AngelTrax ATCF460 MDVR User manual

ATCF460 MDVR
AngelTrax Mobile Digital Video Recorder
Mobile DVR Installation, Setup and User Manual
Includes Quick Setup Guide
Lists all the key features and settings
for the ATCF460 MDVR
Unit Installation
User Menus and Settings
Servicing Procedures

AngelTrax | i
IVS, Inc, dba AngelTrax
AngelTrax designs, manufactures and supports mobile video surveillance for the school bus, mass transit, waste management and rail
industries. AngelTrax drives the market with patented products, including distinctive DVR systems and Virtual Synchronized
Mapping™ technology.
AngelTrax is involved in every stage of product selection, software, professional training and installation. AngelTrax offers, from
beginning to end, the best mobile video surveillance products and services available in the industry.
Mail: IVS, Inc., dba AngelTrax
9540 U.S. Highway 84 West
Newton, Alabama 36352
Telephone: [phone]
Fax: [phone]
Online: www.angeltrax.com
AngelTrax®| Mobile Video Surveillance Solutions
Contact Information

AngelTrax | ii
This user manual is intended for anyone operating, configuring or troubleshooting the ATCF460 mobile digital video recorder (MDVR)
system.
In this manual, the ATCF460 (4-channel DVR) will be referred to hereafter as the ATCF460 DVR or ATCF460.
The following symbols identify conditions or practices that could result in damage to the user, the unit or other equipment if not heeded.
IVS, Inc. holds the following trademarks:
AngelTrax™
Hybrid Component Technology™
FlexPlay™
FlexPlay Pro™
VSM™
SDX™
HDX™
Hybrid Quest™
Hybrid Vault™
MOTOTrax™
MOTOLinx™
This is the June 2013 revision for this User Manual and is copyright, June 2013 of IVS, Inc. dba AngelTrax™ all rights reserved.
IVS, Inc.: This software is provided by the copyright and trademark holders and contributors “as is”, and any express or implied
warranties, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose are disclaimed.
In no event shall the copyright and trademark owners or contributors be liable for any direct, indirect, incidental, special, exemplary
or consequential damages (including, but not limited to procurement of substitute goods or services; loss of use; data or profits; or
business interruption) however caused, and on any theory of liability, whether in contract, strict liability or tort (including negligence or
otherwise), arising in any way out of the use of this software, even if advised of the possibility of such damage.
About This Manual
Advisements
IVS, Inc. Trademarks
User Manual Revision
Exclusion of Liability
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user
to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of
sucient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence
of important operating and maintenance (servicing) instructions in the literature accompanying
theappliance.
Information prefaced by WARNING, NOTICE or CAUTION should be heeded by the user.
Warnings, Notices and Cautions

AngelTrax | iii
A guide for terms used in this manual can be found in the Acronym Guide, page 51.
Please visit the AngelTrax website at www.angeltrax.com to learn more about our company, including a comprehensive listing of
available products and services.
Acronym Guide
Finding Information Online
READ ALL INSTRUCTIONS: All the safety and operating instructions should be read before operating
the device.
RETAIN INSTRUCTIONS: The safety and operating instructions should be retained for future reference.
POWER SOURCE: This device should only be operated from the type of power source indicated on the
panel, or in this manual.
POWER FUSE: This device should only be operated with the fuse rating indicated in this manual. DO NOT
replace power fuse with a higher value than the manual indicates.
OBJECTS/LIQUID ENTRY: DO NOT push objects or allow liquids through openings in this device. This
could result in shock, fire or serious damage to the unit or yourself.
REPLACEMENT PARTS: Contact AngelTrax at 1.800.673.1788 when replacement parts are required.
SERVICING: DO NOT attempt to service this unit yourself. Opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing to qualified personnel.
HEED WARNINGS: All warnings on the device and the instruction manual should be followed.
INSTALLATION: This device requires professional installation by a certified AngelTrax Field Engineer. Do not
attempt to install this device without certification or proper training.
Changes or modifications not expressly approved by the party responsible for compliance with the Federal Communications
Commission (FCC) rules could void the user’s authority to operate this equipment.
Important Safeguards
The stability of the electrical system in the vehicle is critical to the performance and reliability of certain electronics installed onboard.
These electronics rely on the vehicle’s power in order to be fully operational. AngelTrax components require stable voltage in order to
function properly. When connecting any electronics to the power of a 12-24v vehicle, it is connected with wire, which has resistance.
Anytime you have current flow through a resistive element, there will be a voltage loss. Therefore, a voltage regulator is often required to
help maintain the stability of the voltage due to fluctuating current draw. However, AngelTrax learned that most vehicles equipped with
a standard voltage regulator might not be adequate to maintain the correct voltage to the electronics onboard the vehicle. In this case,
the alternator needs a Compensating Voltage Regulator to vary the current flow, keeping the voltage precisely at the target value. This
will ensure the system receives the correct voltage to perform properly. If the Compensating Voltage Regulator is not available, then we
suggest a “Power Conditioner Stabilizer” (PCS5200) connected directly to the mobile surveillance system. The PCS5200 will ensure that
voltage is constant to the mobile surveillance system, thus proper operation and performance of the system can be realized.
Electrical System Disclaimer

