AMT SS-20 User manual

www.amtelectronics.com www.amtelectronics.com
1 1
Safety precautions.
CAUTION! Risk of electric shock! Danger! Even after disconnection from
mains the internal circuits can be up to 500 Volts live. In order to avoid electric
shock you must not remove the cover the rear panel of the device. There are no
user serviceable parts inside. Repair of the device can be carried out only by
qualified experts. If the device is not used it must be disconnected from mains.
WARNING! In order to avoid fire or electric shock the device must not be exposed to
rain or moisture. Do not let water or other liquid get inside the device. Do not place
vessels such as vases filled with liquid on top of the device.
This symbol indicates the presence of non-insulated dangerous
voltage inside the device and the danger of electric shock.
This symbol indicates important information related to the device
maintenance and servicing contained in the accompanying
documentation.
Please read the instruction manual very carefully.
1. Keep the user's guide at hand.
2. Pay attention to warnings.
3. Follow all instructions related to device operation.
4. To clean the device, use only a dry cloth having disconnected
the device from mains prior to that.
5. You must not block or cover vent slots. When installing the
device, follow the instructions provided by the manufacturer.
6. Do not place the device near heat sources, keep it from direct
sunlight.
7. Lay the mains cable so that it is not stepped on and avoid its
contact with sharp corners, etc. If you use the plug or outlet for
switching the device off they should be easily accessible.
8. Use only additional devices and accessories recommended
by the manufacturer. Disconnect the device from mains in
case of thunder-storm or when the device is not in use for
prolonged time.
9. All works related to the device repair must be done only by
qualified service personnel.
10. WARNING! All service instructions are intended only for
qualified personnel in order to avoid electric shock; do not
carry out any repair works which are not described in the
instruction manual. Repair works must be carried out only
by qualified experts.
Contents
Important instructions 1
Complete set 1
Introduction 2
Before you start 2
Specifications 2
Controls 3
Front panel 3
Rear panel 3
Only for qualified service personnel 3
Tube replacement 3
Connections and switching 3
Block diagram 4
References 4
IMPORTANTINSTRUCTIONS!
NON-OBSERVANCE OF THE FOLLOWING INSTRUCTIONS CAN CAUSE
DAMAGE OF THE AMPLIFIER OR SPEAKERS. THE DAMAGES RESULTED
BY NON-OBSERVANCE OF THESE INSTRUCTIONS MAKE THE
WARRANTY VOID.
¾After transportation or storage of the product under
negative temperatures, before switching the device on it is
necessary to leave the device under room temperature in
its original package for AT LEAST 2 hours!
¾To connect the guitar preamp to other devices use only the
cables intended for such connections.
¾You must not use other cables types such as speaker, etc.
SWITCHING ON the guitar preamp:
¾Switch the device on ONLY AFTER YOU HAVE DONE all
audio connections!
¾Before connecting the preamp to mains make sure that the
case, the connecting cable and the of the power adapter
have no damages such as cuts, cracks, dents, etc. and are
operational.
¾To switch the preamp on first insert the low-voltage
connector of the power adapter into corresponding jack on
the rear panel of the guitar preamp and only then plug the
adapter into the mains outlet.
SWITCHING OFF the guitar preamp:
¾To switch the preamp off first disconnect the power
adapter from mains and then disconnect its low-voltage
connector from the jack on the rear panel of the guitar
preamp.
COMPLETE SET:
The complete set includes:
1. The guitar preamp 1
2. Power adapter 1
3. Instruction manual 1
4. Packaging 1
www.amtelectronics.com www.amtelectronics.com
2 2
INTRODUCTION:
The SS-20 guitar preamp is intended for use in studio and live performances. The
principle and the motto of this device: it is the TUBE that sounds in
SS-20, but the transistors do their best to make it sound in all its
beauty and originality not by limiting but helping the TUBE! In order to
make tube drivers fully open under the "hottest" conditions they need huge
amplitude - a hundred and more volts.
The dynamic behavior characteristic to authentic tube preamps have been realized
in SS-20 due to the omission of op amp which normally limits the signal in the
preliminary amplification sector to 20 – 250 V, and application of special drivers
capable of up to 250V amplitude and possessing the nonlinearity similar to 12АХ7
triode. In this way we have managed to realize the complete delivery of guitar signal
avoiding usual hybrid "stiffness" as well as to give SS-20 its peculiar characteristic
sound.
The special attention was given to the clean channel - there we also tried to provide
the maximum guitar signal dynamics simultaneously forming soft "nonlinearity"
inherent in vacuum triodes drivers. It also allowed us to avoid both "stiffness" and
"refinement" which are often found in hybrid devices having CLEAN-channel.
When building the internal preamp structure we were guided by the principle of
maximum use of amplification and nonlinear transformation of the tube sector of the
device. Thus, the semi-conductor part of a hybrid practically does not participate in
limitation process (except for preamp use in LEAD mode with Gain LEAD level of
over 7) and the entire spectrum is formed by the tube part of the preamp.
Architecture and features of SS-20 guitar pedal:
9Unique hybrid circuitry.
9Two full-potential channels: CLEAN and DRIVE with the possibility of DRIVE
channel operating in two basic modes: the mode of moderate sensitivity
(CRUNCH), the mode of high sensitivity (LEAD).
9CLEAN channel has a separate tone-volume controls unit and adjustments of
sensitivity and output level.
9DRIVE channel has separate tone-volume controls and adjustments of
sensitivity and output level.
9Sequential break (LOOP).
9Possibility of operation with specialized guitar amplifiers (OUTPUT) and mixers
or linear power amplifiers (OUTCAB.S.).
LEAD channel is designed for modern, extremely aggressive sounds for players
