APS 12295 User manual

1
Instruction manual
-For Item number 12295-
Foreword
Dear Customer,
please read these operating instructions carefully before
commissioning the induction hotplate. Please especially
observe the safety notices on the following pages.
Keep these instructions for future reference and pass them on
if you give the hotplate away to someone else.

2
The function mode and product advantages of induction hotplates
With induction hotplates, an electric voltage is applied on a conductor spool
beneath the glass ceramics. This creates magnetic fields, which directly heat
up the bottom of the cookware through a physical effect.
This means saving time and energy, because contrary to common hotplates,
the cookware is heated up, not the element and the glass ceramics. Due to the
technical characteristics described above, another advantage is very short
start-up cooking time.
In addition, the heat supply promptly adapts to changed settings and can be
controlled in small steps. The induction hotplate reacts to changed settings just
as fast as a gas stove, as the energy reaches the pot immediately without
having to heat up other materials first. The induction technology combines this
fast reaction with the basic advantage of electricity, meaning being able to
exactly adjust the heat supply.
Additional advantages of an induction hotplate:
As the hotplate is only heated up indirectly via the bottom of the cookware,
over spilling food cannot stick and burn and there is hardly not any danger of
burns for user. The glass ceramics is only heated up by the hot cookware.
Once you take the cookware off the hotplate, the device automatically
switches to standby mode.
The device detects whether suitable cookware is placed in the hotplate. If this
is not the case, no energy is transmitted.
Prior to commissioning
Check the device for visible damage.
The power connections and the plug may not show any damages. If you detect
damage, have the device checked by a qualified technician prior to putting it
into operation in order to avoid any danger. This device is suitable for the
intended use only. It is not intended for commercial use.

3
General safety regulations
The product you have purchased corresponds to the latest state of technology
and the accepted safety regulations, still there are potential risks. Only operate
the induction hotplate in an immaculate condition and observe these operating
instructions!
Attention:
In order to prevent possible injuries or electric shock, please observe the
following:
Never touch the device and the power plug with wet hands.
Do not connect the device to the same outlet with other devices. Connect the
device to a suitable outlet.
Never move the device by pulling on the power cable.
Do not move the induction hotplate during cooking or with hot cookware on
top of it.
Do not place any empty containers on the device.
Do not operate the device on top of any other electric appliances such
as ceramic hob or electronic oven etc.
Do not operate the device on any metallic surface which is too thin
and easy to become deformed.
Check the main connection cable for damage from time to time. Never
operate the device when the cable is damaged. If the main connection cable
shows defects, let a qualified electrician exchange it.
Never use the device when it does not function properly, shows damage or in
case it was dropped.
Do not leave the device unsupervised during operation. Keep children and
other incompetent persons as well as persons under influence of drugs or
alcohol away from the device.
WARNING: This appliance is not intended for use by persons (including
children) with limited physical, sensory or mental abilities or who lack
necessary experience and/or skills unless these persons act under the
supervision of a person responsible for their safety or they were instructed
by such a person on how to use the appliance.
Do not submerge the device in water or other liquids and do not wash it in the
dishwasher.

4
Only qualified experts may perform repair and maintenance work on the
device using original replacement and accessory parts. Never attempt to
repair the device yourself!
Scientific tests have proven that induction hotplates do not pose a risk.
However, persons with a pacemaker should clear with their doctor weather
to take care of some special handling advices.
Installing the device
Place the device on a stable and level non-metallic surface.
Never place the device on a flammable surface (e.g. table cloth, carpet, etc.).
Do not block the ventilation slots of the device. This may overheat the
device. Keep a minimum distance of 5 to 10 cm to walls or other items.
Do not place the induction hotplate next to devices or objects, which react
sensitively to magnetic fields (e.g. radios, TVs, cassette recorders, etc.).
Do not place induction hotplates next to open fires, heaters or other sources
of heat.
Make sure that the main connection cable is not damaged or squashed
beneath the device.
Make sure that the main connection cable does not come into contact with
sharp edges and/or hot surfaces.
The device should be connected to a rolled-out extension cable with a
maximum length a 3 m and a cross-section of 2 mm. If an intermediate
switch is used, it must be rated at min 16 A.
Commissioning the device
Prior to connecting the device, check whether the voltage indicated on the
type plate corresponds to the voltage supply in your home. A wrong
connection may lead to grave damage on the device and injury to persons.
The hotplate surface consist of temperature-resistant ceramics. In case of
damage, even if this concern only a small tear, disconnect the device from the
power supply immediately and contact the customer service.
Place the hot pans in the hob area only. Never place them on the control
panel or the frame.
Do not place any magnetically objects like credit cards, cassettes etc. on the
glass surface while the device is in operation.

