lens Mount C-Mount
Power Requirements DC 12V 1A

HD408N, HD428N User Guide
5
amscope.com
HD428N Specicaons
Sensor IMX485 (color)
Sensor Type BSI CMOS
Sensor Opcal Format 1/1.2”
Acve Recording Pixels 8.3M (3840 x 2160)
Pixel Size 2.9µm x 2.9µm
Acve Sensor Area 11.14mm x 6.26mm
Shuer electronic rolling shuer
Sensivity 2188mV @ 1/30s (f/5.6)
Video Resoluons 3840x2160 30fps
File Formats JPEG, TIFF (photo), MP4 (video)
Recording Media Secure Digital up to 128GB
I/O HDMI (video out), USB 2.0 x 2 (PC, external media, wi-), USB (mouse), LAN, SD
Wi-Fi Standard 802.11ac 2.4GHz/5GHz
Lens Mount C-Mount
Power Requirements DC 12V 1A
What’s In The Box
The HD408N and HD428N standard ouits include:
• One camera
• One USB mouse
• One HDMI cable
• One power adapter
• One USB wi- dongle
• One USB thumb drive
• Soware

HD408N, HD428N User Guide HD408N, HD428N User Guide
6amscope.com
Setup
Aaching the Camera to a Microscope
This camera uses a C-Mount standard lens mount. The camera can
be mounted directly to a microscope which provides a C-Mount
photo port, or it can be mounted to an ocular or photo port by
using an oponal compensang lens. The C-Mount standard uses a
1” (25.4mm) diameter with 32TPI (0.794mm pitch).
To mount the camera to a C-Mount port, simply remove the camera’s lens-port dust-cap, then align the microscope’s
port with the lens port. Rotate the camera in a clockwise manner unl it is rmly aached. The photo port on some
microscopes will have a rotang interface which can be locked and unlocked to change the orientaon of the camera. If
so, you can use this to properly align the camera to produce upright images. If not, you may need to unscrew the camera
slightly to achieve the proper orientaon.
To use a compensang lens, the correct lens must be used. A compable compen-
sang lens would have a C-Mount thread which would allow it to screw onto the
camera’s lens mount. The other end would be cylindrical, and would slide into one
of the microscope’s ocular ports or photo port. The compensang lens will have a
magnicaon such as 0.5X or 0.37X. When the lens has a magnicaon below 1X,
it is referred to as a reducon lens since it reduces the size of the image projected
onto the camera’s sensor. The magnicaon should roughly match the opcal for-
mat of the camera’s image sensor (see Sensor Opcal Format in the specicaon
tables). For example, if the camera’s sensor format is 1/2”, then a 0.5X compensat-
ing lens would be appropriate.
Aach the lens to the camera by aligning the threads with the camera’s lens port. Gently screw the lens into the port in
a clockwise manner unl it is rmly aached. Next, slide the lens into an appropriate port. Because of the camera’s size
and weight, it is beer to use a port on the microscope intended specically for cameras, such as a vercal trinocular
port. This will avoid pping the microscope, and can prevent the camera from rotang. Addionally, a sizing adapter
may be needed if the diameter of the lens’ tube does not match the diameter of the port. Some lenses will include sizing
adapters such as a 23mm to 30mm adapter.

HD408N, HD428N User Guide
7
amscope.com
Stand-Alone Mode
This HD series camera can be used in stand-alone mode when connected to a compable video display such as a monitor
or television. The camera’s controls and sengs are accessed using the supplied USB mouse.
Begin by aaching one end of the supplied HDMI cable to the camera’s HDMI port. Connect the other end of the cable to
the monitor’s or television’s HDMI input. The video display may need to be manually congured to use the correct input.
If so, consult the video display’s manual. Connect the supplied USB mouse to the camera by aaching its USB plug to the
camera’s USB port labeled “USB Mouse”. Next, connect the supplied power adapter by inserng its barrel connector to
the camera’s power port labeled “DC 12V”. The power indicator located above the power port should be red which indi-
cates the camera is receiving power. Press the camera’s power buon to inialize the camera. The power indicator will
change to blue. It will take several seconds for the camera’s soware to boot, during which a cursor will appear on the
screen. Once the camera is fully booted, you can move the cursor around the screen to acvate the on-screen controls.

