Anderson WSR 1.5 User manual

WSR 1.5 | Wireless mini router
User manual
English | Svenska | Norsk

Copyright
This manual is the copyright of CI no 556520-4137. No part of this manual may
be revised, copied or transmitted in any way without written permission from CI
no 556520-4137.
Statement
This manual does not provide any warranty or related declarations. All information
in this manual including the product specification, pictures and literatures is just
for reference, CI no 556520-4137 reserves the rights to update contents of this
manual without further notice.
Copyright
Org.nr 556520-4137 äger upphovsrätten till den här handboken. Inga delar av
handboken får ändras, kopieras eller överföras utan skriftligt tillstånd från org.
nr 556520-4137.
Meddelande
Den här handboken innehåller inga garantier eller andra typer av utfästelser. All
information i handboken, inklusive tekniska data, bilder och texter, är endast ex-
empel och används i referenssyfte. Org.nr 556520-4137 förbehåller sig rätten att
upp-datera innehållet i handboken utan föregående meddelande.
Opphavsrett
Org.nr 556520-4137 har opphavsretten til denne håndboken. Ingen deler av denne
håndboken skal revideres, kopieres eller overføres på noen måte uten skriftlig sam-
tykke fra org.nr 556520-4137.
Erklæring
Denne håndboken gir ingen garanti eller tilhørende forsikringer. All informasjon
i denne håndboken, inklusiv produktspesifikasjon, bilder og tekst, er bare ment
som referanse. Org.nr 556520-4137 forbeholder seg retten til å oppdatere innhol-
det i denne håndboken uten forvarsel.

English
Introduction 4
Getting Started 5
How Connect to Wireless Mini Router 6
Configuring via Web Browser 7-11
Change Management Password 12
Firmware Upgrade 13
Factory Default and Settings Backup , Restore 14
Connect Your Computer/Laptop 15-16
Configure IP Address 17
Svenska
Inledning 18
Kom igång 19
Anslut till mini-routern 20
Konfigurera via webbläsare 21-25
Byt administratörslösenord 26
Uppgradera firmware 27
Fabriksinställning och inställningar för
säkerhetskopiering och återställning 28
Anslut till datorn 29-30
Konfigurera IP-adress 31
Norsk
Innledning 32
Komme i gang 33
Slik konfigurerer du Wireless-N miniruteren 34
Konfigurasjon via webleser 35-39
Endre behandlingspassord 40
Fastvareoppgradering 41
Sikkerhetskopiering av fabrikkinnstillinger og
nye innstillinger, gjenoppretting 42
Slik kobler du datamaskinen til miniruteren 43-4
Konfigurerer med nettverkets IP-adresse 45
Content / Innehållsförteckning / Register

English
4
Introduction
The WSR 1.5 is a combined wired/wireless network connection
device designed specifically for small business, office, and home
office networking requirements. It complies with the IEEE 802.11n
standard. It adopts MIMO as well as SST technologies. It also
works well with other 11b/g and 11n protocol wireless products.
Create instant WiFi hotspots at any location where you have Internet
connection.
Package Contents
1 x Wireless-N Mini Router
1 x Quick Installation Guide
1 x RJ-45 Networking Cable
Open Source Code
This product includes software codes developed by third parties.
These software codes are subject to either the GNU General Public
License (GPL), Version 2, June 1991 or the GNU Lesser General Public
License (LGPL), Version 2.1, February 1999. You can copy, distribute,
and/or modify in accordance with the terms and conditions of GPL
or LGPL.
The source code should be complete, if you think we need to provide
any additional source code files under GNU General Public License
(GPL), please contact us. We are committed to meeting the require-
ments of the GNU General Public License (GPL) .
Please refer to the GNU GPL Web site for further information.
http://www.gnu.org/licenses/licenses.en.html.

English
5
Getting Started
Setting up a Wireless Infrastructure Network
For a typical wireless setup at home (as shown above),
Please do the following:
1. You will need broadband Internet access (a ADSL, Cable
Modem line into your home or office).
2. Consult with your ADSL or Cable Modem provider for proper
installation of the modem.
3. Connect the ADSL or Cable modem to the Wireless Mini
Router.Plug in the Power Adapter to the Wireless Mini Router.
4. Adding computers to the Wireless Mini Router.
IMPORTANT NOTE
You can reset your router to default setting by press and hold the
‘RESET’ button inside the tiny hole for 8 ~10 seconds.
You can use this solution if you forget your password.

