Apollo GX50 GPS User manual

Apollo
Model GX50 GPS
Model GX60 GPS/Comm
Model GX65 GPS/Comm
Installation Manual
Installation ManualInstallation Manual
Installation Manual
March 1999 560-0959-03

1999 by II Morrow Inc. All rights reserved.
Printed in the USA
No part of this document may be transmitted, reproduced, or copied in any form or by any means
without the prior written consent of II Morrow Inc. Due to II Morrow’s commitment to
constantly improve the quality and performance of our products, information contained in this
document is subject to change without notice.
II Morrow, Apollo, and Flybrary are registered trademarks of II Morrow Inc.
II Morrow Inc. 2345 Turner Rd. SE
PO Box 13549 Salem, OR 97302
Salem, OR 97309 USA
Phone [phone]
1-800-525-6726
In Canada 1-800-654-3415
FAX [phone]

HISTORY OF REVISIONS
Revision Date Description
-- Nov 5, 1997 Initial release.
-01 Nov 11, 1997 Corrected altitude input requirements.
-01b June 10, 1998 Added references about altitude encoders, F/AD, & serial
interface
-02 June 26, 1998 Addition of Model GX65 GPS/Comm
-03 Mar 24, 1999 Test Mode additions, Serial data output, Apollo ACU added
IMPORTANT NOTE
“The conditions and tests required for TSO approval of this article are minimum performance
standards. It is the responsibility of those desiring to install this article on or within a specific
type or class of aircraft to determine that the aircraft operating conditions are within TSO
standards. The article may be installed only if further evaluation by the applicant documents
an acceptable installation and is approved by the Administrator.”
Source: FAA TSO-C129a, TSO-C37d, TSO-C38d, and TSO-C128
ORDERING INFORMATION
To receive additional copies of this publication, order part # 560-0959-03, Apollo GX50 GPS
and GX60/GX65 GPS/Comm Installation Manual.

NOTES

Table of Contents
Apollo GX50/60/65 Installation Manual i
TABLE OF CONTENTS
SECTION 1 - INTRODUCTION.................................................................................................1
ABOUT THIS MANUAL......................................................................................................................1
APOLLO GX50/60/65 DESCRIPTION .................................................................................................1
FEATURES.........................................................................................................................................3
SYSTEM CONFIGURATIONS ...............................................................................................................4
VFR GPS NAVIGATION INSTALLATION.....................................................................................................................4
IFR GPS NAVIGATION INSTALLATION ......................................................................................................................5
COMM TRANSCEIVER - GX60/65..............................................................................................................................5
DATABASE UPDATES........................................................................................................................5
REGULATORY COMPLIANCE .............................................................................................................6
UNPACKING THE EQUIPMENT............................................................................................................6
PACKAGE CONTENTS........................................................................................................................6
OTHER REQUIRED MATERIALS .........................................................................................................8
SPECIAL TOOLS REQUIRED ...............................................................................................................8
LICENSE REQUIREMENTS..................................................................................................................8
SECTION 2 - INSTALLATION..................................................................................................9
PRE-INSTALLATION INFORMATION....................................................................................................9
INSTALLATION OVERVIEW................................................................................................................9
INSTALLATION CONSIDERATIONS......................................................................................................9
MOUNTING CONSIDERATIONS....................................................................................................................................9
MINIMUM SYSTEM CONFIGURATION .........................................................................................................................9
ALTITUDE INPUT........................................................................................................................................................9
EQUIPMENT MOUNTING..................................................................................................................10
ELECTRICAL CONNECTIONS............................................................................................................12
POWER ....................................................................................................................................................................12
AVIONICS OUTPUTS.................................................................................................................................................12
SERIAL INTERFACE..................................................................................................................................................12
SPEAKER AND HEADPHONE OUTPUTS (GX60/65 ONLY) .........................................................................................13
MICROPHONE INPUTS (GX60/65 ONLY)..................................................................................................................13
TRANSMIT KEY INPUT (GX60/65 ONLY).................................................................................................................13
INTERCOM SELECTOR SWITCH (GX60/65 ONLY) ....................................................................................................13
REMOTE FLIP/FLOP INPUT (GX60/65 ONLY)...........................................................................................................13
ANTENNA INSTALLATION AND CONNECTIONS ................................................................................13
COMM ANTENNA (GX60/65 ONLY)........................................................................................................................13
GPS ANTENNA........................................................................................................................................................14
POST INSTALLATION CHECKOUT.....................................................................................................24
TEST MODE CHECKOUT AND SETUP........................................................................................................................24
GPS NAVIGATION CHECKOUT.................................................................................................................................26
VHF COMM CHECKOUT (GX60/65)........................................................................................................................27
FINAL SYSTEM CHECK............................................................................................................................................28
SECTION 3 - SPECIFICATIONS.............................................................................................30
ELECTRICAL ...................................................................................................................................30
PHYSICAL .......................................................................................................................................30
ENVIRONMENTAL ...........................................................................................................................31
GPS RECEIVER PERFORMANCE ......................................................................................................31

