AOC GH300 User manual

1
AOC GH300 GAMING HEADSET
USER MANUAL Ver. 1.0.0
CAUTION: To use this product properly, please read the user's guide before installing.

2
Contents
1. Package Contents and System Requirements.............................................................3
2. Technical Specifications..............................................................................................4
3. Device Layout Overview .............................................................................................5
4. Software Installation...................................................................................................6
5. Software Running .......................................................................................................9
6. Software Update.......................................................................................................10
7. Home Page ...............................................................................................................11
8. Headset Settings.......................................................................................................16
9. Discovery ..................................................................................................................28
10. Macro .....................................................................................................................45
11. Language ................................................................................................................49
12. Safety Guide and Maintenance ..............................................................................50

3
1. Package Contents and System Requirements
Package Contents
◼GH300 wired gaming headset
◼Quick start guide
Product Requirements
◼Windows® 7 or above
◼Available USB port
AOC G-Menu Requirements
◼Windows® 7 or above
◼500MB free hard disk space
◼Internet connection
Technical Support
◼2 years limited warranty
Free online technical support at www.aoc.com

4
2. Technical Specifications
◼Driver: 50mm, PU+PEEK composite diaphragm, Neodymium Magnet
◼Frequency range: 20Hz - 20KHz
◼Impedance: 32 Ω±15%
◼Sensitivity: 100 ± 3dB (at 1KH 1mW)
◼Connection: USB
◼Audio: 7.1 Virtual Surround Sound (PC+AOC G-Menu), support up to 24bit/96kHz
Hi-Res Audio(PC/Mac) by internal DAC
◼Software: AOC G-Menu
◼Microphone: Detachable Omnidirectional
◼Control: In-line control
◼LED lighting: AOC Light FX RGB lighting, customizable via AOC G-Menu
Approximate Size & Weight
◼Length: 160 mm
◼Width: 100 mm
◼Height: 195m
◼Weight: 363g (including the cable and the remote controller)

5
3. Device Layout Overview

6
4. Software Installation
Search and download the latest version of AOC G-Menu file from your local/regional
AOC official website by http://www.aoc.com , and double click the EXE file to start
the installation.
Accept the license agreement by selecting the I Agree radio button, and clicking the
Next button.
Select the installation folder. Select the default folder by pressing the Next button.
Selecting the Browse button will open a Browse for Folder dialog box.

7
Confirm Installation by pressing the Next button.
Complete the installation by pressing the Close button. Congratulations on installing
G-menu!

8
To uninstall G-Menu:
For Windows 10: Go to Windows Settings > Apps > Apps and Features > select G-
Menu and press the Uninstall button.
For Windows 7/8/8.1: Go to Control Panel > Programs > Programs and Features >
select G-Menu and press the Uninstall button.

9
5. Software Running
There are 3 ways to run the AOC G-Menu application.
⚫Start Menu>G-Menu
⚫Taskbar>Right click on the taskbar icon
⚫Double click the shortcut on Desktop

10
6. Software Update
When you enter the G-Menu home page, the software will automatically check for
updates, if there is a new version, it will be downloaded in the background.
After the download is complete, the interface will alert you to install the update.
⚫Note: If there is no network connection, G-Menu will not be able to detect
updates.

11
7. Home Page
Open the AOC G-Menu application and enter the home page.
Application name: Displayed on the top left, not clickable.
Brand logo, Software version: Displayed at the bottom right, not clickable.
Minimize/Restore: Displayed at the top right. Click to switch the interface to zoom
in/restore the display.
Setting: Displayed at the top right. Click to enter the setting interface, where you can
modify the language.
Device display:
⚫The device types supported by the current software are displayed by default,
including: Monitor, Keyboard, Mouse, Mouse mat, and Headset.
⚫Currently connected devices are highlighted and may be clicked. Other device
types are grayed out and cannot be clicked.
⚫Click on the device icon to enter the device settings interface.
Discover：Click the Discover button to find the latest game profiles.
Close: Click the Close button to close the application interface, the actual application
is still running in the background.

12
AOC AUDIO CENTER installation (AOC GH300 Headset ONLY)
If it’s the first time for you to use the AOC GH300 headset, you may need to install the
AOC AUDIO CENTER application to activate the audio driver when clicking the headset
device icon and prompt will be displayed.
By following the scree prompt, click the “DOWNLOAD” to download the AOC AUDIO
CENTER software.

13
Please don’t do anything until the downloading is finished and new prompt is
displayed. After the downloading, click “INSTALL” to start the installation of AOC
AUDIO CENTER software package.
Wait for a while, click “Yes” to permit your system to run the “Setup.exe” if you are
receiving an alert about the installation, when the installation interface is displayed,
please click “Next”.

14
Choose “I accept the terms of the license agreement” and click “Next”.

15
When the installation is finished, you may need to restart your computer.

16
8. Headset Settings
8.1 General Settings
8.1.1 Top Navigation
G-Menu navigation options: Home, Monitor, Mouse, Keyboard, Mouse mat, Headset,
and Macro.
The unconnected devices will not be displayed.
Click an active button to open the device settings interface.
Click the Home button to return to the homepage.
8.1.2 Left Navigation
Navigation button are, from top-to-bottom: Monitor, Keyboard, Mouse, Mouse mat,
Headset.
The icons of unconnected devices are hidden.
8.1.3 Profile Management
◼Display Profiles
Click on the Profile drop-down menu to display all local profiles.

17
After switching the profile, it will be automatically configured on the current board
and takes effect in real time.
◼Manage Profiles
Click the Meatball menu to expand the profile selection item: Add, Import, Export,
Rename, and Associate.
A) Add
Enter the name of the new profile.
Click the File button to open the local executable file or enter the execution path in
the input box directly.
Click the Save button to add the profile.
Click the Cancel button to close the pop-up box.
B) Import
Opens a File Explorer dialog box.
Locate the file to import and select it. Press the OK button to import the profile.
The profile will be imported and populate the currently selected profile. The previous
profile will be overwritten with the imported settings.
C) Export
The export command will only export the settings for the current profile.

18
A Save dialog box will open, and you may navigate to where you wish to save the file.
Click the Save button to save the exported profile.
D) Rename
Change the name of the current profile. It cannot be a duplicate of an existing profile
name.
Click the Save button to save the new name.
Click the Cancel button to close the pop-up box.
E) Associate
You may associate an executable file to run each time the profile is selected.
Click the File button to open a File Explorer dialog box that shows .exe files.
Or you can directly enter the execution path in the input box.
After selecting the application, click the Open button, the path will be automatically
filled into the input box.

19
Click the Save button to add the application to the profile.
Click the Cancel button to close the pop-up box.
8.1.4 On board memory
Click the icon to open the On-Board Memory pop-up interface
The left side of the interface is the current device onboard; the right side is list of all
local profile files.

20
On-board adaptation: Drag the profile file to the back of the corresponding on-board
color. After completion, the profile will be immediately applied to the on-board to
take effect.
Delete a profile
◼Click the delete icon behind the profile to delete it.
◼The profile currently in use does not support deletion.
◼Click the close icon to close the pop-up window.