HD408N, HD428N User Guide HD408N, HD428N User Guide
8amscope.com
Using with a PC
The camera can be used with a Windows, Mac, or Linux computer by installing AmScope imaging soware which is
included in the camera’s packaging or can be downloaded from the AmScope website: hps://amscope.com/pages/so-
ware-downloads.
Soware is available for current versions of Windows, Mac OS, and Linux operang systems, but availability or compat-
ibility is subject to change. Before connecng the camera to a computer, install the soware to ensure the device will
be recognized by the operang system. More informaon regarding the soware is available in the soware’s help le
which can be accessed from the soware’s menu under “Help.”
The camera can be accessed from the computer using a USB connecon, wi-, or Ethernet. When the proper connecon
is made, the camera will be displayed in the soware’s list of available devices.
Connecng with USB
The camera can be connected to a computer using the provided USB cable. The cable has a type-A USB connector on
either end. Plug one type-A connector into the camera’s USB port labeled “USB Video”. Plug the other type-A connector
into one of the computer’s available USB 2.0 or USB 3.0 ports. If the camera is not already powered on, press the power
buon and wait for the power indicator LED to turn solid blue. If the AmScope soware has been installed on the com-
puter, the camera will be recognized as an imaging device, and can be accessed using the soware.

HD408N, HD428N User Guide
9
amscope.com
Using on a Network
These camera models can be used in a network, allowing them to be accessed by network users. Each camera has an
Ethernet port which can be used on a local-area network (LAN) by connecng to a network switch or other device using
an Ethernet cable. Each camera also includes a wi- dongle which aaches to the camera’s USB 2.0 port to provide
connecvity over a wireless local-area network (WLAN). Either connecon method requires conguraon which must
be performed while the camera is connected to a video display using HDMI. Once the conguraon is performed, the
camera can be used without the display.
LAN
When connecng to a LAN, the camera is treated as a client device or peer using IPv4 protocol. The camera must be
connected to a network interface such as a switch using an Ethernet cable. Prior to connecon, the camera will need to
be congured. With the camera connected to a video display, use the mouse to move the cursor over the boom of the
screen to display the Camera Control Toolbar. Click on the icon to open the Sengs menu. Select Network from the
sengs list, then click on the LAN tab. There is a check box labeled “DHCP” which designates whether the camera’s net-
work address will be managed by the network’s DHCP server, or manually. In most cases, DHCP is the preferred opon,
allowing the camera to be accessed by computers on the network which are using the provided AmScope soware. In
some cases, it may be necessary to dene the camera’s address manually. To do so, uncheck the DHCP box, then enter
the IP address, subnet mask, and default gateway in their respecve elds. When all sengs are set, click on the apply
buon on the boom right of the screen.

