ANDI ACIF682 User manual

ANDI ELETTRODOMESTICI S.r.l.
Instruction Manual
Induction Hotplate
Model: ACIF682
Thank you for purchasing the induction hotplate, please read this instructions manual
carefully before using and keep it safe for your future reference.

Working Principle
Product Introduction
The induction hotplate is mainly composed of an induced heating coil,
hotplate made of ferromagnetic materials and control system. In principle,
current generates a powerful magnetic field via the coil. Large numbers
of vortexes are produced in the way that the magnetic lines in the field
contact the bottom containing iron or stainless steel substances. The
tremendous energy generated by the vortexes can heat the food directly
by converting efficiency heat energy penetrating through the base.
ANDI MC-IF682 induction hotplate can meet various of cuisine demands
by electromagnetic heating, with micro-computerized control and multi-
functions, really the optimal choice for modern families.
ANDI induction hotplate centres on customers and adopts personalized
design. Made of imported materials and through advanced process, the
unit has safe and reliable performance, making your life comfortable
and enabling to fully enjoy the pleasuresof life.
Dear customer:
Thank you for purchasing the ANDI induction hotplate our product can
serve you many years to your satisfaction.
Please read this instructions manual carefully before using and
installation, keep after reading for future reference.
magnetic circuit
ceramic glass plate
iron pot
induction coil
Induced currents

2
We have designed this hob for private use in home.
With a view to constantly improving our products, we reserve the right to make
any changes to their technical, program or aesthetic features connected with
their technical evolution.
Over- Temperature Protection
A temperature sensor equipped can monitor the temperature inside the hotplate.
Whenanexcessivetemperatureismonitored,theinductionhotplatewillstopoperation
automatically.
Detection of Small Articles
When the pot is less than 80 mm in diameter or small articles (knife, fork, forceps,
key, etc.) exist or non-magnetic pots (such as aluminum pot) the buzzer
can gives out an alarm lasting about 1 minute. In this case the user has not put a
proper pot in time, the induction hotplate can enter the standby mode automatically.
Heat Indication
When the hotplate is used for a long time, waste heat remains in the heating zone
in a few minutes. The code “H” appears, warning to be away from the heating zone.
Auto shutdown protection
Autoshut downisa safetyprotectionfunction foryourinduction hotplate.Itshut down
automatically if ever you forget to turn off your cooking. The default working times
for various power levels are shown in the below table: .
Power level The heating zone shut down
automatically after
1~3
4~6
7~9
8 hours
4 hours
2 hours
Safety
When the pot is removed, the induction hotplate can stop heating immediately and
shut down after the buzzer sounds for 1 minute.
*WARNING
The patient with a heart pacemaker shall use this product under
the guidance of the doctor.

5 cm mini
5cm mini 5cm mini
56 cm
49
c
m
3
Installation
Selection of installation equipment
Drill holes on the table surface according to the sizes shown in the
drawing. For the purpose of installation and use, a minimum of 50 mm
space shall be preserved around the hole.
Be sure the thickness of the table surface is at least 30mm. Please
select heat-resistant table material to avoid larger deformation caused
by the heat radiation from the hotplate.
As shown in Figure (1)
Figure (1)
Figure (2)
Air intake
Air exit
Under any circumstances, make sure the induction hotplate is well
ventilated and the air inlet and outlet are not blocked.
Ensure the induction hotplate is in good work state. As shown in
Figure (2)
Note: The safety distance between the hotplate and the cupboard above the
hotplate should be at least 650mm.
mini 5 cm mini 5 mm
mini 2 cm
mini 650mm

Cautions
4.
5.
1. The induction hotplate must be installed by qualified personnel or technicians.
Please never conduct the operation installation or servicing the unit
by yourself.
The induction hotplate shall not be mounted to cooling equipment, dishwashers
and rotary dryers.
The induction hotplate shall be installed such that better heat radiation
can be ensured to enhance its reliability.
The wall and induced heating zone above the table surface shall withstand
heat.
To avoid any damage, the sandwich layer and adhesive must be resistant
to heat.
2.
3.
Figure (3)
Voltage&frequency
400V 2-N
50\60HZ
220-240V
50\60HZ
220-240V 2+2-N
50\60HZ
1 2
L1 L2
Black Brown
21
L
Black&Brown
1 2
L1 L2 Gray Blue N1 N2
3 4
43
34
Gray&BlueYellow/Green
5
5
5
Wire connection
N
N
Yellow/Green
Yellow/Green
Gray&Blue
Black Brown
Fix the hob on the table by screw four brackets on the bottom of hob
(see picture) after installation. Adjust the bracket position to suit for
different table top thickness.
screw
bracket
base
screw hole
4
Electrical connection
The socket shall be connected according to the relevant standard
or connected to a single-pole cut-out. The method of connection
is shown in Figure (3):

