APURO DY993-A User manual

Model:
DY993-A/DY994-A/DY995-A/DY996-A/DY997-A/
DY998-A
Bistro Contact
Grill
Instruction manual
DY993-A-DY998-A_A5_v1 20200915.indb 1DY993-A-DY998-A_A5_v1 20200915.indb 1 2020/9/15 10:102020/9/15 10:10

2
AU Telephone Helpline: 1300225960
Safety Tips
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out
installation and any repairs if required. Do not remove any
components on this product.
• Consult Local and National Standards to comply with the
following:
- Health and Safety at Work Legislation
- Fire Precautions
- Wiring Regulations
- Building Regulations
• Caution! Hot surface!
• DO NOT immerse the appliance in water.
• DO NOT clean with jet/pressure washers.
• DO NOT carry when hot.
• DO NOT leave the appliance unattended during operation.
• DO NOT obstruct or cover the appliance in any way when in
use.
• During and after cooking, the unit is still hot. Never touch the
surface to avoid scalding.
• Not suitable for outdoor use.
• Always switch off and disconnect the power supply to the
appliance before when not in use.
• This appliance must only be used in accordance with these
instructions and by persons competent to do so.
• Keep all packaging away from children. Dispose of the
packaging in accordance to the regulations of local authorities.
• If the power cord is damaged, it must be replaced by the
Apuro agent or a recommended qualified technician in order
to avoid a hazard.
DY993-A-DY998-A_A5_v1 20200915.indb 2DY993-A-DY998-A_A5_v1 20200915.indb 2 2020/9/15 10:102020/9/15 10:10

3
AU
Telephone Helpline: 1300225960
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience or knowledge, unless they have been
given supervision or instruction concerning the use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play
with the appliance.
• Apuro recommends that this appliance should be periodically
tested (at least annually) by a Competent Person. Testing
should include, but not be limited to: Visual Inspection,
Polarity Test, Earth Continuity, Insulation Continuity and
Functional Testing.
Product Description
• DY993-A - Apuro Bistro Contact Grill, Single
Ribbed plates
• DY994-A - Apuro Bistro Contact Grill, Double
Ribbed plates
• DY995-A - Apuro Bistro Contact Grill, Large
Ribbed plates
• DY996-A - Apuro Bistro Contact Grill, Single
Flat plates
• DY997-A - Apuro Bistro Contact Grill, Large
Flat plates
• DY998-A - Apuro Bistro Contact Grill, Double
Flat plates
Introduction
Please take a few moments to carefully read through this manual. Correct maintenance and operation of
this machine will provide the best possible performance from your Apuro product.
Pack Contents
The following is included:
• Contact Grill
• Scraper
• Allen Key
• Instruction manual
Apuro prides itself on quality and service, ensuring that at the time of packaging the contents are
supplied fully functional and free of damage.
Should you find any damage as a result of transit, please contact your Apuro dealer immediately.
Installation
• Remove the Grill from its packaging and be certain that all protective plastics and residues are
thoroughly cleaned from its surface.
• Locate on a firm level surface.
• Apuro recommended that you allow no less than 100mm ventilated gap around the perimeter of this
unit.
• Ensure that the stainless steel waste tray is correctly positioned.
• Connect to the electricity supply using the plug, the Grill is now ready to turn on and operate.
DY993-A-DY998-A_A5_v1 20200915.indb 3DY993-A-DY998-A_A5_v1 20200915.indb 3 2020/9/15 10:102020/9/15 10:10

