Aosom 370-102 User manual

Suitable age 37-95 months.
This product should be assembled by adult.
This instruction contains important safety information
content,please keep it as a reference.
ASSEMBLY INSTRUCTION
370-102 370-104
INfaa028_US_CA
CHILDREN ELECTRIC MOTORCYCLE MANUAL

-1-
1
1
1
1
About the products
Thank you for choosing our children electric car.We always keep
pursuing being outstanding and designing comfortable and safe
ride on car for children.Let Beisida children carriage be with every
children's growth.
Please read this instruction carefully before use,it will tell you
the right way of assembling and operating.To avoid incorrect
operations damaging the product or injuring your children.
Please keep this instruction.
Specifications
Part
Name
Part
Name
Part
Name
Picture Picture
Q'ty
(pcs)
Q'ty
(pcs)
Part
Number
Part
Number
Main
body
Faucet
Front
fender
Head
stock
Battery: 6V4AH
Main material: PP
Suitable age: 37-95months Maximum weight: 25kg
Motor: RS-380-6V, RPM14000 x1
Car Size: 86x 42x52cm Package Size: 74x 30x35cm
Speed: 2-3km/h
Operation time: 1-2hours after charging about 8-12hours
Charge: Input AC100-240V;Output DC6V500mA
Fuse: Resettable Fuse
Parts List

1
4
1
1
1
2
2
1
1
1 1
1
-2-
Part
Name
Part
Name
Part
Name
Picture Picture
Q'ty
(pcs)
Q'ty
(pcs)
Part
Number
Part
Number
Charger
Screw
parts
Instruction
Wrench
Front
wheel
CHILDREN'S ELECTRIC CAR INSTRUCTION
Please read this instruction carefully before use.
Suitable age 37-95 months.
This product should be assembled by adult.
This instruction contains important safety information
content,please keep it as a reference.
Executive standard：GB6675.1-2014;GB6675.2-2014;
GB6675.3-2014;GB6675.4-2014;
GB19865-2005;GB5296.5-2006
Foot
board
Right
rear
wheel
Left
rear
wheel
(Plum)
Front
axle
Rear
axle
Front
fork
License
plate
Front
cap
Rear
cap

-3-
1
1
2
2
3
3
4
4
5
7
8
8
9
9
10
8
9
8
8
10
11
10
10
10
10
12
12
12
13
13
14
11
6
6
7
5
Main body
Front fork
Front fender
Head stock
Faucet
Rear axle
Right rear wheel
Nut
Rear cap
Gasket
Front cap
Front wheel
Front axle
Left rear wheel
Explosion map
14

-4-
2.Installation of rear wheel
The rear axle passes through the gear box shaft hole and is inserted
into the axle hole of the body from the side of the car body, and the
wheels are respectively put on the rear axle of the left and the right,
and the upper part of the rear axle is fixed with nuts, and then the
upper cap is stuck.
1.Installation of head
Connect the wire terminal with the body, then clip the two feet of the head
into the corresponding position of the body, finally fix with two screws.
Assembling
The vehicle should be assembled by adult before use.It will take
30minutes to complete.
The small parts might cause choke,please keep away from the children.
Please check the number of the parts before assembling,and keep the
packaging bags away from the children in in case of choke.
Gearbox
Gasket
Gasket Gasket
Nut
Nut
Right rear
wheel
Left rear
wheel
A rear
axle
Rear
cap Rear
cap
Wire terminal

-5-
4.Faucet installation
Place the front wheel assembly in the corresponding position of the
car body , fit the faucet and screw it.
3.Front wheel mounting
Figure take off the front axle, the fender set in the front fork pipe.
Turn the front axle from left to right through the gasket, front fork
tube, gasket, front wheel, gasket, front fork tube, gasket, and then
put a nut at both ends of the front axle, and then tighten with a
wrench. Finally buckle the front cap.
Main
body
Gasket
Gasket
Nut
Nut
Nut
Faucet
Front wheel
Front
axle
Front
fork
Front cap
Front cap
Front
Fender
Front wheel
assembly
Screw

7.Connection power supply
Open the seat cushion,
connect the red power cord
with the red end (positive
extreme) on the battery ,
install and fix the seat cushion.
-6-
6.Pedal installation
Pedal board in the groove on the
body , to ensure that it has been
installed in place, not easy to fall
off.
5.Installation of license plate
As shown in the picture, the license plate is inserted into the
corresponding hole of the car body , and the license plate is fixed
in the body with the self tapping screw.
Foot board
License plate

-7-
1.To avoide harmed by the little spare partsl ,less than 3years old can't
drive.
2.Assembled and charged Only by adult,
3.The max loading is 25 kgs,suitabal for 37-95 months old children.
Do not over loading for safety.
4.This product is not traffic tool,keep driving on hard and flat ground.
5.Do not drive in the dangerous place,like street,road or sloap.
6.Do not drive the mire or uneven places.
7.Children should be instructed to the correct operation, to prevent the
damage caused by improper operation, accident
8.When change gears, release the foot switch, after the car stopped.
9.When driving,adult care and supervision is necessary ,Do not leave
and keep your childin your sight.
10.Do not let the product in rain or other ways touch water, avoide
damage the circuit and motor.
11.Check whether the charger ,plug-ins,and other parts are in good
condition and well connected in time.
12.To make sure safety and use longer ,avode damage the charger
battery or system,must be use the orginals.
13.When stop using the car,cut off the power ,turn all buttons to “stop”
or “off”.
14.The charger and battery of the products are not toy ,forbidden
children playing the charger and battery.
15.Do not use the product on other ways.
16.Do not use the spare parts not suppy rom us.
17.The product mainly use PP, safety use tiome is 2 years.
HOW TO OPERATE YOUR VEHICLE
1.Before use ,must be confirm the product asfollows:
According to the instruction assemble the car,connected well.
Make all the screws fastened tightly in the right place.
Before driving, parents should teel your children safety rules and
make them understood.
In order to reduce dangerous.
GIVE SAFETY EDUCATION BEFORE USE