who use both standard and lowered tuning. Carefully calculated spectral and tone
balances of the channel are good for modern “punch” and bright flageolets and
extreme readability fast licks. Thus, the channel can be used both for aggressive
rhythm parts and for brightly outlined solos.
CRUNCH channel is distinguished by lesser overall sensitivity but possesses high
universality. The user can choose using PRE-EQ switch for one of the three variants
of preliminary signal correction having different tone balance between the lowest and
highest frequencies which allows to use the channel both for "rhythm" and "solo".
The wide adjustment range of sensitivity in combination with expanded possibilities
of target tone adjustments results in the sound starting from light airy crunch to
dense and bright Lead channel-like heavy sounding.
CLEAN channel is designed for classical clean sound with graceful light limitation in
the mode of the maximum sensitivity and crystal cleanliness and brightness within
the zone of moderate sensitivity value. It has separate controls of sensitivity and
output level.
Before you start:
For the purpose of transportation the device was carefully packed by the
manufacturer. However, if cardboard packaging is damaged, it is necessary to check
the device for the presence of external damages.
¾In case of damages do not send the device to us, but inform the
seller and transport agency since otherwise you lose the right
to damage compensation.
¾In order to avoid damages during storage and transportation
always use original packaging.
¾Do not allow children to play with the device and packaging
materials.
¾Please recycle all packaging materials in the way harmless to
environment.
¾In order to avoid the device overheating provide sufficient air
flow, do not cover and do not place it near other heat-
generating devices.
¾Operating the device next to powerful radio transmitters and
sources of high-frequency signals can lead to significant sound
distortion. In this case increase the distance between the
device and the transmitter and use the screened cables for all
interconnections.
WARNING!
Please be aware that high sound volume can harm your hearing
and / or to damage the speakers of your PA system. Before
switching the device on turn the controls "Volume" into
extreme left position (counter-clockwise). Always try to adhere
to moderate level of volume.
Specifications:
Use only auxiliary devices and accessories
recommended by the manufacturer.
Tubes
12AX7 (ECC-83) 1
INPUT
Impedance 1,0 МOhm
Sensitivity -10dB
RETURN
Impedance 1,0 МOhm
Sensitivity -10dB
OUTPUT
Output impedance 10кOhm
Output signal level 0dB (0,775V)
OUT CAB.S.
Output impedance 10кOhm
Output signal level -10dB
SEND
Output impedance 10кOhm
Output signal level -10dB
Power supply
Voltage DC 12V
Current 0,5A
Power adapter
Voltage DC 12V
Current 1,0A
Dimensions / Weight
NET dimensions (WхHхD). Without
power adapter. 119х57х103 mm
NET weight without power adapter 0,52 kg
GROSS dimensions (WхHхD). About 206х83х140mm.
GROSS weight About 0,78 kg
www.amtelectronics.com www.amtelectronics.com
3 3
CONTROLS.
Front panel.
1. VOLUME control of channel B. Determines the volume level of DRIVE
channel.
2. VOLUME control of channel А.Determines the volume level of CLEAN
channel.
3. Channel АCLEAN indicator.
4. BASS control of channel A. Sets the low-frequency range of CLEAN
channel.
5. MIDDLE control of channel A. Sets the mid-frequency range of CLEAN
channel.
6. TREBLE control of channel A. Sets the high-frequency range of CLEAN
channel.
7. GAIN CR switch for step change of tube driver frequency
characteristics of B channel (DRIVE) in CRUNCH mode.
8. GAIN CLEANcontrol of channel A. Sets the sensitivity level of CLEAN
channel.
9. GAIN LEAD control of Bchannel. Sets DRIVE channel sensitivity level
in LEAD mode.
10. Вchannel DRIVE indicator in LEAD mode.
11. GAIN CRUNCH control of Bchannel. Sets DRIVE channel sensitivity
level in CRUNCH mode.
12. CRUNCH / LEAD footswitch for switching between CRUNCH and
LEAD modes in DRIVE mode.
13. Вchannel DRIVE indicator in CRUNCH mode.
14. TREBLE control of channel B. Sets DIVE channel high-frequency
response.
15. MIDDLE control of channel B. Sets DRIVE channel mid-frequency
response.
16. BASS control of channel B. Sets DRIVE channel low-frequency
response.
17. CHANNEL A / CHANNEL B footswitch for switching between CLEAN
and DRIVE channels.
18. Top tube protective cover.
19. BDRIVE channel indicator.
Rear panel.
20. INPUT for guitar connection.
21. DC 12V jack for power adapter connection.
22. OUT CAB.S. for connection to Line input of mixing console.
23. RETURN input for connection of external effect unit (-10dB).
24. SEND output for signal sending to external effect unit (-10dB).
25. OUTPUT to amplifier.
26. Bottom cover of the guitar preamp.
WARNING! All cable connections must be made ONLY WITH
GUITAR PREAMP SWITCHED OFF!
For qualified personnel only.
DANGER! High voltage!
Even after disconnection from mains the internal
circuits can be up to 500 Volts live. In order to avoid
electric shock you must not remove the cover the rear
panel of the device. There are no user serviceable parts
inside. Repair of the device can be carried out only by qualified
experts. If the device is not used it must be disconnected from
mains.
The preamp circuitry is powered by high-tension current.
To avoid damages or injuries caused by fire or short-
circuit do not let any foreign objects or liquids inside the
device.
Tube replacement.
Tube replacement procedure:
1. Remove top tube protective cover (18) by unscrewing 4 (four)
fastening screws.
2. Снять нижнюю крышку гитарного предварительного усилителя
(поз.16) открутив 4 (четыре) крепёжных винта.
3. Remove bottom cover of the guitar preamp (16) by unscrewing 4
(four) fastening screws.
4. Remove old tube.
5. Replace it with new tube.
6. Replace bottom cover and top tube protective cover of the guitar
preamp.
For replacement use only the tubes recommended by the manufacturer.
AUDIO CONNECTIONS AND SWITCHING.
WARNING! All cable connections must be made ONLY
WITH GUITAR PREAMP SWITCHED OFF!
The diagram of possible audio connections of the preamp with external units
www.amtelectronics.com www.amtelectronics.com
4 4

