Wolf CI243C/B User manual

CLEANING, MAINTENANCE,
AND MORE
Induction/Electric Cooktop
Use and Care Guide

2 | Wolf Customer Care 800.222.7820
Induction/Electric Cooktop
Contents
4Safety Precautions
6Induction Cooktop Features
7Electric Cooktop Features
8Cooktop Operation
17 Care Recommendations
18 Troubleshooting
19 Wolf Warranty

wolfappliance.com | 3
Customer Care
The model and serial number are printed on the enclosed
product registration card. Both numbers are also listed
on the product rating plate. Refer to pages 6–7 for rating
plate location. For warranty purposes, you will also need
the date of installation and name of your authorized Wolf
dealer. Record this information below for future reference.
SERVICE INFORMATION
Model Number
Serial Number
Date of Installation
Certified Service Name
Certified Service Number
Authorized Dealer
Dealer Number
If your product ever needs attention, be sure to use a
Wolf Factory Certified Service provider recommended
by our Customer Care Center, or select one from our list
of providers available at wolfappliance.com/locator. All
Factory Certified Service providers are carefully selected
and thoroughly trained by us.
Important Note
To ensure this product is installed and operated as safely
and eciently as possible, take note of the following types
of highlighted information throughout this guide:
IMPORTANT NOTE highlights information that is especially
important.
CAUTION indicates a situation where minor injury or prod-
uct damage may occur if instructions are not followed.
WARNING states a hazard that may cause serious injury or
death if precautions are not followed.
IMPORTANT NOTE: Throughout this guide, dimensions in
parentheses are millimeters unless otherwise specified.
Induction/Electric Cooktop

4 | Wolf Customer Care 800.222.7820
Safety Precautions
GENERAL SAFETY PRECAUTIONS
• Wear proper apparel. Never let loose clothing
or other flammable materials come in contact
with the elements while in operation. Fabric
may ignite and result in personal injury.
• Use only dry pot holders when removing pans
from the cooktop. Wet or damp pot holders on
hot surfaces may result in burns from steam.
Do not let pot holders touch hot heating ele-
ments.
• Select cookware of the proper size, mate-
rial, and construction for the particular type of
cooking being done. This unit is equipped with
heating elements of dierent size. Refer to ele-
ment rating on pages 6–7.
• Always turn pan handles inward so they do not
extend over adjacent work areas, heating ele-
ments, or edges of the cooktop to reduce the
risk of burns, ignition of flammable materials,
and spillage due to unintentional contact with
pan. Do not turn handles toward the room,
where they may be bumped or easily hit.
• Never heat an empty pan. It may damage the
cooktop or cookware and overheat the unit.
• Do not heat cookware with water droplets on
the outside of the pan. The droplets may begin
to boil and splatter. Cookware should always be
dry.
• Do not use aluminum foil on the surface of the
cooktop.
• Never use the cooktop to warm or heat a room.
IMPORTANT INSTRUCTIONS
IMPORTANT NOTE: Read all safety instructions
before using this appliance.
• Read this use and care guide carefully before
using your new cooktop to reduce the risk of
fire, electric shock, or injury to persons.
• Ensure proper installation and servicing. This
appliance must be properly installed and
grounded by a qualified technician. Have the
installer show you the location of the circuit
breaker or fuse so that you know where to turn
o power.
• Warranty service must be performed by Wolf
Factory Certified Service.
• Before performing any service, disconnect the
power supply to the cooktop by switching o
the circuit breaker or removing the fuse.
IMPORTANT NOTE: Performance may be com-
promised if the electrical supply is less than 240
volts.