-8-
Only one child drive every time.
Driving must be under the adult supervision
Note the driving in safe place,keep driving on hard and flat grount,
DO not drive in dangerous places.
a.ditch pit,river side,slopes or other uneven ground.
b.Beside the road or other places for cars and people walking.
c.Barrier which might cause damage and injury.
d.Other dangerous places.
Do not drive in black,it may cause injury.Do drive in day time or bright places.
Please sit on the seat when driving.
FUNCTIONS
Note:Must tell your children,When change gears, release the
foot switch, after the car stopped.
Do not change gears when the car is driving,or damage
the line and other parts.
Forward/
backward
Swich
Power
botton
Music botton
Socket
FUSE
Siren
button
This product configure self-resetting fuse,when the driving car stopped,
mainly because of the current exceeds the specified value,at this time ,
you should wait 8 seconds,then the fuse will automatic reset.
To avoid the fuse trip cause cut the power,
please note the things as follows:
The max loading is 25kgs,do not over the loading.
Do not drag everything.
Do not let the water or other liquid touched the
circuit,battery and other parts.
Never modify the structure and the electric circuit systiem.

CHARGE
This product charge should by adult for safey.
Before first use should open the seat,the line s connected(red to red,
black to black)please charge at least 8-12 hours.
The charging jack is on the fuel tank cap,the steps as follows:
When drive slow,should charge 8-12 hours in time,can't be over 20 hours.
NOTE:
Only can use the manufacturers specified battery and charger .
The old and new batteries and different types of batteries can not be
mixed use.
Do not open the battery and charger.
Do not over turn the battery
.
Before charge,please confirm whether the charger battery and the jack
are well,if damaged,stop use,until restored.
When charging,the battery will be warm,it's regular or the battery
maybe damaged.
Must use the platen fasten the battery,the battery will hurt the children
when the car overturn.
The adult should bring out the battery,proper recycling.
When the car will be not used for long time,ensure it be charged and
charge once every 3 month to keep the battery life.
The charger is not toy,keep it away from the children.
Socket
1.to open the charging hole cover. Plug the charger into the charging hole.
2.plug the charger into the power outlet. (charge state car can not start)
-9-

-10-
WARNING: NOT TRAFFIC TOOL, TO KEEP SAFE,
ADULT'S SUPER VISION IS REQUIRED.
MAINTENANCE
1.Check the main parts regularly,check if there's any damage of
the battery,charger,plug,cover and the other parts,check if the
screws are tight,check if the wire lead is old .If any damage,
please stop use and deliver to the professional service.
2.Clean the iron parts with little lubricating oil after a time of use
to avoid rust.
3.Keep the car away from fire,avoid direct sunshine;always turn
it up but not turn it over;put in dry place when not use,and do not
dump the car,Keep the car inside door room or cover it with cloth
when wet weather.
4.Keep the car away from hot obejacts loke stove or heater,for
the plastic might be melted;when charging ,keep it away from
flammable materials to avoid fire.
5.Charge in time after use,and do it by adult,When the car will be
nor used for long time,ensure it be charger and charge once every
3 month to keep the battery life.
6.Clean the vehicle by dry soft cloth ,do not use any chemical
solvents,soap or water,Do not drive in rainning or snowing days.
7.When stop using the car,cut off the power,turn all the buttons to
“stop” or “off”.
8.Do not use inconsistent fuse.
9.Do not change the line system,structure and additional electric
system of the vehicle by yourself,repair work must be done by
career man or under professional supervision.
10.Toy is not to be used for other purposes.

MALFUNCTION ELIMINATES:
Vehicle
couldn't
move
1,Check whether the power switch is off.
2,Check whether the forward/backward switch is
in the neutral gear (in the middle)
3,Check the fuse is damaged,if so ,change it.
4,Check whether the battery wires are
connected well?
5,Charger's dc in the charging socket will make it
not work,if so ,take it out.
6,Check whether stepped on the pedal.
7,Check whether anything trapped in the wheels.
Vehicle
move
slowly
1,Check whether the battery be fully charged.
2,Check whether anything trapped in the wheels.
3,Check whether the vehicle is over loaded.
Vehicle
cannot be
charged
1,Check whether the charger or battery is damaged.
2,Check whether the charger and the battery is
well connected.
3,The charger or battery if there is a loose
connection.
WARNING
1,This note is to use illustrations to illustrate the operation of
the product and product structure, there are a few differences,
in kind prevail.
2,In order to improve the quality of the products, under the
condition of without telling, we may make changes to the product
part of the structure with the appearance, please understanding
-11-