AngelTrax | iv
Section 1: Introduction
Features, Functions and Specifications Table........................................................................................ 1
Parts List (General) ..................................................................................................................................... 2
Parts List (Accessory Box) ......................................................................................................................... 3
Tools Needed for Installation Section..................................................................................................... 3
Section 2: ATCF460 DVR Quick Setup Guide
Section 3: DVR Installation
ATCF460 Parts and Functions Diagram .................................................................................................. 6
Installation Best Practices Section .......................................................................................................... 7
Selecting a Location and Other Installation Requirements Section .................................................. 7
Post-Installation Checklist........................................................................................................................ 8
ATCF460 Hardware Installation ............................................................................................................... 9
Panic Button Connection Section ......................................................................................................... 11
Panic Button Versions Diagram ............................................................................................................. 11
Section 4: ATCF460 Connections, Ports and Controls
Driver Action-detecting per Vehicle Table........................................................................................... 13
DVR Remote Control Diagram............................................................................................................... 14
Section 5: ATCF460 Menu and Setup
ATCF460 Menu Outline........................................................................................................................... 15
On-Screen Display Diagram ................................................................................................................... 17
Using the ATCF460 Menu Section......................................................................................................... 19
Date/Time Setup Section ....................................................................................................................... 20
Vehicle ID Type and Number Section .................................................................................................. 23
Formatting the HDD Section................................................................................................................. 24
Contents

AngelTrax | v
Section 6: Factory Default Settings
Camera Setup Section ............................................................................................................................ 25
Title Setup Section ..................................................................................................................................... 25
Color Setup Section.................................................................................................................................... 26
Color Setup Settings and Ranges Table........................................................................................................ 26
Motion Detection Section............................................................................................................................ 27
Status Select Section.................................................................................................................................. 29
HDD Setup
HDD REC Mode Section .............................................................................................................................. 30
HDD Format Section ................................................................................................................................... 31
Auto Format Section ................................................................................................................................... 31
Record Setup
Record Mode Section.................................................................................................................................. 32
Continuous Record Section ......................................................................................................................... 33
Alarm Record Section ................................................................................................................................. 34
Motion Record Section................................................................................................................................ 35
Backup Setup Section............................................................................................................................. 36
TCP/IP Setup Section.............................................................................................................................. 36
Peripheral Setup Section........................................................................................................................ 36
Buzzer Setup Section ................................................................................................................................. 37
Alarm Setup Section................................................................................................................................... 37
Sequence Setup Section ............................................................................................................................. 38
Password Setup Section.............................................................................................................................. 39
Sub Menu
GPS Menu Section...................................................................................................................................... 40
G Sensor Menu Section............................................................................................................................... 41
PTZ Section ............................................................................................................................................... 41
DVR ID Section........................................................................................................................................... 41
Factory Default Section............................................................................................................................... 41
Update Code Section .................................................................................................................................. 42
Audio Section ............................................................................................................................................. 42
Key Lock Setup Section.......................................................................................................................... 43
Section 7: Recommended Preventative Maintenance
Firmware Upgrade Section .................................................................................................................... 45
Contents (Cont.)