wolfappliance.com | 5
IMPORTANT INSTRUCTIONS
GENERAL SAFETY PRECAUTIONS
• When using the cooktop, do not touch the
glass surface directly above or adjacent to the
heating elements or induction zones. The glass
surface may become hot enough to cause
burns.
• Do not leave children alone or unattended in
the area where the cooktop is in use. Never
allow children to sit or stand on the appliance.
Do not let children play with the cooktop.
• Do not store items of interest to children above
or at the back of the cooktop, as they could
climb on the appliance to reach items and be
injured.
• Do not repair or replace any part of the appli-
ance unless it is specifically recommended in
literature you received. All service should be
referred to Wolf Factory Certified Service.
• Do not use water on grease fires. Smother
the flame or use a dry chemical or foam-type
extinguisher.
• Never leave the cooktop unattended when
using high heat settings. Boilovers and greasy
spillovers may smoke or ignite.
• Do not operate the cooktop if the glass-
ceramic surface is broken or severely pitted.
Call Wolf Factory Certified Service to repair the
cooktop.
• Do not store flammable materials near hot
components or let grease or other flammable
substances accumulate on the cooktop.
• Do not clean the cooktop while it is still hot.
If using a damp sponge or cloth, wait until the
cooktop has cooled suciently to prevent
steam burns. Also, some cleaners give o nox-
ious fumes when applied to hot surfaces. Refer
to Care Recommendations on page 17.
• Do not use a griddle, open roaster, or fish
poacher across two heating elements unless
the bridge element is turned on. This type of
use without the bridge element turned on
could damage or crack the glass. Refer to
Bridge Element on page 13.
• Do not block the cooling fan exhaust or intake
vents. The cooling fan automatically turns on to
cool internal parts. It may continue to run even
after the cooktop has been turned o.
WARNING
PROPOSITION 65 FOR CALIFORNIA
RESIDENTS
Cancer and Reproductive Harm—
www.P65Warnings.ca.gov
Safety Precautions

6 | Wolf Customer Care 800.222.7820
INDUCTION COOKTOP
In induction cooking, the electricity flows through a coil to
produce a magnetic field under the glass-ceramic surface.
When an induction-compatible pan is placed on the cook-
top, currents are induced in the pan and instant heat is
generated. Cookware made of magnetic materials, such as
cast iron or magnetic stainless steel is required for induc-
tion cooking.
ELEMENT RATING
15" INDUCTION COOKTOP W
8⁄" (216) 2300 / 3700 boost
6" (152) 1400
24" INDUCTION COOKTOP W
11" (279) 2600 / 3700 boost
8" (203) 2100 / 3700 boost
8" (203) 2100
30" INDUCTION COOKTOP W
11" (279) 2600 / 3700 boost
8" (203) 2100 / 3700 boost
8" (203) 2100
6" (152) 1400
36" INDUCTION COOKTOP W
11" (279) 2600 / 3700 boost
(2) 8" (203) 2100 / 3700 boost
(2) 8" (203) 2100
Cooktop Features
Induction Cooktop Features
FEATURES
1Product Rating Plate (bottom of cooktop)
2Control Panel
3Induction Element
4Bridge Element
5Timer
6Control Panel Lock
36" Induction Cooktop (CI365C shown)
4
1
2
6
3
5

wolfappliance.com | 7
ELECTRIC COOKTOP
Wolf electric cooktops operate by using high-frequency
pulsation, cycling the heating elements between zero
power and full power. As the heat is increased on the
control panel, the element will stay at full power for longer
periods and have shorter periods of zero power.
ELEMENT RATING
15" ELECTRIC COOKTOP W
8" (203) Dual 700 / 2200
5⁄" (140) Single 1200
30" ELECTRIC COOKTOP W
10⁄" (267) Triple 1050 / 1950 / 2700
(2) 5⁄" (140) Singles 1200
6⁄" (165) Single with Oval 2400
36" ELECTRIC COOKTOP W
10⁄" (267) Triple 1050 / 1950 / 2700
8" (203) Dual 700 / 2200
5⁄" (140) Single 1200
(2) 7" (178) Singles with Bridge 4400
Electric Cooktop Features
FEATURES
1Product Rating Plate (bottom of cooktop)
2Control Panel
3Single Element
4Dual-Zone Element
5Triple-Zone Element
6Bridge Element
7Timer
8Control Panel Lock
36" Electric Cooktop (CE365T shown)
6
1
2
8
5
4
7
3
Cooktop Features