4
AU Telephone Helpline: 1300225960
Preparing the cooking surface
• Make sure the cooking surface is clean, turn the unit on and apply a generous amount of oil to the
plates.
• Using the thermostat control, set the Grill to 110°C.
• When the Grill has reached temperature, switch off and carefully wipe any excess oil from the plates.
Operation
• The Contact Grill should be turned on at least 5 minutes before use.
• To get efficient use out of this unit while in intermittent use, it is recommended that the Grill plates
remain closed and the thermostat turned down, when not cooking. This will assist in reducing power
consumption and also allow for quicker heat response when needed.
• Apuro recommends that the cooking surface is lightly greased before each use.
• A temperature setting of between 200°C and 220°C will be sufficient for general cooking. This may
vary for particular food types, individual needs, or experience.
• Simply place the food products on the bottom grilling surface and lower the top plate down, and cook
to your needs.
Note: If top plate becomes loose/stiff, use the Allen key supplied to adjust the
tension. Turn clockwise to tighten, anti-clockwise to loosen.
Note: With the new treatment for the flat plates, the surfaces now are smoother
and thus better for cooking and cleaning. Whereas, the initial surfaces may
appear to have ribbed markings with the first time use. After several hours of
cooking, such markings will start to fade/disappear.
Cleaning, Care & Maintenance
Before starting to clean the Grill, disconnect from the electricity supply by removing the plug from the
socket.
Clean the cooking surface regularly. We recommend it is cleaned after every use session.
When the cooking surfaces are still warm, wash with warm soapy water and then rinse thoroughly with
clean water. This will help to stop food sticking to the plates. Remove the fat drip tray and wash in warm
soapy water.
Other surfaces can be wiped over with a damp cloth to remove all food residues. Do not immerse the
Contact Grill in water or use water sprays to clean it.
If grease is permitted to accumulate, it will begin to carbonise into a hard substance that is extremely
difficult to remove. To prevent this, follow the cleaning steps below:
• Always turn OFF the appliance and disconnect from the power supply before cleaning.
• Allow the appliance to cool before cleaning, but for best results clean the plates when they are still
slightly warm.
• Use warm, soapy water and a damp cloth to clean the exterior of the appliance.
• Take care when using scrapers to remove cooking residues as they can damage the cooking surface.
• Dry thoroughly after cleaning.
• The Apuro dealer or qualified technician should carry out repairs if required.
DY993-A-DY998-A_A5_v1 20200915.indb 4DY993-A-DY998-A_A5_v1 20200915.indb 4 2020/9/15 10:102020/9/15 10:10

5
AU
Telephone Helpline: 1300225960
Scraping
• After each use, scrape the appliance with a scraper/grill stone/copper brush or flexible spatula to
remove excess fat and food. A waste tray is provided for the scrapings if necessary.
• If there is an accumulation of burned fat or food, the cooking surface should be thoroughly scoured
and re-seasoned.
Note: It is vital that the cooking surface is re-seasoned after scouring.
Warning: Do not use steel wool as it may leave shards that could Contaminate
food.
Waste tray
• This appliance features a waste tray to collect any liquid or fats that run off during cooking.
• At least once a day, remove and empty the waste tray before washing with warm, soapy water.
• Do not allow the tray to overfill, or excess grease will run out of the overflow hole at the front of the
tray.
Warning: Do not remove tray during or immediately after use as the contents
will be hot.
Troubleshooting
Fault Probable Cause Solution
Appliance not
working
The unit is not switched on Check the unit is plugged in correctly and
switched on
Plug and lead are damaged Call Apuro agent or qualified Technician
Power supply Check power supply
Internal wiring fault Call Apuro agent or qualified technician
Appliance does
not reach set
temperature
Faulty thermostat Call Apuro agent or qualified technician
Faulty element Call Apuro agent or qualified technician
Appliance heats up
but indicator light
does not come on
Indicator light has expired Call Apuro agent or qualified technician
Power indicator
light comes on but
appliance does not
heat up
Faulty element Call Apuro agent or qualified technician
Faulty thermostat Call Apuro agent or qualified technician
Thermostat set incorrectly Check thermostat
Appliance slow to
heat up
Cooking surface not cleaned Clean cooking surface as instructed
Faulty element Call Apuro agent or qualified technician
No power Thermal cut-out switch is
activated
Press re-set switch on rear of unit
DY993-A-DY998-A_A5_v1 20200915.indb 5DY993-A-DY998-A_A5_v1 20200915.indb 5 2020/9/15 10:102020/9/15 10:10

6
AU Telephone Helpline: 1300225960
Technical Specifications
Model Voltage Power Current Plate Type Dimensions
H x W x D mm Weight
Top Bottom
DY993-A 220-240V~, 50Hz 1500W 6.5A Rib Rib 210 x 290 x 320 14.5kg
DY994-A 220-240V~, 50Hz 2900W 12.6A Rib Rib 210 x 540 x 320 27kg
DY995-A 220-240V~, 50Hz 2200W 9.6A Rib Rib 210 x 380 x 320 19kg
DY996-A 220-240V~, 50Hz 1500W 6.5A Flat Flat 210 x 290 x 320 16kg
DY997-A 220-240V~, 50Hz 2200W 9.6A Flat Flat 210 x 380 x 320 21kg
DY998-A 220-240V~, 50Hz 2900W 12.6A Flat Flat 210 x 540 x 320 29kg
Electrical Wiring
The plug is to be connected to a suitable mains socket.
This appliance is wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
This appliance must be earthed.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Compliance
The product must not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and environmentally safe
recycling process. For further information on how to dispose of this product correctly, contact the product
supplier, or the local authority responsible for waste disposal in your area.
Apuro parts have undergone strict product testing in order to comply with regulatory
standards and specifications set by international, independent, and federal authorities.
Apuro products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written permission of Apuro.
Every effort is made to ensure all details are correct at the time of going to press, however, Apuro reserve the right to
change specifications without notice.
DY993-A-DY998-A_A5_v1 20200915.indb 6DY993-A-DY998-A_A5_v1 20200915.indb 6 2020/9/15 10:102020/9/15 10:10