AngelTrax | vi
Section 8: Servicing Your ATCF460 DVR
Replacing the Compact Flash (CF) Card.............................................................................................. 47
Upgrading to VSM™ Section ................................................................................................................. 48
Returning Product for Service Instructions ........................................................................................ 49
Section 9: Troubleshooting Guide
Troubleshooting Guide for the ATCF460 ............................................................................................ 50
Acronym Guide
Acronym Guide......................................................................................................................................... 51
Contents (Cont.)

AngelTrax | 1
Section 1: Introduction
Features, Functions and Specifications
This section will introduce you to the ATCF460 mobile DVR, its features and functions, included accessories and the tools necessary for
its installation.
Model ATCF460
Video Format MPEG-4/MJPEG (user selectable)
Medium Removable compact flash drive (4GB, 16GB and 32GB options)
Mounting Removable shock mount; vandal-proof, shock resistant case
Capacity 4GB/up to 32GB capable
FPS (Frames Per Second) 60FPS (MJPEG); 120FPS (MPEG-4)
Resolution 720x584 at 30FPS on all channels
Image File Size Low: 12K, Medium: 15K, High: 20K, Super: 31K/Frame
Cameras 4 inputs standard
Audio 4 inputs standard
Alarms Up to 4 alarm inputs with rule-based event recording. One (1) alarm output.
Interface 6PIN DIN; RJ-45 for remote status indicator; RJ-45 for alarm interface
Power Input 9~30 VDC fused
Enclosure Stamped metal shock resistant housing
Dimensions W4” x H1.44” x D7”/Depth w/ Back cover: 9.38”
Weight 1.95 lbs
Operating Temperature -40 degrees to 185 degrees Fahrenheit
Operating Voltage 9~30 VDC
Current Draw < 2A
Panic ‘PANIC’ button for HDD event mark
Delay Shutdown Previous versions have up to a 1 hour delay. Current versions have up to a 4 hour delay.
Speed/GPS/Direction Data Optional
G-Force Sensor Optional
External VSM™ Module Optional

AngelTrax | 2
Parts List (General)
NOTICE: ATCF460 DVRs are hot-swappable component-based systems. The hot-swappable feature allows the drive to be removed at
any time while the DVR is powered up, allowing efficient and convenient maintenance.
Carefully review the tables below, which outline items needed for proper installation, and make sure you have all of the parts listed.
EXT-VSM
External VSM™ module
GPS-E1
GPS antenna
GFORCE-1
G-Force Inertia sensor
ACCBX-1
Accessory Box
ATCF460 DVR
Base unit with key-locking
front door
COMPACT FLASH (CF)
STORAGE CARD
CF4GB, CF16GB or CF32GB
(purchased separately)
MDSD001 CABLE
15PIN Camera Pigtail
Other items may be included with your system based on your order. Please check the contents of your order carefully. If any items in
your order are missing or damaged, please contact AngelTrax immediately by phone at 1.800.673.1788 or by email at
suppor[email protected] for further assistance.
Optional equipment for the ATCF460 DVR:
WARNING: To prevent fire or shock hazard, DO NOT expose this device to rain or moisture.
CAUTION: To reduce the risk of electric shock, DO NOT remove cover. No user-serviceable parts
inside. Refer servicing to qualified service personnel.