HD408N, HD428N User Guide HD408N, HD428N User Guide
10 amscope.com
WLAN
Camera models which support WLAN (Wireless Local Area Network) connecvity can be used with wi- compable com-
puters and mobile devices. The camera will include a USB wi- dongle (adapter) which must be connected to the USB 2.0
port on the camera. There are two wi- modes which can be used: AP (access point) and STA (staon).
AP mode allows the camera to create an ad hoc wireless network to which other devices can connect. This mode
allows devices to connect directly to the camera without the need for a router or network switch.
STA mode is used to connect the camera to an exisng wireless network. The camera’s accessibility on the net-
work is managed by the network’s hardware, not the camera.
Before using the camera with wi- devices, the WLAN sengs must be congured while the camera is aached to an
HDMI display. Ensure the wi- dongle is aached to the USB 2.0 port, and the camera is powered on. Aer the camera’s
soware has booted and the wi- dongle has been detected, the current wi- mode will be displayed on the top le cor-
ner of the screen. Move the cursor over the boom of the screen to display the Camera Control Toolbar. Click on the
icon to open the Sengs menu. Select Network from the list, then click on the WLAN tab. The wi- mode can be selected
from a drop-down selector.
AP Mode
When AP mode is selected, sengs specic to this mode will be available. The Frequency seng allows you to select
either 2.4GHz or 5GHz to match the wireless devices you will be using. The Channel opon allows you to switch through
dierent frequencies in the selected band. This seng is only needed in the case that interference is encountered
while connecng to wireless devices such as frequent drop-outs. The Password seng allows you to change the default
password to be used by devices connecng to the camera’s network. The default password is 12345678. Use your own
password to beer secure the encrypted connecon.
STA Mode
When STA mode is selected, you must enter the SSID and password for the wireless network to which you will connect.
Aer the informaon has been entered, click the Apply buon on the boom right corner of the screen. If the camera
successfully connects to the network, “AP Mode” will be displayed on the top le corner of the screen. If the connecon
fails, “AP Mode Failed” will be displayed. Should the connecon fail, verify the SSID and password. If the SSID and pass-
word are correct, there may be a seng in the network’s hardware or rewall prevenng the camera from connecng.

HD408N, HD428N User Guide
11
amscope.com
User Interface
This HDMI model uses an on-screen UI to operate. The camera controls are located in the panel on the le side of the
window, the measurement toolbar on the top, and addional display controls and sengs are on the boom.
By default, the panels will only display when the mouse cursor is hovering over the appropriate area. Le-clicking
on the “pin” icon will maintain the panel’s visibility, but will prevent other panels from opening.

HD408N, HD428N User Guide HD408N, HD428N User Guide
12 amscope.com
The Camera Control Panel
The Camera Control Panel controls the camera to achieve the best video or image quality according to the specic appli-
caons. To open the panel, move the mouse cursor toward the le edge of the video window.
Control Panel Funcon Descripon
Snap Capture image and save it to the SD card.
Record Record video and save it to the SD card.
Auto Exposure When Auto Exposure is checked, the system will automacally
adjust exposure me and gain according to the value of expo-
sure compensaon.
Exposure Compen-
saon
Available when Auto Exposure is checked. Slide to increase or
decrease the overall brightness to compensate for varying sub-
jects.
Exposure Time Available when Auto Exposure is not checked. Slide to increase
or decrease exposure me for achieving appropriate brightness.
Gain Available when Auto Exposure is not checked. Slide to increase
or decrease signal amplicaon. Increasing the amplicaon will
increase brightness without adjusng exposure me, but will
result in increased noise levels.
Red Manually adjust the proporonal Red level of the RGB video.
Green Manually adjust the proporonal Green level of the RGB video.
Blue Manually adjust the proporonal Blue level of the RGB video.
Auto (White Bal-
ance)
Connuously adjusts RGB levels automacally based on the
overall video content.
Manual (White
Balance)
Enables the manual RGB controls to adjust the color balance.
ROI (White Bal-
ance)
Use the on-screen Region-of-Interest selector (rectangle will
appear) to dene a region which should be used as reference
when performing white balance.
Sharpness Slide to adjust the sharpness level of the video.
Denoise Slide to adjust the amount of noise-reducon to apply to the
video.
Saturaon Slide to adjust the color saturaon of the video.
Gamma Slide to increase or decrease the Gamma level of the video.
Contrast Slide to adjust the contrast of the video.
DC Select when using DC powered illuminaon. No icker compen-
saon.
AC (50Hz) Select when using AC powered illuminaon with 50Hz to re-
move ickering.
AC (60Hz) Select when using AC powered illuminaon with 60Hz to re-
move ickering.
Default Restore all values in the Camera Control Panel to their default
sengs.