Table of Contents
ii Apollo GX50/60/65 Installation Manual
AVIONICS OUTPUTS........................................................................................................................ 32
ALTITUDE INPUT REQUIREMENTS................................................................................................... 33
ANNUNCIATOR REQUIREMENTS ..................................................................................................... 33
COMM RECEIVER PERFORMANCE (GX60/65 ONLY)....................................................................... 34
COMM TRANSMITTER PERFORMANCE (GX60/65 ONLY)................................................................ 34
INTERCOM PERFORMANCE (GX60/65 ONLY) ................................................................................. 35
CONTROL INPUTS ........................................................................................................................... 35
ANTENNA REQUIREMENTS ............................................................................................................. 35
GPS ANTENNA ........................................................................................................................................................35
COMM ANTENNA.....................................................................................................................................................35
SERIAL INTERFACE......................................................................................................................... 35
REAR CONNECTOR PINOUT ............................................................................................................ 36
SECTION 4 - LIMITATIONS................................................................................................... 39
INSTALLATION................................................................................................................................39
OPERATIONAL................................................................................................................................39
APPENDIX A - TROUBLESHOOTING ................................................................................. 41
CONTACTING THE FACTORY FOR ASSISTANCE................................................................................ 42
APPENDIX B - PERIODIC MAINTENANCE ....................................................................... 43
LITHIUM BATTERY REPLACEMENT................................................................................................. 43
EQUIPMENT CALIBRATION ............................................................................................................. 43
REFERENCE OSCILLATOR (GX60/65) ......................................................................................................................43
CLEANING THE FRONT PANEL ........................................................................................................ 43
APPENDIX C - ENVIRONMENTAL QUALIFICATIONS.................................................. 45
APPENDIX D - ACCESSORIES............................................................................................... 47
FROM II MORROW.......................................................................................................................... 47
COMMERCIALLY AVAILABLE ......................................................................................................... 50
APPENDIX E - SERIAL INTERFACE SPECIFICATIONS................................................. 53
MOVING MAP OUTPUT................................................................................................................... 53
BINARY NEAREST LIST DATA (WHEN EXTENDED DATA IS ENABLED ONLY).................................. 55
ANNUNCIATOR OUTPUTS (WHEN EXTENDED DATA IS ENABLED ONLY)......................................... 56
FLIGHT PLAN WAYPOINT TYPES (WHEN EXTENDED DATA IS ENABLED ONLY).............................. 58
COMM DATA OUTPUT .................................................................................................................... 59
ALTITUDE ENCODER/CONVERTER INPUT........................................................................................ 61
FUEL / AIR DATA COMPUTER INPUT............................................................................................... 62