English
6
How Connect to Wireless Mini Router
You can configure the wireless mini router by connecting it with your
computer/laptop with enclosed RJ45 cable or wirelessly.
1. Plug the Wireless Mini Router to a wall socket.
Open Connect to a Network by right-
clicking the network icon ( or ) in the
notification area. You will find the signal from
the Wireless-N. Click on ‘Connect’ then wait
for a few seconds.
2. Open web browser and type
http://192.168.10.253 in the browser’s address box. This
number is the default IP address for this device.
Note: Please check whether the Wireless Mini Router accord
with factory default settings if you cannot load the page. If you
are still not sure what causes the problem, you can reset the
Wireless Mini Router by simply pressing the reset button for 10
seconds, then try again.
3. The login screen below will appear. Enter the “User Name” and
“Password” then click “OK” to login. The default User name is
“admin” and Password is “admin”.
4. After logging in, you will see the web page below:

English
7
Configuring via Web Browser
After you successfully login, you can click the Wizard’s menu to
quickly configure your Router.
Choose the Operation Mode you need, and then click it.
Mode Description
Router Standard Wireless Router Mode: This router connect
to Internet by WAN port, and then other terminal
devices can connect to this router by wireless
connection or connect to this router’s LAN port by
wired
AP Traditional wired router realize wireless function: This
router can connect to uplink router’s LAN port by
wired connection, user terminal can connect to this
router by wireless connection
Repeater Extend wireless signal comprehensively:This router can
connect to uplink wireless router by wireless connection,
user terminal can connect to this router by wired or
wireless connection
WISP Wireless used as WAN port: This router can connect
to uplink wireless router by wireless connection, at
the same time,it can extend wireless signal for other
devices’ connection

English
8
Router Mode:
Choose your WAN Connection Type.
If Dynamic IP is selected, the Router gets the IP address
automatically from the DHCP server or the ISP. No configuration
should be set and you can go on with the wireless configuration.
If ADSL Dial-up (PPPoE) is selected, please enter the User Name
and Password from your ISP, These fields are case-sensitive.
Set the wireless parameter. It’s recommended that you rename an
SSID, choose a Security Mode and enter a Key.
SSID the “SSID” of your wireless network.
Channel Auto (recommended)
Security type Setup the wireless security and encryption
to prevent from unauthorized access and
monitoring.
Supports 64/128-bit WEP, WPA, WPA2, WPA/
WPA2 encryption methods.
Security key The “Password” of your wireless network.
Click ‘Save&Reboot’ button, It will restart. Wait for a few seconds
your Wi-Fi Router is ready for use.

English
9
AP Mode:
Set the wireless parameter. It’s recommended that you rename an
SSID, choose a Security Mode and enter a Key.
SSID the “SSID” of your wireless network.
Channel Auto (recommended)
Security type Setup the wireless security and encryption
to prevent from unauthorized access and
monitoring.
Supports 64/128-bit WEP, WPA, WPA2, WPA/
WPA2 encryption methods.
Security key The “Password” of your wireless network.
Click ‘Save&Reboot’ button, It will restart. Wait for a few seconds
your Wi-Fi Router is ready for use.

English
10
Repeater Mode:
Select the SSID of the target network and click Select.
The target network’s SSID will be automatically filled into the wireless
setting figure. Then enter the Password.
Click ‘Save&Reboot’ button. It will restart. Wait for a few seconds
your Wi-Fi Router is ready for use.

English
11
WISP Mode:
Select the SSID of the target network and click Select.
The target network’s SSID will be automatically filled into the wireless
setting figure. Then enter the Password.
Click ‘Save&Reboot’ button. It will restart.
Wait for a few seconds your Wi-Fi Router is ready for use.