5
In order to avoid overheating, do not place any aluminium foil or metal plates
on the device. Warning: Please do not put the induction cooker on an
iron/steel board, while operating. Due to electromagnetic reason, the
iron/steel board may heat and damage the bottom of the induction cooker.
Do not insert any objects like wires or tools into the ventilation slots.
Attention: this may Cause electric shocks.
We recommend not placing any metal kitchen utensils, cookware or
pan lids, knives or other metal objects on the hotplate. These may
heat up when the device is turned on.
Do not touch the hot surface of the ceramic field. Please note: the
induction hotplate does not heat up itself during cooking, but the
temperature of the cookware heats up the hotplate!
Do not heat up any unopened tins on the induction hotplate. A heated tin
could explode; therefore remove the lid under all circumstances beforehand.
If you do not use the device for an extended period, we recommend you
disconnect it from the electric outlet.
Suitable and unsuitable cookware
Suitable cookware
Pots and pans with magnetic bottom, as stainless steel pots with iron bottom,
cast iron enameled pans
Flat bottom pans and pots with a diameter of 12 to 19 cm with magnetic
bottom
Max. weight pot and content 6 kg.
Unsuitable cookware
Pots and pans with a diameter of less than 12 cm
Ceramic pots, heat-proof glass
Copper pots and pans, aluminium pots and pans
Cookware with feet
Containers with a curved bottom

6
Operating the device
Plug the power plug into a suitable outlet.
The control lamp of the ON/OFF switch lights up and an acoustic signal
sounds.
Now the device is in standby mode.
Place the suitable cookware in the centre of the hotplate.
Now press the ON/OFF switch to turn on of the induction hotplates on. The
control lamp “Stage” blinks and an acoustic signal sounds.
Press the Function Key . The preset power stage “3” is selected and the
device turn on.
Do not place any empty cookware on the ceramic field. Heating an empty pot
or pan activates the overheating protection and device turns off.
Do not operate the device if it is damaged in any way or does not function
properly.
The use of accessories and spare parts not recommended by the manufacturer
may lead to damage on the device and injuries.
Cleaning and maintenance
Pull the power plug prior to cleaning the device. Do not use any caustic
cleaningagents and make sure that no water penetrates the device.
To protect yourself from electric shock, never immerse the device, its cables
and the plug in water or other liquids.
Wipe off the ceramic field with a damp cloth or use a mild, non-abrasive soap
solution.
Wipe off the casing and the operating panel with a soft cloth or a mild
detergent.
Do not use any petrol products to not damage the plastic parts and the
casing/operating panel.
Do not use any flammable, acidy or alkaline materials or substances near the
device,as this may reduce the service life of the device and lead to
deflagration when the device is turned on.
Make sure that the bottom of the cookware does not scrape across the surface
of the ceramic field, although a scratched surface does not impair the use of
the device.
Make sure that the device was properly cleaned before storing it in a dry
place.

7
Disposal
Dispose of the packaging in the proper manner. If at any time in the future you should
need to dispose of this product please note that Waste electrical products should not be
disposed of with household waste. Please Recycle where facilities exist. Check with
your Local Authority or retailer for recycling advice.
(Waste Electrical and Electronic Equipment Directive)
Technical data
Noise emission
The workplace related noise emission of this appliance is lower than 70
dB(A).
This appliance is not intended to be operated by means of an external timer or separate
remote-control system.
Operating time limitation:
It counts from the last setting. The operating time limitation will cause the cook top to
switch off automatically if no more further operation is activated in the next 2 hours.
CE Declaration of Conformity
This product conforms to the essential requirements of the following EU
safety directives:
EMC Directive 2004/108/EC
Low Voltage Directive 2006/95/EC
Name
Induction Hotplate Basic 12295
Item no.
12295
Temperature range
60°C to 140°C
Power
Up to 900 Watt / dependent on the cookware
Connection
220-240V / 50HZ
Dimensions h/b/t
Ø 24 cm / Height 7,5 cm

8
Trouble Shooting
The control lamp of ON/OFF button flashing, a beep is heard every 3 seconds.
Self-help: this indicates there is no pot on cooking area, please place a suitable pot on
cooking area.
The control lamp No.1 flashing (<100V)
Self-help: Make sure the appliance is connected to the voltage indicated on the rating
label.
The control lamp No. 2 flashing (>275V)
Self-help: Make sure the appliance is connected to the voltage indicated on the rating
label.
The control lamp No. 3 flashing
Self-help: the temperature sensor of IGBT open or short circuit. Please send back to
customer service.
The control lamp No. 4 flashing
Self-help: press ON/OFF switch once to solve the problem.
The control lamp No. 5 flashing
Self-help: The temperature sensor underneath the ceramic glass is defective. Please
send back to customer service.
The control lamps No. 1 and No. 2 both flashing
Self-help: Eliminate the course of overheating. Once the cook top has cooled down,
the appliance can be put into operation again.

9
For this device we guarantee of 24 months, starting with the date of sale
regarding defects due to faulty manufacture of material. Your legal warranty
claims according to §439ff. BGB-E are not affected by this. This guarantee
does not accept defects due to inappropriate treatment or use as well as
defects which do not influence the function or the value of the induction
hotplates essentially. Further on we do not grant a guarantee for wear parts or
damage in transit as well as for defects due to repairs which have not been
effected by us.
In case of legitimate claims we will decide whether to repair the device or to
send
you a new one.
Apparent defects have to be indicated within 14 days after delivery.
Additional claims will not be accepted.
In order to assert your warranty claims please contact us before sending the
device (always together with the sale slip!) to the following address.
Assheuer + Pott GmbH & Co. KG
Talweg 11
59846 Sundern
Germany
[email protected]

10
Instruction
The induction plate can only
be used in relation with the
relevant ring.
Frame
Item no.: 12291
for „Globe“ 12398/ 12393/ 12403 (round)
Item no.: 12296
for „Globe“ 12394/ 12404 (square, GN 1/1)
Induction plate
Item no.: 12295
First put the ring into the
notch of the frame.
The wire of the induction plate
has to be carried below the
frame. Then please insert the
induction plate into the ring to
keep it firm.
Put the chafing dish on top
and the induction plate can
now be used.
2.
1.
3.