8 | Wolf Customer Care 800.222.7820
Getting Started
We know you are eager to start cooking, but before you
do, please take some time to read this use and care guide.
Whether you are an occasional cook or an expert chef, it
will be to your benefit to familiarize yourself with the safety
practices, features, operation, and care recommendations
of your Wolf Induction or Electric Cooktop.
To ensure all residual oil from the manufacturing process
has been removed, clean the cooktop thoroughly with hot
water and a mild detergent prior to use. Rinse and dry with
a soft cloth. Refer to Care Recommendations on page 17.
Cooktop Operation
CONTROL PANEL
The control panel features illuminated touch controls that
are invisible when the cooktop is o. A power level indica-
tor for each control displays the heat setting from Sim
(Mlt) to Hi. Each control is positioned to the corresponding
heating element. Refer to the illustration below.
Indicators on the control panel illuminate to indicate
specific cooktop operation. Some indicators are unique to
either induction or electric cooktops. Refer to the charts
on the following page.
CAUTION
Do not place hot cookware directly over the control
panel.
Cooktop Operation
Touch controls
ELEMENT
CONTROL

wolfappliance.com | 9
Cooktop Operation
CONTROL PANEL INDICATORS
INDUCTION COOKTOP
Control Panel Lock
Element(s) On
Hot Surface
Timer Set
Boost Mode
Front-to-Back Bridge
Side-to-Side Bridge (36" model only)
All Bridge (36" model only)
ELECTRIC COOKTOP
Control Panel Lock
Element(s) On
Hot Surface
Timer Set
Zone 2
Zone 3
Oval Element (30" model only)
Bridge (36" model only)
CONTROL PANEL LOCK
The control panel lock feature prevents unwanted cook-
top operation. Touch and hold Lock for three seconds to
lock and unlock the control panel. illuminates when the
control panel is locked.
The control panel automatically locks after 10 minutes
of inactivity. This automatic lock feature can be disabled
through the extended options menu. Refer to page 16.
When the cooktop is powered up for the first time and
after a power outage, the cooktop will default to lock
mode.
Cooktop Operation

10 | Wolf Customer Care 800.222.7820
Cooktop Operation
POWER LEVEL INDICATOR
When an element is activated, a power level indicator
illuminates above the corresponding control indicating the
level of heat. The lowest heat is represented by the small
flame, varying levels of heat by additional indicators (dots),
and the highest heat by all indicators including the large
flame. Refer to the chart and illustration below.
Power level indicator
SETTING POWER LEVEL USES
Melt 1 (small flame)
indicator
Melting butter, holding
chocolate, and sauces.
Simmer 2–6 indicators Simmering sauces and
steaming rice.
Medium 6–7 indicators Making French toast and
pancakes, heating milk,
cream sauces, soups, and
gravies.
Medium High 7-8 indicators Sauteing, browning, and
frying.
High 8–10 (large flame)
indicators
Boiling water, searing meat,
and canning.
Cooktop Operation

wolfappliance.com | 11
BOOST MODE (INDUCTION)
For induction cooktops, boost mode boosts power on one
element by diverting power from an adjacent element.
If the adjacent element is on high, the power output will
be reduced. The reduction in power is displayed on the
power level indicator of the adjacent element. Refer to the
illustration below. illuminates when an element is in
boost mode.
Boost mode deactivates automatically after approximately
15 minutes of continuous operation and can be reactivated
if desired.
Cooktop Operation
SINGLE ELEMENT AND INNER ZONE
Setting controls:
1 To activate a heating element, touch On/O for the
desired single element on the control panel. The power
level indicator will flash and all indicators for that zone
will flash. Refer to the illustration below.
2 To complete the activation, touch Hi for highest heat,
Sim (Mlt) for lowest heat, Boost (induction) to activate
boost mode, or touch the desired power level indicator.
3 To change the heat setting while the element is on,
touch or slide to the desired power level.
4 To turn the element o, touch On/O.
IMPORTANT NOTE: For induction cooktops only, if
nocookware or an incompatible pan is placed on an induc-
tion element after activation, the control will flash for 30
seconds, then the element will turn o automatically.
Element activation
ON/OFF
Boost mode
BOOST
Cooktop Operation