HD408N, HD428N User Guide
13
amscope.com
Image Exposure
Manual Exposure
Image exposure controls the amount of light captured by the imaging device. Exposure me is used to set the amount
of me over which light is collected. More me will result in a brighter image. For most stac subjects, increasing expo-
sure me to achieve the appropriate brightness is the preferred method. For moving subjects, too much me will result
in blurring as the subject’s locaon changes over me. Exposure me must be limited in these cases to prevent excess
movement. Use of the gain seng would therefore be the preferred method to achieve opmal brightness. Gain controls
the amount of amplicaon applied to the signal generated by the imaging sensor. While the signal strength would be
increased, noise generated during the imaging process would also be increased.
Auto Exposure
Auto exposure relies on soware to set the exposure me and gain. This simplies the workow, especially when captur-
ing images in changing lighng condions. As a microscope’s magnicaon changes, or the distance from the microscope
to the subject changes, the amount of light collected will also change. Auto exposure can connuously compensate for
these changes. This method assumes that the opmal amount of light would create an image with levels which would
average to a middle tone. Because of this, images of light subjects may appear too dark, and images of dark subjects may
appear too bright. For this reason, adjustment can be done using the exposure compensaon control, somemes called
exposure target. This allows you to increase or decrease the target level of brightness.
Color
White Balance
The color of an object is inuenced by the color of light reecng o of it or passing through it. Dierent light sources
produce light with dierent color-biases. Common examples are incandescent lamps which typically produce warm
colors compared to uorescent or LED lamps which produce cooler colors. This sort of bias is referred to as color tem-
perature. Due to this phenomenon, a white object may appear slightly yellow in morning sunlight, and slightly blue in
aernoon shade. To compensate for these variaons, digital imaging devices can process images using what is called
“white balance.” The white balance process shis colors based on the color of the light source, with the goal of produc-
ing a more neutral white or grey.

HD408N, HD428N User Guide HD408N, HD428N User Guide
14 amscope.com
The Measurement Toolbar
The Measurement Toolbar will pop up when moving the mouse cursor toward the upper edge of the video window. This
panel contains tools and sengs for performing measurements.
Icon Funcon
Pin the Measurement Toolbar
Show / Hide Measurement Objects
Select Measurement Unit
Select Magnicaon (requires calibraon process)
Object Selector
Angle
4-Point Angle
Point
Arbitrary-Angle Line
3-Point Lines
Horizontal Line
Vercal Line
Parallel
3 Points Vercal Line
Rectangle
Ellipse
5-Point Ellipse
Circle
3-Point Circle
Annulus (Concentric Circles)

HD408N, HD428N User Guide
15
amscope.com
Icon Funcon
Two Circles with Distance from Centers
Two 3-Point Circles with Distance from Centers
Arc
Text
Polygon
Curve
Scale Bar
Arrow
Perform magnicaon calibraon. Denes relaonship between the measurement
unit and pixel size. Requires the use of a micrometer slide.
Export measurement informaon to CSV le
Access the camera’s sengs
Delete measurement object
Exit measurement mode
Le-clicking on a measurement object will open the Object Locaon & Properes Con-
trol Bar. The icons on the control bar:
• Move Up
• Move Down
• Move Le
• Move Right
• Adjust Color
• Delete
When the Pin icon is clicked to lock the Measurement Toolbar, the Camera Control Panel will not be displayed unl
the Measurement Toolbar is unpinned by clicking the Exit icon .

