Y
Yo ou u M Mu us st t N No ot ti ic ce e
Adobe, the Adobe logo, Acrobat is trademarks of Adobe Systems Incorporated.
AMD, the AMD logo, Athlon and Duron are trademarks of Advanced Micro Devices, Inc.
Intel, the Intel logo, Intel Celeron, Pentium II, Pentium III and Pentium 4 are trademarks of Intel Corporation.
Microsoft, Windows, and Windows logo are either registered trademarks or trademarks of Microsoft Corporation in the United
States and/or other countries.
All product and brand names used on this manual are used for identification purposes only and may be the registered
trademarks of their respective owners.
All of the specifications and information contained in this manual are subject to change without notice. AOpen reserves the right
to revise this publication and to make reasonable changes. AOpen assumes no responsibility for any errors or inaccuracies that
may appear in this manual, including the products and software described in it.
This documentation is protected by copyright law. All rights are reserved.
No part of this document may be used or reproduced in any form or by any means, or stored in a database or retrieval
system without prior written permission from AOpen Corporation.
Copyright©1996-2002, AOpen Inc. All Rights Reserved.

9
A
A
X
X4 4B BR R- -U U O On nl li in ne e M Ma an nu ua al l
B
Be ef fo or re e Y Yo ou u S St ta ar rt t
This Online Manual will introduce to the user how this product is installed. All useful information will be described in later
chapters. Please keep this manual carefully for future upgrades or system configuration changes. This Online Manual is saved
in PDF format, we recommend using Adobe Acrobat Reader 4.0 for online viewing, it is included in Bonus CD or you can get
free download from Adobe web site.
Although this Online Manual is optimized for screen viewing, it is still capable for hardcopy printing, you can print it by A4 paper
size and set 2 pages per A4 sheet on your printer. To do so, choose File > Page Setup and follow the instruction of your printer
driver.
Thanks for the help of saving our earth.

10
A
A
X
X4 4B BR R- -U U O On nl li in ne e M Ma an nu ua al l
O
Ov ve er rv vi ie ew w
Thank you for choosing AOpen AX4BR-U motherboard. The AX4BR-U is Intel®Socket 478 motherboard (M/B) based on the ATX
form factor featuring the Intel®845E (Brookdale) chipset. As high performance chipset built in the M/B, the AX4BR-U
motherboard can support Intel®Socket 478 Pentium®4 (Brookdale) and 533MHz Front Side Bus (FSB) clock. According to
different customer’s requirements, the Intel 845E chipset memory interface supports DDR200/266 SDRAM devices with
densities of 128, 256, 512 and 1024Mb DDR SDRAM DIMM modules and the maximum memory size can be up to 2GB. The
onboard IDE controller supports Ultra DMA 33/66/100 mode and the transfer rate up to 100MB/s. Besides, the AX4BR-U has a
8M ATI Rage XL VGA onboard and equips with Intel LAN controller providing 10/100M bps
Ethernet for office and home use. Now, let’s enjoy all features from AOpen
AX4BR-U motherboard.