Control panel Air vent
Ceramic plate
Air entry
Heating zone selection key ON/OFF
Timer key
System key
Boost
Induction hotplate appearance
Power regulating key
1
23
4
Schematic diagram of the control panel
If the cable is damaged or to be replaced, the operation must be
carried out the by after-sale agent with dedicated tools to avoid
any accidents.
If the appliance is being connected directly to the mains an omnipolar
circuit-breaker must be installed with a minimum opening of 3mm
between contacts.
The installer must ensure that the correct electrical connection has
been made and that it is compliant with safety regulations.
The cable must not be bent or compressed.
The cable must be checked regularly and replaced by authorised
technicians only.
5

Preparation before using:
After power on, the buzzer beep once, all the indicators
light up for 1 second then go out, indicating the induction
hotplate enters the state of standby.
Put the pot in the center of the heating zone.
Operation Instructions
After the “ON/OFF” key is pressed, all the indicators show
“-”. According to the heating zone where the pot is placed,
select a relevant zone selection, with a corresponding
power level indicator flashing. At the moment, press the
"+" or "-" button, the indicator displays 5, then adjust the
power levels using the“+” or“-” button. Press the "+" and
"-" buttton simultaneously, the hotplate immediately returns
the power setting to 0 and all the cooking zone switches
off.
See the attached table on PAGE 8 for the power specific
to each heating zone.
Note: After the “ON/OFF” key is pressed, the induction
hotplate will restore to its standby state if no any operation
is carried out within 1 minute.
Boost function
To get a quicker heating speed, directly press “BOOST”
after selecting the heating zone, with the power level indicator
showing “P. ” This function can reach the heating power of
up to 2800W.
Note:
1. The boost function only operates for 5 minutes, after
which the cooking zone returns to its orginal setting.
2. The boost function only works on the third cooking zone.
3. As the boost function is activated ,the 4th cooking zone
is limited under level 2 automatically.
Instructions for Use
6

Cancellation of “BOOST” function
When in " Boost " mode,select the third cooking zone and press
the
" Boost " key or the "-" key to cancel the Boost mode, then
the cooking zone will revert to its original setting.
Timing function
Press the timing key, then the indicator flashes, and at this point,
you can set time. Using the “+” and “-“ keys, you can realize the
setting of timing from 1 to 99 minutes. When the “+” key is
pressed, the set time will increase by 1 minute; when the “-“ key
is pressed, the set time will decrease by 1 minute; when the set
time exceeds 99 minutes, it will restore to 0 minute automatically.
If press the "+" and "-" simultaneously, the indicator displays 0.
Timing confirmation:
1.Select the power level of the cooking zone, then press the
"Timer" button, you can set the timer.
2. Once the timing indicator flashes for 5 seconds, the set time
will be confirmed to be valid automatically.
3. After selecting a set time, press the “Timing” key, confirming
its effectiveness.
Timing cancellation:
After setting time again, hold the “Timer Key” for 5 seconds, then
the timing can be cancelled automatically, with the timing indicator
showing “0”.
Unlocking: under the locking state of the induction hotplate,
hold the “Interlock” key for 2 seconds, removing the locking state
automatically.
System function: to ensure the safety of children, the induction
hotplate is provided with the function of interlock.
Locking: Press the “Interlock” key, then the induction hotplate
enters the locking state, with the timing indicator showing “L0”
and the rest keys disabled except the "ON/OFF" key.
7