12 | Wolf Customer Care 800.222.7820
Cooktop Operation
DUAL-ZONE OR OVAL ELEMENT (ELECTRIC)
Setting controls:
1 To activate a dual-zone or oval element, touch On/
O on the control panel. The power level indicator will
flash and all indicators for that zone will flash.
2 Set the desired heat level for the inner zone as
described on page 11. Outer zones cannot be turned on
independently of the inner zone.
3 Touch Zone 2 or Oval. The outer zone will be set to the
same heat setting as the inner zone. or illu-
minates to indicate the outer zone is on. Refer to the
illustration below.
4 Change the heat setting for the entire dual-zone or oval
element the same as for a single element. Both zones
maintain the same heat setting.
5 To turn the outer zone o, touch Zone 2 or Oval. To
turn the entire element o, touch On/O.
TRIPLE-ZONE ELEMENT (ELECTRIC)
Setting controls:
1 To activate the triple-zone element, touch On/O on
the control panel. The power level indicator will flash
and all indicators for that zone will flash.
2 Set the desired heat level for the inner zone as
described on page 11. The outer zones cannot be
turned on independently of the inner zone.
3 Touch Zone 2. The middle zone will be set to the same
heat setting as the inner zone. illuminates to indi-
cate the middle zone is on.
4 Touch Zone 3. The outer zone will be set to the same
heat setting as the inner and middle zones. illu-
minates to indicate the outer zone is on. Refer to the
illustration below.
5 Change the heat setting for the entire triple-zone ele-
ment the same as for a single element. All three zones
maintain the same heat setting.
6 To turn the outer zone o, touch Zone 3. To turn the
middle zone o, touch Zone 2. To turn the entire ele-
ment o, touch On/O.
Dual-zone element activation
ZONE 2
Triple-zone element activation
ZONE 2 ZONE 3
Cooktop Operation

wolfappliance.com | 13
BRIDGE ELEMENT (ELECTRIC)
Setting controls:
1 To activate bridge, select the desired power level on
one of the single elements.
2 Touch Bridge. illuminates.
3 To change the power level, adjust the power level on
either active bridged element.
4 To turn o, touch On/O on either active bridged ele-
ment.
Cooktop Operation
BRIDGE ELEMENT (INDUCTION)
Setting controls:
1 To activate bridge, select the desired power level on
one of the single elements.
2 Touch Bridge between the corresponding element
con-trols to bridge the elements front to back, Brg to
bridge the elements side to side, or All Bridge to bridge
all elements. , , or illuminates respectively.
3 To change the power level, adjust the power level on
any active bridged element.
4 To turn o, touch On/O on any active bridged
element.
For 36" induction cooktops, All Bridge should be used for
cookware larger than 12" (305) in diameter. For smaller
cookware, use the right rear element.
Bridge element activation
BRIDGE
Cooktop Operation