English
12
Change Management Password
Default password of wireless mini router is “admin”, and it’s displayed
on the login prompt when accessed from web browser. There’s
a security risk if you don’t change the default password, since
everyone can see it. This is very important when you have wireless
function enabled.
To change password, please follow the following instructions: Please
click ‘Administrator ’ menu on the web management interface, the
following message will be displayed on your web browser:
If you want to change password, fill in the Username and Password,
Click ‘Apply’ button, The WiFi Repeater will log off.

English
13
Firmware Upgrade
The system software used by this router is called as ‘firmware’, just
like any applications on your computer, when you replace the old
application with a new one, your computer will be equipped with new
function. You can also use this firmware upgrade function to add new
functions to your router, even fix the bugs of this router.
The upper right corners please click ‘Firmware’, and then the
following message will be displayed on your web browser:
Click ‘Browse’ button first; you’ll be prompted to provide the filename
of firmware upgrade file. Please download the latest firmware file from
our website, and use it to upgrade your router.
After a firmware upgrade file is selected, click ‘Upgrade‘ button, and
the router will start firmware upgrade procedure automatically. The
procedure may take several minutes. Please be patient.
NOTE: Never interrupt the upgrade procedure by closing the web
browser or physically disconnect your computer from router. If the
firmware you uploaded is corrupt, the firmware upgrade will fail, and
you may have to return this router to the dealer of purchase to ask for
help. (Warranty voids if you interrupted the upgrade procedure).

English
14
Factory Default and Settings Backup , Restore
You can backup all settings of this router to a file, so you can make
several copied of router configuration for security reason.
To backup or restore router settings, please follow the following
instructions:
Please click ‘Save/Reload setting’ located at the web management
interface, then the following message will be displayed on your web
browser:
Save Set-
tings
to File
Press ‘Save…’ button, you can save it as another
filename for different versions, and keep it in a safe
place.
Load Set-
tings
Press ‘Browse…’ to pick a previously-saved
configuration file from your computer, and then click
‘Upload…’ to transfer the configuration file to router.
After the configuration is uploaded, the router’s
configuration will be replaced by the file you just
uploaded.
Reset
Settings
Click this ‘Reset‘ button to remove all settings you
made, and restore the configuration of this router
back to factory default settings.

English
15
Connect Your Computer/Laptop
Adding wireless computers to the
wireless mini router
1. Log on to the computer.
2. Plug the Wireless Mini Router to a
wall socket.
Open Connect to a Network by
right-clicking the network icon (
or ) in the notification area.
3. Choose the wireless network from
the list that appears, and then click
Connect.
4. Type the network security key or
passphrase if you are asked to do
so, and then click OK. You’ll see a
confirmation message when you
are connected to the network.
5. To confirm that you added the computer, do the following:
Open Network by clicking the Start button , and then
clicking Control Panel. In the search box, type network, and
then, under Network and Sharing Center, click View network
computers and devices. You should see icons for the
computer you added andfor the other computers and devices
that are part of the network.
Note : If you don’t see icons in the Network folder, then
network discovery and file sharing might be turned off.

English
16
Adding a Wireless computers to the wireless mini router with
WPS Button
1. Log on to the computer.
2. Press the WPS button of thewireless mini router directly for 2-3
seconds.
3. Press the WPS button of the Wireless Adapter directly for 2-3
seconds. Click Finish to complete the WPS configuration.
(Please check your Wireless adapter Manual with WPS
configuration)
4. You should see icons for the computer you added and for
the other computers and devices that are part of the network.
Adding a wired (Ethernet) computer to the wireless mini router
1. Plug the wireless mini router to a wall socket. Connect your
computer / laptop with the wireless mini routerwith enclosed
RJ45 Cable.
2. To confirm that you added the computer, do the following:
Open Network by clicking the Start button , and then
clicking Control Panel. In the search box, type network, and
then, under Network and Sharing Center, click View network
computers and devices. You should see icons for the
computer you added and for the other computers and devices
that are part of the network.
For more information:
http://windows.microsoft.com/en-US/windows7/Add-a-device-or-computer-
to-a-network
http://windows.microsoft.com/en-US/windows7/Setting-up-a-Wirelessetwork
http://windows.microsoft.com/en-US/windows-vista/Setting-up-a-
Wirelessetwork