123 4 56
79
811
10 12 13
AngelTrax | 3
Parts List (Accessory Box)
The ATCF460 comes with all of the parts required for a qualified field engineer to perform a complete installation in your vehicle.
1. DVR BACK
Stamped metal back for
ATCF460 DVR
2. KEYS
Two (2) 905 keys
3. SPARE FUSES
Two (2) fuses for B+ and ignition
4. RCA CABLES
Connects a portable monitor
5. A/V ADAPTER CABLE
A/V cable for portable monitor.
Connect cable to A/V output on the
main board located on the front of
the DVR
6. USB CABLE
For DVR connection to PC
7. DRIVER ACTION CABLE
For driver action events
8. DRIVER ACTION
EXTENSION CABLE
For extending driver action cable
to DVR
9. WIRELESS REMOTE CONTROL
Remote for DVR setup
10. ALLEN TOOL
To remove screws from components
11. MOUNTING SCREWS
Screws for DVR mounting
and installation
12. POWER AND
IGNITION CABLE
Cables for power connection
13. PANIC BUTTON
Button to mark recordings and
label as ‘PANIC’ for easy review
Tools Needed for Installation
A qualified field engineer MUST perform the installation to ensure reliable operation. Ninety-nine percent of all issues concerning our
MDVRs are related to improper installation.
The following tools and supplies are needed for proper installation:
• Power drill with various bits
• Stepper drill bit
• Fish tape
• Various wire connectors
• Multimeter
• Portable monitor with audio
• Various screwdrivers and nut
drivers (0.3125 in)
• Wire ties
• Split loom
• Connectors for signal inputs
• Rubber grommets

AngelTrax | 4
Parts and Functions Date/Time Setup
Hardware Installation
Menu and Setup
Ports and Connections
Please refer to the following sections for information on the
ATCF460 MDVR parts and functions:
Page 2 - Parts List (General)
Page 3 - Parts List (Accessory Box)
Page 6 - ATCF460 Parts and Functions Diagram
Plan the location for each piece of your mobile video surveillance
system. It is important to mount the DVR in a location providing
easy access to the front and rear of the device. This ensures you
will be able to quickly and easily access the rear of the DVR,
where all connections are made. You will always need access to
the front of the DVR to pull the Compact Flash card.
Please refer to the Installation Best Practices Section, page
7, for further information.
The ATCF460 MDVRs are equipped with a user menu section
designed for customization of your system. However, there are a
few features that must be set including: Date and Time, Vehicle
I.D., Vehicle I.D. Number and Formatting the Hard Drive (CF card).
To begin setup of your ATCF460, follow the quick guide
instructions referenced below:
Power up the ATCF460 by turning on your vehicle’s ignition.
Remove the plastic insert in the battery compartment of the
supplied ATCF460 DVR remote.
Connect your portable monitor to the composite A/V output on
the front of the ATCF460 using the supplied cables.
You should now see a live view of your cameras. Please refer to
the On-Screen Display Diagram, page 17, for an explanation
of live camera view features.
NOTICE: Use the arrow buttons located around the ENTER
button near the top of the remote to navigate up, down, left or
right on each menu list. Use the plus or minus buttons located
under the arrow buttons to adjust values. Press ENTER on
the remote to select menu list options. Please refer to the DVR
Remote Control Diagram, page 14, for detailed information on
the remote control features.
The red highlighted box on each of the Menu screens indicates
adjustable settings.
At the live camera view, press the Menu button on the remote to
go the Main Menu. Use the arrow buttons on the remote to select
the Date/Time Setup feature, and press ENTER.
The Date/Time Setup menu has the following options: Display
Format, Time Format, Year, Month, Day, Hour, Minute, Second,
Daylight-saving Time and Time Zone Setup.
The Year, Month, Day, Hour, Minute and Second settings may be
adjusted using the plus and minus buttons on the remote.
Select the Display Format Month, Day and Year (MM/DD/YY),
and press the plus and minus buttons on the remote to adjust
the Display Format order.
Under the Date/Time Setup menu, the Time Format can be set
for 12-hour (AM-PM) or 24-hour (13:00) by pressing the plus or
minus buttons on the remote.
NOTICE: Always program the hour as 24-hour (13:00) so the
MDVR can distinguish between AM and PM, and display
it accordingly.
Adjust the Daylight-saving Time setting by selecting it using the
arrow buttons on the remote, and press ENTER.
The Daylight-saving Time setting may be turned ON or OFF.
Start and End times may also be adjusted by selecting the
Month, Day and Hour of each, and pressing the plus or minus
buttons on the remote.
After adjusting the Daylight-saving Time feature, press the Menu
button on the remote to save your changes and return to the
Date/Time Setup menu.
Please refer to Section 4: ATCF460 Connections, Ports and
Controls, page 12, for further information.
Section 2: ATCF460 DVR Quick Setup Guide
Use the following section for quick reference to important features and settings on your ATCF460 DVR.