DECLARATION OF CONFORMITY
•Conformiteitsverklaring • Déclaration de conformité • Konformitätserklärung • Dichiarazione di conformità •
• Declaración de conformidad • Declaração de conformidade
Equipment Type • Uitrustingstype • Type d'équipement • Gerätetyp
• Tipo di apparecchiatura • Tipo de equipo • Tipo de equipamento
Model • Modèle • Modell • Modello
• Modelo • Malli
Single Ribbed Bistro Contact Grill
Double Ribbed Bistro Contact Grill
Large Ribbed Bistro Contact Grill
Single Flat Bistro Contact Grill
Large Flat Bistro Contact Grill
Double Flat Bistro Contact Grill
DY993-A
DY994-A
DY995-A
DY996-A
DY997-A
DY998-A
Application of Territory Legislation &
Council Directives(s)
Toepassing van Europese Richtlijn(en)
• Application de la/des directive(s) du
Conseil • Anwendbare EU-Richtlinie(n)
• Applicazione delle Direttive
• Aplicación de la(s) directiva(s) del
consejo • Aplicação de directiva(s) do
Conselho
Electrical Safety
AS/NZS 60335.1:2011 +A1:2012 +A2:2014
+A3:2015 +A4:2017
IEC 60335-2-38:2002 +A1:2008
EN 62233:2008
Electromagnetic Compatibility
EN 55014-1:2017
EN 55014-2:2015
EN 61000-3-2:2014
EN 61000-3-3:2013
Producer Name • Naam fabrikant • Nom du producteur • Name des Herstellers
• Nome del produttore • Nombre del fabricante • Nome do fabricante
Apuro
Producer Address • Adres fabrikant •
Adresse du producteur • Anschrift des
Herstellers • Indirizzo del produttore •
Dirección del fabricante • Morada do
fabricante
15 Bagdally Road,
Campbelltown
NSW 2560
I, the undersigned, hereby declare that the equipment specified above conforms to the above Territory Legislation,
Directive(s) and Standard(s).
Ik, de ondergetekende, verklaar hierbij dat de hierboven gespecificeerde uitrusting goedgekeurd is volgens de bovenstaande
Richtlijn(en) en Standaard(en).
Je soussigné, confirme la conformité de l'équipement cité dans la présente à la / aux Directive(s) et Norme(s) ci-dessus
Ich, der/die Unterzeichnende, erkläre hiermit, dass das oben angegebene Gerät der/den oben angeführten Richtlinie(n) und Norm(en)
entspricht.
Il sottoscritto dichiara che l'apparecchiatura di sopra specificata è conforme alle Direttive e agli Standard sopra riportati.
El abajo firmante declara por la presente que el equipo arriba especificado está en conformidad con la(s) directiva(s) y estándar(es)
arriba mencionadas.
Eu, o abaixo-assinado, declaro que o equipamento anteriormente especificado está em conformidade com a(s) anterior(es)
Directiva(s) e Norma(s)
Date • Data • Date • Datum • Data • Fecha • Data
27th August 2020
Signature • Handtekening • Signature • Unterschrift
Firma • Firma • Assinatura
Full Name • Volledige naam • Nom et prénom •
Vollständiger Name • Nome completo
•Nombre completo • Nome por extenso
Ashley Hooper
Josie Holt
Position • Functie • Fonction • Position • Qualifica
•Posición • Função
Technical & Quality Manager
Commercial Manager/
Responsible Supplier
DY993-A-DY998-A_A5_v1 20200915.indb 7DY993-A-DY998-A_A5_v1 20200915.indb 7 2020/9/15 10:102020/9/15 10:10

DY993-A-DY998-A_A5_v1_20200915
DY993-A-DY998-A_A5_v1 20200915.indb 8DY993-A-DY998-A_A5_v1 20200915.indb 8 2020/9/15 10:102020/9/15 10:10
