API UP2000 User manual

83
8VHU0DQXDO
3DUW1XPEHU$
ZZZDOSKDSURFHVVRUFRP

838VHU0DQXDO
$ LL
© 2000 Alpha Processor, Inc. All rights reserved.
Part #: 51-0031-1A
Date: 4/7/00
Alpha Processor, Inc.
A Samsung Company
130C Baker Avenue Extension
Concord, MA 01742
Tel: [phone]
Fax: [phone]
Alpha Processor, Inc. reserves the right to make changes in its products without notice in
order to improve design or performance characteristics.
This document is considered to be preliminary with further revisions and corrections in
process. Alpha Processor, Inc. makes no representations or warranties with respect to the
accuracy or completeness of the contents of this publication or the information contained
herein, and reserves the right to make changes at any time, without notice. Alpha Processor,
Inc. disclaims responsibility for anyconsequences resulting from the use of the information
included in this publication.
This publication neither states nor implies any representations or warranties of any kind,
including but not limited to, any implied warranty of merchantability or fitness for a
particular purpose. Alpha Processor, Inc.’s products are not authorized for use as critical
components in life support devices or systems without Alpha Processor, Inc.’s written
approval. Alpha Processor, Inc. assumes no liability whatsoever for claims associated with
the sale or use (including the use of engineering samples) of Alpha Processor, Inc. products
exceptasprovidedinAlphaProcessor,Inc.’sTermsandConditionsofSaleforsuchproducts.
7UDGHPDUNV
Product names used in this publication are for identification purposes only and may be
trademarks of their respective companies.
3UHOLPLQDU\3URGXFW,QIRUPDWLRQ
The information in this publication is preliminary, and is believed to be accurate at the time
of publication.. API makes no representations or warranties with respect to the accuracy or
completeness of the contents of this publication or the information contained herein, and
reserves the right to make changes at any time, without notice.

838VHU0DQXDO 5HYLVLRQ+LVWRU\
$ LLL
5HYLVLRQ+LVWRU\
Date Rev Description
4/07/00 51-0031-1A
UP2000 User Manual initial review. This manual describes the
UP2000-A3 product, and was modified to include the following
information:
• Firmware platform moved to Reset PAL code, Alpha SRM
Console and Alpha Diagnostics
• COM1 port reserved for serial console devices
• Add remote reset capabilities
• Add thermal sensitivity information

838VHU0DQXDO 7DEOHRI&RQWHQWV
$ LY
Revision History iii
Table of Contents iv
List of Figures . . . . . . . . . . . . . . . . . vi
List of Tables . . . . . . . . . . . . . . . . . . vii
Preface viii
Chapter 1 Introduction 1-1
1.1 Features. . . . . . . . . . . . . . . . . . . . 1-1
1.2 System Components . . . . . . . . . . . . . . . 1-2
Chapter 2 System Configuration 2-1
2.1 Board Layout and Components . . . . . . . . . . . 2-1
2.2 Configuration Jumpers . . . . . . . . . . . . . . 2-4
2.3 Memory Subsystem . . . . . . . . . . . . . . . 2-5
2.3.1 Memory Configuration . . . . . . . . . . . . . 2-5
2.3.2 Memory Guidelines . . . . . . . . . . . . . . 2-6
2.4 Disk Ports . . . . . . . . . . . . . . . . . . . 2-7
2.5 Internal I/O Connections. . . . . . . . . . . . . . 2-8
Chapter 3 Electrical, Environmental and Physical Data 3-1
3.1 Power Specifications . . . . . . . . . . . . . . . 3-1
3.1.1 Power Requirements . . . . . . . . . . . . . . 3-1
3.1.2 Estimated Power Consumption . . . . . . . . . . 3-2
3.2 Environmental Specifications . . . . . . . . . . . . 3-2
3.2.1 Safety . . . . . . . . . . . . . . . . . . . 3-2
3.2.2 EMI . . . . . . . . . . . . . . . . . . . . 3-3
3.3 Enclosure Requirements . . . . . . . . . . . . . . 3-3
3.3.1 Mounting Procedures . . . . . . . . . . . . . . 3-3
3.4 Physical Parameters . . . . . . . . . . . . . . . 3-5
3.4.1 UP2000 Motherboard Parameters . . . . . . . . . . 3-5
3.4.2 Alpha Slot B Module Parameters . . . . . . . . . . 3-5
3.4.3 UP2000 Motherboard Mounting Hole Specifications . . . 3-5
3.5 I/O Shield information . . . . . . . . . . . . . . 3-7
7DEOHRI RQWHQWV

838VHU0DQXDO 7DEOHRI&RQWHQWV
$ Y
Chapter 4 Software Support 4-1
4.1 Software Overview . . . . . . . . . . . . . . . . 4-1
4.1.1 Alpha SRM Console . . . . . . . . . . . . . . 4-1
4.1.2 Alpha Diagnostics . . . . . . . . . . . . . . . 4-1
4.1.3 Operating System . . . . . . . . . . . . . . . 4-1
4.2 Alpha SRM Console . . . . . . . . . . . . . . . 4-2
4.2.1 Invoking the SRM Console . . . . . . . . . . . . 4-2
4.2.2 Command Summary . . . . . . . . . . . . . . 4-2
4.2.3 Displaying the System Configurations . . . . . . . . 4-6
4.2.4 Booting the Operating System . . . . . . . . . . . 4-11
4.2.5 Updating Firmware . . . . . . . . . . . . . . 4-13
4.2.6 Using Environment Variables . . . . . . . . . . . 4-14
4.2.7 Environment Variable Summary . . . . . . . . . . 4-15
4.2.8 Finding Help . . . . . . . . . . . . . . . . . 4-24
4.3 Alpha Diagnostics . . . . . . . . . . . . . . . . 4-25
4.4 Installing the Linux Operating System . . . . . . . . . 4-26
4.4.1 Requirements. . . . . . . . . . . . . . . . . 4-26
4.4.2 Before Installing Linux . . . . . . . . . . . . . 4-26
4.4.3 Starting the Linux OS Installation. . . . . . . . . . 4-27
Chapter 5 Troubleshooting 5-1
5.1 Hardware Startup . . . . . . . . . . . . . . . . 5-1
5.1.1 Video Presence Checklist. . . . . . . . . . . . . 5-1
5.1.2 LED Status Indicators . . . . . . . . . . . . . . 5-1
5.1.3 POST (Power On Self Test) Codes. . . . . . . . . . 5-2
5.1.4 Beep Codes . . . . . . . . . . . . . . . . . 5-3
5.2 Error Recovery Procedures . . . . . . . . . . . . . 5-3
5.2.1 Error Situations . . . . . . . . . . . . . . . . 5-3
5.2.2 Error Recovery Jumper Settings . . . . . . . . . . 5-4
5.2.3 Error Recovery Procedure . . . . . . . . . . . . 5-6
Appendix A Support, Products and Documentation A-1
A.1 Customer Support . . . . . . . . . . . . . . . . A-2
A.2 Supporting Products . . . . . . . . . . . . . . . A-2
A.3 Alpha Products . . . . . . . . . . . . . . . . . A-2
A.4 Related Publications . . . . . . . . . . . . . . . A-2
Index Index-1
Publication Evaluation Form Form-1

838VHU0DQXDO /LVWRI)L XUHV
$ YL
Figure: 1-1 UP2000 Functional Block Diagram. . . . . . . . . . . 1-3
2-1 UP2000 Motherboard Layout . . . . . . . . . . . . 2-2
2-2 Location of Configuration Jumper Blocks . . . . . . . . 2-4
2-3 Configuration Settings . . . . . . . . . . . . . . . 2-5
2-4 Memory Subsystem with Two Banks . . . . . . . . . . 2-6
2-5 Disk Ports with Pin Orientation. . . . . . . . . . . . 2-7
2-6 Internal I/O Connectors with Ground Orientation . . . . . 2-8
3-1 UP2000 Power Connectors . . . . . . . . . . . . . 3-1
3-2 UP2000 Motherboard Mounting Hole Specification . . . . . 3-6
3-3 I/O Shield . . . . . . . . . . . . . . . . . . . 3-7
5-1 LED Status Indicators . . . . . . . . . . . . . . . 5-2
5-2 J29 Configuration Jumper Block. . . . . . . . . . . . 5-5
/LVWRI)LJXUHV

838VHU0DQXDO /LVWRI7DEOHV
$ YLL
Table: 1-1 UP2000 Product Features . . . . . . . . . . . . . . 1-1
2-1 UP2000 Motherboard Jumper and Connector Component List . 2-3
3-1 Environmental Requirements . . . . . . . . . . . . 3-2
3-2 UP2000 Motherboard Physical Parameters . . . . . . . . 3-5
3-3 Alpha Slot B Module Physical Parameters . . . . . . . . 3-5
3-4 RearPanel I/O Connectors . . . . . . . . . . . . . 3-7
4-1 Summary of SRM Console Commands . . . . . . . . . 4-3
4-2 Syntax for SRM Console Commands . . . . . . . . . . 4-4
4-3 Special Characters for SRM Console . . . . . . . . . . 4-5
4-4 Device Naming Convention . . . . . . . . . . . . . 4-9
4-5 PCI Address Assignments . . . . . . . . . . . . . 4-9
4-6 Boot Command Options . . . . . . . . . . . . . . 4-12
4-7 Set Envar Options . . . . . . . . . . . . . . . . 4-14
4-8 Environment Variable Summary . . . . . . . . . . . 4-16
4-9 Auto_Action Options . . . . . . . . . . . . . . . 4-17
4-10 Boot_Osflags Options . . . . . . . . . . . . . . . 4-18
4-11 ew*0_mode Options. . . . . . . . . . . . . . . . 4-19
4-12 ew*0_protocols Options . . . . . . . . . . . . . . 4-20
4-13 Language Options . . . . . . . . . . . . . . . . 4-21
4-14 pk*0_soft_term Options . . . . . . . . . . . . . . 4-24
4-15 SRM Console Variables. . . . . . . . . . . . . . . 4-27
5-1 LED Status Indicators . . . . . . . . . . . . . . . 5-2
5-2 POST Codes Information . . . . . . . . . . . . . . 5-3
5-3 Beep Codes Information . . . . . . . . . . . . . . 5-3
5-4 Diagnostics and Flash Recovery Configuration Settings (J29) . 5-6
/LVWRI7DEOHV

838VHU0DQXDO 3UHIDFH
$ YLLL
3UHIDFH
2YHUYLHZ
This manual describes the Alpha Processor, Inc. UP2000 product,
including the UP2000 Motherboard and the Alpha Slot B Module.
The document emphasizes the Alpha System Reference Manual (SRM)
Console firmware user interface.
Topics include a description of how to:
•Install an operating system
•Check or change system configurations
•Troubleshoot basic system problems
Hardware-oriented topics include how to:
•Set system speed and L2 cache size
•Configure the memory subsystem
•Cable the I/O connections
•Cable the diskette, IDE disk, and SCSI I/O ports
$XGLHQFH
This manual is intended for technicians and engineers who support
resellers, dealers, system integrators and OEM vendors who supply
UP2000-based systems.
6FRSH
This manual describes the features, configuration options, functional
operation, troubleshooting analysis and user interface of the system and
its Alpha System Reference Manual (SRM) Console firmware. It is a part of
the Alpha Processor, Inc.’s UP2000 document set that includes the UP2000
Quick Start Installation Guide (51-0030-1A).

838VHU0DQXDO 3UHIDFH
$ L[
0DQXDO2UJDQL]DWLRQ
The UP2000 User Manual is organized as follows:
n Chapter 1, “Introduction,”presents the product features and includes
a functional block diagram of the system.
n Chapter 2, “System Configuration,”provides a pictorial layout of the
UP2000 Motherboard with its key components. Configuration
elements include jumper settings for system speed and cache memory
size. Main memory guidelines, I/O disk port cabling, and non-keyed
I/O connections are included.
n Chapter 3, “Electrical, Environmental and Physical Data,”furnishes
the electrical and environmental requirements, and physical board
dimensions.
n Chapter 4, “Software Support,”describes the firmware that forms the
UP2000 user interface. Topics include installing and upgrading an
operating system, initializing and upgrading the firmware, as well as
displaying and configuring system parameters.
n Chapter 5, “Troubleshooting,”discusses solutions for hardware and
software problems encountered during system startup.
n Appendix A, “Support, Products and Documentation,”provides
directions for obtaining additional product information and technical
support.
RQYHQWLRQVDQG'HILQLWLRQV
This section defines product-specific terminology, abbreviations, and
other conventions used throughout this manual.
$FURQ\PV
The following is a list of the acronyms used in this document and their
definitions.
Abbreviation Meaning
AGP Accelerated Graphics Post
API Application Program Interface
BIOS Basic Input/Output System
CE European Conforming
CPU Central Processing Unit