AngelTrax | 5
Date/Time Setup (Cont.) HDD (CF Card) Format
If your unit has a Global Positioning System (GPS) antenna,
you may set the unit to automatically adjust the time with GPS
satellites. At the Date/Time Setup menu, use the arrow buttons
on the remote to select the Time Zone Setup feature, and press
ENTER. At the Time Zone Setup menu, turn the Auto Time
Adjust By GPS feature ON using the plus or minus buttons on
the remote. Use the arrow buttons on the remote to highlight
the UTC (Coordinated Universal Time), and set to your time
zone using the plus or minus buttons. As you scroll through the
selections, different time zone regions will appear for reference.
Select the Menu button to save the settings, and return to the
Date/Time Setup menu. Press Menu again to return to the
Main Menu.
The ATCF460 DVR records data and mobile surveillance footage
onto a Compact Flash card. For the purposes of working with the
ATCF460 user menu, this manual may refer to the Compact Flash
card as the DVR’s hard drive or HDD.
To format the CF card, use the arrow buttons on the remote to
select HDD Setup from the Main Menu, and press ENTER.
Use the arrow buttons on the remote to select HDD Format from
the HDD Setup menu and press ENTER.
At the HDD Format menu, use the arrow buttons to scroll down
to the Run option (located beside the Confirm option). Press
ENTER on the remote to select the Run option. At the bottom of
the HDD Format screen, a Format message will appear to show
formatting is in progress.
After the CF card is formatted, a Format OK message will appear
at the bottom of the HDD Format screen. The Compact Flash
card is now reset and enabled for recording.
The system will return to the camera view and record
(REC) mode.
Vehicle ID Type and Number
Factory Default Settings
Servicing Your ATCF460
Select Sub Menu from the Main Menu using the arrow buttons
on the remote, and press ENTER. At the Sub Menu, use the
arrow buttons on the remote, to navigate to the DVR ID menu,
and press ENTER.
At the DVR ID menu, you will have the following options: ID Type
and ID.
Select ID Type and press the plus or minus button on the remote
to scroll through the ID Type options. These options include: Bus,
ID, Train and Taxi. Select the desired option and press ENTER.
Select the ID option using the arrow buttons on the remote. Edit
each digit by pressing the plus or minus buttons on the remote.
There are eight digits, and available options are A through Z and
zero through nine for each digit.
After setting adjustments have been made, press the Menu
button on the remote to save your changes and return to the
Sub Menu. Press Menu again to return to the Main Menu. Press
Menu again if you wish to return to the live camera view.
NOTICE: When the vehicle type is changed, the signal wire labels
will change. Please refer to the Driver Action-detecting per
Vehicle Table, page 13, for more information.
CAUTION: Do not adjust factory settings.
Please refer to Section 8: Servicing Your ATCF460 DVR, page
47, for preventative maintenance tips.

Signal I/O GPS
SIGNAL DATA
ATCF 460
1
2
3
4
5
6
G Sensor Box
Power 0.5G 1G 1.5G 2G 2.5G
AngelTrax | 6
This section details the installation of the ATCF460 mobile DVR, including the DVR’s parts and functions, installation best practices,
mounting the DVR and connecting the signal, camera and power cables.
Section 3: DVR Installation
ATCF460 Parts and Functions
1. MAIN DVR HOUSING
• Houses components
• All cable connections
• Mounts to bulkhead
• CF Card Slot for memory (4GB,16GB or 32GB)
• Power indicator light (red)
• Record indicator light (amber)
• A/V output
• Remote receiver
2. FRONT COVER
• Remote access window
• Front key lock
• A/V output opening
3. BACK COVER
• Protects cable connections
4. G-FORCE SENSOR (OPTIONAL FEATURE)
5. GPS ANTENNA (OPTIONAL FEATURE)
6. EXTERNAL VSM™ (OPTIONAL FEATURE)
• SD Data card slot (mapping)
• LED indicator
• Signal input/output connection

