ANBTEK TS10 User manual

Copyright © 2015 Shenzhen ANB Technology Co., Ltd. All rights reserved.
Vehicle GPS Tracker
(GSM+GPS+SMS/GPRS)
TS10 User Manual
(Version 1.1)

Copyright © 2015 Shenzhen ANB Technology Co., Ltd. All rights reserved.
IndexContents
1. Package Contents ........................................................................................................................... 3
2. Features and Specifications.............................................................................................................3
3. Knowledge before Usage................................................................................................................ 3
3.1 Factory Default Setting......................................................................................................... 3
3.2 Power Supply and consumption............................................................................................4
3.3 How to Insert Simcard.......................................................................................................... 4
4. Installation....................................................................................................................................... 4
4.1 Wiring Diagram.....................................................................................................................4
5. Device configuration....................................................................................................................... 5
5.1 Configure GPRS Parameter.................................................................................................. 5
5.2 ConfigureAuthorized Phone Numbers for alarm alerts........................................................5
5.3 Change SMS Password......................................................................................................... 5
5.4 Time zone Localization Setting.............................................................................................6
6. Functionality and Operation............................................................................................................6
6.1 Voice Listen-in...................................................................................................................... 6
6.2 Remote Cut-engine (Immobilizer)........................................................................................6
6.3 Reset Mileage report value................................................................................................... 6
6.4 Tracking parameter setting....................................................................................................6
6.5 Query vehicle status.............................................................................................................. 7
6.6 Query GPRMC data.............................................................................................................. 7
6.7 Query Google map Position Link......................................................................................... 7
6.8 Recover factory setting......................................................................................................... 7
6.9 Remote reboot....................................................................................................................... 7
6.10 Alarm Alerts........................................................................................................................ 7
6.11 OTAOperation..................................................................................................................... 7

Copyright © 2015 Shenzhen ANB Technology Co., Ltd. All rights reserved.
1.Package Contents
Tracker Wire Harness Immobilizer Relay Fastening Tape
2. Features and Specifications
Item
Description
Dimension
66*63*25mm
Power range
9-36V DC/1.5A
Working Humidity
5%~95%
Operating Temperature
‐30℃~75℃
Internal backup battery
350mAh/4.2V
Data Transmit
SMS/GPRS Communication
GSM chip
FIBOCOM G510
GSM Quad bands
850/900/1800/1900MHz
GPS chip
Skylab GPS Receiver (Sirf III chip)
GPS Sensitivity
-160dB
GPS Position Accuracy
10 Meters
GPRS Null zone data storage
2000 Waypoints
Position report
Time based and Distance based
Alarm alerts
GEO Fence, Speed over, Power tamper and Panic
OTA
Support
I/O Ports
Ignition,
Immobilizer,
Door status detect,
Panic(SOS) detect
3. Knowledge before Usage
3.1 Factory Default Setting
-IP/Port: Empty
-APN, User and pass: Empty
-Speed Limit: Off=000Km/H
-Position data Update Time Interval: 30Seconds when moving, 30seconds when static
-Authorized Phone numbers A/B/C: None

Copyright © 2015 Shenzhen ANB Technology Co., Ltd. All rights reserved.
-Device SMS password: 1234
3.2 Power Supply and consumption
This device is expected to connect with a DC power source with range of 11.2-36V DC.
Working current maximum 2A input.
In standby mode, device working current < 40mA @12V DC
In sleep mode, working current is less than 6mA @12V DC.
3.3 How to Insert Simcard
Before inserting the simcard, please make sure the simcard SMS and GPRS activated.
Before inserting the simcard, please make sure the device is power off.
1.Open device box 2. Open card set 3.Install simcard 4.Switch battery to on
4. Installation
4.1 Wiring Diagram
Wire
Color
Remark
Black
Power Ground