English
17
Configure IP Address
How to configure your computer/laptop with the Network IP Address
1. Log on to the computer.
2. Click the “Start” button (it should be located at the lower-
left corner of your screen), then click “Control Panel”. Click
“View Network Status and Tasks”, and then click “Manage
Network Connections”. Right-click “Local Area Network”,
then select “Properties”. When the “Local Area Connection
Properties” window appears, select “Internet Protocol
Version 4 (TCP/IPv4)” and then click “Properties”.
3. Setting IP address manually: Type IP address is 192.168.10.x
(x is from 2 to 252), and Subnet mask is 255.255.255.0. Type
the Router’s LAN IP address (the default IP is 192.168.10.253)
into the Default gateway field.

Svenska
18
Inledning
WSR 1.50 är en kombinerad fast / trådlös nätverksanslutningsenhet
som har utformats speciellt för nätverk på små företag, kontor och
hemmakontor. Den uppfyller IEEE 802.11n (Draft 2.0)-standard. Den
använder MIMO- samt SST-teknik. Det fungerar också bra med
andra trådlösa produkter som använder 11b/g och 111n-protokoll.
Du kan omedelebart upprätta WiFi-hotspots på en plats där du har
Internet-anslutning.
Medföljande tillbehör:
1 x WSR 1.5 Trådlös minirouter
1 x Snabbstartsguide
1 x RJ-45 Nätverkskabel
Öppen källkod
Den här produkten innehåller mjukvarukoder som har utvecklats av
tredjepart. Dessa mjukvarukoder omfattas antingen GNU General
Public License (GPL), Version 2 juni 1991, eller GNU Lesser General
Public License (LGPL), Version 2.1, februari 1999. Du kan kopiera, dis-
tribuera och / eller modifiera i enlighet med villkoren i GPL eller LGPL.
Källkoden ska vara komplett. Vi har åtagit oss att uppfylla kraven i GNU
General Public License (GPL).
Se GNU GPL:s hemsida för ytterligare information:
http://www.gnu.org/licenses/licenses.en.html.

Svenska
19
Kom igång
Sätt upp ett trådlöst nätverk
För ett vanligt trådlöst nätverk hemma (såsom på bilden ovan)
Gör följande:
1. Du kommer att behöva internet-åtkomst (exempelvis ADSL eller
bredband) till ditt hem eller kontor.
2. Du kan rådgöra med din internetleverantör för hur du ska
installera modem.
3. Anslut eventuellt modem till den trådlösa mini-routern. Koppla
in strömadaptern till mini-routern.
4. Koppla datorer till mini-routern.
VIKTIGT
Du kan återställa routern till fabriksinställningar genom att trycka på
“RESET”-knappen på baksidan av routern. Du kan använda den här
lösningen om du har glömt lösenordet till routern.

Svenska
20
Anslut till mini-routern
Du kan konfigurera routern genom att ansluta till den med din dator /
laptop med medföljande RJ45-kabel eller trådlöst.
1. Koppla den trådlösa mini-routern till ett
vägguttag. Öppna Anslut till ett nätverk genom
att högerklicka på nätverksikonenn
( eller ) i aktivitetsfältet. Du kommer
att hitta en signal från Wireless-N. Klicka på
“Anslut”. Vänta sedan i några sekunder.
2. Öppna webbläsaren och skriv
http://192.168.10.253 i webbläsarens adressfält. Den här siffran
är den förinställda IP-adressen för den här enheten.
OBS: Kontrollera om routern är konfigurerad enligt
fabriksinställningar ifall den inte kan ladda sidan. Om du
fortfarande inte säker på vad som orsakar problemet, kan du
återställa den trådlösa mini-routern genom att trycka på reset-
knappen i 10 sekunder, sedan försöka igen.
3. Inloggningsfönstret nedan visas. Ange “Användarnamn” och
“Lösenord” och klicka på “OK” för att logga in. Förvalt standard-
användarnamn är “admin” och lösenordet är “admin”,
4. När du har loggat in, kommer du att se webbsidan nedan:
