Apex Cirrus Trimless kit User manual

1
Apex Cirrus
Instructions for Trimless kit
These instructions must be read in conjunction with the main installation guide, the conversion work below
should be carried out prior to installing the firebox into position.
Remove the burner tray from the fire box by the following steps shown below:
Fig 3. Remove access panel
Fig 4. Disconnect gas supply pipe from the restictor valve
Fig 5. Carefully remove the burner tray by lifting the back of tray first
.
Fig 1. Carefully lift the ceramic base
boards to reveal the burner screws
Fig 2. Remove 6 - 8 screws

2
You are required to reposition the isolation bracket for the trimless version
Burner tray showing standard bracket Burner tray with trimless bracket option
1. Remove bracket and retain the screws
2. Fold the new bracket to the shape shown
3. Fit the bracket using the new location holes as below
4. Fit the isolation valve to the bracket

3
Now fit the remote control valve key operating mechanism and power supply as follows:
1. Place the screws into the holes of the key mechanism and fix to the bracket on the remote control valve
If using a back panel with this installation ensure the keys fit above the panel as shown in Fig 2
Fig 1
Fig 2

4
The power supply cord should be routed into the fire box along with the gas supply to keep the cable hidden,
connect into the USB socket on the side of the remote control valve ensuring the cord is routed away from any
hot surfaces and the grommet provided is used to prevent chafing to the cord when passing through the fire box
The key mechanism will now give you manual control of the remote valve as shown above
The keys have a small movement of approx 1mm.
Re fit the burner tray and fix in place the sub frame as shown below, care must be taken to get this into the
correct position as you can see in Fig 3 the bottom area of the subframe sits level to line up the manual control
mechanism and the heat outlet at the top has a clear area see Fig 4.
Fig 1
Fig 2
To Increase Flame
Press to Decrease flame
Power
Button
Fig 1

5
Fig 3
Fig 4

6
When using the appliance in conjuntion with a fireplace suite, you can use either non combustable slips like stone
granite or marble, or an Apex metal back panel.
Main Firebox
Front fascia panel always ensure that the
fascia is fitted in the correct position as in
correct fitting this may result in the
appliance not working correctly.

7
If you are plastering the appliance in then you will need to remove the plaster from the
wall around the fire enough to be able to fix a sheet of master board or non-
combustible board over the fire box when in place to be able to be plastered to a finish
ready to be decorated, you can surface fix if you wish to use non-combustable slips
such as granite, stone or marble, around the appliance.
As with all heating appliances, any decorations, soft furnishings, and wall coverings (i.e. flock, blown
vinyl and most wallpaper) positioned too close to the appliance may discolour or scorch. Possible
cracking of the plaster may occur with this type of appliance, combined with the variations of plaster
conditions and thicknesses from property to property, we recommend that a heat proof plaster be
used.
An area of 600mm above plus 300mm on either side and below should be finished with a heat proof
plaster, it may be required to use a heat proof screed under the finish, please see contact details below
of possible suppliers of these goods for your reference.
The Greener Company Vitcas
Huddersfield Road, Elland, WEST YORKSHIRE HX5 0EE 8 Bonville Road, Brislington, Bristol BS4 5NZ
www.thegreenercompany.com http://www.vitcas.com
SITE REQUIREMENTS

8
It is recomended that with the opening created prior to securing the firebox into position that all gas supply
pipe work and electrical cabling be placed in position to accomplish a clean and aesthetically pleasing finish
Opening
Requirements
MM
A
Width
610-645mm / 875-895mm (860)
B
Height
455-470mm (600)
615-630mm (6x6)
460-470mm (860)
C
Depth
340mm minimum
300mm minimum (860)
D
From Floor
300-Minimum
D
A
B
C