14 | Wolf Customer Care 800.222.7820
Cooktop Operation
GRIDDLE USE
The bridge element provides an oblong heating area for
use with a griddle, open roaster, or fish poacher.
To preheat a griddle, set the bridge element power level to
high for five minutes, then reduce for cooking.
CAUTION
A griddle, open roaster, or fish poacher should not
be used when the bridge element is o or with any
other combination of heating elements.
TIMER
The timer can be set in one-minute increments up to 99
minutes. Once a time is set, illuminates on the control
panel and the countdown is visible on the timer display.
The timer is independent from the cooktop. Refer to the
illustration below.
Setting timer:
1 Touch Timer.
2 Touch and hold + or – until the desired time is shown
in the timer display. The timer begins the countdown in
minutes.
3 The timer chimes with one minute left and completes
the countdown in seconds.
4 When complete, the timer chimes and continues to
chime until Timer is touched.
Timer controls
TIMER
Cooktop Operation

wolfappliance.com | 15
Cooktop Operation
HOT SURFACE INDICATOR
illuminates on the control panel and may remain illu-
minated even when the cooktop is o.
ALL OFF
When one or more heating elements are on, illumi-
nates on the control panel. To turn o all elements at the
same time, touch All O.
Cooktop Operation

16 | Wolf Customer Care 800.222.7820
Cooktop Operation
EXTENDED OPTIONS
The extended options feature allows the user to set prefer-
ences for volume, tone, control panel lock, and Sabbath
feature.
Setting adjustment:
1 While the unit is o and unlocked, touch and hold All
O for five seconds.
2 Power level 1 on the rear element control is displayed
and “Vo” appears on the timer display. Touch Sim (Mlt)
or Hi on the front element control to adjust volume.
3 Touch + on the timer control to adjust tone. Power
level 2 on the rear element control is displayed and “Fr”
appears on the timer display. Touch Sim (Mlt) or Hi on
the front element control to adjust tone.
4 Touch + on the timer control to adjust the automatic
control panel lock. Power level 3 on the rear element
control is displayed and “Lo” appears on the timer dis-
play. Touch Sim (Mlt) or Hi on the front element control
to turn the automatic lock feature o or on respec-
tively.
5 Touch + on the timer control to enter Sabbath mode
(electric cooktop only). Power level 4 on the rear ele-
ment control is displayed. Touch Hi on the front ele-
ment control to initiate Sabbath feature. “Sa” appears on
the timer display. Touch Sim (Mlt) on the front element
control to activate or deactivate the feature.
6 Touch All O at any time while in extended options to
confirm settings and return the cooktop to idle.
Sabbath
ELECTRIC COOKTOP
This appliance is certified by Star-K to meet strict religious
regulations in conjunction with specific instructions found
on www.star-k.org.
Cooktop Operation

wolfappliance.com | 17
Care Recommendations
CLEANING
Stainless steel Use a nonabrasive stainless steel cleaner and apply with a soft lint-free cloth. To bring out the natural
luster, lightly wipe the surface with a water-dampened microfiber cloth followed by a dry polishing
chamois. Always follow the grain of stainless steel.
Control panel Use a spray degreaser to remove fingerprints and food soil. Spray on a cloth before wiping the control
panel.
IMPORTANT NOTE: Do not spray cleaners directly on the control panel.
Glass-ceramic surface Allow to cool. Use a spray degreaser to remove fingerprints and a non-abrasive Ceran®cooktop cleaner
for food soil. Do not allow any item that could melt to come in contact with the glass-ceramic surface
when hot. If this occurs, use the razor blade scraper provided with the cooktop to remove.
Care Recommendations