Iron oil frying pan Stainless steel pot Iron pan Iron kettle
Enamel stainless
steel kettle Enamel cooking utensil Iron plate
Selection of heating appliances
The above power may vary if the material or the size of pot is different.
The max. power of each heating zone are as follows:
1
2
3
4
2000
1400
2000
1400
------
------
------
2800
Safety Reminding and Maintenance:
Heating zone Max. power (W)
Boost
Normal
You may have multiple cookware suitable for induction heating.
This induction hotplate is able to identify the correct cookware, and you
can test them according to one of the following methods:
Place the cookware in the heating zone. If the corresponding heating zone
displays a power level, it shows the suitability of the cookware; if “U” flashes, it
shows the cookware does not fit in the induction cooking. Use a magnet to
contact the cookware. If there is attraction between them, it shows the cookware
also fits in the induction cooking.
Requirement for pot material: the bottom contains materials of magnetic
conductivity.
Requirement for shape: flat bottom, more than 12 cm in diameter.
*
*
Please use a dedicated
power protection air switch; Never directly wash the induction hotplate with water
so as to avoid dangers.
Indoor use only.
8

After being used for a long
time, the corresponding
heating zone of the induction
hotplate is till hot. Never touch
the ceramic surface to avoid
burning.
We suggest that you should
periodically check that there
are no object (glass, paper,
etc) that could obstruct the
inlet under your induction
hotplate.
Keep electrical appliance out
of reach from children or
infirmed person. Do not let
them use the appliances
without supervision.
If the supply cord is damaged ,
it must be replaced by the
manufacturer, its service agent
or similarly qualified persons in
order to avoid a hazard.
Clean the induction hotplate
on a regular basis to prevent
foreign matters from entering
the fan thus influencing the
normal operation.
Do not put any detergents or
flammable materials in the
equipment installed under the
induction hotplate.
For sealed food such as
canned goods, please do not
heat them before opening their
covers so as to avoid any
dangers of explosion due to
heating expansion.
Never have the induction
hotplate to work without food
inside, otherwise its
operational performance may
be affected and danger may
happen.
Do not place rough or uneven
appliances, which may
damage the ceramic surface.
If the surface is cracked, swith
off the appliance to avoid the
possibility of electric shock.
Metallic objects such as
knives, forks,spoons and lids
should not be placed on the
hotplate since they can get
hot.
Never use the induction
hotplate in high temperature
environments such as near a
gas stove or kerosene stove.
9

Light Immerse in hot water then
wipe it dry Cleaning sponge
Accumulation
of dirt Immerse in hot water then
wipe it dry with abrasive
sponge
Special cleaning
sponge for ceramic
glass
Rings and lime
crumbles
melted
aluminum
or plastics
Apply white vinegar to the
polluted zone, then wipe it
dry with soft cloth or a
special article available in
local markets
Use a scraper suitable for
ceramic glass (to protect
glass, a silicon product is
preferred) to remove
residuals
Special non-abrasive
cleaner for ceramic
glass
Special non-abrasive
cleaner for ceramic
glass
DISPOSAL: Do not dispose this
product as unsorted municipal
waste. Collection of such waste
separately for special treatment
is necessary.
Cleanness and Maintenance
Type of contam-
ination Method of cleaning Articles used for
cleaning
You can easily clean the surface of the induction hotplate if following
the methods given in the table.
Hint: please disconnect power before the cleaning.Hint: please disconnect power before the cleaning.
10

If an abnormality comes up, the induction hotplate will enter the
protective state automatically and display corresponding protective
codes:
E3/E4 Abnormal
temperature Please inspect the pot.
The above are the judgment and inspection of common failures.
Please do not disassemble the unit by yourself to avoid any dangers and damages
to the induction hotplate.
F0/F1/F2
E1/E2
E5/E6
Fan failure Please contact the
supplier
Temperature
sensor failure Please contact the supplier.
Abnormal supply voltage Please inspect whether
power supply is normal.
Power on after the
power supply is normal.
Bad hotplate
heat radiation Please restart after the hotplate cools down.
Failure Display and Inspection
F3-F8
Troubles Possible reasons Solutions
11

Customer Care Service
Before calling the After Sales Service
In case the appliance should not work correctly we suggest to:
-verify if the plug is correctly inserted in the socket
-read the Failure and Display table above
In case it is not possible to establish the reason for the bad functioning
of the appliance:
switch it off, do not try to use unit and call the After Sales Service.
Special DecIaration
All the contents in this material have been subjected to careful check.
For any mistake and omission in printing or misunderstanding of the
contents,the company keeps the right of interpretation.
Addition:any technical improvement will be placed in the revised
manual without notice;for product appearance and color is according
to the actual one