Table of Contents
Apollo GX50/60/65 Installation Manual iii
LIST OF TABLES
TABLE 1 PACKAGE CONTENTS ........................................................................................................7
TABLE 2 COMM INTERFACE CONNECTOR PINOUT .........................................................................36
TABLE 3 NAVIGATION INTERFACE CONNECTOR PINOUT................................................................37
TABLE 4 TROUBLESHOOTING GUIDE .............................................................................................41
TABLE 5 RS-232 SERIAL INTERFACE SELECTIONS.........................................................................53
TABLE 6 MOVING MAP ASCII NAVIGATION DATA.......................................................................54
TABLE 7 NEAREST WAYPOINT LIST DATA.....................................................................................55
TABLE 8 ANNUNCIATOR OUTPUT DATA........................................................................................56
TABLE 9 MOVING MAP BINARY ROUTE DATA ..............................................................................57
TABLE 10 FLIGHT PLAN WAYPOINT TYPE.....................................................................................58
TABLE 11 ALTITUDE INPUT DATA .................................................................................................61
TABLE 12 FUEL / AIRDATA MESSAGE DATA .................................................................................63
LIST OF ILLUSTRATIONS
FIGURE 1 GX50 FRONT PANEL........................................................................................................2
FIGURE 2 GX60/65 FRONT PANEL ..................................................................................................2
FIGURE 3 UNIT INSERTION CHECK.................................................................................................10
FIGURE 4 MOUNTING FRAME ASSEMBLY ......................................................................................11
FIGURE 5 CABLE ROUTING............................................................................................................11
FIGURE 6 REAR COAX CONNECTOR ASSEMBLY ............................................................................15
FIGURE 7 TNC COAX CONNECTOR ASSEMBLY.............................................................................15
FIGURE 8 GX50/60 POWER AND AVIONICS CONNECTIONS ...........................................................16
FIGURE 9 - APOLLO ACU TO APOLLO GX50/60 WIRING DIAGRAM ..............................................17
FIGURE 10 - APOLLO ACU TO APOLLO GX65 WIRING DIAGRAM..................................................18
FIGURE 11 CONNECTIONS WITH MD41 ANNUNCIATOR / RELAY...................................................19
FIGURE 12 RS-232 SERIAL CONNECTIONS ....................................................................................20
FIGURE 13 GX60/65 COMM WIRING DIAGRAM ............................................................................21
FIGURE 14 GX60/65 TYPICAL AUDIO PANEL CONNECTIONS ........................................................22
FIGURE 15 - GX65 POWER AND AVIONICS CONNECTIONS .............................................................23
FIGURE 16 UNIT DIMENSIONS........................................................................................................31
FIGURE 17 - EXAMPLE ANNUNCIATORS..........................................................................................33
FIGURE 19 MOVING MAP DATA OUTPUT (EXTENDED DATA DISABLED).......................................58
FIGURE 20 MOVING MAP DATA OUTPUT (EXTENDED DATA ENABLED)........................................59
FIGURE 21 ALTITUDE DATA INPUT................................................................................................62
FIGURE 22 FUEL / AIRDATA DATA INPUT ......................................................................................64

Table of Contents
iv Apollo GX50/60/65 Installation Manual
NOTES

Introduction
Apollo GX50/60/65 Installation Manual 1
SECTION 1 - INTRODUCTION
ABOUT THIS MANUAL
This manual describes the installation of the Apollo GX50 GPS and GX60/65 GPS/Comm
units. It is intended for use by persons certified by the Federal Aviation Administration (FAA)
to install aircraft navigation devices. It includes installation and checkout procedures for the
GX50, GX60, GX65 and units to standards described in FAA advisory circulars AC 20-138
(for GPS) and AC 20-67B (for comm).
The GX50 and GX60/65 units are equivalent except that the GX50 does not include the VHF
Comm. Throughout this manual, references to the GX50/60/65 are for the GX50, GX60, and
GX65. The GX65 differs from the GX60 in that it is not certified for IFR approaches.
Provides an introduction to the Apollo GX50/60/65 units. TSO certification
information is also included in this section.
Includes installation and checkout procedures.
Includes complete specifications.
Includes limitations for the equipment and installation.
Includes troubleshooting information.
Includes periodic maintenance requirements.
Includes the environmental qualification form.
Includes information on accessories.
Includes serial data specifications.
APOLLO GX50/60/65 DESCRIPTION
The Apollo GX50 GPS is a TSO-C129a, Class A1 GPS supplemental navigation receiver for
IFR en route, terminal, and non-precision approach operation. The unit features a moving map
display and a database provided by means of a plug-in data card for convenience in changing
and updating the database.
The Apollo GX60 GPS/Comm includes the same GPS capabilities as the GX50 and includes
a 760 channel VHF Comm transceiver. The Apollo GX65 includes the same GPS and Comm
capabilities as the GX 60, except that it is not certified for non-precision approach.
Section 1
Section 2
Section 3
Section 4
Appendix A
Appendix B
Appendix C
Appendix D
Appendix E

Introduction
2 Apollo GX50/60/65 Installation Manual
Figure 1 GX50 Front Panel
Figure 2 GX60/65 Front Panel