838VHU0DQXDO 3UHIDFH
$ [
cUL Canadian Underwriters Laboratory
DIMM Dual Inline Memory Module
DMA Direct Memory Access
DRAM Dynamic Random Access Memory
ECC Error Correcting Code
EIDE Enhanced Integrated Device Electronics
EMI Electromagnetic Interference
FDD Floppy Disk Drive
FIFO First In, First Out
FPGA Field Programmable Gate Array
HDD Hard Disk Drive
IDE Integrated Device Electronics
ISA Industry Standard Architecture (re: I/O Bus)
LED Light Emitting Diode
LVD Low Voltage Differential
LW Late Write
OEM Original Equipment Manufacturer
PAL Privileged Architecture Library
PCI Peripheral Component Interconnect
PIO Programmed Input/Output
PLL Phase Locked Loop
PWB Printed Wiring Board
RAM Random Access Memory
ROM Read Only Memory
SCSI Small Computer System Interface
SDRAM Synchronous Dynamic Random Access Memory
SRAM Static Random Access Memory
SRM System Reference Manual
SROM Serial Read-only Memory
SSRAM Synchronous SRAM
TIG TTL Integrated Glue Logic
UART Universal Asynchronous Receiver Transmitter
UL Underwriters Laboratory
USB Universal Serial Bus
Abbreviation Meaning

838VHU0DQXDO &KDSWHU ,QWURGXFWLRQ
$ 
KDSWHU  ,QWURGXFWLRQ
This chapter provides an overview of the UP2000 product consisting of a
UP2000 Motherboard and one or two Alpha Slot B Modules.
 )HDWXUHV
Table 1-1 provides a summary of the UP2000 product features.
Table 1-1 UP2000 Product Features
Feature Description Manufacturer
Physical Form Factor: ATX Extended (12 inch X 13 inch)
Daughter Card
Interface: Supports one or two Alpha Slot B Modules using the Alpha 21264 microprocessor, at speeds of 667 or 750 MHz Alpha Processor, Inc.
Chipset:
21272 (Tsunami)—One Cchip, four Dchips, and two
Pchips provide the following:
Compaq
•Maximum 83 MHz system bus with Double Data Rate
(DDR) transfers, maximum bandwidth of
2.67 GBytes/second
•One 256-bit memory bus
•One 64-bit, 33 MHz PCI bus with two 64-bit slots and
one 32-bit slot, and one 32-bit, 33 MHz PCI bus with
three 32-bit slots
Cache:
External Bcache with 128-bit data path for an Alpha
Slot B Module supports:
•2MB or 4 MB cache per 667 MHz processor
•4MB or 8 MB cache per 750 MHz processor
•Late Write (LW) Synchronous SRAMS (SSRAMs)
Main Memory:
•Eight 168-pin Dual Inline Memory Module (DIMM)
sockets, up to 2 GB (256 MB per DIMM)
•Supports Phase Locked Loop (PLL) or Register-based
Synchronous Direct Random Access Memory
(SDRAM) Serial Presence Detect (SPD) modules of
64 MB, 128 MB, and 256 MB
•Low Voltage Transistor-Transistor Logic (LVTTL)
compatible memory I/O
Power: ATX power connector, supplying +3.3 Vdc, ± 5 Vdc, and
±12Vdc