Copyright © 2015 Shenzhen ANB Technology Co., Ltd. All rights reserved.
Red
Power +(12-36V DC)
Yellow
Cut-off, Digital output
White
Ignition Detection(ACC)
Brown
Door status high input
Blue
Panic(SOS) low input
5. Device configuration
TS10 allow user to use SMS Commands to configure necessary parameters.
Details please check as follows instruction:
5.1 Configure GPRS Parameter
SMS Command:
*1234*GPRS:211.154.142.150,9119,T,apnName,apnUser,apnPass#
Tis data transmit mode. T=1 is using UDP mode. T=0, is using TCP mode. Default as 0.
-Device ID
TS10 doesn’t need configure device ID. The device is default using device SN code as ID.
On the unit case side is with a barcode sticker. please use this code as device ID when
you register device tracking platform.
5.2 ConfigureAuthorized Phone Numbers for alarm alerts
SMS command:
*1234*A8613554806820*B13554806821*C13554806822#
5.3 Change SMS Password
TS10 only will accept SMS command with correct password and correct command format.
The factory default password is 1234.
SMS command:
*1234*E4321#
<<1234 is the original password. 4321 is the new password>>

Copyright © 2015 Shenzhen ANB Technology Co., Ltd. All rights reserved.
5.4 Time zone Localization Setting
TS10 adopts UTC time as standard system time. In order to get correct Local time in SMS data,
please use command to configure your time zone to device.
SMS Command:
*1234*GMT+/-AABB#
<AA= Hour, BB=Minutes>
Example: China is in Eastern 8 Zone.
So we need to send command as *1234*GMT+0800# to device.
6. Functionality and Operation
6.1 Voice Listen-in
By connect the microphone to TS10, it can achieve Voice listen-in feature.
The user can use this function by two methods:
-Authorized NumberA/B/C call device in, device auto pickup to activate voice Listen-in
- By send following SMS command to get device call back to you:
*1234*VMxxxxxxxx#
<xxxxxxx is call back phone No. for system>
6.2 Remote Cut-engine (Immobilizer)
User can use any phone to send SMS command to cut-off engine immediately by correct
Password and command format.
*1234*Stop#
< Wireless cut-off engine SMS command>
*1234*K#
<Wireless disable engine lock status SMS command>
6.3 Reset Mileage report value
In every GPRS Position data packet to GRPS server,TS10 data package includes the current travel
mileage. And the user can by SMS command to reset or adjust the mileage report value.
*1234*M:1,115,15000#
<Reset Mileage report value SMS command>
Explain:
1: Unit. =1 Km, =0 Meter. Default=0
115: Different rate, default=100.
15000: Mileage. Default as 0 Meter
6.4 Tracking parameter setting
By following SMS command to setup device data update interval in Moving/Static:
*1234*E:1,30,180#
<Tracking parameter configuration>
1: Monitoring mode. Define position data update by moving/Static.

Copyright © 2015 Shenzhen ANB Technology Co., Ltd. All rights reserved.
30: Position update interval, 30Seconds when in moving.
180: Position update interval, 180seconds when in static
Default setting: 1,30,30.
<Update interval cannot less than 10seconds>
6.5 Query vehicle status
TS10 can track location by SMS commands.
SMS command: *1234*X#
Device reply:
<Unarmed; Engine:On/Off; Door:Off/On;LAC:xxxxxx;CID:xxxxx;Signal Strength:xx
$GPRMC,xxxxxx.xxx,A,xxxx.xxxx,N,xxxxx.xxxx,E,x.x,xxx.x, xxxxxx,,,A*xx >
6.6 Query GPRMC data
SMS command: *1234*GPS#
Device reply:
<$GPRMC,063231.00,A,2232.64712,N,11355.45466,E,0.581,195.93,050811,,,A*6C>
6.7 Query Google map Position Link
SMS command: *1234*P#
Device reply:
<2011-12-08 12:32:13,V,60Km/H,Heading:60,LAC:2638,CID:0ECF;
http://maps.google.com/maps?hl=en&q=22.537222,114.020948>
6.8 Recover factory setting
By SMS command or GPRS command, TS10 can be initialized to be factory default setting status.
SMS Command: *1234*V#
6.9 Remote reboot
By SMS command: *1234*Z#
<user can reboot TS10 wirelessly>
6.10 Alarm Alerts
TS10 only provide two type alarm alerts. See:
-
Power tamper alarm alert
< Disconnect TS10 external power to trigger>
-
Panic(SOS) alarm alert
<By press panic button to trigger>
6.11 OTAOperation
TS10 allow user to do firmware upgrading via GPRS connection. Details operation
command and procedure, please consult with your seller.