Other AMT Amplifier manuals

AMT Legend Amps M-1 User manual

AMT

AMT Legend Amps M-1 User manual

AMT Bass ZEALOT BZ-300 User manual

AMT

AMT Bass ZEALOT BZ-300 User manual

AMT SS-30 User manual

AMT

AMT SS-30 User manual

AMT Vt2 Legend Amps User manual

AMT

AMT Vt2 Legend Amps User manual

AMT Legend Amps K2 User manual

AMT

AMT Legend Amps K2 User manual

AMT S-Drive FX-Drive Series User manual

AMT

AMT S-Drive FX-Drive Series User manual

AMT V1 User manual

AMT

AMT V1 User manual

AMT SS-10 User manual

AMT

AMT SS-10 User manual

Popular Amplifier manuals by other brands

piezosystemjena 30V300 instruction manual

piezosystemjena

piezosystemjena 30V300 instruction manual

TEXONIC DX850 owner's manual

TEXONIC

TEXONIC DX850 owner's manual

Quantum QC 310 Brochure & specs

Quantum

Quantum QC 310 Brochure & specs

WILSON PRO ENTERPRISE 4300 installation guide

WILSON PRO

WILSON PRO ENTERPRISE 4300 installation guide

Premier Builders Guild Two-Rock Jet 22 owner's manual

Premier Builders Guild

Premier Builders Guild Two-Rock Jet 22 owner's manual

Key Digital Xplosion Series KD-SCDA8 Specifications

Key Digital

Key Digital Xplosion Series KD-SCDA8 Specifications

Taramps Electronics DS440X4 instruction manual

Taramps Electronics

Taramps Electronics DS440X4 instruction manual

Digital Acoustics IP7-SS20 Getting started guide

Digital Acoustics

Digital Acoustics IP7-SS20 Getting started guide

Steg K 2.01 user guide

Steg

Steg K 2.01 user guide

Warwick Pro Fet II Service manual

Warwick

Warwick Pro Fet II Service manual

MUSIC HALL ha25.3 instruction manual

MUSIC HALL

MUSIC HALL ha25.3 instruction manual

Yamaha C-50 owner's manual

Yamaha

Yamaha C-50 owner's manual

Bouyer AR 1050 manual

Bouyer

Bouyer AR 1050 manual

McIntosh C41 Brochure & specs

McIntosh

McIntosh C41 Brochure & specs

Rotel RB-985 MKII owner's manual

Rotel

Rotel RB-985 MKII owner's manual

Benchmark h1 manual

Benchmark

Benchmark h1 manual

Audiolab 8300A User instructions

Audiolab

Audiolab 8300A User instructions

Kenwood KAC-X10D - eXcelon Amplifier Service manual

Kenwood

Kenwood KAC-X10D - eXcelon Amplifier Service manual

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