838VHU0DQXDO &KDSWHU ,QWURGXFWLRQ
$ 
 6\VWHP RPSRQHQWV
The functional components of the UP2000 are shown in Figure 1-1 in block
diagram form.
On-board I/O:
•CY82C693UB Peripheral Component Interconnect
(PCI)/Industry Standard Architecture (ISA) Bridge
(PCI Local Bus Specification Revision 2.1 compliant),
Enhanced Integrated Device Electronics (EIDE)
controller, and two Universal Serial Bus (USB) ports
Cypress
•AIC-7891 Small Computer System Interface (SCSI)
Controller (Ultra2 SCSI), connections for up to 15 SCSI
devices Adaptec
•FDC37C669 Super Input/Output (I/O) Controller—
2.88 MB Floppy Disk Controller (FDC), Parallel port,
two NS16C550-compliant Serial ports, Real-time
Clock (RTC) port, Keyboard, and Mouse SMC
I/O Slots:
•Four 32-bit, 33 MHz PCI Slots, PCI Local Bus
Specification Revision 2.1 compliant
•Two 64-bit, 33 MHz PCI Slots, PCI Local Bus
Specification Revision 2.1 compliant
•One ISA Slot (Shared)
Firmware: Embedded Alpha System Reference Manual (SRM)
Console
System Management
(via PCI-ISA Bridge
I2C Controller
PCF8584):
•Monitoring of processor thermal state
Philips
•Detection of processor asset record
Table 1-1 UP2000 Product Features (Continued)
Feature Description Manufacturer

838VHU0DQXDO &KDSWHU ,QWURGXFWLRQ
$ 
Figure 1-1 UP2000 Functional Block Diagram
PCI - Bus 1
Dchip
(4)
Cchip P Chip
(2)
Main
Memory
SDRAM
8DIMMs
PCI/ISA Bridge
( CY82C693UB )
Super I/O
(SMC669)
Flash
ROM Config IRQ
ISA Bus
6 PCI Slots
* 1 memory bus: 256-bit
Sysdata
capbus
Memdata*
TigBus
Motherboard
21272
PCI - Bus 0
Cmd/addr
21264
L2 Cache
2/4/8 MB
(1 or 2)
Alpha Slot B
Module
1 ISA Slot
padbus
USB
Mouse
Keyboard
Parallel Port
Serial Ports
Floppy Diskette
I
2
C
IDE
AIC
7891
AIC
3860
Ultra2
LVD
SCSI
SE
Ultra
Wide
SCSI

838VHU0DQXDO &KDSWHU 6\VWHP&RQIL XUDWLRQ
$ 
KDSWHU  6\VWHP RQILJXUDWLRQ
This chapter describes the layout and configuration of the UP2000
components.
 %RDUG/D\RXWDQG RPSRQHQWV
The UP2000 Motherboard uses onboard connectors to provide for:
n Alpha Slot B Modules
n Memory modules
n PCI and ISA modules
n I/O peripherals (keyboard, mouse, serial, parallel, and USB)
n SCSI devices
n IDE and floppy disk devices
n System power
n I/O connections (indicators and buttons)
These connectors and the system’s configuration jumper blocks are shown
in the following figure and table.
-XPSHU
RQILJXUDWLRQ
Jumper blocks with manually inserted jumpers are used to select two
system parameters:
n Speed—to match CPU rating of Alpha Slot B Module
n Size—to match L2 cache memory of Alpha Slot B Module
See section 2.2 for jumper configuration details.
0HPRU\
RQILJXUDWLRQ
Memory modules employed in the system must be selected and utilized
under guidelines shown in section 2.3.
'LVN3RUW DEOLQJ Disk ports (including sockets for diskette, IDE disk, and SCSI devices) are
shown in Figure 2-5.
,QWHUQDO,2 DEOLQJ Internal I/O connections for system I/O functions are shown in
Figure 2-6. These connectors are not keyed, but ground pin orientation is
depicted.
5HDU3DQHO,2
DEOLQJ
Note: COM1 is reserved as a serial console device. All other serial devices must
be connected to COM2 or to expansion serial ports. The RS232 Ring
Indicator signal on COM1 is connected to the Reset function on the
UP2000 Motherboard.