AngelTrax | 7
Installation Best Practices
Selecting a Location and Other Installation Requirements
CAUTION - DVR INSTALLATION:
• DO NOT install the DVR in a location where the
unit is exposed to extreme heat. Installation close
to extreme heat will void the product warranty.
• DO NOT install the DVR in a location where
the unit is exposed to moisture, such as
condensation from air conditioning units or
open windows.
• Route the wiring and cables away from sharp
edges that could damage the insulation. Avoid
sharp bends in the cable.
• Contact the AngelTrax technical support staff
at 1.800.673.1788 before attaching the DVR to
other equipment in the vehicle.
ATCF460 DVRs are secured with a security front cover and a cable cover.
The DVR can be installed horizontally or vertically.
Before installing your DVR, keep in mind a well-ventilated location and sufficient clearance around the unit are key factors in performance
and maintenance. Refer to the Selecting a Location and Other Installation Requirements Section, page 7, for further information.
Ventilated Location
Install the DVR AWAY FROM any sort of heat outlet, heater
or AC blower. Do not operate the DVR in a closed-in area or
restrict ventilation in any way. The DVR requires air circulation to
maintain optimum operating temperature and provide
best performance.
Dry Location
Install the DVR AWAY FROM any sort of outlet which could build
up or dispense moisture. The DVR requires arid conditions to
maintain and provide best performance.
Mount to Secure Surfaces Only
Do not mount the DVR to a plastic panel or other surface that is
subject to constant vibration.
Mounting Orientation
Mount the DVR in either a horizontal or vertical orientation.
Clearance Around the DVR
Allow sufficient clearance of at least six (6) inches in front of the
DVR, and two (2) inches on each side for removal of the security
front cover and easy access to the CF card and USB port. Allow
sufficient clearance behind the DVR for camera cables, mounting
cables, Ethernet cables and power cables.
Mounting Cables
The radius for the mounting cables will be dictated by the cable
cover. The rearmost surface of the cable cover will be about three
(3) inches from the back of the DVR to allow camera cables to
bend over each other.
Power Cables
Provide enough slack on the power cable to prevent any force
from being exerted on the connectors. A single four-inch (4”)
diameter loop is sufficient.

AngelTrax | 8
Post-Installation Checklist
Please use the following checklist to ensure that your mobile DVR has been installed properly and that all functionality is working correctly.
Start vehicle
Plug in video/audio monitor
Make sure all lights on panic event button are working
Program time, date and vehicle number (Unit with GPS: select time, time zone & turn on)
Make sure GPS is displaying coordinates on screen (if applicable)
Push panic event button
Make sure DVR is secure and neatly installed
Make sure all cameras are aimed properly for desired capture
Test audio
Push brake to make sure lights work outside, on monitor and driver’s monitor
Turn on amber lights. Check outside and on monitor. Open door and make sure red lights on stop arm and stop sign are
working outside and that stop arm shows up on monitor and driver’s monitor (if applicable)
Disconnect monitor
Lock DVR
Check radio and PA system
Check 2-way radio
Check all switches on vehicle control panel (fans, lights, etc)
Make sure dip (delay time) switches are in the correct position
Check for missing screws. Make sure panels are installed properly with no cracks in plastic
Make sure camera grommets/wire loom are in place