HD408N, HD428N User Guide HD408N, HD428N User Guide
16 amscope.com
The Camera Control Toolbar
The Camera Control Toolbar provides a subset of tools for controlling the camera’s video, as well as general sengs and
the le viewer.
Icon Funcon Icon Funcon
Zoom In Zoom Out
Horizontal Flip Vercal Flip
Color/Grayscale Freeze Video
Display Crosshair/Grid Browse Images and Videos on SD Media
Sengs Soware Version Informaon
The Zoom tools allow you to use digital zoom to enlarge the on-screen image up to 10X in 0.2X increments.
Horizontal and Vercal Flip are used to reorient the on-screen image due to image-inversion caused by a microscope’s
opcs or the camera’s physical orientaon.
Color/Grayscale can be used to switch between the camera’s normal color image and a desaturated image.
Freeze Video will pause the live video.
A Crosshair or Grid can be displayed to assist with segmenng and counng, image alignment, and other operaons.
The Browse tool allows you to view media les recorded by the camera on the inserted SD media.
The Sengs panel can be used to customize certain display opons, manage saved magnicaon calibraons, choose
image formats, and congure the camera for network operaon.

HD408N, HD428N User Guide
17
amscope.com
Sengs
Network
Network sengs are used to congure the camera’s LAN and WLAN sengs. Camera models equipped with an Ethernet
port can connect to a local-area network (LAN). Camera models which include a wi- dongle can be used with compa-
ble computers and mobile devices using a wireless local-area network (WLAN).
General Name The camera’s name which will appear on the network.
Wi-Fi AP Frequency Select the wi- band: 2.4GHz or 5GHz
Channel Select the wi- channel to use
Password Edit the password other devices will use to connect to the camera
STA SSID
Password
LAN DHCP Select to allow the network’s DHCP server to manage this device’s network address
Transfer Unicast Sends data to one network device
Mulicast Sends data to mulple network devices
IP Address Manually dene the network IP address
Subnet Mask Manually dene the network subnet mask
Default Gateway Manually dene the network default gateway

HD408N, HD428N User Guide HD408N, HD428N User Guide
18 amscope.com
Measurement
Measurement sengs allow you to customize shapes, and dene the precision of measurements.
Global Precision Sets the decimal scale: number of digits aer a decimal point
Calibraon Line Width Sets the width of lines used for calibraon
Color Sets the color of lines used for calibraon
Endpoint Sets the shape used at each endpoint of a line. Includes null or rectangle
Angle, Point, Line, Parallel Line, Vercal Line, Rectangle, Ellipse, Circle, Annulus, Two Circles, Arc, Text, Polygon, Curve,
Scale Bar, Arrow
Each shape or element can be customized using aributes such as Line Width and Color

HD408N, HD428N User Guide
19
amscope.com
Magnicaon
Magnicaon sengs allow you to edit stored magnicaon calibraons. Each me the calibraon process is completed,
you can save the results as a magnicaon preset. These presets can be selected from the Measurement Toolbar to use
the appropriate, calibrated sengs.
Name This is the user-dened name of magnicaon seng. Names typically incorporate the magnicaon of
the objecve lens used, and addional informaon pertaining to the microscope or camera used.
Resoluon The number of pixels per meter.
Clear All Clears all saved calibraon data
Delete Clears the selected calibraon data
Image Format
Image Format sengs allow you to determine whether measurement objects will be merged into saved images, or em-
bedded as a separate layer.
Image Format Choose the le type to be used: JPEG or TIFF
Measurement Object
Saving Method
Burn In Mode Measurement objects are merged with the image before saving the le.
Objects can neither be edited nor removed.
Layered Mode Measurement objects are saved in a separate layer, and can be edited.

HD408N, HD428N User Guide HD408N, HD428N User Guide
20 amscope.com
Video
Video sengs allow you to change the fast-forward and reverse intervals, and to choose the video codec.
Playback Fast Forward/Reverse
Interval
The number of seconds to be skipped when fast-forwarding or reversing
playback of videos
Video Encode H264 Older AVC video codec with beer compability across mulmedia de-
vices, but less ecient compression compared to H265.
H265 Newer HEVC video codec with improved compression while retaining
high quality
Storage
Storage displays the format of any recognized storage media including Secure Digital cards and USB ash drives. If com-
pable media is recognized, the media’s le system will be shown, such as FAT32, exFAT, and NTFS. Unformaed cards
must be formaed on a computer or other device prior to being used with the camera.