838VHU0DQXDO &KDSWHU 6\VWHP&RQIL XUDWLRQ
$ 
Figure 2-1 UP2000 Motherboard Layout
Cchip
Dchip 0
Dchip 1 Dchip 3
Dchip 2
Pchip 0 Pchip 1
CY82C693
PCI->ISA
Adaptec
AIC-7891
Flash ROM
BATTERY FD37C669
Adaptec
AIC-3860
TIG
Logic
Reset
EPLD
UW SCSI (SE)
Floppy Conn.
UW SCSI (LVD)
DIMM 2
DIMM 6
DIMM 3
DIMM 7
DIMM 0
DIMM 4
DIMM 1
DIMM 5
ISA Slot
PCI 32-bit Slot 4, Bus 1
PCI 32-bit Slot 3, Bus 1
PCI 32-bit Slot 5, Bus 1
PCI 64-bit Slot 1, Bus 0
PCI 64-bit Slot 0, Bus 0
PCI 32-bit Slot 2, Bus 0
Secondary Alpha Slot-B (5V)
Primary Alpha Slot-B (12V)
J5
P1
J6
J7 J8 J9 J10 J11 J12
J4 J3
J17
J16
J15
J14
J24 J23
J22
J25 J26
J28
J31
J35 J39 J37
J13
J21
J20
J19
J18
J2J1
J40 J41 J42 J43
J44 J45 J46 J47
J38
J33J32
D4 D5 D8 D9 D10
D6 D7
D11
J27
J34
J36
IDE Conn.
J29
J30
N OTE : P IN 1 OFEACH
JUMPERISINDICATEDIN
BLACK
.

838VHU0DQXDO &KDSWHU 6\VWHP&RQIL XUDWLRQ
$ 
Table 2-1 UP2000 Motherboard Jumper and Connector Component List
Comp.
No. Specification Comp. No. Specification
J1 System Chassis Fan Connector J2 System Chassis Fan Connector
J3 Keyboard/Mouse Connector J4 USB Connector
J5 D-SUB Connector (Serial IO/
Parallel IO)* J6 ISA Expansion Bus Connector
J7 32-bit PCI Slot 5, Bus 1 Connector J8 32-bit PCI Slot 4, Bus 1 Connector
J9 32-bit PCI Slot 3, Bus 1 Connector J10 32-bit PCI Slot 2, Bus 0 Connector
J11 64-bit PCI Slot 1, Bus 0 Connector J12 64-bit PCI Slot 0, Bus 0 Connector
J13 Reset Electrically Programmable
Logic Device (EPLD) In-system
Programmability (ISP) Connector J14 168-pin DIMM 0 Socket
J15 168-pin DIMM 4 Socket J16 168-pin DIMM 1 Socket
J17 168-pin DIMM 5 Socket J18 168-pin DIMM 2 Socket
J19 168-pin DIMM 6 Socket J20 168-pin DIMM 3 Socket
J21 168-pin DIMM 7 Socket J22 Alpha Slot B Connector for
Secondary Module (5V)
J23 Alpha Slot B Connector for Primary
Module (12V) J24 Floppy Drive Connector
J25 Alpha Slot B Module Power
Connector (4 pin) J26 ATX Power Connector (20 pin)
J27 System Configuration Jumper J28 AUX ATX (Optional) Power Connector
for 3.3V (6 pin)
J29 Configuration Jumper J30 IDE Bus Connector
J31 Not Used J32 Ultra-wide SCSI Single-ended (SE)
Connector
J33 Ultra-wide SCSI Low Voltage
Differential (LVD) Connector J34 CPU Speed/Flash_Sel Jumper
J35 Alpha Slot B Module Fan Connector
(Secondary) J36 Bcache Configuration Jumper
J37 Alpha Slot B Module Fan Connector
(Primary) J38 Alpha Slot B Module Fan Connector (Secondary)
J39 Alpha Slot B Module Fan Connector
(Primary) J40 Power Light Emitting Diode (LED) Connector
J41 Speaker Connector J42 Secondary Alpha Slot B Module
Debug Port Connector
Note: Connector J5 includes the COM1 and COM2 ports. COM1 is reserved for a serial console device. Connect all other
serial devices to COM2 or any expansion serial ports.