1.5 in
greater than 1.5 in
BULKHEAD
{ mounting surface }
1
2
3
4
AngelTrax | 9
ATCF460 Hardware Installation
Plan the location for each piece of your mobile video surveillance system. It is important to mount the MDVR in a location providing
easy access to the front and rear of the device. This ensures you will be able to quickly and easily access the rear of the MDVR, where
all connections are made. You will always need access to the front of the MDVR to pull the CF card.
1. The bulkhead is the recommended location to mount the
DVR. The cables should be run to the bulkhead from their
source (i.e. power, signals, cameras, GPS antenna, etc.).
2. Drill a hole slightly to the left of the mounting location of the
ATCF460. The hole should be a diameter larger than the end
of your largest cable (approximately 1.5 inches - see
Figure 1). We recommend placing a rubber grommet around
the edges of this hole to prevent the cable being cut by
sliding across its sharp edges.
3. Run all cables, including power, signals, cameras, etc. to the
mounting location for the ATCF460. Pull the cables through
the hole drilled in step two (see Figure 2).
4. Using the screws provided, attach the DVR to the bulkhead
(see Figure 3).
5. Connect the power cable to the power source, then connect
the power cable and ignition to the MDVR (see Figure 4).
Power-up the MDVR by turning on the vehicle’s ignition.

ATCF 460
Record indicator light
flickers in REC mode
{ Panic Button }
5
6
A/V Output on MDVR
A/V Opening on Door
ATCF 460
7
MENU
POP
AUDIO
REWIND
PLAY
PAUSE
STOP
QUAD
ZOOM
SEQUENCE
COPY
ENTER
8
AngelTrax | 10
6. Ensure the ATCF460 powers-up and goes into REC (Record)
mode, indicated by the flickering amber light on the front of
the unit and -- if connected -- on the panic event button (see
Figure 5). If the unit fails to go into REC mode, make sure
the CF card is fully inserted.
7. Power-down the unit by turning off the ignition and
disconnect the power cables.
8. Connect all signal and camera cables to the back of the unit
and reconnect the power cables to the unit.
9. When everything is working properly, attach the back cover
around the cables and onto the back of the unit (see
Figure 6).
10. Power-up the ATCF460 by turning on the vehicle’s ignition.
11. Connect the local monitor to the ATCF460, either without
the front cover, or through the A/V output opening in the
front cover (see Figure 7).
12. Check camera angles, signal inputs and test audio.
13. Remove the plastic insert in the battery compartment of
the supplied DVR remote. Select Menu located in the top
left corner of the remote (see Figure 9), to set the correct
time (Refer to the Date/Time Setup Section, page 20, for
detailed instructions).
14. Turn the vehicle ignition off and confirm the shut down
delay is working properly.
CAUTION - POWER CONNECTION:
Ensure the connection to the power source is secure,
and then connect the cables to the rear of the DVR.

Panic Button
1.125 in
PANIC BUTTON
{ mounting surface }
1
Panic Button Mounting Surface
2
AngelTrax | 11
Panic Button Connection
Panic Button Versions
The external signal button (or panic button), can be connected to show DVR status without using a video monitor. This button has the
following functions when installed: Power indicator LED (red), Record indicator LED (amber), GPS signal indicator LED (green) and event
marker (panic button), to cause an alarm event to be recorded by the DVR.
1. Determine the proper location before drilling the mounting
hole. The vehicle’s control panel should be easily accessible
to the driver.
2. Drill a 1.125” hole in the desired location (see Figure 1).
Ensure the area behind the hole is clear of obstructions
before drilling.
3. Feed the connector and cable through the mounting hole
and attach the panic button (see Figure 2).
4. Put the panic button into the hole.
Panic Button Ring Color
Flashing amber light The DVR is recording
Green light (blinks until locking
in to the GPS signal, then
becomes solid)
GPS signal indicator
Red light (blinks intermittently) The DVR is powered up
There are three versions of the panic event button, each outlined below:
Panic Button
Version 1
Event Marker Button
GPS Signal Indicator
(red)
Power Indicator
(green)
Recording Indicator
(amber)
Panic Button
Version 2
Event Marker Button
Power Indicator
(red)
GPS Signal Indicator
(green)
Recording Indicator
(amber)
Panic Button
Version 3*
Event Marker Button
Power Indicator
GPS Signal Indicator
Recording Indicator
(*all indicators red)

