APART MASK4C(T) User manual

MASK4C(T) / MASK6C(T)
Instruction manual

Instruction manual
MASK4C(T) / MASK6C(T)
3
MASK4C(T) / MASK6C(T) manual

4
Design cabinet loudspeaker
Safety precautions
• Keep this manual for future reference.
• Take care of the speaker wires, they should be free of damage.
Damaged speaker wires may result in poor sound quality and
can damage amplifiers.
• No mains power shall be connected to the speakers, doing so
will damage the speaker.
• This speaker should only be serviced by qualified personnel. If
not, warranty might be void.
• Use cables of the right gauge, certainly for long runs.
• Use cables with clear colour indication and maintain polarity
throughout the whole system.
• Avoid loud feedback.
• Clean only with dry cloth.
• Do not operate near heaters or place it near other apparatus
which produce a lot of heat.
• Only use accessories specified by the manufacturer.
• Make sure the mounting surface can easily support the
speaker’s weight.
• Use only industry-accepted mounting tools and methods.
• Exposure to loud audio levels over a long time can cause severe
hearing loss.
• Don’t forget to consult the local law directions regarding
producing sound in public places.
• Please check the unit’s condition after unpacking. If the outside
of the carton box has been damaged, inform your shipper
immediately.

Instruction manual
MASK4C(T) / MASK6C(T)
5
The enduring success story
The origin of MASK loudspeakers goes back as far as 2006, when
the introduction of MASK4 and MASK6 set an industry standard for
numerous professional users all over the world. Reliability, sound
performance, an unseen design and a unique ease-of-use Intelli-
mount bracket resulted in an instant success in every major market
worldwide.
So with this essential philosophy of construction quality, reliability,
ease-of-installation and sound performance in mind the next
generation of MASK was created.
MASK4C - MASK4CT / MASK6C - MASK6CT
A designer evolution with an installer friendly revolution. MASKC
series got a subtle facelift resulting in a more mature look and feel.
Its underlying engineering evolved to an unprecedented level,
exceeding every installer’s expectations.
The patent pending ClickMount bracket is a true revolution for
installers and users alike.
Rigid constructed to withstand the most fierce conditions in which
a professional loudspeaker can be used. MASK will remain an iconic
industry standard for many years to come.

6
Design cabinet loudspeaker
Features
• Timeless design
• Weather resistant (aluminium grille)
• ClickMount: click & connect
• Connectors with passthrough and 0.14 – 4 mm² solid or
stranded wire capacity
• Wall and ceiling mountable
• Integrated spirit level
• Unique 3 stage overload protection
• Asymmetric tweeter horn design
• Coated 4.25”LF driver for MASK4C(T) and 6.5” LF driver for
MASK6C(T)
• Horn loaded silk dome tweeter
• Paintable in any RAL color
• Rotatable logo
• 70W power handling for MASK4C(T) and 200W for MASK6C(T)
• 70V and 100V compatible (T versions)
• 8 ohm and 16 ohm (T) versions available
• Integrated safety nut for SAFCAB (supplied)
• The installer can mount the ClickMount and connect the
speaker cables while the speakers are still safely packed inside
the packing carton.
• Glass fibre reinforced bracket included
• Speakers designed to be used in combination with the included
ClickMount
• Incorporated 5° downward listening angle

Instruction manual
MASK4C(T) / MASK6C(T)
7
Downward listening axis
5°
5°

8
Design cabinet loudspeaker
Mounting & connecting the MASK4C(T) loudspeaker
CEILING
WALL
min 145 mm
min 50 mm
speaker
wires
80 mm
vertical mounting
MASK4(T)

Instruction manual
MASK4C(T) / MASK6C(T)
9
The intelligent ClickMount mounting system helps you to install
the MASK4C(T) speaker in a safe and easy way. Please note the
minimum distance from the ceiling and wall as shown in the
drawings below:
CEILING
WALL
min 115 mm
min
20 mm
speaker
wires
80 mm
horizontal mounting
MASK4(T)

10
Design cabinet loudspeaker
CEILING
WALL
min 200 mm
min 105 mm
speaker
wires
80 mm
vertical mounting
MASK6(T)
Mounting & connecting the MASK6C(T) loudspeaker

Instruction manual
MASK4C(T) / MASK6C(T)
11
The intelligent ClickMount mounting system helps you to install
the MASK6C(T) speaker in a safe and easy way. Please note the
minimum distance from the ceiling and wall as shown in the
drawings below:
horizontal mounting
MASK6(T)
CEILING
WALL
min 140 mm
min
45 mm
speaker
wires
80 mm