838VHU0DQXDO &KDSWHU 6\VWHP&RQIL XUDWLRQ
$ 
 RQILJXUDWLRQ-XPSHUV
The UP2000 Motherboard has four sets of programmable jumper blocks,
located at J27, J29, J34, and J36 as shown in Figure 2-2.
Alpha Slot B Module CPU speed and L2 cache size determine which
configuration settings are used. Configuration setting selections are
shown in Figure 2-3.
Figure 2-2 Location of Configuration Jumper Blocks
J43 Primary Alpha Slot B Module Debug
Port Connector J44 Power Button Connector
J45 Halt Button Connector J46 SCSI LED Connector
J47 Reset Button Connector
Table 2-1 UP2000 Motherboard Jumper and Connector Component List (Continued)
Comp.
No. Specification Comp. No. Specification
Note: Connector J5 includes the COM1 and COM2 ports. COM1 is reserved for a serial console device. Connect all other
serial devices to COM2 or any expansion serial ports.
Diskette Port
IDE Disk Port
J34
J36
J29 J27
L2 Cache size
selection Jumper
Block (J36)
CPU Speed
selection jumper blocks
(J27, J29, and J34)
NOTE:AllthreeCPUSpeed
Selection jumper blocks
must be set correctly to
implement a particular
speed rating.

838VHU0DQXDO &KDSWHU 6\VWHP&RQIL XUDWLRQ
$ 
Figure 2-3 Configuration Settings
 0HPRU\6XEV\VWHP
 0HPRU\ RQILJXUDWLRQ
The memory subsystem is comprised of two DIMM banks, designated
0+]0%
J27
J29
J34
J27
J29
J34
l
l
l
l
l
ll l
l
ll
ll
l
l
l
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
l
l
l
l
l
ll l
l
ll
ll
l
l
l
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
%LW
%LW
%LW
%LW
%
L
W


%
L
W


l
l
-XPSHUHG2SHQ
RIHDFKMXPSHUEORFN
2EVHUYHWKHELWRULHQWDWLRQ
1RWH /HJHQG
0%
J36
l
l
l
l
l
ll l
l
ll
ll l
l
l
0%
l
l
l
l
l
ll l
l
ll
ll
l
l
l
%
L
W


%
L
W


J36
J27
J29
J34
l
l
l
l
l
ll l
l
ll
ll l
l
l
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
0%
l
l
l
l
l
ll l
l
ll
ll
l
l
l
J36
0+] 0% 0+] 0%
0+]0%
J27
J29
J34
l
l
l
l
l
ll l
l
ll
ll
l
l
l
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
ll
0%
J36
l
l
l
l
l
ll l
l
ll
ll
l
l
l

838VHU0DQXDO &KDSWHU 6\VWHP&RQIL XUDWLRQ
$ 
Bank 0 and Bank 1. Each bank has four slots (sockets) that accept 168-pin,
PC100 SDRAM PLL Register based SPD DIMM modules. Slots are
configured in an alternating pattern. See Figure 2-4 below.
 0HPRU\*XLGHOLQHV
Use the following rules:
n A bank must be fully populated (all four assigned slots must be
utilized).
n Populate Bank 0 first.
n A bank must utilize the same type, size, and speed DIMMs.
n Bank 0 and Bank 1 can have different type, size, and speed DIMMs.
n Memory is supported in a size range between 256 MB (minimum) to
2 GB (maximum).
Figure 2-4 Memory Subsystem with Two Banks
Bank 0
Bank 0 - Slot 0 (J14)
Bank 0 - Slot 1 (J16)
Bank 0 - Slot 2 (J18) Bank 0 - Slot 3 (J20)
Bank 1 - Slot 4 (J15)
Bank 1 - Slot 5 (J17)
Bank 1 - Slot 6 (J19) Bank 1 - Slot 7 (J21)
Bank 1
Alternating Slots
Memory Subsystem

838VHU0DQXDO &KDSWHU 6\VWHP&RQIL XUDWLRQ
$ 
 'LVN3RUWV
A pictorial view of the UP2000 disk I/O ports is shown in Figure 2-5. The
IDE and diskette port sockets are keyed with one or more notches.
The SCSI connectors are high density 68-pin female sockets. For certain
SCSI disk peripherals, a 50-pin to 68-pin adapter is required.
Figure 2-5 Disk Ports with Pin Orientation
SCSI Connectors
Disk Ports
Diskette
IDE Bus
Ultra/Wide
Ultra2 LVD
Single-ended
-
-
- -
3LQ6RFNHWV
6RFNHW3LQ
6WDWXV/('V
IHPDOH
3LQ
3LQ
+LJK'HQVLW\