18 | Wolf Customer Care 800.222.7820
Troubleshooting
OPERATION
Cooktop does not operate.
• Verify power is on.
• Verify electrical power to the cooktop and home circuit
breaker is on.
• The cooktop is in lock mode. Touch and hold Lock for
three seconds to unlock the control panel.
• The cooktop automatically turns o after 2 hours of
continual use (high), 6 hours (medium), and 8 hours
(simmer), except in Sabbath mode.
Cooktop temperature issue.
• Contact Wolf Customer Care at 800-222-7820 for
recommendations.
Troubleshooting
Sub-Zero, Sub-Zero & Design, Sub-Zero & Snowflake Design, Dual Refrigeration, The Living Kitchen, Great American Kitchens The Fine Art of Kitchen Design, Wolf, Wolf &
Design, Wolf Gourmet, W & Design, red colored knobs, Cove, and Cove & Design are registered trademarks and service marks of Sub-Zero Group, Inc. and its subsidiaries.
All other trademarks are property of their respective owners in the United States and other countries.
SERVICE
• Maintain the quality built into your product by contact-
ing Wolf Factory Certified Service. For the name of the
nearest Wolf Factory Certified Service, check the Product
Support section of our website, wolfappliance.com,
or call Wolf Customer Care at 800-222-7820.
• When contacting service, you will need the model and
serial number of your product. Both numbers are listed
on the product rating plate. Refer to pages 6–7 for
rating plate location.
• For warranty purposes, you will also need the date of
installation and name of your authorized Wolf dealer.
This information should be recorded on page 3 of this
guide.

wolfappliance.com | 19
Wolf Appliance Residential Limited Warranty
FOR RESIDENTIAL USE
FULL TWO YEAR WARRANTY*
For two years from the date of original installation, this Wolf Appliance product warranty covers all parts and labor to repair or
replace, under normal residential use, any part of the product that proves to be defective in materials or workmanship. All service
provided by Wolf Appliance under the above warranty must be performed by Wolf Factory Certified Service, unless otherwise speci-
fied by Wolf Appliance, Inc. Service will be provided during normal business hours.
LIMITED FIVE YEAR WARRANTY
For five years from the date of original installation, Wolf Appliance will repair or replace the following parts that prove to be defec-
tive in materials or workmanship: gas burners (excludes appearance), electric heating elements, blower motors (ventilation hoods),
electronic control boards, magnetron tubes and induction generators. If the owner uses Wolf Factory Certified Service, the service
provider will repair or replace these parts with the owner paying for all other costs, including labor. If the owner uses non-certified
service, the owner must contact Wolf Appliance, Inc. (using the information below) to receive repaired or replacement parts. Wolf
Appliance will not reimburse the owner for parts purchased from non-certified service or other sources.
TERMS APPLICABLE TO EACH WARRANTY
The warranty applies only to products installed for normal residential use. The warranty applies only to products installed in any one
of the fifty states of the United States, the District of Columbia or the ten provinces of Canada. This warranty does not cover any
parts or labor to correct any defect caused by negligence, accident or improper use, maintenance, installation, service or repair.
THE REMEDIES DESCRIBED ABOVE FOR EACH WARRANTY ARE THE ONLY ONES THAT WOLF APPLIANCE, INC. WILL PROVIDE,
EITHER UNDER THIS WARRANTY OR UNDER ANY WARRANTY ARISING BY OPERATION OF LAW. WOLF APPLIANCE, INC. WILL
NOT BE RESPONSIBLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES ARISING FROM THE BREACH OF THIS WARRANTY
OR ANY OTHER WARRANTY, WHETHER EXPRESS, IMPLIED OR STATUTORY.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may
not apply to you. This warranty gives you specific legal rights and you may also have other legal rights that vary from state to state.
To receive parts and/or service and the name of Wolf Factory Certified Service nearest you, contact Wolf Appliance, Inc., P.O. Box
44848, Madison, WI 53744; check the Product Support section of our website, wolfappliance.com, email us at customerservice@
subzero.com or call 800-222-7820.
*Stainless steel (doors, panels, handles, product frames and interior surfaces) are covered by a limited 60-day parts and labor warranty
for cosmetic defects.
*Replacement filters for ventilation hood recirculating kits are not covered by the product warranty.
Warranty

2 | Atención al cliente de Wolf 800.222.7820
Contenido
4Precauciones de seguridad
6Funciones de la parrilla de inducción
7Funciones de la parrilla eléctrica
8Funcionamiento de la parrilla
17 Recomendaciones sobre el cuidado
18 Resolución de problemas
19 Garantía de Wolf
Parrillas de inducción y eléctricas