12
Design cabinet loudspeaker
• Determine the position where the ClickMount will be mounted
on the wall. Please allow a minimum distance of 105 mm for
MASK6C and 50 mm for MASK4C between the top of the
ClickMount and the ceiling is necessary when installing the
speaker in the upright position. The cable entry point is 95mm
below the top of the bracket. The cable can enter from the
rear of the bracket so that it is completely hidden from view.
The ClickMount MUST be mounted with the arrows facing
upwards!
• Now mark the four mounting holes on the wall. Use the built-in
spirit level for correct positioning of the ClickMount unit.
Drill the mounting holes and attach the ClickMount in place using
adequate hardware. Use only hardware capable of supporting the
speaker’s weight safely. Be careful when you drill the holes in the
wall: make sure not to drill into the speaker cables or other objects
hidden inside the wall.

Instruction manual
MASK4C(T) / MASK6C(T)
13
• The speaker wires must be guided through the ClickMount
bracket.
• Open the connection terminals.

14
Design cabinet loudspeaker
• Connect the speaker wires taking care of the polarity. Two
positive and two negative connectors are supplied to allow
speakers to be connected in a daisy chain system.
• Click the cover plate in place.
1
2

Instruction manual
MASK4C(T) / MASK6C(T)
15
• Rotate the ClickMount as required by loosening the quick lock
lever
• Attach the SAFCAB cable to the rear of the speaker and
attach the other end firmly to the wall close to the ClickMount
(preferably above the ClickMount). The SAFCAB can handle
more than 10 times the speaker’s weight, so mount the
cable on the wall using appropriate mounting hardware (not
included). Do not use ClickMount to attach the SAFCAB. The
SAFCAB must be attached to the wall structure separately.

16
Design cabinet loudspeaker
• MASK(4)(6)CT only: set the power selector in the required
position.
• Warning: the 16 ohm setting is not compatible with 70 or
100 volt line amplifiers!
MASK4CT
MASK4CT
MASK6CT
MASK6CT
16 ohm position: for low impedance amplifiers only! This switch
position is not compatible with 70 / 100 volt line amplifiers!
Do not use the speaker on 100 volt speaker lines with the
power switch in this position! This position is the highest setting
compatible with 70 volt lines only!

Instruction manual
MASK4C(T) / MASK6C(T)
17
• Fasten the quick lock lever and Click the speaker on the
ClickMount until the unit clicks firmly in place. If necessary,
adjust the lock tension from the quick lock lever.
• WARNING: do not push onto the grille. If the ClickMount
is located close to the ceiling (minimum 105 mm, then
you will have to temporarily loosen the quick lock lever
and tilt the mounting plate downward a few clicks.
Push the loudspeaker on the click mount.
Don’t touch the grille.
1

18
Design cabinet loudspeaker
• The speaker can be mounted on the ClickMount in 4 ways:
upright, 90° rotated to the left, 90° rotated to the right or at
the ceiling. It is not possible nor allowed to mount the speaker
upside down on the ClickMount. When the speakers are
mounted 90° rotated to the left or right, you can also rotate
the logo on the grille accordingly.
CLICK!
2

Instruction manual
MASK4C(T) / MASK6C(T)
19
Note: All MASK models have a unique 3 stage overload protection,
which is activated when the speakers are overloaded for long
periods. When too much power is fed into your MASK, first the
red led will blink when the music signal hits peak levels. When you
neglect this early warning, the overload protection will disconnect
the signal going to the loudspeakers and the red led will remain lit.
Turn down the music level . After about 3 seconds cooling down
the signal will be reconnected to the loudspeakers.
REMINDER
Protection systems are not built to be activated all the time, they are
to warn you and to give you a safety margin!

20
Design cabinet loudspeaker
Specifications
model name MASK4C MASK4CT
Woofer size 4.25”
tweeter size 1”
loudspeaker system 2-way
nominal impedance 8 ohms 16 ohms
power @ 100 volts N/A 2.5W / 5W / 10W / 20W
power @ 70 volts N/A 1.25W / 2.5W / 5W / 10W / 20W
connector wire capacity
(connection and passthrough) 0.14 – 4 mm² solid or stranded wire x2
frequency range 80 - 20 kHz 80 - 20 kHz
program power 70 W 70 W
SPL at 1 W / 1 m 92 dB 89 dB
Max SPL at 1m 104 dB 104 dB
Distance from wall 80 mm
IP rating 64
Main construction material ABS plastic / PA66
Grille main material Aluminium
Net weight 1.6 kg / pc 1.85 kg / pc
Dimensions H x W x D mm 238 x 144 x 144
Colour black / white
Accessories (supplied) 2x ClickMount, 2x safety cable