2
3
4
5
6
7
8910
1
AngelTrax | 12
This section details the connections and ports on the ATCF460 DVR and their functions.
Section 4: ATCF460 Connections, Ports and Controls
1. AUDIO/VIDEO OUTPUT CONNECTION
• Audio and video output for onboard monitor
(A/V “Y” cable)
2. CAMERA INPUT PORT
• Camera connection cables connect to this port
• The ATCF460 system has 4 A/V channels (1-4)
3. G-FORCE RECEIVER (Optional Feature)
• Connect the G-Force sensor to this port
• Detects changes in G-Force such as sudden stops
or collisions
4. GPS RECEIVER (Optional Feature)
• GPS antenna connection
5. MILE/KM SELECT SWITCH
• Allows user to select the mile or kilometer setting
6. PANIC BUTTON CONNECTION
• The external signal button (or “PANIC” button) can be
connected to show DVR status without using a video
monitor. This button has the following functions:
a. Power indicator LED
b. Record indicator LED
c. GPS signal indicator LED
d. ‘PANIC’ button for emergencies
7. POWER CONNECTION
• Connects the key on the connection wire (yellow) to
vehicle ignition ON position
• Plugs the power cord to the battery (red)
• Connects to the common vehicle ground (black)
8. DELAY TIME SWITCH
• Allows user to record after the vehicle has been shut off.
• Switch 1 is used to bypass the ignition, and the unit will
not shut off
• Switch 2 delays by 5 minutes
• Switch 3 delays by 10 minutes
• Switch 4 delays by 20 minutes
• Switch 5 delays by 30 minutes
• Switch 6 delays by 240 minutes
• If all the switches are off, the delay is five seconds.
• See the Delay Time Switch Illustration, page 13.
9. DRIVER ACTION-DETECTING WIRE CONNECTION
• Sensor record cable connection has eight (8) wires:
a. AL - Amber lights ON (gray wire)
b. BR - Brake ON (red wire)
c. BU - Reverse (blue wire)
d. SA - Stop arm extended (white wire)
e. RT - Right turn (green wire)
f. LT - Left turn (yellow wire)
g. D:1 - Door 1 (purple wire)
h. D:2 - Door 2 (orange wire)
• See the Driver Action-detecting per Vehicle Table, page
13, for details on each wire’s function on different types
of vehicles
10. EXPANSION PORT
• Alarm expansion: up to four (4) inputs and
one (1) output

Delay Time
010 30
520 240
1
ON
2 3 4 56
AngelTrax | 13
NOTICE - POWER CONNECTION &
SWITCH-OFF DELAY:
The power supply is equipped with a delay circuit.
The MDVR switch-off delay function will only work if
the ignition start wire is connecting correctly.
Delay Time Switch
1=bypass - You can turn on the unit by
flipping up this switch without turning
on the vehicle’s ignition. The unit will
remain on for five (5) minutes.
Driver Action-detecting per Vehicle Configuration
School Bus and Taxi Transit Bus Train Police Truck (Future
Application)
AL - Amber lights ON HL - Headlights HR - Horn EL - Emergency Light HL - Headlights
BR - Brake ON PB - Parking Brake BR - Brake ON BR - Brake ON BR - Brake ON
BU - Back Up or Reverse BU - Back Up or Reverse BU - Back Up or Reverse SI - Siren Indicator BU - Back Up or Reverse
SA - Stop arm extended SB - Service Brake BL - Bell PK - Parking SB - Service Brake
RT - Right Turn RT - Right Turn FW - Forward RT - Right Turn RT - Right Turn
LT - Left Turn LT - Left Turn EM - Emergency LT - Left Turn LT - Left Turn
D:1 - Door 1 D:1 - Door 1 D:1 - Not used DR - Door Open PE2 - Panic Event 2
D:2 - Door 2 D:2 - Door 2 D:2 - Not used MR - Microphone
Reception PE3 - Panic Event 3
PANIC PANIC PANIC PANIC PE1 - Panic Event 1
ATCF460 Connections/Ports (Cont.)
